Kraun Wireless ADSL2/2plus Modem Router 54Mbps User manual

Manual
www.kraun.it
Warning
The manufacturer is under no circumstances liable for any unauthorised modifications made to
the product by the user or any other parties which may compromise its conformity and safety.
Cod. KN.3N
User’s Manual
ADSL2/2+ Wireless-N
Router 300Mbps

2
Manual
www.kraun.it
TABLE OF CONTENTS
Package Contents 4
Chapter 1. Introduction 4
1.1 Product Overview 4
ADSL 4
Wireless 4
1.2 Main Features 5
1.3 Factory Defaults 5
Chapter 2. Hardware Installation 6
2.1 The Front Panel 6
LED Explanation 6
2.2 The Back Panel 7
2.3 Installation Environment 7
2.4 Connecting the Router 8
Chapter 3. Quick Installation Guide 9
3.1 Congure PC 9
3.2 Login 12
Chapter 4. Software Conguration 15
4.1 Status 15
4.1.1 Device Info 15
4.1.2 System Log 16
4.1.3 Statistics 16
4.2 Quick Start 18
4.3 Interface Setup 18
4.3.1 Internet 19
Dynamic IP Address 20
Static IP Address 21
PPPoA/PPPoE 22
Bridge Mode 23
4.3.2 LAN 24
4.3.3 Wireless 26
WEP-64Bits 28
WEP-128Bits 28
WPA-PSK 28
WPA2-PSK 29
WPA-PSK/WPA2-PSK 29
4.4 Advanced Setup 32
4.4.1 Firewall 32
4.4.2 Routing 32
4.4.3 NAT 33
4.4.3.1 DMZ 34
4.4.3.2 Virtual Server 34
4.4.3.3 IP Address Mapping 35
4.4.4 QoS 37

3
Manual
www.kraun.it
4.4.5 VLAN 38
Assign VLAN PVID for each Interface 39
Dene VLAN Group 39
4.4.6 ADSL 40
4.5 Access Management 40
4.5.1 ACL 41
4.5.2 Filter 41
4.5.2.1 IP Filter 41
4.5.2.2 MAC Filter 45
4.5.2.3 Application Filter 47
4.5.2.4 URL 47
4.5.3 SNMP 48
4.5.4 UPnP 49
4.5.5 DDNS 49
4.5.6 CWMP 50
4.6 Maintenance 51
4.6.1 Administration 51
4.6.2 Time Zone 51
NTP Server automatically 52
PC’s Clock 52
Manually 53
4.6.3 Firmware 53
4.6.4 System Restart 55
4.6.5 Diagnostic 55
4.7 Help 56
Chapter 5. Appendix A: Specications 57

4
Manual
www.kraun.it
Package Contents
The following contents should be found in your package:
yOne Kraun ADSL2/2+ Wireless-N Router 300Mbps
yOne Power Adapter for Kraun ADSL2/2+ Wireless-N Router 300Mbps
yQuick Installation Guide
yOne RJ45 cable
yTwo RJ11 cables
yOne ADSL splitter
yOne Resource CD, which includes this User Manual
NOTE:
Make sure that the package contains the above items. If any of the listed items are damaged or missing, please
contact your distributor.
Chapter 1. Introduction
Thank you for choosing the Kraun ADSL2/2+ Wireless-N Router 300Mbps.
1.1 Product Overview
The device is designed to provide a simple and cost-eective ADSL Internet connection for a private Ethernet or
IEEE 802.11n/ IEEE 802.11g/ IEEE 802.11b wireless network.
The Kraun-300N connects to an Ethernet LAN or computers via standard Ethernet ports. The ADSL connection
is made using ordinary telephone line with standard connectors. Multiple workstations can be networked and
connected to the Internet using a single Wide Area Network (WAN) interface and single global IP address. The
advanced security enhancements, IP/MAC Filter, Application Filter and URL Filter can help to protect your
network from potentially devastating intrusions by malicious agents from the outside of your network.
Quick Start of the Web-based Utility is supplied and friendly help messages are provided for the conguration.
Network and Router management is done through the Web-based Utility which can be accessed through local
Ethernet using any web browser.
ADSL
The Kraun-300N supports full-rate ADSL2+ connectivity conforming to the ITU and ANSI specications. In addi-
tion to the basic DMT physical layer functions, the ADSL2+ PHY supports dual latency ADSL2+ framing (fast and
interleaved) and the I.432 ATM Physical Layer.
Wireless
In the most attentive wireless security, the Router provides multiple protection measures. It can be set to turn
o the wireless network name (SSID) broadcast so that only stations that have the SSID can be connected. The
Router provides wireless LAN 64/128-bit WEP encryption security, WPA-PSK/WPA2-PSK authentication, as well
as TKIP/AES encryption security.

