Kompact KC567GMM User manual

KOMPACT
KC567GMM
USER
MANUAL
www.kompactuk.co.uk
CUSTOMER CARE
0844 800 1128
BUILT-IN GAS OVEN

2
IMPORTANT INFORMATION
KC567GMM
CONTENTS
Important Information
Before you start 2
Safety information 3
Environment information 4
Technical and legal information 4
Voltage and frequency of power supply 4
Your oven
Your control panel 5
Your Oven 5
First use/Setting up your oven
Cleaning the oven 6
The right gas connection 6
Product functions 6
Daily operation of your oven
Minute minder 7
Using the grill 7
Using the oven 7
Care and Maintenance
How to keep your oven in good condition 8
How to remove the oven doors 9
Replacing the oven lamp 10
Installation 11
Trouble shooting 13
Guarantee 14
Useful contacts 15
BEFORE YOU START
To avoid the risks that are always present when you use
an electrical appliance it is important that this appliance is
installed correctly and that you read the safety instructions
carefully to avoid misuse and hazards. Please keep this
instruction booklet for future reference and pass it on to
any future owners. After unpacking the appliance please
check that it is not damaged. If in doubt, do not use the
appliance but contact Kompact on 0844 800 1128.
Decide on the appropriate location for your product.
Check the package and make sure you have all of the
parts below.
Your product contains glass please take care when tting
or handling to prevent personal injury or damage to the
product.
The specications plate displays all the necessary
identication information for ordering replacement parts.
If you sell the appliance, give it away, or leave it behind
when you move house, make sure you also pass on this
manual so that the new owner can become familiar with
the appliance and its safety warnings.
10
20
30
40
50
60
70
80
90
100
110
120
60
80
100
120
140
160180
200
220
MAX
°C
MAX
240210
180
150
MIN
KC567GMM Oven x1 Grill pan handle x1
Grill pan/drip tray x1
Oven shelf x1
Ø4mm x 25mm screws x4
Plastic washers x4

3
IMPORTANT INFORMATION
KC567GMM
SAFETY INFORMATION
These instructions are for your safety. Please read through
them thoroughly prior to installation and retain them for
future reference.
All installation work must be carried out by a competent
person or qualied electrician.
This appliance must be installed correctly by a suitably
qualied person, strictly following the manufacturer’s
instructions.
This appliance complies with all current European safety
legislation, however, the Manufacturer must emphasise
that this compliance does not prevent the surfaces of the
appliance from heating up during use and remaining hot
during its operation.
Do not allow the electric cables to touch the hot parts of
the appliance.
Make sure that the power cord is not caught under or in
the appliance and avoid damage to the power cable.
Do not remove the plug in the presence of ammable gas.
Do not install the appliance outdoors in a damp place or in
an area which may be prone to water leaks such as under
or near a sink unit. In the event of a water leak allow the
machine to dry naturally.
Please dispose of the packing material carefully.
Do not use ammable sprays in close vicinity to the
appliance.
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
Regularly check the power plug and power cord for
damage. If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly qualied
persons in order to avoid a danger or injury.
A steam cleaner is not to be used.
The appliance is not intended to be operated by means of
external timer or separated remote-control system.
The appliance is for domestic use only.
The Manufacturer declines all liability for personal or
material damage as a result of misuse or incorrect
installation of this appliance.
Danger of burns! During use the appliance becomes hot.
Care should be taken to avoid touching heating elements
inside the oven.
WARNING! Accessible parts may become hot during use.
Children should be kept away.
WARNING! If the door or door seals are damaged, the
oven must not be operated until it has been repaired by a
competent person.
Do not lean on the door or place any objects on the door
of the appliance. This can damage the door hinges.
The oven should be cleaned regularly and any food
deposits removed.
WARNING! Ensure that the appliance is switched off
before replacing the lamp to avoid the possibility of electric
shock.
The oven must be installed in accordance with installation
instructions and all dimensions must be followed.
Before connecting the appliance to the power supply,
check that the power supply voltage and current rating
corresponds with the power supply details shown on the
appliance rating label.
Never use a damaged appliance! Disconnect the appliance
from the electrical outlet and contact your retailer if it is
damaged.
Danger of electric shock! Do not attempt to repair the
appliance yourself. In case of malfunction, repairs are to
be conducted by qualied personnel only.
To avoid damaging the cord, do not squeeze, bend or
chafe it on sharp edges. Keep it away from hot surfaces
and open ames as well.
Lay out the cord in such a way that no unintentional
pulling or tripping over it is possible.
Keep the appliance and its cord out of reach of children.
Do not operate the appliance with wet hands or while
standing on a wet oor. Do not touch the power plug with
wet hands.
Connect the power plug to an easily reachable electrical
outlet so that in case of an emergency the appliance can
be unplugged immediately. Pull the power plug out of the
electrical outlet to completely switch off the appliance. Use
the power plug as the disconnection device.
Means for isolating the appliance must be incorporated
in the xed wiring in accordance with the current wiring
regulations. An all-pole disconnection switch having a
contact separation of at least 3 mm in all poles should be
connected in xed wiring.
Disconnect the power plug from the electrical outlet when
not in use and before cleaning.
Always turn the appliance off before disconnecting the
power plug.

