KT kpc-e650nu User manual

M167-E650U-001
HIGH PERFORMANCE
CCTV CAMERA
OPERATION MANUAL
Thank you for choosing our high quality camera.
Before attempting to connect or operate, please read and
follow these instructions.
NAME AND FUNCTION
• LENS CONNECTION
Lenses are sold separatele. Lenses such as an auto iris lens,
CS-Mount lens and C-Mount lens can be used.
NOTE
• Please keep the lens clean.
• Any foreign objects and fingermarks on the lens can cause
inferior image quality in low light level conditions.
When using an auto iris lens
1.Please peel off about 8mm of the
outer skin of the auto iris lens cable.
2. Please peel off about 2mm of the
outer skin of the insulated conductor
inside the lens cable.
3. Please remove the cover of the auto iris lens connection plug and solder
the lens cable ti the connector pin in the plug.
*PIN ASSIGNMENT OF THE LENS CONNECTOR
Signal for DC + iris lens
Pin 1: DAMP-
Pin 2: DAMP+
Pin 3: DRV+
Pin 4: DRV-(GND)
Signal for Video + iris lens
Pin 1: Power source: +9 DC,50mA MAX
Pin 2: N.C(Not used)
Pin 3: Video Signal:0.7Vp-p/10K ohms.
Pin 4: Shield, ground
4. Please replace the auto iris lens connection plug cover and take off the
CCD protection cap and than attach the auto iris lens to the camera by
screwing it in clockwise.
Back Focus Procedure
Step 1 - Remove Lens Cover.
Step 2 - If using a C-Mount lenses it can be applied
to the camera at this time.
Step 3 - Most current lenses are CS-Mount and
require removal of the C/CS ring.
Step 4 - To remove the C/CS ring loosen but do not
remove completely the two set screws and
than remove the C/CS ring.
Step 5 - Screw on the CS-Mount lens until a good
picture is obtained and tighten the set screws.
Step 6 - Use the focus ring on the lens to obtain
a finer focusing
NOTE
- if a C-Mount lens was applied and focus could not be obtained, please try the following :
• Ensure that the lens is in face a C-Mount and not a CS-Mount.
•Check the focus adjust on the lens.
• if need be loosen the set screws and adjust the position of the lens
and C/CS ring as one unit until a good focus is obtained.
5. Please insert the connection plug that is connected to the auto iris lens cable into the
auto lens connector, which is located on the back of the camera
* As the connecting method varies with instruments, refer to the
manual supplied with the instrument.
* Only connect the cable when the power is turned off.
* Set the 75Ω / Hi-Z selection switch as shown below if you have an intermediate device.
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions;
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
Any changes or modications in construction of this devies which are not
expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
Caution -
CAUTION
1. A regulated DC12V 300mA power supply is recommended for use with
this camera for the best picture and the most stable operation.
An unregulated power supply can cause damage to the camera.
When unregulated power supply is applied, product warranty will be
out of subject.
2. It is recommended that the camera is used with a monitor that has a
CCTV quality 75 video impedance level. If your monitor is switched to
high impedance then please adjust accordingly.
3. Do not attempt to disassemble the camera to gain access to the
internal componets. Refer servicing to your dealer.
4. Never face the camera towards the sun or any bright or reective light,
which may cause smear on the picture and possible damage to the CCD.
5. Do not remove the serial sticker for the warranty service.
This equipment has been tested and found to comply with the limits for a
Class Adigital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.”
Note -
This is a class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
WARNING -
CAUTIONS CAUTIONS
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European
countries with separate collection systems)
This marking shown on the product or its literature, indicate that
it should not be disposed with other household wastes at the end
of its working life. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, please separate
this from other types of wastes and recycle it responsibly to
promote the sustainable reuse of material resources.
This product should not be mixed with other commercial wastes
purchased this product, or their local government ofce, for details
of where and how they can take item for environmentally safe
recycling.
