KTM 125 SX 2017 Manual

SETUP INSTRUCTIONS 2017
125 SX
150 SX
250 SX
250 XC
300 XC
Art. no. 3213573en

INTRODUCTION 1
*3213573en*
3213573en
08/2016
INTRODUCTION
Perform the work described in these setup instructions before the vehicle is delivered to the customer.
Read the setup instructions in their entirety before beginning work.
These setup instructions were written to correspond to the latest state of this series. We reserve the right to make changes in the interest
of technical advancement without at the same time updating this manual.
We shall not provide a description of general workshop methods. Likewise, safety rules that apply in a workshop are not specified here. It
is assumed that the work will be performed by a fully trained mechanic.
All specifications are non-binding. KTM Sportmotorcycle GmbH specifically reserves the right to modify or delete technical specifications,
prices, colors, forms, materials, services, designs, equipment, etc., without prior notice and without specifying reasons, to adapt these to
local conditions, as well as to stop production of a particular model without prior notice. KTM accepts no liability for delivery options, devi-
ations from illustrations and descriptions, misprints, and other errors. The models portrayed partly contain special equipment that does not
belong to the regular scope of supply.
© 2016 KTM Sportmotorcycle GmbH, Mattighofen Austria
All rights reserved
Reproduction, even in part, as well as copying of all kinds, is permitted only with the express written permission of the copyright owner.
ISO 9001(12 100 6061)
According to the international quality management standard ISO 9001, KTM uses quality assurance processes that lead to
the maximum possible quality of the products.
Issued by: TÜV Management Service
KTM Sportmotorcycle GmbH
5230 Mattighofen, Austria
This document is valid for the following models:
125 SX EU (F6101Q0)
125 SX US (F6175Q0)
150 SX EU (F6101Q1)
150 SX US (F6175Q1)
250 SX EU (F6301Q0)
250 SX US (F6375Q0)
250 XC US (F6375Q5)
300 XC US (F6475Q5)

1 MEANS OF REPRESENTATION 2
1.1 Symbols used
The meaning of specific symbols is described below.
Indicates an expected reaction (e.g. of a work step or a function).
Indicates an unexpected reaction (e.g. of a work step or a function).
Indicates a page reference (more information is provided on the specified page).
Indicates information with more details or tips.
Indicates the result of a testing step.
Denotes a voltage measurement.
Denotes a current measurement.
Denotes a resistance measurement.
1.2 Formats used
The typographical formats used in this document are explained below.
Proprietary name Identifies a proprietary name.
Name®Identifies a protected name.
Brand™ Identifies a trademark.
Underlined terms Refer to technical details of the vehicle or indicate technical terms, which are explained
in the glossary.

2 SETUP 3
2.1 Unpacking and setting up the vehicle
B02176-10
Package 2
–Remove the box and the plastic film.
Info
To avoid damaging the motorcycle during the setup, leave the protective
film on the vehicle until you have finished.
–Remove the separate enclosure and unpack it. Check that everything is
included and complete using the enclosed packing list.
–Have a lift stand available.
Lift stand (78129955100)
–Carefully loosen and remove the tension belt of the footrest mount.
Info
An assistant prevents the motorcycle from falling over.
402050-01
–Together with an assistant, take the vehicle off the pallet.
–Position the vehicle on a lift stand.
–Check the vehicle for transport damage.
B02008-10
Package 12
–Remove the box and the plastic film.
Info
An assistant prevents the motorcycle from falling over.
To avoid damaging the motorcycle during the setup, leave the protective
film on the vehicle until you have finished.
–Remove the separate enclosure and unpack it. Check that everything is
included and complete using the enclosed packing list.
–Have a lift stand available.
Lift stand (78129955100)
–Together with an assistant, take the vehicle off the pallet.
402051-01
–Position the vehicle on a lift stand.
–Check the vehicle for transport damage.
K00613-10
–Remove the cardboard from around the shock absorber.
–Position the angle lever and linkage lever.
–Mount and tighten fitting .
Guideline
Nut, linkage lever to angle lever M14x1.5 80 Nm (59 lbf ft)
–Mount and tighten screw .
Guideline
Screw, bottom shock
absorber
M10 60 Nm
(44.3 lbf ft)
Loctite®2701™