5
Manual
www.kraun.it
1.2 Main Features
yFour 10/100Mbps Auto-Negotiation RJ45 LAN ports (Auto MDI/MDIX), one RJ11 port.
yProvides external splitter.
yAdopts Advanced DMT modulation and demodulation technology.
ySupports bridge mode and Router function.
yMulti-user sharing a high-speed Internet connection.
yDownstream data rates up to 24Mbps, upstream data rates up to 3.5Mbps（With Annex M enabled（.
ySupports long transfers, the max line length can reach to 6.5Km.
ySupports remote conguration and management through SNMP and CWMP.
ySupports PPPoE, it allows connecting the internet on demand and disconnecting from the Internet when idle.
yProvides reliable ESD and surge-protect function with quick response semi-conductive surge protection circuit.
yHigh speed and asymmetrical data transmit mode, provides safe and exclusive bandwidth.
ySupports All ADSL industrial standards.
yCompatible with all mainstream DSLAM (CO).
yProvides integrated access of internet and route function which face to SOHO user.
yReal-time Conguration and device monitoring.
ySupports Multiple PVC (Permanent Virtual Circuit).
yBuilt-in DHCP server.
yBuilt-in rewall, supporting IP/MAC lter, Application lter and URL lter.
ySupports Virtual Server, DMZ host and IP Address Mapping.
ySupports Dynamic DNS, UPnP and Static Routing.
ySupports system log and ow Statistics.
yProvides WPA-PSK/WPA2-PSK data security, TKIP/AES encryption security.
yProvides 64/128-bit WEP encryption security and wireless LAN ACL (Access Control List).
1.3 Factory Defaults
Item Default Value
Common Default Settings
Username admin
Password admin
IP Address 192.168.1.1
Subnet Mask 255.255.255.0
Wireless
SSID KRAUN_XXXXXX
KRAUN_the last 6 characters of MAC address (example KRAUN_123456)
Wireless Security Enable
Security Type WPA-PSK/WPA2-PSK
Encryption TKIP+AES
WPA KEY KRAUN_KN.3N
DHCP Server Enable

6
Manual
www.kraun.it
Chapter 2. Hardware Installation
2.1 The Front Panel
Figure 2-1
The LEDs locate on the front panel, they indicate the device’s working status. For details, please refer to LED
Explanation.
LED Explanation
Name Status Indication
Power On Power is on.
O Power is o.
ADSL
Flash The ADSL negotiation is in progress.
On The LINE port is linked up.
O The LINE port is linked down.
Internet
O There is no successful PPP connection or the Router works on Bridge mode.
On A successful PPP connection has been built.
Flash Data is being transferred over the Internet.
WLAN
On The wireless function is enabled but no data is being transmitted.
Flash There is wireless data being transmitted.
O The wireless function is disabled.
LAN(1-4)
Flash Data is being transferred over the 1-4 (LAN) port.
On There is a successful connection on the corresponding 1-4 (LAN) port but no
activity.
O There is no connection on the corresponding 1-4 (LAN) port or the connection
is abnormal.
WPS
Flash A wireless device is connecting to the network by WPS function. This process will
last in the rst 2 minutes and then turn o.
On A wireless device has been successfully added to the network by WPS function.
The WPS LED will keep on for about 5 minutes and then turn o.
O The WPS function is disabled or a wireless device is failed to add the network.

