SETUP INSTRUCTIONS 2017
1290 Super Duke GT
Art. no. 3213610en

INTRODUCTION 1
*3213610en*
3213610en
11/2016
INTRODUCTION
The work described in these setup instructions must be performed before the vehicle is delivered to the customer.
Read the setup instructions in their entirety before beginning work.
These setup instructions were written to correspond to the latest state of this series. We reserve the right to make changes in the interest
of technical advancement without at the same time updating this manual.
We shall not provide a description of general workshop methods. Likewise, safety rules that apply in a workshop are not specified here. It
is assumed that the work will be performed by a fully trained mechanic.
All specifications are non-binding. KTM Sportmotorcycle GmbH specifically reserves the right to modify or delete technical specifications,
prices, colors, forms, materials, services, designs, equipment, etc., without prior notice and without specifying reasons, to adapt these to
local conditions, as well as to stop production of a particular model without prior notice. KTM accepts no liability for delivery options, devi-
ations from illustrations and descriptions, misprints, and other errors. The models portrayed partly contain special equipment that does not
belong to the regular scope of supply.
© 2016 KTM Sportmotorcycle GmbH, Mattighofen Austria
All rights reserved
Reproduction, even in part, as well as copying of all kinds, is permitted only with the express written permission of the copyright owner.
ISO 9001(12 100 6061)
According to the international quality management standard ISO 9001, KTM uses quality assurance processes that lead to
the maximum possible quality of the products.
Issued by: TÜV Management Service
KTM Sportmotorcycle GmbH
5230 Mattighofen, Austria
This document is valid for the following models:
1290 Super Duke GT EU (F9903QF, F9903QE)
1290 Super Duke GT JP (F9986QE)
1290 Super Duke GT US (F9975QE, F9975QF)
1290 Super Duke GT CN (F9987QE)

1 MEANS OF REPRESENTATION 2
1.1 Symbols used
The meaning of specific symbols is described below.
Indicates an expected reaction (e.g. of a work step or a function).
Indicates an unexpected reaction (e.g. of a work step or a function).
Indicates a page reference (more information is provided on the specified page).
Indicates information with more details or tips.
Indicates the result of a testing step.
Denotes a voltage measurement.
Denotes a current measurement.
Denotes a resistance measurement.
1.2 Formats used
The typographical formats used in this document are explained below.
Proprietary name Identifies a proprietary name.
Name®Identifies a protected name.
Brand™ Identifies a trademark.
Underlined terms Refer to technical details of the vehicle or indicate technical terms, which are explained
in the glossary.

2 SETUP 3
2.1 Unpacking and setting up the vehicle
Preparatory work
–Remove the box.
S01182-01
Main work
–Remove the adhesive tape in the upper area of the motorcycle.
S01183-01
–Roll down the film at the sides.
Info
To avoid damaging the motorcycle during unpacking, leave the other films
on the vehicle until you have finished work on the vehicle.
–Remove the separate enclosure and unpack it. Check the separate enclosure for
completeness.
–Check the vehicle for transport damage.
S01184-01
–Remove the controls from the transport holder. Remove the screws of the handlebar
clamp. Take off the handlebar clamp and transport holder.
S01185-10
–Remove right-hand handlebar weight 1.
–Position the controls on the right half of the handlebar but do not tighten yet.
E00283-10
Warning
Danger of accidents A repaired handlebar poses a safety risk.
If the handlebar is bent or straightened, the material becomes fatigued.
The handlebar may break as a result.
–Change the handlebar if the handlebar is damaged or bent.
–Position the handlebar.
Info
Make sure the cables and wiring are positioned correctly.
–Position the handlebar clamp. Mount screws 2but do not tighten yet.
Marking Aon the handlebar scale is aligned with the top edge of the handle-
bar clamp.
Center line Bon the handlebar scale is aligned with the center of the handle-
bar clamp.

