Introduction1
Congratulations on becoming the owner of the Integrated Access Device. You will now be able
to access the Internet using your high-speed DSL connection.
This User Guide will show you how to connect your Integrated Access Device, and how to
customize its conguration to get the most out of your new product.
Features
The list below contains the main features of the device and may be useful to users with
knowledge of networking protocols. If you are not an experienced user, the chapters throughout
this guide will provide you with enough information to get the most out of your device.
Features include:
Internal DSL modem for high-speed Internet access•
10/100Base-T Ethernet router to provide Internet connectivity to all computers on your LAN•
Network address translation (NAT) functions to provide security for your LAN•
Network conguration through DHCP Server and DHCP Client•
Services including IP route and DNS conguration, RIP, and IP and DSL performance •
monitoring
User-friendly conguration program accessed via a web browser•
User-friendly conguration program accessed via EasySetup program•
Device Requirements
In order to use the Integrated Access Device, you must have the following:
DSL service up and running on your telephone line•
Instructions from your ISP on what type of Internet access you will be using, and the •
addresses needed to set up access
One or more computers each containing an Ethernet card (10Base-T/100Base-T network•
interface card (NIC))
For system conguration using the supplied •
a. web-based program: a web browser such as Internet Explorer v4 or later, or Netscape v4 or
later. Note that version 4 of each browser is the minimum version requirement – for optimum
display quality, use Internet Explorer v5, or Netscape v6.1
b. EasySetup program: Graphical User Interface
Note
You do not need to use a hub or switch in order to connect more
than one Ethernet PC to your device. Instead, you can connect
up to four Ethernet PCs directly to your device using the ports
labeled Ethernet on the rear panel.

3
Manual
www.kraun.it
Using this Document
Notational conventions
Acronyms are dened the rst time they appear in the text and also in the glossary.•
For brevity, the Integrated Access Device is referred to as “the device”.•
The term• LAN refers to a group of Ethernet-connected computers at one site.
Typographical conventions
Italic• text is used for items you select from menus and drop-down lists and the names of
displayed web pages.
Bold• text is used for text strings that you type when prompted by the program, and to
emphasize important points.
Special messages
This document uses the following icons to draw your attention to specic instructions or
explanations.
Note
Provides clarifying or non-essential information on the current
topic.
Denition
Explains terms or acronyms that may be unfamiliar to many
readers. These terms are also included in the Glossary.
WARNING
Provides messages of high importance, including messages
relating to personal safety or system integrity.
Getting Support
Supplied by:
Helpdesk Number:
Website:

4
Manual
www.kraun.it
Getting to know the device2
Parts Check
In addition to this document, your package should arrive containing the following:
1. Power Supply•
2. CD-ROM containing the online manual and Easy Setup software•
3. Integrated Access Device•
4. Ethernet Cable•
5. Standard Phone Cable•
6. Quick Installation Guide•
Integrated Access Device Package ContentsFigure 1:

5
Manual
www.kraun.it
Front Panel
The front panel contains lights called Light Emitting Diodes (LEDs) that indicate the status of the
unit.
Front Panel and LEDsFigure 2:

6
Manual
www.kraun.it
Label Color Function
POWER green On: device is powered on
Off: device is powered off
DSL green On: DSL link reaches showtime, which means
that your device has successfully connected
to your ISP’s DSL network.
Off: DSL link not in showtime, your device has
not successfully connected to your ISP’s DSL
network.
Blink: Data being transmitted
INTERNET green On: PPP link established and active, which
means that your device has successfully
connected to your ISP’s network.
Off: No PPP link, your device has not
successfully connected to your ISP’s network.
Blink: PPP link established and active
WLAN green On: WLAN link established and active
Blink: Valid Wireless packet being transferred
WPS green Off: WPS link isn’t established and active
Blink: Valid WPS packet being transferred
LAN
1/2/3/4
green On: LAN link established and active
Off: No LAN link
Blink: Valid Ethernet packet being transferred
PHONE 2 green On: VoIP link established
Off: No VoIP link
Blink: VoIP packet being transferred
PHONE 1 green On: VoIP link established
Off: No VoIP link
Blink: VoIP packet being transferred

