Package Contents
The following contents should be found in your package:
 One WIRELESS ROUTER 150MBPS ADSL2/2+
 One DC power Adapter for WIRELESS ROUTER 150MBPS ADSL2/2+
 Quick Installation Guide
 One RJ45 cable
 Two RJ11 cables
 One ADSL splitter
 One Resource CD, which includes this User Guide
 Note:
Make sure that the package contains the above items. If any of the listed items are damaged or
missing, please contact your distributor.
Manual
www.kraun.it
󼁣1󺵉󻹥󺅟

WIRELESS
ROUTER
150MBPS
ADSL2/2+
WIRELESS ROUTER 150MBPS ADSL2/2+ User
Guide
2
Chapter 1 Introduction
Thank you for choosing the WIRELESS ROUTER 150MBPS ADSL2/2+.
1.1 Product Overview
The device is designed to provide a simple and cost-effective ADSL Internet connection for a
private Ethernet or IEEE 802.11n/ IEEE 802.11g/ IEEE 802.11b wireless network.
The WIRELESS ROUTER 150MBPS ADSL2/2+ connects to an Ethernet LAN or computers via
standard Ethernet ports. The ADSL connection is made using ordinary telephone line with
standard connectors. Multiple workstations can be networked and connected to the Internet using
a single Wide Area Network (WAN) interface and single global IP address. The advanced security
enhancements, IP/MAC Filter, Application Filter and URL Filter can help to protect your
network from potentially devastating intrusions by malicious agents from the outside of your
network.
Quick Start of the Web-based Utility is supplied and friendly help messages are provided for the
configuration. Network and Router management is done through the Web-based Utility which can
be accessed through local Ethernet using any web browser.
ADSL
The WIRELESS ROUTER 150MBPS ADSL2/2+ supports full-rate ADSL2+ connectivity
conforming to the ITU and ANSI specifications. In addition to the basic DMT physical layer
functions, the ADSL2+ PHY supports dual latency ADSL2+ framing (fast and interleaved) and the
I.432 ATM Physical Layer.
Wireless
In the most attentive wireless security, the Router provides multiple protection measures. It can be
set to turn off the wireless network name (SSID) broadcast so that only stations that have the
SSID can be connected. The Router provides wireless LAN 64/128-bit WEP encryption security,
WPA-PSK/WPA2-PSK authentication, as well as TKIP/AES encryption security.
1.2 Main Features
 Four 10/100Mbps Auto-Negotiation RJ45 LAN ports (Auto MDI/MDIX), one RJ11 port.
 Provides external splitter.
 Adopts Advanced DMT modulation and demodulation technology.
 Supports bridge mode and Router function.
 Multi-user sharing a high-speed Internet connection.
 Downstream data rates up to 24Mbps, upstream data rates up to 3.5Mbps（With Annex M enabled）.
 Supports long transfers, the max line length can reach to 6.5Km.
2
Manual
www.kraun.it

WIRELESS
ROUTER
150MBPS
ADSL2/2+
WIRELESS ROUTER 150MBPS ADSL2/2+ User
Guide
3
 Supports remote configuration and management through SNMP and CWMP.
 Supports PPPoE, it allows connecting the internet on demand and disconnecting from the
Internet when idle.
 Provides reliable ESD and surge-protect function with quick response semi-conductive surge
protection circuit.
 High speed and asymmetrical data transmit mode, provides safe and exclusive bandwidth.
 Supports All ADSL industrial standards.
 Compatible with all mainstream DSLAM (CO).
 Provides integrated access of internet and route function which face to SOHO user.
 Real-time Configuration and device monitoring.
 Supports Multiple PVC (Permanent Virtual Circuit).
 Built-in DHCP server.
 Built-in firewall, supporting IP/MAC filter, Application filter and URL filter.
 Supports Virtual Server, DMZ host and IP Address Mapping.
 Supports Dynamic DNS, UPnP and Static Routing.
 Supports system log and flow Statistics.
 Supports firmware upgrade and Web management.
 Provides WPA-PSK/WPA2-PSK data security, TKIP/AES encryption security.
 Provides 64/128-bit WEP encryption security and wireless LAN ACL (Access Control List).
1.3 Conventions
The Router or device mentioned in this User guide stands for WIRELESS ROUTER 150MBPS
ADSL2/2+ without any explanations.
Parameters provided in the pictures are just references for setting up the product, which may
differ from the actual situation.
3
Manual
www.kraun.it