2 SETUP 4
–First bolt the handlebar support with screws 2onto the longer, higher side of the
handlebar supports so that both parts touch.
–Tighten screws 2evenly.
Guideline
Screw, handlebar clamp M8 20 Nm
(14.8 lbf ft)
S01186-10
–Tighten screws 3and 4of the controls.
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw, combination switch, right M5 3.5 Nm
(2.58 lbf ft)
–Mount right handlebar weight, tighten screw.
Guideline
Screw, handlebar weight M6 10 Nm (7.4 lbf ft)
–Check the throttle grip for smooth operation.
E00278-01
–Mount and tighten the rear mirror on both sides.
E00279-10
–Position windshield 5.
–Mount and tighten screws 6.
Guideline
Screw, windshield M5 3.5 Nm
(2.58 lbf ft)
E00277-01
–Tape on the protective plastic sheet for the swingarm.
–Remove the cable ties of the rider footrests.
E00281-10
–Mount splash protector 7with screws 8on license plate holder 9.
Guideline
Remaining screws, chassis EJOT PT®K50x12 1 Nm (0.7 lbf ft)

2 SETUP 5
E00282-10
(Super Duke GT US)
–Bond the reflectors on the right and left side of the reflector holder.
–Mount the reflector holder on license plate holder 9.
Guideline
Remaining screws, chassis M6 10 Nm
(7.4 lbf ft)
E00273-01
–Remove the passenger seat. ( p. 7)
–Remove spare key and KEYCODECARD and keep in a safe place for the handover.
–Secure the tool set with the rubber holder.
E00274-01
–Carefully loosen and remove the tension belt from the frame.
Info
An assistant prevents the motorcycle from falling over.
–Carefully loosen and remove the tension belts around the fork legs.
The vehicle is released at the front.
–Together with an assistant, take the vehicle off the palette.
–Remove the radiator shield.
S01188-10
–Position the front spoiler. Mount and tighten screws bk with the washers.
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
S01189-10
–Position metal sheets on the left and right. Mount and tighten screws bl.
Guideline
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
E00280-10
–Remove the front rider's seat. ( p. 7)
–Plug in the connector of starter relay bm.
(Super Duke GT US)
–Mount the side cases.
Info
Observe the accompanying fitting instructions.
–Recharge the battery. ( p. 8)
–Remove the protective plastic.
–Refuel. ( p. 10)

2 SETUP 6
–Prepare the vehicle according to the specifications in the KTM Dealer.net for han-
dover to the customer.

3 WORK 7
3.1 Removing the passenger seat
S01106-10
–Insert the ignition key in seat lock 1and turn it clockwise.
–Raise front of the passenger seat, pull toward the tank, and remove upward.
–Remove the ignition key.
3.2 Mounting the passenger seat
402652-10
–Attach the hooks on the passenger seat to seat mounts 1.
–Lower the passenger seat and push back.
–Position locking pin 2in the lock housing and push down the passenger seat at
the front.
The locking pin engages with an audible click.
–Check that the passenger seat is correctly mounted.
3.3 Removing the front rider's seat
Preparatory work
–Remove the passenger seat. ( p. 7)
S01104-10
Main work
–Press seat release 1in the direction of the arrow and lift the front rider's seat at
the rear at the same time.
–Detach the front of the front rider's seat and remove it.
3.4 Mounting the front rider's seat
401921-10
Main work
–Attach recesses 1on the front rider's seat to the fuel tank, push the front rider's
seat forward.
–Position locking pin 2in the lock housing and push down the front rider's seat at
the rear.
The locking pin engages with an audible click.
–Check that the front rider's seat is correctly mounted.
Finishing work
–Mount the passenger seat. ( p. 7)