7
Manual
www.kraun.it
Rear and Right Panel
The rear panel contains a Restore Defaults button, the ports for the unit’s data and power
connections.
Rear Panel ConnectionsFigure 3:
Right Panel ConnectionsFigure 4:

8
Manual
www.kraun.it
Label Function
ANETENNA ANETENNA
ON/OFF
SWITCH
Power on/off the device
POWER Connects to the supplied power cable
LAN 4/3/2/1 Connects the device via Ethernet to up to four PCs on
your LAN
STB Connects the device via Ethernet to STB on your LAN
RESET Pressing this button restores the factory default
conguration on your device
ADSL Connects the device to a telephone port in the wall of
your home/ofce for DSL communication
PSTN Connects the device to a telephone port in the wall of
your home/ofce
PHONE 2 Connects the device to a regular telephone
PHONE 1 Connects the device to a regular telephone
WLAN Disable or Enable Wireless LAN
WPS Disable or Enable WPS function

9
Manual
www.kraun.it
Connecting your device3
This chapter provides basic instructions for connecting the Integrated Access Device to a
computer or LAN and to the Internet.
In addition to conguring the device, you need to congure the Internet properties of your
computer(s). For more details, see the following sections:
Conguring Ethernet PCs •
Conguring Wireless PCs•
This chapter assumes that you have already established a DSL service with your Internet
service provider (ISP). These instructions provide a basic conguration that should be
compatible with your home or small ofce network setup. Refer to the subsequent chapters for
additional conguration instructions.
Connecting the Hardware
This section describes how to connect the device to the wall phone port, the power outlet and
your computer(s) or network.
WARNING
Before you begin, turn the power off for all devices. These
include your computer(s), your LAN hub/switch (if applicable),
and the Integrated Access Device.
The diagram below illustrates the hardware connections. The layout of the ports on your device
may vary from the layout shown. Refer to the steps that follow for specic instructions.
Overview of Hardware ConnectionsFigure 5:

10
Manual
www.kraun.it
Step 1. Attach the power connector
Connect the power adapter to the POWER connector on the back of the device and plug the
adapter into a wall outlet or power strip. Turn on and boot up your computer(s) and any LAN
devices such as hubs or switches.
Step 2. Connect the Ethernet cable
Connect either a LAN hub or Ethernet computers directly to the device via Ethernet cable(s).
Note that the cables do not need to be crossover cables.
Step 3. Connect the Ethernet cable to STB
Connect either STB directly to the device via Ethernet cable(s).
Note that the cables do not need to be crossover cables.
Step 4. Connect the Telephone cable to ADSL line
Connect one end of the provided phone cable to the port labeled ADSL on the rear panel of the
device. Connect the other end to your wall phone port.
Step 5. Connect the Telephone cable to PSTN line
Connect one end of the provided phone cable to the port labeled PSTN on the rear panel of the
device. Connect the other end to your wall phone port.
Step 6. Connect the Telephone cable to a telephone
Connect one end of the provided phone cable to the port labeled PHONE 2 and/or PHONE 1 on
the rear panel of the device. Connect the other end to your Telephone.
Step 7. Power on the device
Press ON/OFF SWITCH to power on the device.
Step 8. Congure your Ethernet PCs
You must also congure the Internet properties on your Ethernet PCs. See Conguring Ethernet
PCs.
Step 9. Install a Wireless card and connect Wireless PCs
You can attach a Wireless LAN that enables Wireless PCs to access the Internet via your
device.
You must congure your Wireless computer(s) in order to access your device. For complete
instructions, see Conguring Wireless PCs.
Next step
After setting up and conguring the device and PCs, you can log on to the device by following
the instructions in Getting Started with the Web pages. The chapter includes a section called
Testing your Setup, which enables you to verify that the device is working properly.

