Kortex KX ROUTER 3G PRO User manual

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 1 -
KORTEX
Kx Router 3G Pro
User Manual

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 2 -
Content
CHAPTER 1 INTRODUCTION...............................................................................................................4
1.1 PURPOSE..........................................................................................................................................4
1.2APPLICATION RANGE.........................................................................................................................4
1.3 EDITION.............................................................................................................................................4
1.4 TECHNICAL SUPPORT........................................................................................................................4
CHAPTER 2 PRODUCT SPECIFICATION..........................................................................................5
2.1 OVERVIEW.........................................................................................................................................5
2.2 SPECIFICATION..................................................................................................................................6
CHAPTER 3 INSTALLATION.................................................................................................................7
3.1ACCESSORIES...................................................................................................................................8
3.2 INSTALLATION....................................................................................................................................8
CHAPTER 4 CONFIGURE .....................................................................................................................9
4.1 OVERVIEW.........................................................................................................................................9
4.2 CONNECTION ....................................................................................................................................9
4.2.1 Computer network configuration ..........................................................................................9
4.2.2 Login the router.....................................................................................................................10
4.3 FRONT LEDS..................................................................................................................................11
4.4 REAR PANEL ...................................................................................................................................13
4.5 CONFIGURE PARAMETERS..............................................................................................................14
4.5.1 Internet Settings....................................................................................................................14
4.5.2 WAN settings ............................................................................................................................15
4.5.3 LAN SETTINGS............................................................................................................................17
4.5.4 DHCP clients ...........................................................................................................................19
4.5.5 VPN..........................................................................................................................................20
4.5.6 Advanced Routing ....................................................................................................................22
4.5.7 Wireless settings...................................................................................................................24
4.5.7.1 Basic Wireless Settings..........................................................................................................24
4.5.7.2 Wireless Security/Encryption Settings...................................................................................28
4.5.7.3 Station List.............................................................................................................................31
4.5.7.4 Statistics ................................................................................................................................32
4.5.8 Firewall....................................................................................................................................33
4.5.8.1 MAC/IP/Port Filter Settings..................................................................................................33
4.5.8.2 Port Forwarding ...................................................................................................................34
4.5.8.3 DMZ Settings.........................................................................................................................38
4.5.8.4 System Security......................................................................................................................38
4.5.8.5 SMS Server Settings ..............................................................................................................40
4.5.9 Management.............................................................................................................................41

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 3 -
4.5.9.1 System....................................................................................................................................41
4.5.9.2 SIM........................................................................................................................................44
4.5.9.3 SMS .......................................................................................................................................47
4.5.9.4 Firmware...............................................................................................................................48
4.5.9.5 Configuration........................................................................................................................48
4.5.9.6 Status.....................................................................................................................................50
4.5.9.7 Statistics ................................................................................................................................51
4.5.9.8 System log .............................................................................................................................52
4.5.9.9 REBOOT ...............................................................................................................................52
4.5.9.10 REMOTE SMS.....................................................................................................................53
4.5.9.11 TELNET...............................................................................................................................54
CHAPTER 5 FAQ...................................................................................................................................55

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 4 -
Chapter 1 Introduction
Here to introduce the KX ROUTER 3G PRO, it will be much helpful during your application.
1. Purpose
2. Application range
3. Version
4. Technical support
1.1 Purpose
The user manual will be used for your installation and test.
1.2 Application range
This manual is intended for persons with certain computer networks and electronic
technical knowledge, network administrators, and other related equipment managers
who need to use the 3G router.
1.3 Edition
According to the market and the needs of users, the router products will make
adjustments on related features and technical improvements. The following table
explains product specifications and amendments in the revised version of the reasons
described in different periods.
Version No.
Amendment
Participation
Date
Details
V1.0
R&D
Market, Technical Dep.
2015.05
First Version
V1.1
R&D
Market, Technical Dep.
2015.10
Second Version
V1.2
R&D
Market, Technical Dep.
2016.10
Third Version
V1.2, V1.3
R&D
Market, Technical Dep.
2016.10 & 2018.08
Fourth and Fifth Versions
1.4 Technical support
To enable users to quickly solve problems encountered in the course, and get the right
solution on hardware, operating system and installation, please contact customer
service staff: France : 0820 69 00 42 International : [phone]

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 5 -
Chapter 2 Product specification
2.1 Overview
With the development of mobile communication technology, the mobile data communication
network using GPRS/CDMA/EDGE/EVDO/HSDPA/HSUPA/HSPA+ has covered many
regions in the world. And network is very stable. All these make a large market for wireless
terminals. Different industries have different applications and different information needs, so
the industry application solutions provided by the mobile communication operators must
satisfy both the common needs and the special individual needs of the industry users
perfectly. Therefore, in recent two years, based on the needs of industry users,
Telecommunication, Telecom Operator do innovative practice energetically in mobile
application and provide solutions to meet the unique needs of the users. Being different with
the popular data requirements, industry application is very professional. Different industry
users need different terminals. So hardware and software development and system
integration must be accord with different industry needs. By analyzing the different industry
application features in recent years and according to the network features and the actual
condition of the network operators, we launched the individually designed KX ROUTER 3G
PRO.
KX ROUTER 3G PRO provide users the high-speed, always-online and
transparent-data-transmission communication network, to meet the needs of Electronic
Power System Automation, Industry Monitoring, Transportation Management, Weather,
Environment Protection, Pipe Network Monitoring, Finance, Bond industries and pos
terminals.