3 WORK 8
3.5 Recharging the battery
Warning
Risk of injury Battery acid and battery gases cause serious chemical burns.
–Keep batteries out of the reach of children.
–Wear suitable protective clothing and safety glasses.
–Avoid contact with battery acid and battery gases.
–Keep sparks or open flames away from the battery.
–Only charge batteries in well-ventilated rooms.
–Rinse the affected area immediately with plenty of water in the event of contact with the skin.
–Rinse eyes with water for at least 15 minutes and consult a doctor immediately if battery acid and battery gases get into
the eyes.
Warning
Environmental hazard Batteries contain environmentally-hazardous materials.
–Do not dispose of batteries as household waste.
–Dispose of batteries at a collection point for used batteries.
Warning
Environmental hazard Hazardous substances cause environmental damage.
–Dispose of oils, grease, filters, fuel, cleaning agents, brake fluid, etc., correctly and in compliance with the applicable regu-
lations.
Info
Even when there is no load on the battery, it discharges steadily.
The charging level and the method of charging are very important for the service life of the battery.
Rapid recharging with a high charging current shortens the service life of the battery.
If the charging current, charging voltage, and charging time are exceeded, the battery will be destroyed.
If the battery is depleted from starting the vehicle repeatedly, the battery must be charged immediately.
If the battery is left in a discharged state for an extended period, it will become over-discharged and sulfated, destroying the
battery.
The battery is maintenance-free, i.e., the acid level does not have to be checked.
Preparatory work
–Switch off the ignition by turning the black ignition key to the position OFF .
–Remove the passenger seat. ( p. 7)
–Remove the front rider's seat. ( p. 7)
–Disconnect the negative cable of the battery. ( p. 9)
311910-10
Main work
–Connect the battery charger to the battery. Set the battery charger.
Alternative 1
Battery charger XCharge-professional EU (00029095050)
Alternative 2
Battery charger XCharge-professional US (00029095051)
Alternative 3
Battery charger XCharge-professional GB (00029095052)
Alternative 4
Battery charger XCharge-professional CH (00029095053)
Info
Follow the instructions of the charger and the manual.
–Disconnect the battery charger after charging the battery.
Guideline
The charging current, charging voltage, and charging time must not be exceeded.
Charge the battery regularly when the
motorcycle is not in use
3 months

3 WORK 9
Finishing work
–Connect the negative cable of the battery. ( p. 10)
–Mount the front rider's seat. ( p. 7)
–Mount the passenger seat. ( p. 7)
–Set the time and date.
3.6 Disconnecting the negative cable of the battery
Warning
Risk of injury Battery acid and battery gases cause serious chemical burns.
–Keep batteries out of the reach of children.
–Wear suitable protective clothing and safety glasses.
–Avoid contact with battery acid and battery gases.
–Keep sparks or open flames away from the battery.
–Only charge batteries in well-ventilated rooms.
–Rinse the affected area immediately with plenty of water in the event of contact with the skin.
–Rinse eyes with water for at least 15 minutes and consult a doctor immediately if battery acid and battery gases get into
the eyes.
Caution
Danger of accidents Electronic components and safety devices will be damaged if the battery is discharged or missing.
–Never operate the vehicle with a discharged battery or without a battery.
Preparatory work
–Switch off the ignition by turning the black ignition key to the position OFF .
–Remove the passenger seat. ( p. 7)
–Remove the front rider's seat. ( p. 7)
E00168-10
Main work
–Remove screw 1.
–Lift cover 2at the rear and pull toward the rear.
–Fold up the cover.
D01427-10
–Disconnect negative cable 3from the battery.

3 WORK 10
3.7 Connecting the negative cable of the battery
Warning
Risk of injury Battery acid and battery gases cause serious chemical burns.
–Keep batteries out of the reach of children.
–Wear suitable protective clothing and safety glasses.
–Avoid contact with battery acid and battery gases.
–Keep sparks or open flames away from the battery.
–Only charge batteries in well-ventilated rooms.
–Rinse the affected area immediately with plenty of water in the event of contact with the skin.
–Rinse eyes with water for at least 15 minutes and consult a doctor immediately if battery acid and battery gases get into
the eyes.
Caution
Danger of accidents Electronic components and safety devices will be damaged if the battery is discharged or missing.
–Never operate the vehicle with a discharged battery or without a battery.
D01427-11
Main work
–Position negative cable 1; mount and tighten the screw.
Guideline
Screw, battery terminal M6 4.5 Nm
(3.32 lbf ft)
D01428-10
–Fold down cover 2.
–Mount and tighten screw 3.
Guideline
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Finishing work
–Mount the front rider's seat. ( p. 7)
–Mount the passenger seat. ( p. 7)
–Set the time and date.
3.8 Refueling
Danger
Fire hazard Fuel is highly flammable.
The fuel in the fuel tank expands when warm and can escape if overfilled.
–Do not refuel the vehicle in the vicinity of open flames or lit cigarettes.
–Switch off the engine for refueling.
–Make sure that no fuel is spilled; particularly not on hot parts of the vehicle.
–If any fuel is spilled, wipe it off immediately.
–Observe the specifications for refueling.