4
IMPORTANT INFORMATION
KC567GMM
This appliance is classied as protection class I and must
be connected to a protective ground (Earth).
Means for full disconnection must be incorporated in
the xed wiring in accordance with the wiring rules. To
achieve this install an appropriate circuit breaker (CB) and
residual current device (RCD). It should be installed in an
easily reachable place so that in case of emergency the
appliance can be disconnected from power immediately.
The xed wiring must be protected against heat surfaces.
Do not hang an objects to the handle of the oven door.
Do not cover the bottom of the oven with aluminium foil or
other objects. Caution: Risk of re!
Do not allow aluminium foil, plastic, paper or fabric contact
with heating elements.
Never leave the appliance unattended during use,
especially when cooking with ammable substances (e.g.
hot oil, fat, etc.).
Do not store or never use harsh chemicals, sprays,
ammable or non-food in or near the oven. Oven is
designed specically for heating or cooking food. The use
of corrosive chemicals in heating or cleaning will damage
the unit and may cause injury.
Should any food inside the oven catch re, keep the
door closed. Switch the oven off and disconnect the power
supply.
Always exercise caution when opening the door. Move
to side, open the door slowly to vent the hot air and/or
steam. Make sure your face is away from the opening and
make sure there are no children or pets near the oven.
Only use utensils that are suitable for use in this type
of oven.
ENVIRONMENTAL INFORMATION
Waste electrical products should not be disposed of
with household waste. Please recycle where facilities
exist. Check with your Local Authority or
retailer for recycling advice.
This symbol on the product or its packaging
indicates that this product cannot be treated
as normal household waste. This product must
be handed over to an electric and electronic equipment
collection point for recycling.
On ensuring that this product is disposed of correctly, you
will help to avoid possible negative consequences for the
environment and public health, which could occur if this
product is not handled correctly. To receive more detailed
information about recycling this product, contact your
local government, domestic waste disposal services or the
outlet where the product was bought.
TECHNICAL AND LEGAL INFORMATION
TECHNICAL INFORMATION:
Power supply: 220-240V~, 50/60Hz
Bulb Type: E14
Wattage & Voltage: 25W/220-240V
Measurements:
Oven capacity (net): 56L
External dimensions (WxHxD): 594x594x543mm
Net weight: 32.5kg
LEGAL INFORMATION
The Manufacturer declines all liability for damage caused
to persons and objects due to incorrect or improper
installation of the appliance.

5
YOUR OVEN
KC567GMM
A. Minute minder dial
B. Grill temperature dial
C. Oven temperature dial with oven indication light.
When lit, it indicates the ovens is heating up to the
temperature set
YOUR CONTROL PANEL
AC
B
a. Control panel
b. Shelf guides
c. Oven shelf
d. Grill pan set
YOUR OVEN
a
b
b
d
10
20
30
40
50
60
70
80
90
100
110
120
60
80
100
120
140
160180
200
220
MAX
°C
MAX
240210
180
150
MIN
c

