KTI Networks KPW-300T User manual

KPW-300T, KPW-1000T
1U Rack Mountable Switching
Power Supply for PoE/PoE+ applications
User’s Guide
DOC.140509
-1-

(C) 2013 KTI Networks Inc. All rights reserved. No part of this documentation may be reproduced in any form
or by any means or used to make any directive work (such as translation or transformation) without permission
from KTI Networks Inc.
KTI Networks Inc. reserves the right to revise this documentation and to make changes in content from time to
time without obligation on the part of KTI Networks Inc. to provide notification of such revision or change.
For more information, contact:
United States KTI Networks Inc.
P.O. BOX 631008
Houston, Texas 77263-1008
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
URL: http://www.ktinet.com/
International Fax: [phone]
E-mail: [email protected]
URL: http://www.ktinet.com.tw/
-2-

The information contained in this document is subject to change without prior notice.Copyright (C) All Rights
Reserved.
TRADEMARKS
Ethernet is a registered trademark of Xerox Corp.
FCC NOTICE
This device complies with Class A Part 15 the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received
including the interference that may cause.
CE NOTICE
Marking by the symbol indicates compliance of this equipment to the EMC directive of the European
Community. Such marking is indicative that this equipment meets or exceeds the following technical
standards:
EMC Class A
EN55022: CISPR22 Class A
EN61000-3-2
EN61000-3-3
EN 55024:
IEC 61000-4-2
IEC 61000-4-3
IEC 61000-4-4
IEC 61000-4-5
IEC 61000-4-6
IEC 61000-4-8
IEC 61000-4-11
-3-

-4-
Table of Contents
Model Definition................................................................................................................................................. 5
Specifications.................................................................................................................................................... 7
Safety Cautions ................................................................................................................................................. 9
Mounting the Power........................................................................................................................................ 10
Applying Power ............................................................................................................................................... 12
Application Example....................................................................................................................................... 14

Model Definition
KPW-300T-xx Front Panel
KPW-1000T-xx Front Panel
KPW-300T-xx KPW-1000T-xx Rear Panel
Model Options Input Output
KPW-300T-48 AC 100~240V +48VDC / 6.25A, 300W
KPW-300T-52 AC 100~240V +52VDC / 5.77A, 300W
KPW-300T-54 AC 100~240V +54VDC / 5.56A, 300W
KPW-1000T-48 AC 100~240V +48VDC / 20.8A, 1000W
KPW-1000T-52 AC 100~240V +52VDC / 19.2A, 1000W
KPW-1000T-54 AC 100~240V +54VDC / 18.5A, 1000W
-5-

-6-
Features:
Full range of AC input with IEC320 AC socket for universal installation
Built-in active PFC function, PF>0.95
High efficiency up to 89%
Protections: Short circuit / Overload / Over voltage / Over temperature
Built-in constant current limiting circuit
Industrial terminal block connector for DC output
Wide range of operating temperature
Support 19” rack mounting
Applications:
External power supply for typical PoE & high power PoE+ switches or systems
General power supply for critical temperature environments
General power supply for 19” rack-mount systems

Specifications
AC Input
Models KPW-300T-xx KPW-1000T-xx
AC voltage rating 100 ~ 240VAC 100 ~ 240VAC
Frequency range 47 ~ 63Hz 47 ~ 63Hz
AC current (Typ.) 5A/115VAC
2.5A/230VAC
12A/115VAC
6A/230VAC
Inrush current (Typ.) 35A/115VAC
70A/230VAC
25A/115VAC
40A/230VAC
Efficiency (Typ.) 89% 90%
AC IN Connector IEC320 C14 socket
DC Voltage Options +48VDC, +52VDC, +54VDC (＋/－1%)
DC OUT Connector Terminal block 3P: Vout+ / Vout- / FG
LED Indicator DC out OK
Protection
Models Short circuit Over load Over voltage Over temperature
KPW-300T-xx 105~135% 58 ~ 67VDC 95C ( +/-5C)
KPW-1000T-xx 105~125% 57 ~ 66VDC 75C ( +/-5C)
-7-