WIRELESS
ROUTER
150MBPS
ADSL2/2+
WIRELESS ROUTER 150MBPS ADSL2/2+ User
Guide
4
Chapter 2 Hardware Installation
2.1 The Front Panel
Figure 2-1
The LEDs locate on the front panel, they indicate the device’s working status. For details, please
refer to LED Explanation.
LED Explanation:
4
Manual
www.kraun.it
Name Status Indication
On Power is on.
Power Off Power is off.
Flash The ADSL negotiation is in progress.
On The LINE port is linked up.
ADSL
Off The LINE port is linked down.
Off There is no successful PPP connection or the Router works on Bridge
mode.
On A successful PPP connection has been built.
Internet
Flash Data is being transferred over the Internet.
On The wireless function is enabled but no data is being transmitted.
Flash There is wireless data being transmitted.
WLAN
Off The wireless function is disabled.
Flash Data is being transferred over the 1-4 (LAN) port.
On There is a successful connection on the corresponding 1-4 （LAN）
port but no activity.
LAN(1-4)
Off There is no connection on the corresponding 1-4 (LAN) port or the
connection is abnormal.
Slow Flash A wireless device is connecting to the network by WPS function. This
process will last in the first 2 minutes.
On A wireless device has been successfully added to the network by
WPS function.
WPS
Quick Flash A wireless device failed to be added to the network by WPS function.

WIRELESS
ROUTER
150MBPS
ADSL2/2+
WIRELESS ROUTER 150MBPS ADSL2/2+ User
Guide
5
2.2 The Back Panel
Figure 2-2
 POWER: The Power plug is where you will connect the power adapter.
 1, 2, 3, 4 (LAN): Through the port, you can connect the Router to your PC or the other
Ethernet network devices.
 RESET: There are two ways to reset the Router's factory defaults.
Method one: With the Router powered on, use a pin to press and hold the Reset button for at
least 5 seconds. And the Router will reboot to its factory default settings.
Method two: Restore the default setting from “Maintenance-SysRestart” of the Router's
Web-based Utility.
 LINE: Through the port, you can connect the router with the telephone. Or you can connect
them by an external separate splitter. For details, please refer to 2.4.
 Antenna: Used for wireless operation and data transmit.
2.3 Installation Environment
 The Product should not be located where it will be exposed to moisture or excessive heat.
 Place the Router in a location where it can be connected to the various devices as well as to
a power source.
 Make sure the cables and power cord are safely placed out of the way so they do not create a
tripping hazard.
5
Manual
www.kraun.it

WIRELESS
ROUTER
150MBPS
ADSL2/2+
WIRELESS ROUTER 150MBPS ADSL2/2+ User
Guide
6
 The Router can be placed on a shelf or desktop.
 Keep away from the strong electromagnetic radiation and the device of electromagnetic sensitive.
2.4 Connecting the Router
Before installing the device, please make sure your broadband service provided by your ISP is
available. If there is any problem, please contact your ISP. Before cable connection, cut off the
power supply and keep your hands dry. You can follow the steps below to install it.
Step 1: Connect the ADSL Line.
Method one: Plug one end of the twisted-pair ADSL cable into the ADSL LINE port on
the rear panel of WIRELESS ROUTER 150MBPS ADSL2/2+, and insert the other end
into the wall socket.
Method two：You can use a separate splitter. External splitter can divide the data and
voice, and then you can access the Internet and make calls at the same time. The
external splitter has three ports:
• LINE: Connect to the wall jack
• PHONE: Connect to the phone sets
• MODEM: Connect to the ADSL LINE port of WIRELESS ROUTER 150MBPS
ADSL2/2+
Plug one end of the twisted-pair ADSL cable into the ADSL LINE port on the rear panel
of WIRELESS ROUTER 150MBPS ADSL2/2+. Connect the other end to the MODEM
port of the external splitter.
Step 2: Connect the Ethernet cable. Attach one end of a network cable to your computer’s
Ethernet port or a regular hub/switch port, and the other end to the LAN port on the
WIRELESS ROUTER 150MBPS ADSL2/2+.
Step 3: Power on the computers and LAN devices.
Step 4: Attach the power adapter. Connect the power adapter to the power connector on the rear
of the device and plug in the adapter to a wall outlet or power extension.
6
Manual
www.kraun.it