6
FIRST USE/SETTING UP YOUR OVEN
KC567GMM
We recommend that you read the instructions in this owner’s manual carefully before use for the best performance and to
extend the life of your appliance, as it will provide you with all the instructions you require to ensure its safe installation,
use and maintenance. Always keep this owner’s manual close to hand since you may need to refer to it in the future.
Thank you.
CLEANING THE OVEN FOR THE FIRST TIME
Before using the oven for the rst time we recommend
that oven be switched on and set to there highest
temperature. Keep the oven door closed and leave the
appliance on for 30 minutes with nothing in it. Ensure
adequate ventilation during this process by opening any
doors and windows in the room. Any odours created
during this operation will be due to the evaporation of
substances used to protect the appliance during storage
prior to installation.
THE RIGHT GAS CONNECTION
This oven can be use on NATURAL GAS or LPG.
It is a legal requirement that all gas appliances are
Installed & Serviced by a competent person in accordance
with the current editions of the following Standards &
Regulations:
Gas Safety (Installation & Use) Regulations
Building Regulations
British Standards
Regulations for Electrical Installation
Installation and service of any gas product must be made
by a suitably qualied and registered person competent
on the type of product being installed or serviced and
holding a valid certicate of competence for the work
being carried out.
PRODUCT FUNCTIONS
The gas oven is controlled by a thermostat between 50°C
and 231°C, depending on the temperature required.
The thermostat light turns on and off to indicate the
temperature control during use.
The gas grill is controlled by a dial that has a temperature
range of 60°C and 230°C.
The minute timer has a timing range of 10 to 120 minutes
and also includes a light function that lights the inside of
the oven when the timer is not being used.
The oven is equipped with auto ignition and is also tted
with a safety switch off and a ame failure device (FFD).

7
DAILY OPERATION OF YOUR OVEN
KC567GMM
This gas oven uses gas for both the oven and grill
functions and is equipped with a minute timer.
MINUTE MINDER
To use the minute minder, set the timer by turning the
dial clockwise. The numbers correspond to minutes
(maximum 120 minutes). Setting is on a gradual scale and
intermediate positions between the numbers can be used.
At the end of the set time a buzzer sounds but does not
turn off the oven.
The light “ ” setting turns on the light inside the oven
during normal operation (without timer).
USING THE GRILL
The grilling temperature is set by turning the dial clockwise
to the value required, between Min. and Max.
To ignite the grill, turn on the grill function and turn the
dial to the position “ ”. The grill is equipped with an auto
ignition system.
To operate this system completely open the oven door
and press the grilling dial and turn it to the maximum
temperature setting; this automatically activates the
electric spark ignition device. Once the burner has ignited,
keep the knob pressed down for a few seconds to allow
the thermocouple to heat up.
If the burner has not lit after 15 seconds, stop trying,
leave the oven door open and wait 1 minute before trying
again.
USING THE OVEN
The oven is equipped with an auto ignition system.
To operate this system completely open the oven door
and press the thermostat dial and turn it to the maximum
temperature setting; this automatically activates the
electric spark ignition device. Once the burner has ignited,
keep the knob pressed down for a few seconds to allow
the thermocouple to heat up.
If the burner has not lit after 15 seconds, stop trying,
leave the oven door open and wait 1 minute before trying
again.
You can also lighting the burner by hand by completely
open the oven door and turn the thermostat dial to max.
Place a lit match close to the end of the ame pipe “A”
in the centre of the bottom of the oven and press the
thermostat knob. Once the burner has ignited, keep
the knob pressed down for a few seconds to allow the
thermocouple to heat up and check that the burner has
lit properly through the inspection hole B. The cooking
temperature is
set by turning the
knob clockwise to
the value required,
between 50° and
231°.
If the burner
accidentally goes out,
turn the dial to the
off position and wait
at least one minute
before trying to
relight it.
WARNING
The gas oven and grill cannot be used simultaneously.
BAB