7
Manual
www.kraun.it
2.2 The Back Panel
Figure 2-2
yPOWER: The Power plug is where you will connect the power adapter.
yON/OFF: The power for the Router.
y1, 2, 3, 4 (LAN): Through the port, you can connect the Router to your PC or the other Ethernet network
devices.
yRESET: There are two ways to reset the Router’s factory defaults.
yMethod one: With the Router powered on, use a pin to press and hold the Reset button for at least 5 seconds.
And the Router will reboot to its factory default settings.
yMethod two: Restore the default setting from “Maintenance-SysRestart” of the Router’s Web-based Utility.
yLINE: Through the port, you can connect the router with the telephone. Or you can connect them by an
external separate splitter. For details, please refer to 2.4.
yAntenna: Used for wireless operation and data transmit.
2.3 Installation Environment
yThe Product should not be located where it will be exposed to moisture or excessive heat.
yPlace the Router in a location where it can be connected to the various devices as well as to a power source.
yMake sure the cables and power cord are safely placed out of the way so they do not create a tripping hazard.
yThe Router can be placed on a shelf or desktop.
yKeep away from the strong electromagnetic radiation and the device of electromagnetic sensitive.

8
Manual
www.kraun.it
2.4 Connecting the Router
Before installing the device, please make sure your broadband service provided by your ISP is available. If there
is any problem, please contact your ISP. Before cable connection, cut o the power supply and keep your hands
dry. You can follow the steps below to install it.
Step 1: Connect the ADSL Line.
Method one: Plug one end of the twisted-pair ADSL cable into the ADSL LINE port on the rear panel
of Kraun-300N, and insert the other end into the wall socket.
Method two: You can use a separate splitter. External splitter can divide the data and voice, and then
you can access the Internet and make calls at the same time. The external splitter has three ports:
• LINE: Connect to the wall jack
• PHONE: Connect to the phone sets
• MODEM: Connect to the ADSL LINE port of Kraun-300N
Plug one end of the twisted-pair ADSL cable into the ADSL LINE port on the rear panel of Kraun-300N.
Connect the other end to the MODEM port of the external splitter.
Step 2: Connect the Ethernet cable. Attach one end of a network cable to your computer’s Ethernet port or a
regular hub/switch port, and the other end to the LAN port on the Kraun-300N.
Step 3: Power on the computers and LAN devices.
Step 4: Attach the power adapter. Connect the power adapter to the power connector on the rear of the
device and plug in the adapter to a wall outlet or power extension.
Figure 2-3

9
Manual
www.kraun.it
Chapter 3. Quick Installation Guide
3.1 Congure PC
After you directly connect your PC to the Kraun-300N or connect your adapter to a Hub/Switch which has con-
nected to the Router, you need to congure your PC’s IP address. Follow the steps below to congure it.
Step 1: Click the Start menu on your desktop, right click My Network Places, and then select Properties
(shown in Figure 3-1).
Figure 3-1
Step 2: Right click Local Area Connection (LAN), and then select Properties.
Figure 3-2

10
Manual
www.kraun.it
Step 3: Select General tab, highlight Internet Protocol (TCP/IP), and then click the Properties button.
Figure 3-3
Step 4: Congure the IP address as Figure 3-4 shows. After that, click OK.
Figure 3-4

11
Manual
www.kraun.it
NOTE: You can congure the PC to get an IP address automatically, select “Obtain an IP address automatically”
and “Obtain DNS server address automatically” in the screen above.
Now, you can run the Ping command in the command prompt to verify the network connection. Please click
the Start menu on your desktop, select run tab, type cmd or command in the eld and press Enter. Type ping
192.168.1.1 on the next screen, and then press Enter.
If the result displayed is similar to the screen below, the connection between your PC and the Router has been
established.
Figure 3-5
If the result displayed is similar to the screen shown below, it means that your PC has not connected to the
Router.
Figure 3-6
You can check it follow the steps below:
1) Is the connection between your PC and the Router correct?
The LEDs of LAN port which you link to the device and the LEDs on your PC’s adapter should be lit.
2) Is the TCP/IP conguration for your PC correct?
If the Router’s IP address is 192.168.1.1, your PC’s IP address must be within the range of 192.168.1.2 ~
192.168.1.254.

