Kramer KC-Virtual Brain1 User manual

KC-Virtual Brain1 Quick Start
P/N:
2900- 301658QS
Rev:
2
Scan for full manual
KC-Virtual Brain1 Quick Start Guide
This guide helps you install and use your KC Virtual Brain1 for the first time.
Go to www.kramerav.com/downloads/KC-Virtual Brain1 to download the latest user manual and check if
firmware upgrades are available.
Step 1: Check what’s in the box
KC-Virtual Brain1 Control Server
1 VESA mounting bracket
1 Quick start guide
1 Power supply (12V DC) with adapters for US, UK, and EU
1 VESA screw set
Step 2: Get to know your KC-Virtual Brain1
#
Feature
Function
1
HDMI OUT Connector
Connect to an HDMI sink.
2
RJ-45 Port
Connect to a LAN (default mode).
3
HDMI IN Connector
Connect to an HDMI source.
4
Power Connector
Connect to the 12V DC power supply.
5
Power Button with LED
Press to power ON or turn OFF the device.
6
USB 3.0 Connectors (x2)
Connect to USB devices, for example, a keyboard and a mouse.
7
USB 2.0 Connector
Connect to a USB device, for example, a keyboard or mouse.
8
Micro SD Card Slot
Not in use.
9
N/A
10
Lock Anchor
Use to lock the device to the desk.
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
Step 3: Mount KC-Virtual Brain1
Install KC-Virtual Brain1 using one of the following methods:
•Place KC-Virtual Brain1 on a flat surface.
•When mounting on a wall, install the VESA mounting plate with 4 screws, insert the 2 hand-tightened screws into the
bottom of the device, and mount the device on the mounting plate using the 2 screws.
•Ensure that the environment (e.g., maximum ambient temperature & air flow) is compatible with the device.
•Avoid uneven mechanical loading.
•Appropriate consideration of equipment nameplate ratings should be used to avoid circuit overloading.
•Reliable earthing of rack-mounted equipment should be maintained.
•Maximum mounting height for the device is 2 meters.

Step 4: Connect inputs and outputs
If direct connectivity to KC-Virtual Brain1 is required, connect the device as shown below.
Always switch off each device’s power before connecting it to your KC-Virtual Brain1.
To achieve specified extension distances, use the recommended Kramer cables available at
www.kramerav.com/product/KC-Virtual Brain1.
Using third-party cables may cause damage!
Step 5: Connect the power
Connect the power cord to KC-Virtual Brain1 and plug it into the mains electricity.
Safety Instructions (See www.kramerav.com for updated safety information)
Caution:
•For products with relay terminals and GPI\O ports, please refer to the permitted rating for an external connection, located next to the terminal or in the User Manual.
•There are no operator-serviceable parts inside the unit.
Warning:
•Use only the power cord that is supplied with the unit.
•Disconnect the power and unplug the unit from the wall before installing.

Step 6: Operate KC-Virtual Brain1
Knowledge of IP networking is required to perform the following procedure. Inaccurate IP calculation could damage your IP
network when you start KC-Virtual Brain1.
DHCP server is recommended. You may need to contact your IT manager to get the IP of your brain.
To operate KC Virtual Brain 1:
1. Open a browser and enter Brain <IP_Address>:8090/docker.html in the URL.
When opening a KC/brain UI for the first time, the screen appears blank.
2. Click INSTALL/UPGRADE to install the brain on the docker. The process can take around 1 min.
KC-Virtual Brain1 is shipped with a license installed and Docker image is configured to ensure that powering on a
new KC-Virtual Brain1 unit will start your brain.
3. Go to GET LICENSES to check how many licenses are installed. If the window is empty, contact your local customer
support.

4. Click STATUS to check the status of the brain.
5. Click RESTART or STOP to restart or stop the brain.
6. Click LOG to download the logs. A zip file is created in the download directory.
Host Network
If you want to work with different network parameters, contact your local service engineer.
The URL to access the brain is <IP_Address>:8001/kramer-ui/index.html.