2 SETUP 4
Info
Raise the wheel slightly to be able to mount the screw more easily.
–Route the clutch line with the clutch master cylinder toward the front between
the upper and lower triple clamps.
–Install the fork legs. ( p. 10)
K00620-10
–Remove screws . Take off the handlebar clamp. Remove the handlebar and lay it
to one side.
Info
Cover the components to protect them against damage.
Do not kink the cables and lines.
–Remove screws . Take off handlebar supports .
–Position rubber bushings and push through nuts from below.
–Place the handlebar supports in the required position.
Info
The handlebar supports are longer and higher on one side.
Position the left and right handlebar supports evenly.
–Mount and tighten screws .
Guideline
Screw, handlebar support M10 40 Nm
(29.5 lbf ft)
Loctite®243™
–Position the handlebar.
Info
Make sure the cables and wiring are positioned correctly.
–Position the handlebar clamp.
–Mount screws but do not tighten yet.
–First bolt the handlebar clamp with screws onto the longer, higher side of the
handlebar supports so that both parts touch.
–Tighten screws evenly.
Guideline
Screw, handlebar clamp M8 20 Nm
(14.8 lbf ft)
K00615-10
–Position the controls on the right half of the handlebar.
K00616-10
–Position the controls on the left half of the handlebar.
–Mount the cable tie(s).
–Mount the fuel tank breather.
–Install the front wheel. ( p. 10)
–Install the front fender. ( p. 11)
–Install the start number plate. ( p. 13)

2 SETUP 5
K00617-10
–Mount the handlebar cushion.
D00674-10
Left and right footrest (All SX models)
–Position the new footrest and pin.
Info
Only insert the pin to the extent that the spring can still be mounted.
K00621-10
–Position spring as shown.
Spring engages in area .
K00622-10
–Press the spring with special tool .
Pliers for footrest spring (79029083000)
The special tool is applied to area on the footrest.
–Mount pin .
K00623-10
–Mount the washer and split pin .
–Repeat these steps on the opposite side.

2 SETUP 6
R00757-10
Left footrest (All XC models)
–Raise the motorcycle with a lift stand. ( p. 9)
–Position the new footrest and pin.
Info
Only insert the pin to the extent that the spring can still be mounted.
K00624-10
–Position spring as shown.
Spring engages in area .
K00625-10
–Press the spring with special tool .
Pliers for footrest spring (79029083000)
The special tool is applied to area on the footrest.
–Mount pin .
K00626-10
–Mount the washer and split pin .
–Remove the motorcycle from the lift stand. ( p. 9)
D00674-10
Right footrest (All XC models)
–Position the new footrest and pin.
Info
Only insert the pin to the extent that the spring can still be mounted.

2 SETUP 7
K00621-11
–Position spring as shown.
Spring engages in area .
K00622-11
–Press the spring with special tool .
Pliers for footrest spring (79029083000)
The special tool is applied to area on the footrest.
–Mount pin .
K00623-11
–Mount the washer and split pin .
K00618-10
(All XC models)
–Recharge the battery. ( p. 11)
–Install the battery. ( p. 12)
K00512-12
–Position the frame protector on the left and right.
–Mount and tighten screws  with the washers.
Guideline
Screw, frame protector M5 3 Nm (2.2 lbf ft)
–Mount and tighten screws .
Guideline
Screw, frame protector M5 3 Nm (2.2 lbf ft)
–Mount the cable tie(s).

2 SETUP 8
–Unpack and mount the KTM PowerParts included in the delivery (optional).
Info
Read the accompanying KTM PowerParts fitting instructions.
–Apply the sticker included in the delivery (optional).
–Refuel. ( p. 13)
–Position all controls in their exact positions on the handlebar. Tighten all screws.
–Prepare the vehicle according to the specifications in the KTM Dealer.net for han-
dover to the customer.