12
Manual
www.kraun.it
3.2 Login
Once your host PC is properly congured, please proceed as follows to use the Web-based Utility: Start your web
browser and type the private IP address of the Router in the URL eld: 192.168.1.1.
After that, you will see the screen shown below, enter the default User Name admin and the default Password
admin, and then click OK to access to the Quick Setup screen. You can follow the steps below to complete the
Quick Setup.
Figure 3-7
Step 1: Select the Quick Start tab, then click RUN WIZARD, and you will see the next screen. Click the NEXT
button.
Figure 3-8

13
Manual
www.kraun.it
Step 2: Congure the time for the Router, and then click the NEXT button.
Figure 3-9
Step 3: Select the connection type to connect to the ISP (We select PPPoE/PPPoA mode for example here),
and then click the NEXT button.
Figure 3-10
Step 4: Congure the following options provided by your ISP: Username, Password, VPI, VCI and Connection
Type. Then click Next.
Figure 3-11

14
Manual
www.kraun.it
Step 5: Congure the rules for the WLAN, and click NEXT.
Figure 3-12
NOTE: If the Access Point is activated, the wireless function will be available even without the external antenna
because of an additional printed antenna. To adopt the wireless security protection measures, please
refer to section 4.3.3.
Step 6: Click NEXT to nish the Quick Start.
Figure 3-13

15
Manual
www.kraun.it
Chapter 4. Software Conguration
This User Guide recommends using the “Quick Installation Guide” for rst-time installation. For advanced users,
if you want to know more about this device and make use of its functions adequately, maybe you will get help
from this chapter to congure the advanced settings through the Web-based Utility.
After your successful login, you can congure and manage the device. There are main menus on the top of the
Web-based Utility; submenus will be available after you click one of the main menus. On the center of the Web-
based Utility, there are the detailed congurations or status information. To apply any settings you have altered
on the page, please click the SAVE button.
4.1 Status
Choose “Status”, you can see the next submenus: Device Info, System Log and Statistics. Click any of them,
and you will be able to congure the corresponding function.
Figure 4-1
Click any of them, and you will be able to view the corresponding information.
4.1.1 Device Info
Choose “StatusDevice Info” menu, and you will be able to view the device information, including LAN, WAN
and ADSL. The information will vary depending on the settings of the Router congured on the Interface Setup
screen.
Figure 4-2

16
Manual
www.kraun.it
NOTE: Click the other submenus System Log or Statistics in Figure 4-2, and you will be able to view the system
log and trac statistics about the Router.
4.1.2 System Log
Choose “StatusSystem Log” menu, and you will be able to query the logs of the Router.
Figure 4-3
The Router can keep logs of all trac. You can query the logs to nd what happened to the Router.
Click the CLEAR LOG button to clear the logs.
Click the SAVE LOG button to save the logs.
4.1.3 Statistics
Choose “StatusStatistics” menu, and you will be able to view the network trac over Ethernet, ADSL and
WLAN.
Figure 4-4

17
Manual
www.kraun.it
yInterface: You can select Ethernet, ADSL and WLAN to view the corresponding network trac over dierent
ports.
ySelect Ethernet, and you will see the statistics table as below.
Statistics Table:
Transmit
Statistics
Transmit Frames The frames transmitted over the Ethernet port.
Transmit Multicast Frames The multicast frames transmitted over the Ethernet port.
Transmit total Bytes The total bytes transmitted over the Ethernet port.
Transmit Collision The collision occurred over the Ethernet port when data is being transmit-
ted.
Transmit Error Frames The error frames over the Ethernet port when data is being transmitted.
Receive
Statistics
Receive Frames The frames received over the Ethernet port.
Receive Multicast Frames The multicast frames received over the Ethernet port.
Receive total Bytes The total bytes received over the Ethernet port.
Receive CRC Errors The CRC errors occurred over the Ethernet port when data is being received.
Receive Under-size Frames The Under-size frames received over the Ethernet port.
ySelect ADSL, and you will see the statistics table as below.

