Konfor SPS-807W User manual

Ultrasonic Mist Humidifier
User Manual
ＫＯＮＦＯＲ
ＳＰＳ－８０７Ｗ

Catalog
Attentions & Working Principle and Characteristics 2
Attentions 1-2
Humidity introduction and function 3
Operating steps 4-6
Connect to mobile client 6-8
Maintenance Instruction 9
Trouble Shooting Guide 10

Attentions
1
Thank you for purchasing your new Ultrasonic Humidifier.
The humidifier helps you to restore an appropriate level of humidity and eliminate the discomfort
associated with dry air. We wish you many years of healthy indoor air with this efficient and effective
product.
We recommend you spend some time reading this instruction manual in order to fully understand all the
operational features it offers.
* Read all the safety instructions carefully before use and keep this instruction manual for future
reference.
Warning: Please be aware of the following points or you might be in danger of high voltage charges or
burn your body.
1). Never disassemble the base unit without consulting qualified personnel.
2). If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
3). Do not add detergents, chemical solutions which are not made by our company into the unit.
4). Unplug appliance during filling, cleaning and maintenance.
5). Keep detergents and chemical solutions away from children.
6). Do not change attachment without definitive permission from our company otherwise you might
cause a hazard.
7). If any abnormal smell during normal operation, please switch off and disconnect power supply
and have qualified personnel amend.
8). If when cleaning with water, detergents & chemical solutions splash into mouth & eyes, consult
a doctor to refrain from serious hazard.
9). Never touch water in the water basin & components in the water when the unit is in function.
10). Never switch on when there is no water in the water basin.
11). Never scrape Transducer cpl on your own.
12). Never clean Transducer cpl with detergents or chemical solutions that are not made by our
company.
13). Never let water splash into inner base unit to avoid components damage.
14). Care should be taken when using the appliance due to emission of hot water vapor.

Attentions & Working Principle and Characteristics
2
Ultrasonic Humidifier uses the ultrasonic high-frequency oscillator to break up water into tiny water
particles with the diameter of about 1-5um.The ventilation system blows out this water into the dry air
where they evaporate to give the required humidity. The clearly visible smooth and even fog can be seen
out of the unit.
Working Principle
• High efficient in humidification with large output.
• Low energy consumption, save 85-90 percent of electricity than normal stream humidifier.
• Long lifetime.
• Automatic control of humidity level, lack-of-water security protection.
• Heating Function: Touch the Heating symbol to make warm mist. Press again to stop the heating
function.
• Plasma: Touch the Plasma symbol of Plasma to spread a number of Plasma elements. Press again to
stop the Plasma function.
• Base with tray for the felt, to wet it with aromatic oil.
Features
15). Before cleaning and maintenance, the appliance must be disconnected from the power supply.
16). Prior to cleaning or other maintenance, the appliance must be disconnected from the supply
mains.
17). This appliance can be used by children aged from 8 years and above if they have been given
supervision or instruction concerning use of the appliance in a safe way and if they understand the
hazards involved. Cleaning and user maintenance shall not be made by children unless they are older
than 8 and supervised. Keep the appliance and its cord out of reach of children aged less than 8
years. Cleaning and user maintenance shall not be made by children without supervision.
18). Children should be supervised to ensure that they do not play with the appliance.
19). Indoor use only.