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 6 -
2.2 Specification
CPU
RAM:256Mbit
FLASH:64Mbit
Power Input
Input DC 6-12V, standard DC8V 1A 5% 8.0W (max)
Low-voltage, over current, over voltage, anti-reverse protection
Environment
Storage Temperature：-20℃～60℃
Work Temperature：-10℃～65℃
Humidity：5%～85
Volume
L*W*H：110*155*32mm
Weight
Net weight（no accessories）:255g
Data Interface
1 WAN 4LAN 10/100Mb RJ45
WIFI
Transmitting power:
802.11n 11dbm
802.11g 13dbm
802.11b 15dbm
Distance：80～100 m in open area 30～50 m interior
Allow 32 users to access in theory
EMC：
Electrostatic discharge immunity：EN6100-4-2，level 2
RFEMS：EN6100-4-3, level 2
Surge：EN6100-4-3, level 2
PFMF：EN6100-4-6, level 2
Shockwave immunity ：EN6100-4-8, Horizontal / vertical direction
400A/m(>level 2)
Physical property
Shockproof：IEC60068-2-27
Drop test：IEC60068-2-32
Vibration test：IEC60068-2-6
Applications area
Pos terminals
ATM terminals access internet
Environment monitor
Remote meter reading

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 7 -
Distribution automation
Outdoor LED
Smart home
Oil monitor
Car video surveillance (Coach, bus)
Chapter 3 Installation
Here you can see the appearance of KX ROUTER 3G PRO, and how to install.
1. Accessories
2. Edition

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 8 -
3.1 Accessories
Name
Unit
No.
Description
KX
ROUTER
3G PRO
pc
1
router
Power
pc
1
standard
Antenna
pc
2
Integrated for
WIFI, one for 3G
SMA connector.
RJ45 cable
pc
1
standard
User manual
pc
1
standard
3.2 Installation
KX ROUTER 3G PRO must be properly installed and configured to meet the design
features.
Note: Please install the router and SIM card before inputting power.

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 9 -
Chapter 4 Configure
4.1 Overview
The router has its own webpage for parameter settings. You can access the router by
the following way.
4.2 Connection
4.2.1 Computer network configuration
Find “Local Area Connection”, and choose “Properties”
Choose “Internet Protocol”,
Choose automatically or input IP manually

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 10 -
4.2.2 Login the router
Open the Web browser, and type http://192.168.8.1 into the address field and
press Enter button in your computer keyboard.
Type User Name “admin” and Password “kxpro75002” in the pop-up Login
Window, and then press the “OK” button.
To use the read only access (no possible to save modifications)Type User Name
“user” and Password “75002” in the pop-up Login Window, and then press the
“OK” button. We strongly recommend that you change the default username
and password.

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 11 -
4.3 Front LEDs

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 12 -
LED
Meaning
1
PWR
Lit when power is ON.
2
MAIL
Lit when a SMS is received. Used for remote monitoring.
3
WLAN
Lit when the Wi-Fi function is enabled (default).
Flash when the data is transmitting.
Off when the Wi-Fi function is disabled.
4
LAN port 1
Lit when the cable connection with device exists.
Flash when the data is transmitting.
Off when no cable connection exists.
5
LAN port 2
Lit when the cable connection with device exists.
Flash when the data is transmitting.
Off when no cable connection exists.
6
LAN port 3
Lit when the cable connection with device exists.
Flash when the data is transmitting.
Off when no cable connection exists.
7
LAN port 4
Lit when the cable connection with device exists.
Flash when the data is transmitting.
Off when no cable connection exists.
8
WAN
Lit when connected to an Ethernet device.
Green for 100Mbps; Orange for 10Mbps
Blinking when data is transmitted/received.
9
Phone
Lit when the router is ready to use.
10
3G
Lit when the router is attached to the networks.
Flash when the data is transmitting in 3G networks.
Off when dialup is disconnected.
11
Low (1)
3 Cellular Signal Strength LEDs. All 3 LEDs lit when the
signal strength is good. The LEDs lit would decrease
progressively upon the signal strength.
12
Medium (2)
13
High (3)

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 13 -
4.4 Rear Panel
Items
Meaning
1
RESET
After the device is powered on, press the reset button
to restore to factory default settings.
10 seconds above: restore to factory default settings
(this is used when you cannot login to the router. E.g.
forgot the password).
2
LAN 1X —4X (RJ-45 connector)
Connect a UTP Ethernet cable (Cat-5 or Cat-5e) to
one of the four LAN ports when connecting to a PC or
an office/home network of 10Mbps or 100Mbps.
3
WAN (RJ-45 connector)
Connect a UTP Ethernet cable (Cat-5 or Cat-5e) to
the WAN ports when connecting to a xDSL router or
an office/home network of 10Mbps or 100Mbps.
4
DC
Connect the supplied power adapter to this jack.
5
ANTENNA CONNECTOR
Connect an SMA antenna.
6
SIM
Insert a SIM card into the SIM card holder.