8
CARE AND MAINTENANCE
KC567GMM
WARNING
Always switch off the electricity supply before
performing maintenance work. In the event of a
fault, contact customer services.
CAUTION
Do not use hot water, dilutents, petrol, alcohol, kerosene,
washing powder, cleanser, alkaline detergent, acid,
chemical cloth, etc. for cleaning so as not to damage the
enamel coating and plastic. The appliance must not be
cleaned directly with water as this could cause rusting or
render the insulation less efcient.
The enamelled and stainless steel parts of the appliance
should be wiped clean using a damp cloth using the
minimum possible amount of soap and lukewarm water.
Do not use abrasive powders or corrosive substances
which could ruin the surfaces. Remember stainless steel
could tarnish and restoring these surfaces can be difcult.
Specialist stainless steel cleaners are available from major
supermarkets. After cleaning these surfaces should be
wiped with a clean cloth and lukewarm water to remove
any traces of detergent.
The inside of the oven should ideally be cleaned when the
oven is still warm using a damp cloth and the minimum
possible amount of soap and hot water. After cleaning the
soap should be removed using a clean damp cloth and hot
water. Dry the interior of the oven with a soft dry cloth
after cleaning.
Do not use abrasive powders, cleaners, sponges or acids
(lime scale remover) to clean the interior as these can
damage the enamel. If the interior is very difcult to
clean use a specialist oven cleaner. Follow closely the
instructions provided on the packaging.
WARNING!
DO NOT USE EXCESSIVE AMOUNTS OF WATER WHEN
CLEANING THE PRODUCT AND NEVER USE A STEAM
CLEANER TO CLEAN THE INSIDE OF THE OVEN.
If the oven is in use for an extended length of time
condensation may form. Once the oven has cooled remove
the condensation using a dry cloth.
HOW TO KEEP YOUR OVEN IN GOOD
CONDITION
Before cleaning your oven, or performing maintenance,
disconnect it from the power supply.
To extend the life of your oven, it must be cleaned
frequently, keeping in mind that
The enamelled or stainless steel parts should be washed
with lukewarm water without using any abrasive powders
or corrosive substances which could ruin them. Stainless
steel could get stained. If these stains are difcult to
remove, use special products available on the market.
After cleaning, it is advisable to rinse thoroughly and dry.
The inside of the oven should preferably be cleaned
immediately after use, when it is still warm, with hot water
and soap. The soap should be rinsed away and the interior
dried thoroughly. Avoid using abrasive detergents (for
example cleaning powders, etc.) and abrasive sponges for
dishes or acids (such as lime scale remover, etc.) as these
could damage the enamel. If the grease spots and dirt
are particularly tough to remove, use a special product for
oven cleaning, following the instructions provided on the
packet.
WARNING!
NEVER USE A STEAM CLEANER TO CLEAN THE INSIDE OF
THE OVEN.
If you use your oven for an extended period of time,
condensation may form. Dry it using a soft cloth.
There is a rubber seal surrounding the oven opening which
guarantees its perfect functioning. Check the condition
of this seal on a regular basis .If necessary, clean it and
avoid using abrasive products or objects to do so. Should
it become damaged, please contact the customer service
centre. We recommend you avoid using the oven until it
has been repaired.
Clean the glass door using non-abrasive products or
sponges and dry it with a soft cloth.
FUSE
USE A 30 AMP FUSE
DOUBLE POLE SWITCHED
FUSED SPUR OUTLET
ON

9
CARE AND MAINTENANCE
KC567GMM
1. Open the door to the full extent. 2. Open the lever A completely on
the left hand hinges
3. Open the door to angle as
shown.
A
B
4. Close the door until the left & right hand
levers A are hooked to part B of the door
5. Withdraw the hinge hoods for
there position following arrow C.
To replace the door, reverse the
above procedure
C
HOW TO REMOVE THE OVEN DOORS
For a more thorough clean, you can remove the oven door.
To remove the oven door use the following instructions:

10
CARE AND MAINTENANCE
KC567GMM
REPLACING THE OVEN LAMP
WARNING!
Disconnect the appliance from the electricity supply, open
the oven door remove the oven shelves. During use the
appliance becomes hot. Care should be taken to avoid
touching heating elements inside the oven.
Remove the glass cover
that protects the light
bulb by turning it anti-
clockwise.
Unscrew the old light
bulb and dispose of it
safely and ecologically,
change it for one as
specied in the “Technical
data” and replace the cover.
90’