Business users should contact their supplier and check the terms
and conditions of the purchase contract.
Household users should contact either the retailer where they for
disposal.
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER(OR BACK). NO USER. SERVICING TO
QUALIFED SERVICE PERSONNEL.
This symbol is intended to alert the user to the presence
of uninsulated "dangerous voltage" within the product's
enclosure that may be of sufcient mangnitude to constitute
a risk of electric shock to persons.
This symbol is intended to alert the user to the presence of
important operating and maintenance(servicing) instruction in
the literature accompanying the appliance.
COMPONENTS
FRONT
BACK
CS-Mount
C-Mount
High Performance
DSP Color Camera
Auto Iris Lens
Connection Plug
C-mount Adaptor Ring
Spare Screw (Machine 2x2) - 2ea
Operation Manual
Lens Cover
Lens Cover
C/CS RING
AUTO
IRIS
OSD
CONTROL
INSTALLATION
• MONITOR CONNECTION
BNC FEMALE
VIDEO
DC12V REGULATED
POWER SUPPLY
VIDEO IN
①. ■ MENU BUTTON
▲ UP BUTTON
▼ DOWON BUTTON
◀ LEFT BUTTON
▶ RIGHT BUTTON
②. Auto IRIS Jack
CS-MOUNT ADAPTOR RING
Set Screw(Left Side)
①
②

OSD MANUAL
SPECIFICATION
DIMENSIONSUnit(mm)
MAIN MENU 1st Sub MENU 2nd Sub MENU 3rd Sub MENU 4th Sub MENU
LENS
MANUAL
AUTO
TYPE DC / VIDED
MODE AUTO,OPEN,CLOSE
SPEED 000 ~ 255
RETURN
SHUTTER
/ AGC
AUTO
HIGH LUMINANCE MODE SHUT,AUTO IRIS, SHUT+AUTO IRIS
BRIGHTNESS 000 ~ 255
LOW LUMINANCE MODE AGC,OFF
BRIGHTNESS x0.25,x0.50,x0.75,x1.00
RETURN
MANUAL
MODE SHUT+AGC
SHUTTER
1/50(PAL),1/100(NTSC)
1/60(NTSC),1/120(PAL)
1/250,1/500,1/1000
1/2000,1/4000,1/10000
AGC 6,12,18,24,30,36,42,44.8
RETURN
WHITE
BAL
ATW
SPEED 000 ~ 255
DELAY CNT 000 ~ 255
ATW FRAME x0.50,x1.00,x1.50,x2.00
ENVIRONMENT INDOOR,OUTDOOR
RETURN
PUSH
USER1
B-GAIN 000 ~ 255
R-GAIN 000 ~ 255
RETURN
USER2
B-GAIN 000 ~ 255
R-GAIN 000 ~ 255
RETURN
ANTI CR
MANUAL LEVEL NTSC: 30 ~ 115
PAL: 28 ~ 134
RETURN
PUSH LOCK
BACK LIGHT OFF,BLC,HLC
PIC
ADJUST
MIRROR OFF,ON
BRIGHTNESS 000 ~ 255
CONTRAST 000 ~ 255
SHARPNESS 000 ~ 255
HUE 000 ~ 255
GAIN 000 ~ 255
RETURN
ATR ON
LUMINANCE LOW,MID,HIGH
CONTRAST LOW,MIDLOW,MID,MIDHIGH,HIGH
RETURN
OFF
MOTION
DET
ON
DETECT SENSE 000 ~ 255
BLOCK DISP OFF,ON,ENABLE (CONTROLER)
MONITOR AREA ON,OFF
AREA SEL
1/4, 2/4, 3/4, 4/4
TOP NTSC:000 ~ 244 / PAL: 000 ~ 288
BOTTOM NTSC:000 ~ 244 / PAL: 000 ~ 288
LEFT NTSC:000 ~ 474 / PAL: 000 ~ 468
RIGHT NTSC:000 ~ 474 / PAL: 000 ~ 468
RETURN
OFF
NEXT
EXIT
SAVE ALL
*SHUT+IRIS:Both the Shutter and the Mechanical Iris are automatically adjusted according to brightness.