3 WORK 9
3.1 Raising the motorcycle with a lift stand
Note
Material damage The vehicle may be damaged by incorrect procedure when parking.
Significant damage may be caused if the vehicle rolls away or falls over.
The components for parking the vehicle are designed only for the weight of the vehicle.
–Park the vehicle on a firm and level surface.
–Ensure that nobody sits on the vehicle when the vehicle is parked on a stand.
401942-01
–Raise the motorcycle at the frame underneath the engine.
Lift stand (78129955100)
Neither wheel is in contact with the ground.
–Secure the motorcycle against falling over.
3.2 Removing the motorcycle from the lift stand
Note
Material damage The vehicle may be damaged by incorrect procedure when parking.
Significant damage may be caused if the vehicle rolls away or falls over.
The components for parking the vehicle are designed only for the weight of the vehicle.
–Park the vehicle on a firm and level surface.
–Ensure that nobody sits on the vehicle when the vehicle is parked on a stand.
0
0
11
402001-10
(All SX models)
–Remove the motorcycle from the lift stand.
–Remove the lift stand.
–To park the motorcycle, insert plug-in stand into the left side of the wheel
spindle.
Info
Remove the plug-in stand before riding.
401943-10
(All XC models)
–Remove the motorcycle from the lift stand.
–Remove the lift stand.
–To park the motorcycle, press side stand to the ground with your foot and
lean the motorcycle on it.
Info
While riding, the side stand must be folded up and secured with the
rubber band.

3 WORK 10
3.3 Installing the fork legs
H01182-10
Main work
–Position the fork legs.
Bleeder screw of the right fork leg is positioned to the front.
Valve of the left fork leg faces the front.
Info
Grooves are milled into the side of the upper end of the fork legs. The sec-
ond milled groove (from the top) must be flush with the top edge of the
upper triple clamp.
The air suspension is located in the left fork leg. The pressure and rebound
damping is located in the right fork leg.
F00011-11
–Tighten screws .
Guideline
Screw, top triple clamp M8 17 Nm
(12.5 lbf ft)
–Tighten screws .
Guideline
Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft)
K00462-11
–Position the brake caliper. Mount and tighten screws .
Guideline
Screw, front brake caliper M8 25 Nm
(18.4 lbf ft)
Loctite®243™
–Position the brake line and clamp. Mount and tighten screws .
Finishing work
–Install the front wheel. ( p. 10)
3.4 Installing the front wheel
Warning
Danger of accidents Oil or grease on the brake discs reduces the braking effect.
–Always keep the brake discs free of oil and grease.
–Clean the brake discs with brake cleaner when necessary.
H00935-10
–Check the wheel bearing for damage and wear.
» If the wheel bearing is damaged or worn:
–Change the front wheel bearing.
–Clean and grease shaft seal rings and contact surface of the spacers.
Long-life grease ( p. 18)
–Insert the spacers.

3 WORK 11
K00454-11
–Lift the front wheel into the fork, position it, and insert the wheel spindle.
The brake linings are correctly positioned.
–Mount and tighten screw .
Guideline
Screw, front wheel spindle M20x1.5 35 Nm
(25.8 lbf ft)
–Operate the hand brake lever several times until the brake linings are lying correctly
against the brake disc.
–Remove the motorcycle from the lift stand. ( p. 9)
–Operate the front brake and compress the fork a few times firmly.
The fork legs straighten.
–Tighten screws .
Guideline
Screw, fork stub M8 15 Nm
(11.1 lbf ft)
3.5 Installing the front fender
M01144-10
Main work
–Position the front fender. Mount and tighten screws and .
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Finishing work
–Install the start number plate. ( p. 13)
3.6 Recharging the battery (All XC models)
Warning
Risk of injury Batteries contain harmful substances.
–Keep batteries out of the reach of children.
–Keep sparks and open flames away from the batteries.
–Only charge batteries in well-ventilated rooms.
–Maintain a minimum clearance from inflammable materials when charging batteries.
Minimum clearance 1 m (3 ft)
–Do not charge deeply discharged batteries if charge is already below the minimum voltage.
Minimum voltage before the start of the charge 9 V
–Dispose of batteries with less than the minimum voltage correctly.
Warning
Environmental hazard Batteries contain environmentally-hazardous materials.
–Do not dispose of batteries as household waste.
–Dispose of batteries at a collection point for used batteries.
Warning
Environmental hazard Hazardous substances cause environmental damage.
–Dispose of oils, grease, filters, fuel, cleaning agents, brake fluid, etc., correctly and in compliance with the applicable regu-
lations.