11
INSTALLATION
KC567GMM
595mm
565mm
595mm
595mm
594mm
594mm
543mm
21mm
570mm
Only a qualied person in compliance with the instructions
provided must install the appliance. The manufacturer
declines all responsibility for improper installation, which
may harm persons and animals and damage property.
CAUTION
The power supply to the appliance must be switched
off before any adjustments or maintenance work is
undertaken.
INSTALLATION OF BUILT-IN SINGLE GAS
OVEN
This product can be tted under the work surface or in
a tall unit. To ensure that the oven functions correctly it
should be installed using one of the two methods shown:
INSTALLATION METHOD 1
Fitting under the work top in a new or existing oven
housing unit.
INSTALLATION METHOD 2
Fitting in a tall unit in a new or existing oven housing unit.
ELECTRICAL CONNECTION
All installation work must be carried out by a competent
person or qualied electrician.
Before connecting the mains supply ensure that the mains
voltage corresponds to the voltage on the rating plate
inside the cooker hood.
WARNING:
THIS APPLIANCE MUST BE EARTHED.
Mains Supply could be connected to the Mains Voltage by
Direct Connection
WARNING
Make sure the fused spur outlet is
located in an accessible position.
DIRECT CONNECTION
If the appliance is being connected
directly to the mains an omnipolar
circuit-breaker must be installed with a minimum opening
of 3mm between contacts.
If the cable is damaged or to be replaced, the operation
must be carried out the by a qualied electrician with
dedicated tools to avoid any accidents.
The installer must ensure that the correct electrical
connection has been made and that it complies with wiring
diagram.
The cable must not be bent or compressed.
The cable must be checked regularly and replaced by
authorized technicians only.
ELECTRICAL REQUIREMENTS
Any permanent electrical installation must comply with
the latest I.E.E. Regulations and local electricity company
regulations. For your own safety a qualied electrician or
contractor who is on the roll of the National Inspection
Council for Electrical Installation Contracting (NICEIC)
should undertake the electrical installation.
Electrical Connection
Before connecting the mains supply ensure that the mains
voltage corresponds to the voltage on the rating plate
inside the appliance.
WARNING:
THIS APPLIANCE MUST BE EARTHED
The appliance is supplied with a 3-core mains cable and
must be connected to the electricity supply via a double
pole switch having a 3mm minimum contact gap on each
connector.
FUSE
USE A 3 AMP FUSE
DOUBLE POLE SWITCHED
FUSED SPUR OUTLET
ON

12
INSTALLATION
KC567GMM
A Switched Fused Connection Unit to BS 1363 Part 4 is
recommended
The fuse must be rated at 3 Amps.
The wires in the mains lead are coloured in accordance
with the following code:
Brown = L - Live
Blue = N - Neutral
Green and Yellow = - Earth
The connection point must be placed in a position adjacent
to the appliance so as to be readily accessible for an
engineer in the event of a breakdown.
Disconnect the appliance from the mains supply before
carrying out any kind of maintenance or cleaning.
FIXING THE GAS SINGLE OVEN
VENTILATION
An air circulation slot that should be cut into the plinth if
tted. See below for air circulation requirements.
It is essential when installing your oven there is adequate
air circulation around the appliance to ensure the correct
operation of the appliance. Inadequate air circulation will
greatly impair the operation of the appliance and can
affect surround cabinets due to the rise in temperature.
Once the oven has been lifted into place insert the 4x
plastic washers into the holes located within the sides
of the metal casing of the oven as shown and secure
with 4x screws [Ø4mm x 25mm].
Also ensure
that you adjust
the furniture
doors adjacent
to the sides
of the oven
so there is a
5 - 7mm gap
between them,
otherwise heat
displaced from
the oven might damage the furniture door.
THE APPLIANCE IS NOW READY TO USE.
570mm
600 mm
200mm
10mm

13
TROUBLESHOOTING
KC567GMM
WHAT SHOULD I DO IF THE OVEN/GRILL
DOESN’T STAY LIT?
If the burner has not lit after 15 seconds, stop trying,
leave the oven door open and wait 1 minute before trying
again.
If after trying again the burner does not stay lit contact
the customer service centre.
WHAT SHOULD I DO IF THE OVEN LIGHT DOES
NOT ILLUMINATE?
The oven light could be faulty. Replace the oven light bulb
(see “Replacing the oven lamp the lamp”).
If after replacing the light it still does not illuminate
contact the customer service centre.
I CAN STILL HEAR A FAN RUNNING AFTER THE
OVEN HAS BEEN SWITCHED OFF?
The oven is equipped with a thermodynamically controlled
cooling fan. This can continue to run after the oven has
been used if the temperature around the oven is still high.
This feature is designed to dissipate heat to protect the
oven and the installation housing. This does not indicate a
fault and is normal operation.