18
Manual
www.kraun.it
Statistics Table:
Transmit
Statistics
Transmit total PDUs The total PDUs transmitted over the ADSL port.
Transmit total Error Counts The total errors occurred over the ADSL port when data is being transmitted.
Receive
Statistics
Receive total PDUs The total PDUs transmitted over the ADSL port.
Receive total Error Counts The total errors occurred over the ADSL port when data is being received.
ySelect WLAN, and you will see the statistics table as below.
Statistics Table:
Transmit
Statistics
Tx Frames Count The frames transmitted over the WLAN when wireless data is being trans-
mitted.
Tx Errors Count The errors occurred over the WLAN when wireless data is being transmitted.
Tx Drops Count The drops occurred over the WLAN when wireless data is being transmitted.
Receive
Statistics
Rx Frames Count The frames received over the WLAN when wireless data is being transmit-
ted.
Rx Errors Count The errors occurred over the WLAN when wireless data is being received.
Rx Drops Count The drops occurred over the WLAN when wireless data is being received.
Click the Refresh button to refresh immediately.
4.2 Quick Start
Please refer to “3.2 Login”.
4.3 Interface Setup
Choose “Interface Setup”, you can see the next submenus: Internet and LAN.
Figure 4-5
Click any of them, and you will be able to congure the corresponding function.

19
Manual
www.kraun.it
4.3.1 Internet
Choose “Interface SetupInternet” menu, you can congure the parameters for WAN ports in the next screen
(shown in Figure 4-6).
Figure 4-6
yATM VC: ATM settings are used to connect to your ISP. Your ISP provides VPI (Virtual Path Identier), VCI (Virtual
Channel Identier) settings to you. In this Device, you can totally setup 8 VCs on dierent encapsulations,
if you apply 8 dierent virtual circuits from your ISP. You need to activate the VC to take eect. For PVCs
management, you can use ATM QoS to setup each PVC trac line’s priority.
• Virtual Circuit: Select the VC number you want to setup, PVC0~PVC7.
• Status: If you want to use a designed VC, you should activate it.
• VPI: Identies the virtual path between endpoints in an ATM network. The valid range is from 0 to 255.
Please input the value provided by your ISP.
• VCI: Identies the virtual channel endpoints in an ATM network. The valid range is from 32 to 65535 (1 to
31 is reserved for well-known protocols). Please input the value provided by your ISP.
• PVCs Summary: Click the button, and you can view the summary information about the PVCs.
• QoS: Select the Quality of Service types for this Virtual Circuit, including CBR (Constant Bit Rate), UBR
(Unspecied Bit Rate) and VBR (Variable Bit Rate). These QoS types are all controlled by the parameters
specied below, including PCR (Peak Cell Rate), SCR (Sustained Cell Rate) and MBS (Maximum Burst Size),
please congure them according to your needs.
yEncapsulation: There are four connection types: Dynamic IP Address, Static IP Address, PPPoA/PPPoE and
Bridge Mode. Please choose the designed type that you want to use. After that, you should follow the
conguration below to proceed.

20
Manual
www.kraun.it
1) Dynamic IP Address
Select this option if your ISP provides you an IP address automatically. This option is typically used for Cable
services. Please enter the Dynamic IP information accordingly.
Figure 4-7
yEncapsulation: Select the encapsulation mode for the Dynamic IP Address, you can leave it default.
yNAT: Select this option to Enable/Disable the NAT (Network Address Translation) function for this VC. The NAT
function can be activated or deactivated per PVC basis.
yDefault Route: If enable this function, the current PVC will be considered as the default gateway to internet
from this device.
yTCP MTU Option: Enter the TCP MTU as your desire.
yDynamic Route: Select this option to specify the RIP (Routing Information protocol) version for WAN interface,
including RIP1, RIP2-B and RIP2-M. RIP2-B and RIP2-M are both sent in RIP2 format, the dierence is that
RIP2-M using Multicast, while RIP2-B using Broadcast format.
yDirection: Select this option to specify the RIP direction. None is for disabling the RIP function. Both
means the ADSL Router will periodically send routing information and accept routing information, and
then incorporate them into routing table. IN only means the ADLS router will only accept but will not send
RIP packet. OUT only means the ADLS router will only send but will not accept RIP packet.
yMulticast: Select IGMP version, or disable the function. IGMP (Internet Group Multicast Protocol) is a session-
layer protocol used to establish membership in a multicast group. The ADSL ATU-R supports both IGMP
version 1 (IGMP v1) and IGMP v2. Select “Disabled” to disable it.
yMAC Spoong: Enable the MAC Spoong, and enter a MAC address to congure the WAN port. It makes your
inside network appear as a device with this MAC address to the outside world.