Humidity Introduction and Function
3
What exactly is relative humidity: Relative humidity is the amount of water vapor in the air, expressed as a
percentage of the maximum amount that the air could hold at the given temperature.. We normally mark it with ％
RH, like 45％RH. Atomosphereic air always contains water vapor, the percentage of which depends on the
meterological conditions. The higher the temperature is the more the air keeps water vapor. Therefore, we use the
concept of “relative humidity”. When the cold air is heated up to the comfort temperature in winter, the relative
percentage of the water vapor falls which means the relative humidity drops. In order to keep a comfortable and
health environment at home, we need some artificial addition of water or water vapor to the room air- that’s air
humidification.
Ideal relative humidity levels under different situations:
(The most comfortable RH for human being 45-65％RH)
• Ideal RH for prophylactic and curative purpose: 40-55％RH
• Computer and telecom apparatuses: 45-60％RH • Library art gallery and museums: 40-60％RH
• Furniture and musical instruments: 40-60％RH • Library art gallery and museums: 40-60％RH
Correct Humidity Level
A：The percentage of water mist in a given space with a given air temperature is named as relative
humidity, usually marked as %RH, i.e. 45%RH. The air contains water mist more or less. The proportion
of water mist to the air varies according to different air temperatures. The higher the temperature, the
more water mist inhaled in the air.
B：In the winter, the cold air outside enters the room and becomes warmer by the higher temperature in
the room. As a result, the relative humidity decreases. If you want to keep the healthy environmental
humidity, we need to increase the mist volume in the air. The humidifier can do that for us.
C：Relative humidity in different environments suitable for people:
Functions
1: Relative Humidity
Bedroom, living room：45-64%RH
Room with computer, experiment equipments：45-60%RH
Patient’s room：40-55RH Room with piano：40-60%RH
Museum, exhibition hall, and library：40-50%RH
A：Cation exchange resin filter can soften the hard water.
B：Cation exchange resin filter demineralize in the water.
2: Water filter

First Operation, put unit in the room temperature for half of an hour before running.
It is recommended to use the unit under temperature of 20 degree C, relative humidity less than 80％RH.
Use clear water not over 40 degree C
Check the water basin, make sure it is clear.
Operation Instruction
Operating Steps
4
2. Fill the water into the water tank, and then tighten the tank cover. 1. Put the machine on a flat surface.
4. Check if the rated voltage meets the input voltage, and plug into the
socket. Then display shows the current temperature and humidity.
3. Put the water tank on the main
base.
INSTRUCTIONS FOR USAGE
Temperature Humidity

Operating Steps
5
5. Touch the symbol POWER “ ” on the machine; the background LED light will be on. The machine will begin to
work in AUTO mode. Display shows AUTO symbol. After 15 seconds without any operation, the display will become
dim, press any key except power key to wake up the display.
6. Touch the symbol ANION “ ” the anion generator works. On the LED display, it shows the shape of anion “ ” .
Touch again to stop the function.
7. Touch the symbol HEATING “ ” the warm mist will come out after 10~15 minutes. On the LED display, it shows
the same symbol “ ” . Touch again to stop the function. Mist will become cool.
9. Touch the symbol MODE “ ” , baby mode will be turn on (keep constant humidity at 55% with warm mist and
plasma turn on). In baby mode,mist output speed cannot be set. Press symbol MODE “ ” again to enter auto
mode. Press MODE “ ” for two seconds to enter sleep mode. In sleep mode, display and water tank indication
light will turn off and “ ” will be turn on. Humidifier will keep running. Touch any button to cancel sleep mode and
display will turn on.
11. Auto Shut-Off: Once the water in the basin is too little to keep the machine working, the machine will
automatically stop working. LED shows the shape of lack of water “ ” . Refill the water, and the machine will
restart. If don’t refill water within 15 minutes, the machine will automatically power off.
10. Timer setting: There are 12 timer setting: 1,2,3,4,5,6,7,8,9,10,11,12 hours. Touch the symbol TIMER “ ” , the
LED display will show the desired setting timer. Touch till “Co” display on the LED, timer setting is cancelled. The
timer shows the rest operation time and decreases by 1 hours, i.e., if the timer is set at 12 hours, LED display shows
11 after one hour. To know what time have been set, just to touch TIMER symbol. Touch again, to set timer again.
8. Constant humidity: Before you touch the symbol HUMIDITY “ ” , LED display shows the current humidity. You
may set the humidity arranged from 30%RH to 75%RH. Touch once, AUTO mode is cancelled, it will increase by
5%RH. When it reaches 75%RH, touch again, it will show “Co” and flash for 3 seconds to exit humidity setting
function. After you set the expected humidity, the machine will keep the memory and confirm after 5 seconds. 5
seconds later, the symbol %RH will blink and LED display shows the current humidity. Touch again, it shows the
expected humidity setting. If the expected humidity is less than the current humidity, the machine will be in sleeping
state. But if the expected humidity is 3% higher than the current humidity, the humidify function will work. Mist
output speed cannot be set during the constant humidity mode. Long-press the symbol “ ” or “ ” , to cancel
auto humidity, but enter to AUTO mode.
Temperature of the
air, degrees Celsius ≤19
65
20
60
21
58
22
57
24
53
25
50
26
48
31
36
28
43
32
35
33
34
30
38
29
40
27
45
35
31
34
32
36
30
≥37
25
23
55Humidity(%)