14
GUARANTEE
KC567GMM
This appliance is covered by a full manufacturer’s 2 year
parts and 2 year labour guarantee and covers all parts and
labour costs associated with the repair of the appliance
in a domestic environment. We will repair any defect that
arises due to faulty materials or workmanship and use
genuine manufacturers parts.
All claims must be supported with the original receipt or
other reasonable proof of purchase.
If, during the guarantee period, the appliance becomes
irreparable as agreed by the engineer approved by
Apelson Appliances UK Ltd then we reserve the right, at
our discretion, to exchange the defective product with
a replacement appliance at Apelson Appliances UK Ltd
sole cost. If the same product is no longer available an
alternative will be offered with the same functions as the
faulty item.
After an appliance has been repaired or replaced any
remaining balance of the Apelson Appliances UK Ltd
guarantee will be valid and any further call outs during this
prescribed period will be covered by Apelson Appliances
UK Ltd on the replacement appliance.
Should any person other than an authorized engineer
modify or attempt to repair the appliance then the
warranty will be invalid.
The guarantee applies to the UK mainland, Scotland and
Ireland but is not transferable between EU countries.
This guarantee is non-transferable to any other person or
product.
The guarantee is covered by UK law and is in addition to
and does not diminish your legal rights.
EXTENDED PARTS ONLY WARRANTY
As testimony to our commitment to you as a valued
customer of Apelson Appliances UK Ltd, we will offer you
an additional 3 years parts warranty absolutely free.
If during the extended parts warranty period the
appliance fails and it is considered uneconomical to repair
our Customer Service Department will offer you the
opportunity to purchase the same or equivalent model at a
discounted price.
All parts supplied free of charge under the extended
warranty must be tted by our approved engineers and
will be subject to a call out charge to t the part.
EXCLUSIONS TO THE GUARANTEE
This guarantee does NOT cover:
Appliances that have been damaged or neglected as a
result of failure to store, assemble, install, use or care
of the products in accordance with the manufacturer’s
instructions - Apelson Appliances UK Ltd will not accept
responsibility under this guarantee if a product is damaged
or becomes defective due to, misuse, neglect, wilful or
accidental damage or act of god.
Normal wear and tear.
Consumable items such as carbon lters and bulbs.
Claims arising from non-domestic use or commercial
environment.
Any gas appliance not tted by a gas safe qualied
installer.
If no fault is found then Apelson Appliances UK Ltd
reserves the right to charge for the call out at the going
rate of £55.00 plus VAT.
In the course of the service work carried out it may be
necessary to remove the built in appliance from its tted
position. If the appliance is glued, grouted or tiled in such
a manner that it cannot be removed, it is the responsibility
of the customer/installer to remove and reinstall the
appliance to facilitate the repair.
This Guarantee does not affect your statutory rights.
The guarantee is offered by Apelson Appliances UK Ltd,
1 Express Way, Off California Drive, Castleford, WF10 5QJ

15
USEFUL CONTACTS
KC567GMM
USEFUL CONTACTS
TECHNICAL SUPPORT
Kompact Appliances
Phone: [phone]
Email: [email protected].uk
Web: www.leakerdirect.co.uk
SPARES
Apelson Appliances UK LTD
Phone: [phone]
Email: [email protected]
Web: www.myspareparts.co.uk
SERVICE AND GUARANTEE
Apelson Appliances UK LTD
Phone: [phone]
Email: [email protected]
Web: www.myspareparts.co.uk

APELSON APPLIANCES UK LTD,
1 EXPRESS WAY
OFF CALIFORNIA DRIVE
CASTLEFORD
WF10 5QJ