WIRELESS
ROUTER
150MBPS
ADSL2/2+
WIRELESS ROUTER 150MBPS ADSL2/2+ User
Guide
7
Figure 2-3
7
Manual
www.kraun.it

WIRELESS
ROUTER
150MBPS
ADSL2/2+
WIRELESS ROUTER 150MBPS ADSL2/2+ User
Guide
8
Chapter 3 Quick Installation Guide
3.1 Configure PC
After you directly connect your PC to the WIRELESS ROUTER 150MBPS ADSL2/2+ or connect
your adapter to a Hub/Switch which has connected to the Router, you need to configure your PC’s
IP address. Follow the steps below to configure it.
Step 1: Click the Start menu on your desktop, right click My Network Places, and then select
Properties
Step 2: Right click Local Area Connection (LAN), and then select Properties.
Figure 3-2
Step 3: Select General tab, highlight Internet Protocol (TCP/IP), and then click the Properties
button.
8
Manual
www.kraun.it

WIRELESS
ROUTER
150MBPS
ADSL2/2+
WIRELESS ROUTER 150MBPS ADSL2/2+ User
Guide
9
Figure 3-3
Step 4: Configure the IP address as Figure 3-4 shows. After that, click OK.
9
Manual
www.kraun.it

WIRELESS
ROUTER
150MBPS
ADSL2/2+
WIRELESS ROUTER 150MBPS ADSL2/2+ User
Guide
10
Figure 3-4
 Note:
You can configure the PC to get an IP address automatically, select “Obtain an IP address
automatically” and “Obtain DNS server address automatically” in the screen above.
Now, you can run the Ping command in the command prompt to verify the network connection.
Please click the Start menu on your desktop, select run tab, type cmd or command in the field
and press Enter. Type ping 192.168.1.1 on the next screen, and then press Enter.
If the result displayed is similar to the screen below, the connection between your PC and the
Router has been established.
WIRELESS
ROUTER
150MBPS
ADSL2/2+
WIRELESS ROUTER 150MBPS ADSL2/2+ User
Guide
11
Figure 3-5
If the result displayed is similar to the screen shown below, it means that your PC has not
connected to the Router.
Figure 3-6
You can check it follow the steps below:
1) Is the connection between your PC and the Router correct?
The LEDs of LAN port which you link to the device and the LEDs on your PC's adapter should
be lit.
2) Is the TCP/IP configuration for your PC correct?
If the Router's IP address is 192.168.1.1, your PC's IP address must be within the range of
192.168.1.2 ~ 192.168.1.254.
3.2 Login
Once your host PC is properly configured, please proceed as follows to use the Web-based Utility:
Start your web browser and type the private IP address of the Router in the URL field: 192.168.1.1.
After that, you will see the screen shown below, enter the default User Name admin and the
default Password admin, and then click OK to access to the Quick Setup screen. You can follow
the steps below to complete the Quick Setup.
Step 1: Select the Quick Start tab, then click RUN WIZARD, and you will see the next screen.
Click the NEXT button.
10
Manual
www.kraun.it