Operating Steps & Connect To Mobile Client
6
• Take the water tank out of the unit, open the water tank cover and fill the tank with clear water. Close
the cover and put the tank onto the base unit carefully.
• Put the nozzle into the socket on top of the water tank.
• Connect the power supply, switch on the unit (NEVER RUN THE UNIT WHEN THERE IS NO WATER IN
WATER BASIN), the main connection lamp will on. The unit will begin working.
Operation steps
12. Slide the symbol MAX-MIN “ ” , AUTO mode is cancelled and the mist output is in the
first speed. You may select 7 desired levels of mist volume. The corresponding strip symbol will appear on the
display. 5 seconds after setting mist output speed, the current room humidity will appear on the display as well. On
the remote control, just to press symbol “ ” to select mist output level and AUTO mode in different times.
14. On the remote controller, the related symbol controls the corresponding function.
15. No matter in any working mode, if no any operation in about 15 seconds, the display will turn dim.
13. Auto Shut-Off: Once the water in the basin is too little to keep the machine working, the machine will
automatically stop working. LED shows the shape of lack of water “ ” . Refill the water, and the machine will
restart. If don’t refill water within 15 minutes, the machine will automatically power off.
Connect To The Mobile Client ——Quick Connect mode
1. Configure the network. 2. Scan the QR code below to download
the APP, or search for “ProscenicHome"
in the APP store to download the APP.
3. In the power-on state, long press
the key “ ” 3 seconds until the
WiFi indicator “ ” flashes quickly.

Connect To Mobile Client
7
Connect to the mobile client ——Hotspot Mode
1. Connect your phone to WiFi, scan the QR code
below, or search for “ProscenicHome” in the app store
to download the app.
2. In the power-on state, long press the key “ ” 66
seconds until the WiFi indicator “ ” Slow flash.
Add device
Add device
Add device
Confirmation indicator
5. erform network configuration.
According to the APP page prompt, select and enter the WiFi password to
make the device enter the connection state and wait for the distribution
network to complete.
* Note: the host does not support 5.8g band WiFi network.
confirm
Change network
4. APP add device: turn on the APP,
select add humidifier device and
confirm WiFi indicator “ ” flash.

Connect To Mobile Client & Parameters
8
• Model: SPS-807W
• Power supply: 110-120V 50/60Hz
• Heating power: 80W
• Humidify power: 30W
• Total power: 110W
• Water tank capacity: 5.3L(1.4gal)
• Evaporation Rate: ≥300mL/h
• Noise level: ≤35dB(A)
TECHNICAL DATA
3. Add a humidifier device to the app, switch to the hotspot mode, and
confirm that the WiFi indicator is in a slow flashing state.
4. According to the prompt of the
APP interface, select WiFi and enter
the password.
807C
LDS-xxxx
M7
H500
H600
Please select the purchased device
Click or pull up to load more
Please select the p
807C
......
......
indicator flashes slowly
Add a Device AP mode
make sure the WiFi indicator flashes slowly
Add a Device AP mode
make sure the WiFi indicator flashes slowly
5. According to the APP interface prompt, turn on“Phone Settings - Wireless LAN(WiFi)”, select “Proscenic-xxxx”
network connection and return to APP. Perform network configuration and wait for the distribution network to
complete.
* Note: the host does not support 5.8g band WiFi network.
Setting
AVAILABLENETWORKS
WLAN
WLAN
807C
XXXXXXXX
XXXXXXXX
Setting
AVAILABLE NETWORKS
WLAN
WLAN
807C
XXXXXXXX
XXXXXXXX
Network Configuration
SmartLife-XXXX
807C
Device Choice
Cancel Refresh
SmartLife-XXXX
807C
Device Choice
Cancel Refresh

