KRAMER ELECTRONICS LTD.
USER MANUAL
MODEL:
SPK-W511
On-Wall Speakers
P/N: 2900-300115 Rev 2

SPK-W511 – Contents i
Contents
1Introduction 1
2Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Recycling Kramer Products 2
3Overview 3
3.1 Defining the SPK-W511 3
4Installing the SPK-W511 4
4.1 Choosing the Best Location 4
4.2 Installing the Speaker Wires 4
4.3 Installing the Mounting Bracket 5
4.4 Installing the SPK-W511 6
5Technical Specifications 7
Figures
Figure 1: SPK-W511 3
Figure 2: SPK-W511 with Brackets Connected 5
Figure 3: Installing the SPK-W511 6

SPK-W511 - Introduction 1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront the video, audio, presentation, and broadcasting
professional on a daily basis. In recent years, we have redesigned and upgraded
most of our line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Products.
Congratulations on purchasing your Kramer SPK-W511 On-Wall Speakers, which
are ideal for:
•Conference Rooms
•Boardrooms
•Schools and University Classrooms
•Presentation Venues
•Home Theater

2 SPK-W511 - Getting Started
2 Getting Started
We recommend that you:
•Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
•Review the contents of this user manual
Go to http://www.kramerelectronics.com to check for up-to-date
user manuals, application programs, and to check if firmware
upgrades are available (where appropriate).
2.1 Achieving the Best Performance
To achieve the best performance:
•Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
•Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
•Position your Kramer Speakers away from moisture, excessive sunlight and
dust
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
2.2 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
aims to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country
go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.
i
!

SPK-W511 - Overview 3
3 Overview
The SPK-W511 includes a pair of high performance speakers that can be
mounted on the wall vertically or horizontally, and indoors as well as outdoors. The
mounting brackets are made of painted steel that can be attached to each
speaker, letting you rotate each speaker to the left or right.
The speakers are weather resistant but not waterproof, and can
withstand the humidity in the air. We recommend that you locate
them in an area that is covered and protected from rain.
3.1 Defining the SPK-W511
This section defines the SPK-W511:
Figure 1: SPK-W511
# Feature Function
1 Speaker Grille Do not remove from the speakers
2 Bracket Knob (4) Use two knobs to fasten the bracket to the speaker
3 Speaker Bracket Used for mounting the speaker onto the wall
4 Screw Type
Input Port
Positive (red) Connect to the positive stereo analog audio output
of the receiver
5 Negative (black) Connect to the negative stereo analog audio output
of the receiver
i

4 SPK-W511 - Installing the SPK-W511
4 Installing the SPK-W511
This section explains how to:
•Choose the best location for your speakers (see Section 4.1)
•Install the speaker wires (see Section 4.2)
•Install the mounting brackets (see Section 4.3)
•Install the SPK-W511 (see Section 4.4)
4.1 Choosing the Best Location
Before installing the speakers:
•Experiment by placing the speakers in different locations before finally
deciding on the most suitable location
•Be sure that the wall type is appropriate for the mounting brackets, that is,
either solid wood, bricks, concrete, hollow building blocks, or wood studs
•Check that the mounting location is free of obstructions, such as electrical
piping, AC ducts or water lines, and so on
4.2 Installing the Speaker Wires
To install the speakers, do the following:
1. Measure the length from each speaker to the receiver, and cut the wires
accordingly, adding some access wire length to let you easily remove the
speakers from the bracket without having to disconnect the input wires.
The distance should measure up to about 4 meters (13 feet)
2. Strip the ends of the wires approximately 3/8 inch.
3. Pass the speaker wires through the round hole in the mounting bracket.
4. Unscrew the negative (black) screw-type connector, insert the wire from the
negative terminal on the receiver, and retighten.
5. Unscrew the positive (red) screw-type connector, insert the wire from the
positive terminal on the receiver, and retighten.

SPK-W511 - Installing the SPK-W511 5
6. Insert the brackets (see Section 4.3)
4.3 Installing the Mounting Bracket
To install the mounting brackets, do the following:
1. Mark the location of the mounting holes on the wall.
2. Screw the mounting screws onto the wall at the location where you want to
mount the speakers.
If the location is backed by wall studs, you can use the wood screws
provided. If the location is backed by a gypsum board, use wall anchors (not
included in the package).
3. Slide a speaker into each mounting bracket.
4. Align the bracket screw holes (upper and lower) to those on the speaker and
screw a knob to each of the holes to secure the speaker to the bracket (see
Figure 2).
Figure 2: SPK-W511 with Brackets Connected
5. You can slightly loosen the knobs on a speaker to adjust its direction.

6 SPK-W511 - Installing the SPK-W511
4.4 Installing the SPK-W511
You can connect the SPK-W511 speakers to an amplifier, for example the Kramer
907xl Power Amplifier/Mixer, as illustrated in Figure 3:
Figure 3: Installing the SPK-W511

SPK-W511 - Technical Specifications 7
5 Technical Specifications
Audio and Power
DESCRIPTION: 2-way on-wall speakers
FREQUENCY RESPONSE: 70Hz to 20kHz@ -10dB
WOOFER: 5.25” (133mm) polypropylene cone
TWEETER: 0.51” (13mm) Mylar
IMPEDANCE: 8Ω
NOMINAL SENSITIVITY: 89dB 1W @1M
DIRECTIVITY FACTOR (Q): 3.3 (2kHz)
DIRECTIVITY INDEX (DI) 5.2dB (2kHz)
POWER CAPACITY: 30W RMS
80W continuous program
CROSSOVER FREQUENCY: WOOFER: Full range
TWEETER: High-pass @ 8kHz
INPUT CONNECTORS: Gold-plated 5-way binding posts
Shipping and Installation
MATERIALS: Frame, grill and brackets steel; cabinet ABS
OPERATING TEMPERATURE: 0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE: -40° to +70°C (-40° to 158°F)
HUMIDITY: 10% to 90%, RHL non-condensing
WEIGHT PER SINGLE SPEAKER: 2kg (4.4lbs) approx.
WEIGHT WITH MOUNTING KIT: 2.4kg (5.3lbs) approx.
SHIPPING WEIGHT (FOR PAIR): 4.8kg (10.6lbs) approx.
DIMENSIONS: 18.5cm x 16.5cm x 24.9cm (7.28” x 6.5” x 9.8”), W, D, H.
DIMENSIONS with mounting
brackets:
18.5cm x 16.7cm x 27cm (7.28” x 6.6” x 10.6”), W, D, H.
INSTALLATION CLEARANCE: Front panel to wall (with mounting bracket): 21cm (8.2”)
Back panel to wall (with mounting bracket): 4.5cm (1.8”)
ACCESSORIES: 2 mounting brackets (including 4 knobs and 4 mounting
screws)
OPTIONS: BCP-2S speaker cable
COLORS: Available in white or black
Specifications are within a 10% tolerance and are subject to change without notice at
http://www.kramerelectronics.com

For the latest information on our products and a list of Kramer distributors,
visit our Web site where updates to this user manual may be found.
We welcome your questions, comments, and feedback.
Web site: www.kramerelectronics.com
E-mail: [e-mail]
P/N:
2900- 300115
Rev:
2
!