WIRELESS
ROUTER
150MBPS
ADSL2/2+
WIRELESS ROUTER 150MBPS ADSL2/2+ User
Guide
11
Figure 3-5
If the result displayed is similar to the screen shown below, it means that your PC has not
connected to the Router.
Figure 3-6
You can check it follow the steps below:
1) Is the connection between your PC and the Router correct?
The LEDs of LAN port which you link to the device and the LEDs on your PC's adapter should
be lit.
2) Is the TCP/IP configuration for your PC correct?
If the Router's IP address is 192.168.1.1, your PC's IP address must be within the range of
192.168.1.2 ~ 192.168.1.254.
3.2 Login
Once your host PC is properly configured, please proceed as follows to use the Web-based Utility:
Start your web browser and type the private IP address of the Router in the URL field: 192.168.1.1.
After that, you will see the screen shown below, enter the default User Name admin and the
default Password admin, and then click OK to access to the Quick Setup screen. You can follow
the steps below to complete the Quick Setup.
Step 1: Select the Quick Start tab, then click RUN WIZARD, and you will see the next screen.
Click the NEXT button.
11
Manual
www.kraun.it

WIRELESS
ROUTER
150MBPS
ADSL2/2+
WIRELESS ROUTER 150MBPS ADSL2/2+ User
Guide
12
Figure 3-8
Step 2: Configure the time for the Router, and then click the NEXT button.
Figure 3-9
Step 3: Select the connection type to connect to the ISP (We select PPPoE/PPPoA mode for
example here), and then click the NEXT button.
Figure 3-10
Step 4: Configure the following options provided by your ISP: Username, Password, VPI, VCI
and Connection Type. Then click NEXT.
12
Manual
www.kraun.it

WIRELESS
ROUTER
150MBPS
ADSL2/2+
WIRELESS ROUTER 150MBPS ADSL2/2+ User
Guide
13
Figure 3-11
Step 5: Configure the rules for the WLAN, and click NEXT.
Figure 3-12
 Note:
If the Access Point is activated, the wireless function will be available even without the external
antenna because of an additional printed antenna. To adopt the wireless security protection
measures, please refer to section 4.3.3.
Step 6: Click NEXT to finish the Quick Start.
WIRELESS
ROUTER
150MBPS
ADSL2/2+
WIRELESS ROUTER 150MBPS ADSL2/2+ User
Guide
14
Figure 3-13
13
Manual
www.kraun.it

14
Manual
www.kraun.it

WIRELESS
ROUTER
150MBPS
ADSL2/2+
WIRELESS ROUTER 150MBPS ADSL2/2+ User
Guide
15
Chapter 4 Software Configuration
This User Guide recommends using the “Quick Installation Guide” for first-time installation. For
advanced users, if you want to know more about this device and make use of its functions
adequately, maybe you will get help from this chapter to configure the advanced settings through
the Web-based Utility.
After your successful login, you can configure and manage the device. There are main menus on
the top of the Web-based Utility; submenus will be available after you click one of the main menus.
On the center of the Web-based Utility, there are the detailed configurations or status information.
To apply any settings you have altered on the page, please click the SAVE button.
4.1 Status
Choose “Status”, you can see the next submenus: Device Info, System Log and Statistics.
Click any of them, and you will be able to configure the corresponding function.
Figure 4-1
Click any of them, and you will be able to view the corresponding information.
4.1.1 Device Info
Choose “Status→Device Info” menu, and you will be able to view the device information,
including LAN, WAN and ADSL. The information will vary depending on the settings of the Router
configured on the Interface Setup screen.
15
Manual
www.kraun.it

WIRELESS
ROUTER
150MBPS
ADSL2/2+
WIRELESS ROUTER 150MBPS ADSL2/2+ User
Guide
16
Figure 4-2
 Note:
Click the other submenus System Log or Statistics in Figure 4-2, and you will be able to view the
system log and traffic statistics about the Router.
4.1.2 System Log
Choose “Status→System Log” menu, and you will be able to query the logs of the Router.
16
Manual
www.kraun.it

WIRELESS
ROUTER
150MBPS
ADSL2/2+
WIRELESS ROUTER 150MBPS ADSL2/2+ User
Guide
17
Figure 4-3
The Router can keep logs of all traffic. You can query the logs to find what happened to the Router.
Click the CLEAR LOG button to clear the logs.
Click the SAVE LOG button to save the logs.
4.1.3 Statistics
Choose “Status→Statistics” menu, and you will be able to view the network traffic over Ethernet,
ADSL and WLAN.
Figure 4-4
17
Manual
www.kraun.it