3 WORK 12
Info
Even when there is no load on the battery, it discharges steadily.
The charging level and the method of charging are very important for the service life of the battery.
Rapid recharging with a high charging current shortens the service life of the battery.
If the charging current, charging voltage, or charging time are exceeded, the battery will be destroyed.
If the battery is depleted by repeated starting, the battery must be charged immediately.
If the battery is left in a discharged state for an extended period, it will become over-discharged and sulfated, destroying the
battery.
The battery is maintenance-free.
Preparatory work
–Remove the seat. ( p. 13)
311910-10
Main work
–Connect the battery charger to the battery. Set the battery charger.
Alternative 1
Battery charger XCharge-professional EU (00029095050)
Alternative 2
Battery charger XCharge-professional US (00029095051)
Alternative 3
Battery charger XCharge-professional GB (00029095052)
Alternative 4
Battery charger XCharge-professional CH (00029095053)
Info
Follow the instructions of the charger and the manual.
–Disconnect the battery charger after charging the battery.
Guideline
The charging current, charging voltage, and charging time must not be exceeded.
Charge the battery regularly when the
motorcycle is not in use
3 months
Finishing work
–Mount the seat. ( p. 13)
3.7 Installing the battery (All XC models)
H00386-10
Main work
–Position the battery in the battery compartment with the terminals facing forward,
and secure with holding bracket .
Battery (HJTZ5S-FP)
–Mount and tighten screw .
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
–Connect positive cable to the battery.
Guideline
Screw, battery terminal M5 2.5 Nm
(1.84 lbf ft)
Contact disks must be mounted under screws and cable sockets with
the claws toward the battery terminal.
–Slide positive terminal cover over the positive terminal.
–Connect negative cable to the battery.
Guideline
Screw, battery terminal M5 2.5 Nm
(1.84 lbf ft)
Finishing work
–Mount the seat. ( p. 13)

3 WORK 13
3.8 Installing the start number plate
F00013-10
–Connect the brake line at the start number plate.
–Position the start number plate.
The holding lugs engage in the fender.
–Mount and tighten screw .
3.9 Removing the seat
F00017-10
–Remove screws .
–Raise the rear of the seat, pull the seat back, and lift it off.
3.10 Mounting the seat
F00016-10
–Mount the front of the seat on the collar bushing of the fuel tank, lower the seat at
the rear, and push the seat forward.
–Make sure that the seat is correctly locked in.
F00017-10
–Mount and tighten screws .
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
3.11 Refueling
Danger
Fire hazard Fuel is highly flammable.
The fuel in the fuel tank expands when warm and can escape if overfilled.
–Do not refuel the vehicle in the vicinity of open flames or lit cigarettes.
–Switch off the engine for refueling.
–Make sure that no fuel is spilled; particularly not on hot parts of the vehicle.
–If any fuel is spilled, wipe it off immediately.
–Observe the specifications for refueling.