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 14 -
4.5 Configure Parameters
4.5.1 Internet Settings

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 15 -
4.5.2 WAN settings
The WAN (Wide Area Network) section is where you configure your Internet connection
type. The KX ROUTER 3G PRO supports 3G dialup connection type to access Internet.
Please contact your Internet Service Provider before configuring the required parameters.

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 16 -
WAN Connection Type: support: Static IP (fixed IP), DHCP (Auto Config),
PPPOE (ADSL)
DHCP Mode:
Hostname: input it (optional)
3G Mode:
APN (Access Point Name): This SIM Card APN name is from Mobile
Management Service Provider.
Dial Number: Input the Dialing Number you get from ISP. Default is *99#.
Username: input it if ISP offers
Password: input it if ISP offers
Auth Mode: PAP/CHAP/Auto
Connection Type : AUTO/2G Only/3G Only...
Operation Mode : KeepAlive / On Demand.
Wan Priority:
WAN1: WAN2(AP Client) : WAN3 (3G/4G): Default 1:2:3
Ping To Verify connection WAN :
Check WAN Through Ping: Enable/Disable
WAN IP to PING: Default 8.8.8.8 (Google DNS)
WIFI IP to PING: Default 8.8.8.8 (Google DNS)
3G IP to PING: Default : None
Fixed Time Auto Reboot: The possibility to auto-reboot the router with a time
interval.
Enable Reboot: Disable/Enable
Interval: Default: None (Hour)

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 17 -
4.5.3 LAN settings
These are the settings of the LAN (LocalArea Network) interface for the router. The router's
local network (LAN) settings are configured based on the IP Address and Subnet Mask
assigned in this section. The IP address is also used to access this web-based
management interface. It is recommended that you use the default settings if you do not
have an existing network.
Setting the LAN parameters, include IPAddress, Subnet Mask, DHCP, etc.
IP Address: The IP address of your router’s LAN port. Default: 192.168.8.1.
Subnet Mask: Subnet Mask of your LAN (default: 255.255.255.0).
All devices on the network must have the same subnet mask to communicate on the
network.

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 18 -
DHCP Type: DHCP stands for Dynamic Host Configuration Protocol. The DHCP section is
where you configure the built-in DHCP Server to assign IP addresses to the computers and
other devices on your local area network (LAN). When you select Server item from this
pull-down list to enable this function, the following parameters will be displayed. You must
enter the IP address, Subnet Mask, Primary DNS Server and/or Secondary DNS Server.
Start IP Address: Specify the DHCP Client IP address that will start.
End IP Address: Specify the DHCP Client IP address that will end.
Note: The number of the “End IP” must be greater than “Start IP”, and cannot be the same
as the router’s IP address.
DHCP Lease Time: Designate the amount of the time for the device to recycle and give out
the IP addresses to the devices in your network (default: 86400).
Statically Assigned: You can statically assign the client MAC and IP address. Up to three
IPs and MACs can be assigned.

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 19 -
4.5.4 DHCP clients
In this section, you can see clearly which devices are currently leasing IP
addresses that you had defined for the DHCP Server‘s allocation of addresses to
computers and devices on your Local Area Network.
List the Clients which gain IP address from DHCP.
Host Name: A name for each computer or device that is given an IP address by the DHCP
Server. This may help you keep track of which computers are assigned this way.
MAC Address: A MAC address is usually located on a sticker at the bottom of a network
device. The MAC address is comprised of twelve digits. Each pair of hexadecimal digits are
usually separated by dashes or colons such as 00-0D-88-11-22-33 or 00:0D:88:11:22:33.
IP Address: The address which is obtained from the DHCP Server.
Expires in: The remaining time of the IP address’s lease. A specific LAN device no longer
needs the leased IP address when the time ends up, and this device will also free the IP
address it had leased.

KORTEX PSI –KX Router 3G Pro User Manual V1.3
- 20 -
4.5.5 VPN
4.5.5.1 L2TP
L2TP (Layer Two Tunneling Protocol) uses a virtual private network to connect to your ISP.
This method of connection requires you to enter a Username and Password (provided by
your Internet Service Provider) to gain access to the Internet.
L2TP Server IP Address: The ISP provides this parameter, if necessary. The value may be
the same as the Gateway IPAddress.
Operation Mode: The KX ROUTER 3G PRO allows you to set the reconnection mode. The
setting is:
KeepAlive:A connection to the Internet is always maintained.