11
Manual
www.kraun.it
Easy Setup4
For easy conguration, insert the CD into your CD-ROM drive.•
The CD should auto-start and then click “Easy Setup”. If it does not start, click on Start -> Run •
and type in CD:\fscommand \vbpES.exe (where CD is the drive letter of your CD-ROM drive.)
•
Please enter the last 6 digit MAC Address and then click • submit.
You can nd the MAC Address on the sticker which is on the bottom side of the device. If the •
MAC Address is 001333abcdef, you need to enter abcdef.
This program is checking the IAD conguration.•

12
Manual
www.kraun.it
WAN Conguration only:
There are Three options of Protocol Modes on WAN Conguration: PPPoA VC-Mux, PPPoE
LLC and 1483 Bridged IP LLC Mode.
PPPoE LLC
Click1. Enter your ADSL username and password.
Enter2. Username/Password which was given by Telecom or by your Internet Service Provider
(ISP).
Click3. Next.

13
Manual
www.kraun.it
Enter4. Registrar and Registrar Port of SIP Server for example 192.168.10.101 and 5060.
Enter5. Proxy and Proxy Port of SIP Server for example 192.168.10.101 and 5060.
Enter6. Outbound Server and Outbound Server Port of SIP Server for example
192.168.10.101 and 5060.
Enter7. User Domain for example 192.168.10.101.
Enter8. Name and Password for SIP Account 0.
Enter9. Name and Password for SIP Account 1.
Click10. Next, it will start to congure the router for a while. Follow the instructions of the Easy
Setup utility which will guide you to complete the conguration.

14
Manual
www.kraun.it
Easy setup conguration completed.11.
Now you are ready to Surf the Internet and VoIP Service!!!12.

15
Manual
www.kraun.it
PPPoA VC-Mux
After selecting the Protocol : 1. PPPoA VC-Mux:
Enter2. VPI/VCI which was given by Telecom or by your Internet Service Provider (ISP).
Enter3. Username/Password which was given by Telecom or by your Internet Service Provider
(ISP).
Click4. Next.

16
Manual
www.kraun.it
Enter5. Registrar and Registrar Port of SIP Server for example 192.168.10.101 and 5060.
Enter6. Proxy and Proxy Port of SIP Server for example 192.168.10.101 and 5060.
Enter7. Outbound Server and Outbound Server Port of SIP Server for example
192.168.10.101 and 5060.
Enter8. User Domain for example 192.168.10.101.
Enter9. Name and Password for SIP Account 0.
Enter10. Name and Password for SIP Account 1.
Click11. Next, it will start to congure the router for a while. Follow the instructions of the Easy
Setup utility which will guide you to complete the conguration.

17
Manual
www.kraun.it
Easy setup conguration completed.12.
Now you are ready to Surf the Internet and VoIP Service!!!13.

18
Manual
www.kraun.it
1483 Bridged IP LLC DHCP Client
After selecting the Protocol : 1483 Bridged IP LLC:1.
Enter2. VPI/VCI which was given by Telecom or by your Internet Service Provider (ISP).
Click3. DHCP Client which was given by Telecom or by your Internet Service Provider (ISP).
Click4. Next.

19
Manual
www.kraun.it
Enter5. Registrar and Registrar Port of SIP Server for example 192.168.10.101 and 5060.
Enter6. Proxy and Proxy Port of SIP Server for example 192.168.10.101 and 5060.
Enter7. Outbound Server and Outbound Server Port of SIP Server for example
192.168.10.101 and 5060.
Enter8. User Domain for example 192.168.10.101.
Enter9. Name and Password for SIP Account 0.
Enter10. Name and Password for SIP Account 1.
Click11. Next, it will start to congure the router for a while. Follow the instructions of the Easy
Setup utility which will guide you to complete the conguration.

20
Manual
www.kraun.it
Easy setup conguration completed.12.
Now you are ready to Surf the Internet and VoIP Service!!!13.