3 WORK 14
Warning
Danger of poisoning Fuel is poisonous and a health hazard.
–Avoid skin, eye and clothing contact with fuel.
–Immediately consult a doctor if you swallow fuel.
–Do not inhale fuel vapors.
–In case of skin contact, rinse the affected area with plenty of water.
–Rinse the eyes thoroughly with water, and consult a doctor in case of fuel contact with the eyes.
–Change your clothing in case of fuel spills on them.
Warning
Environmental hazard Improper handling of fuel is a danger to the environment.
–Do not allow fuel to enter the groundwater, the soil, or the sewage system.
–Switch off the engine.
–Open the filler cap. ( p. 14)
400382-10
–Fill the fuel tank with fuel up to measurement .
Guideline
Measurement of 35 mm (1.38 in)
Total fuel tank
capacity, approx.
(All SX models)
7 l (1.8 US gal) Super unleaded (98 octane) mixed
with 2-stroke engine oil (1:40)
( p. 17) (All 125/150 models)
Super unleaded (95 octane) mixed
with 2-stroke engine oil (1:60)
( p. 17) (All 250 SX models)
Total fuel tank
capacity, approx.
(All XC models)
10 l (2.6 US gal) Super unleaded (95 octane) mixed
with 2-stroke engine oil (1:60)
( p. 17)
Engine oil, 2-stroke ( p. 17)
–Close the filler cap. ( p. 15)
3.12 Opening the filler cap
Danger
Fire hazard Fuel is highly flammable.
The fuel in the fuel tank expands when warm and can escape if overfilled.
–Do not refuel the vehicle in the vicinity of open flames or lit cigarettes.
–Switch off the engine for refueling.
–Make sure that no fuel is spilled; particularly not on hot parts of the vehicle.
–If any fuel is spilled, wipe it off immediately.
–Observe the specifications for refueling.
Warning
Danger of poisoning Fuel is poisonous and a health hazard.
–Avoid skin, eye and clothing contact with fuel.
–Immediately consult a doctor if you swallow fuel.
–Do not inhale fuel vapors.
–In case of skin contact, rinse the affected area with plenty of water.
–Rinse the eyes thoroughly with water, and consult a doctor in case of fuel contact with the eyes.
–Change your clothing in case of fuel spills on them.
–Keep fuels correctly in a suitable canister, and out of the reach of children.
Warning
Environmental hazard Improper handling of fuel is a danger to the environment.
–Do not allow fuel to enter the groundwater, the soil, or the sewage system.

3 WORK 15
F00003-10
(All SX models)
–Turn filler cap counterclockwise and lift it off.
K00508-10
(All XC models)
–Press release button , turn the filler cap counterclockwise, and lift it off.
3.13 Closing the filler cap
F00003-11
(All SX models)
–Mount filler cap and turn it clockwise until the fuel tank is tightly closed.
Info
Run the fuel tank breather hose without kinks.
K00508-11
(All XC models)
–Mount filler cap and turn it clockwise until the release button engages.
Info
Run the fuel tank breather hose without kinks.