-8-
Environment
Models Operating
Temperature
Storage
Temperature
Relative
Humidity
KPW-300T-xx -40C ~ +64C -40C ~ +85C 10% ~ 95%
KPW-1000T-xx -20C ~ +60C -40C ~ +85C 10% ~ 95%
Power Rating Suggested maximal consumed power at different working temperatures
Models +50C +60C+70C
KPW-300T-xx 300Watts 225Watts 150Watts
KPW-1000T-xx 1000Watts 600Watts -
Air Flow
Models Air Flow
KPW-300T-xx Still air @ -40C ~ 64C
KPW-1000T-xx For US: Still air @ -20C ~ 30C
Forced air 10CMM @ 30C ~ 60C
For EU: Still air @ -20C ~ 60C
Fan Cooling Yes
Mounting Support Desktop, 19” Rack, Enclosure
Dimensions 325 x 210 x 43 mm (WxDxH )
MTBF >176K Hours for KPW-300T-xx, >117K Hours for KPW-1000T-xx
Power Module UL60950-1, TUV EN60950-1 Certified
Approval FCC Part 15, CE Mark, LVD
IEC60950-1 safety
EN 55022 emission
EN 61000-3-3
EN 61000-6-2 immunity for industrial environment

-9-

-10-
Safety Cautions
To reduce the risk of bodily injury, electrical shock, fire and damage to the product, observe the following
precautions.
Do not service any product except as explained in your system documentation.
Opening or removing covers may expose you to electrical shock.
Only a trained service technician should service components inside these compartments.
If any of the following conditions occur, unplug the product from the electrical outlet and replace the part
or contact your trained service provider:
The power cable, extension cable, or plug is damaged.
An object has fallen into the product.
The product has been exposed to water.
The product has been dropped or damaged.
The product does not operate correctly when you follow the operating instructions.
Do not push any objects into the openings of your system. Doing so can cause fire or electric shock by
shorting out interior components.
Make sure that there is proper heat dissipation from and adequate ventilation around the power supply.

Mounting the Power
Desktop Mounting
The power supply can be mounted on a desktop or shelf. Make sure that there is proper heat dissipation from
and adequate ventilation around the power. Do not place heavy objects on the power.
19” Rack Mounting
Two 19-inch rack mounting brackets are supplied in the power package for 19-inch rack mounting.
The steps to mount the power onto a 19-inch rack are:
1. Turn the AC power off.
2. Install left and right brackets with supplied screws onto the power as shown in figure below.
3. Mount the power onto 19-inch rack with rack screws securely.
4. Turn the power to the switch on.
-11-

Wall Mounting
The product also supports wall mounting by installing optional wall-mount brackets as shown below:
Consult the agent where the product was purchased for the wall-mount brackets.
-12-

Applying Power
Applying AC Power Input
If the purchased product is with AC power input, one AC power cord which meets the specification of your
country of origin was supplied in package. Before installing AC power cord to the product, make sure the AC
power is OFF and the AC power to the power cord is turned off.
AC power input specifications
Connector: IEC320 type
Power Rating: 100 ~ 240VAC, 50/60Hz
Notice
An approved AC power supply cord should be used and not lighter than IEC 60227, H03VV-F, 3G, 0.75mm2 or
alternatively IEC 60245, H05RR-F, 3G, 0.75mm2.
-13-

Applying DC Power Output
Receptacle: Screw-type terminal block
Operating Voltages: +48/+52/+54VDC (model dependent)
Power Wire gauge: 12AWG
Terminal Contacts
Vout+ (Isolated to FG)
Vout- (Isolated to FG)
FG (Frame ground, Protective Earth)
Note
1. Both Vout+ and Vout- contacts are isolated to FG contact and chassis.
2. The device to the system, the user should pay attention to not come into contact the hazardous energy.
-14-

Application Example
The power can be used as an external power supply for typical Power over Ethernet (PoE) PSE switches or
injectors as illustrated below:
Typical PoE Information
Technology PoE PoE+ (High Power)
Standard IEEE 802.3af IEEE 802.3at
Max. power delivered at PSE end 15.4W 34.2W
Voltage range at PSE 44 ~ 57VDC 50 ~ 57VDC
Max. current 350mA 600mA
Note: Above information are typical data by IEEE standard. The exact ratings and limits among different PoE
devices might differ according to the implementation of each device respectively. Consult the user’s guide of
the PoE device you are using.
By number of PoE PSE ports, the maximal PoE power required is calculated as follows:
Number of PSE Ports 1 8 16 24
PoE standard 15.4W 123W 247W 370W
PoE+ standard 34.2W 274W 548W 821W