*Auto Iris(Default): The Shutter stays at the manually selected value and only the Mechanical Iris adjusts to brightness.
MAIN MENU 1st Sub MENU 2nd Sub MENU 3rd Sub MENU 4th Sub MENU
PRIVACY ON
AREA SEL
1/4, 2/4, 3/4, 4/4
TOP NTSC:000 ~ 244 / PAL: 000 ~ 288
BOTTOM NTSC:000 ~ 244 / PAL: 000 ~ 288
LEFT NTSC:000 ~ 474 / PAL: 000 ~ 468
RIGHT NTSC:000 ~ 474 / PAL: 000 ~ 468
COLOR 1 ~ 8
TRANSP 0.00, 0.50, 0.75, 1.00
MOSAIC OFF,ON
RETURN
OFF
DAY/NIGHT
AUTO
BURST OFF,ON
DELAY CNT 0 ~ 255
DAY > NIGHT 0 ~ 255
NIGHT > DAY 0 ~ 255
RETURN
COLOR
BW
NR
NR MODE OFF,Y,C,Y/C
C LEVEL 000 ~ 015
Y LEVEL 000 ~ 015
RETURN
CAMERA ID
ON EDIT MODE
RETURN
OFF
LANGUAGE ENGLISH, 日本語, DEUTSCH, FRANCAIS, Русский, PORTUGUÊS, ESPAÑOL, 中文
CAMERA RESET
BACK
EXIT
SAVE ALL
*Important Note : - Any changes made to the camera settings must be saved prior to exiting the OSD menu. Else all changes will be discarded.
- By changing the lens option in the OSD from MANUAL to AUTO will automatically change the
SHUTTER/AGC setting from AUTO IRIS to SHUT+AUTO IRIS.(Default:AUTO IRIS)
Signal Format NTSC PAL
Image Device 1/3˝ SONY Super HAD CCD II
Scanning System 2 : 1 Interlace
Scanning Frequency 15.734KHz(H),
59.94Hz(V)
15.625KHz(H),
50Hz(V)
Total Pixels 1020(H) X 508(V) 1020(H) X 596(V)
Effective Pixels 976(H) X 494(V) 976(H) X 582(V)
Electronic Shutter 1/60 ~1/100,000sec 1/50 ~1/100,000sec
H.Resolution 700TV Lines
S/N Ratio More than 50dB(AGC OFF)
Min.Illumination 0.08Lux ([email protected])
Sync System Internal
Gamma r= 0.45
Video Output Level 1.0 Vp-p Composite(75Ω)
OSD Built in
BLC OFF / BLC / HLC
2DNR OFF / ON (Level adjustable)
ATR OFF / ON (Level adjustable)
Function MIRROR / BRIGHTNESS / CONTRAST /
SHARPNESS / HUE / GAIN
White Balance ATW / PUSH / USER1 / USER2 /
ANTI CR / MANUAL / PUSH-LOCK
Privacy Masking 4 Zones
Motion Detection 4 Zones
Day & Night AUTO / COLOR / BW
Language ENGLISH / JAPANESE / GERMAN / FRENCH / RUSSIAN / PORTUGUESE /
SPANISH / CHINESE
Operating
Temperature 14°F~122°F(-10°C~+50°C)
Weight 113g
Storage Temperature -4°F~140°F(-20°C~+60°C)
Humidity Less than 80%
Dimension 30.5(W) x 30.5(H) x 55(D)
Power
Consumption DC12V DC12V(±10%), Max. 110mA
Lens MANUAL / DC / VIDEO
Specications and designs are subject to change for
improving the functionality of this product without notice.
CS-Mount
C-Mount