4 TECHNICAL DATA 16
4.1 chassis tightening torques
Screw, fixed grip M4 5 Nm (3.7 lbf ft) Loctite®243™
Screw, service hour counter M4 1 Nm (0.7 lbf ft) –
Spoke nipple, front wheel M4.5 6 Nm (4.4 lbf ft) –
Spoke nipple, rear wheel M4.5 6 Nm (4.4 lbf ft) –
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft) –
Remaining screws, chassis M5 5 Nm (3.7 lbf ft) –
Screw, battery terminal (All XC models) M5 2.5 Nm (1.84 lbf ft) –
Screw, shock absorber adjusting ring M5 5 Nm (3.7 lbf ft) –
Screws on the main silencer M5 7 Nm (5.2 lbf ft) –
Nut, cable on starter motor (All XC
models)
M6 4 Nm (3 lbf ft) –
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft) –
Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –
Screw, absorbing element on frame M6 6 Nm (4.4 lbf ft) –
Screw, absorbing element on manifold M6 6 Nm (4.4 lbf ft) –
Screw, ball joint of push rod on foot
brake cylinder
M6 10 Nm (7.4 lbf ft) Loctite®243™
Screw, chain sliding guard M6 6 Nm (4.4 lbf ft) Loctite®243™
Screw, front brake disc M6 14 Nm (10.3 lbf ft) Loctite®243™
Screw, rear brake disc M6 14 Nm (10.3 lbf ft) Loctite®243™
Screw, throttle grip M6 5 Nm (3.7 lbf ft) –
Nut, foot brake lever stop M8 20 Nm (14.8 lbf ft) –
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft) Loctite®2701™
Nut, rim lock M8 12 Nm (8.9 lbf ft) –
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –
Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –
Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft) –
Screw, chain sliding piece M8 15 Nm (11.1 lbf ft) –
Screw, engine brace M8 25 Nm (18.4 lbf ft) Loctite®2701™
Screw, fork stub M8 15 Nm (11.1 lbf ft) –
Screw, front brake caliper M8 25 Nm (18.4 lbf ft) Loctite®243™
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –
Screw, side stand attachment (All XC
models)
M8 35 Nm (25.8 lbf ft) Loctite®2701™
Screw, subframe M8 35 Nm (25.8 lbf ft) Loctite®2701™
Screw, top steering stem M8 20 Nm (14.8 lbf ft) Loctite®243™
Screw, top triple clamp M8 17 Nm (12.5 lbf ft) –
Engine bracket screw M10 60 Nm (44.3 lbf ft) –
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft) –
Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –
Screw, bottom shock absorber M10 60 Nm (44.3 lbf ft) Loctite®2701™
Screw, handlebar support M10 40 Nm (29.5 lbf ft) Loctite®243™
Screw, top shock absorber M10 60 Nm (44.3 lbf ft) Loctite®2701™
Nut, frame on linkage lever M14x1.5 80 Nm (59 lbf ft) –
Nut, linkage lever on swingarm M14x1.5 80 Nm (59 lbf ft) –
Nut, linkage lever to angle lever M14x1.5 80 Nm (59 lbf ft) –
Nut, swingarm pivot M16x1.5 100 Nm (73.8 lbf ft) –
Screw, front wheel spindle M20x1.5 35 Nm (25.8 lbf ft) –
Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft) –
Screw-in nozzles, cooling system M20x1.5 12 Nm (8.9 lbf ft) Loctite®243™
Nut, rear wheel spindle M25x1.5 80 Nm (59 lbf ft) –

5 SUBSTANCES 17
Engine oil, 2-stroke
Standard/classification
–JASO FD ( p. 19)
Guideline
–Only use high grade 2-stroke engine oil of a reputable brand.
Fully synthetic
Recommended supplier
Motorex®
–Cross Power 2T
Super unleaded (ROZ 98 / RON 98 / PON 94)
Standard/classification
–DIN EN 228 (ROZ 98 / RON 98 / PON 94)
Super unleaded (ROZ 95/RON 95/PON 91)
Standard/classification
–DIN EN 228 (ROZ 95/RON 95/PON 91)
Guideline
–Only use unleaded super fuel that matches or is equivalent to the specified fuel grade.
–Fuel with an ethanol content of up to 10 % (E10 fuel) is safe to use.
Info
Do not use fuel containing methanol (e. g. M15, M85, M100) or more than 10 % ethanol (e. g. E15, E25, E85, E100).
Super unleaded (95 octane) mixed with 2-stroke engine oil (1:60)
Standard/classification
–DIN EN 228
–JASO FD ( p. 19) (1:60)
Mixture ratio
1:60 Engine oil, 2-stroke ( p. 17)
Super unleaded (ROZ 95/RON 95/PON 91) ( p. 17)
Recommended supplier
Motorex®
–Cross Power 2T
Super unleaded (98 octane) mixed with 2-stroke engine oil (1:40)
Standard/classification
–DIN EN 228
–JASO FD ( p. 19) (1:40)
Mixture ratio
1:40 Engine oil, 2-stroke ( p. 17)
Super unleaded (ROZ 98 / RON 98 / PON 94) ( p. 17)
Recommended supplier
Motorex®
–Cross Power 2T

6 AUXILIARY SUBSTANCES 18
Long-life grease
Recommended supplier
Motorex®
–Bike Grease 2000