Maintenance Instruction
9
In a case when the water is hard which means water contains too much calcium and magnesium, it can
cause a “white powder” problem and leave heavy scales on the surface of water basin, transducer and
inner surface of the water tank. Scales on the surface of transducer will let the unit work improperly.
Maintenance
1). Use cold boiled water or distilled water.
2). Clean the transducer, water tank and basin unit every week.
3) .Change the water in water tank more often to keep it fresh.
4) .Make sure to pull out the water from the water tank and dry the water basin before you store the unit
unused for a long period of time.
5).Clean the whole unit and make sure that all parts of the unit are dried completely before unused for
longer period of time.
We recommend
1). Put 5-10 drops of cleaning abluent on the surface of the transducer, wait for 2-5 minutes.
2). Brush off the scale from the surface.
3). Rinse the transducer with clean water.
How to clean the transducer
1). Clean the water basin with soft cloth and the cleaning abluent if there is scale in it.
2). If the scale is covered on the security switch, drop the cleaning abluent on the scale and clean it out
with the brush.
3). Rinse the water basin with clean water.
How to clean the basin unit

Trouble Shooting Guide
10
If any trouble is found in normal operation, please kindly refer to the following points:
Trouble Shooting Guide
Do not dispose this product as unsorted municipal waste, collection of such waste separately for
special treatment is necessary.
DISPOSAL
Trouble Possible reasons Solution
Power lamp off, does not work No power supply Connect power supply, switch on
Power lamp on, no mist outlet
with wind
Abnormal smell mist 1. New unit
2. Dirty water or water sitting too long
1. Take out water tank, open cover,
let it stay 12 hours in cool position
2. Clean water tank, fill with clear water
1. No water in water tank
2. Security switch is too loose
1. Fill water into water tank
2. Tighten the switch
Power lamp on, unit doesn’t work Too much water in the water basin
Pull out same water from the water
basin, close the cover of water tank
tightly
Mist fog is too low
1. Too much scale in the water basin
2. Water is too dirty or water kept too
long in the tank
1. Clean transducer
2. Clean water tank, change to fresh
clear water
Abnormal noise
1. Resonant in water tank when
water is too low
2. Unit is on a unstable surface
1. Fill water into water tank
2. Move the unit to a stable flat surface
Mist fog coming out from around
nozzle
There are apertures between the
nozzle and water tank
Dip the nozzle in water for a while
and then fix it to the socket on
water tank

ＫＯＮＦＯＲ Ｆｏｓｈａｎ Ｓａｍｙｏｏ Ｅｌｅｃｔｒｏｎｉｃ Ｃｏ．，Ｌｔｄ
Ａｄｄ ： Ｊｉａｎｇｃｕｎ Ｉｎｄｕｓｔｒｉａｌ Ｚｏｎｅ ，Ｌｅｌｉｕ ，Ｓｈｕｎｄｅ
Ｆｏｓｈａｎ， Ｇｕｇｎａｇｄｏｎｇ ， Ｐ．Ｒ．Ｃｈｉｎａ
Ａｄｄ ：
Ｔｅｌ ：[phone]
Ｆａｘ ：[phone]

FCC STATEMENT :
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
Warning: Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving an tenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