3 WORK 11
Warning
Danger of poisoning Fuel is poisonous and a health hazard.
–Avoid skin, eye and clothing contact with fuel.
–Immediately consult a doctor if you swallow fuel.
–Do not inhale fuel vapors.
–In case of skin contact, rinse the affected area with plenty of water.
–Rinse the eyes thoroughly with water, and consult a doctor in case of fuel contact with the eyes.
–Change your clothing in case of fuel spills on them.
Note
Material damage Inadequate fuel quality causes the fuel filter to quickly become clogged.
In some countries and regions, the available fuel quality and cleanliness may not be sufficient. This will result in problems with the
fuel system.
–Refuel only with clean fuel that meets the specified standards.
Warning
Environmental hazard Improper handling of fuel is a danger to the environment.
–Do not allow fuel to enter the groundwater, the soil, or the sewage system.
H01291-10
–Switch off the engine.
–Open the filler cap. ( p. 11)
–Fill the fuel tank with fuel up to the lower edge Aof the filler neck.
Total fuel tank
capacity, approx.
23 l (6.1 US gal) Super unleaded (ROZ 95/RON 95/PON
91) ( p. 16)
–Close the filler cap. ( p. 12)
3.9 Opening the filler cap
Danger
Fire hazard Fuel is highly flammable.
The fuel in the fuel tank expands when warm and can escape if overfilled.
–Do not refuel the vehicle in the vicinity of open flames or lit cigarettes.
–Switch off the engine for refueling.
–Make sure that no fuel is spilled; particularly not on hot parts of the vehicle.
–If any fuel is spilled, wipe it off immediately.
–Observe the specifications for refueling.
Warning
Danger of poisoning Fuel is poisonous and a health hazard.
–Avoid skin, eye and clothing contact with fuel.
–Immediately consult a doctor if you swallow fuel.
–Do not inhale fuel vapors.
–In case of skin contact, rinse the affected area with plenty of water.
–Rinse the eyes thoroughly with water, and consult a doctor in case of fuel contact with the eyes.
–Change your clothing in case of fuel spills on them.
–Keep fuels correctly in a suitable canister, and out of the reach of children.
Warning
Environmental hazard Improper handling of fuel is a danger to the environment.
–Do not allow fuel to enter the groundwater, the soil, or the sewage system.

3 WORK 12
H01281-10
–Lift cover 1of the filler cap and insert ignition key 2in the fuel tank lock.
H01282-10
Note
Danger of damage The ignition key may break if overloaded.
Damaged ignition keys must be replaced.
–Push down on the filler cap to take pressure off the ignition key.
–Turn ignition key 2clockwise.
–Fold open filler cap 3.
3.10 Closing the filler cap
H01283-10
–Fold down filler cap 1.
–Turn ignition key 2clockwise.
H01284-10
–Press down the filler cap and turn back ignition key 2until the fuel tank lock
locks.
Warning
Fire hazard Fuel is highly flammable, toxic and a health hazard.
–Check the filler cap is locked correctly after closing.
–Change your clothing in case of fuel spills on them.
–Rinse the affected area immediately with plenty of water in the event of
contact with the skin.
–Remove ignition key 2and close cover 3.
3.11 "Clock/Date"
401990-02
Condition
• The vehicle is stationary.
–Press the UP or DOWN button until the "Settings" menu appears on the matrix dis-
play. Pressing the SET button opens the menu.
–Press the UP or DOWN button until "Clock/Date" is highlighted in black on the matrix
display. Pressing the SET button again opens the menu.
–Use the UP or DOWN button to navigate through the menu. Use the SET button to
set the time and date.
If the battery was disconnected from the vehicle, the time and date must be set in the
matrix display.

4 TECHNICAL DATA 13
4.1 Chassis tightening torques
Remaining screws, chassis EJOT PT®K50x12 1 Nm (0.7 lbf ft) –
Remaining screws, chassis EJOT PT®K50x14 1 Nm (0.7 lbf ft) –
Remaining screws, chassis EJOT PT®K50x16 2 Nm (1.5 lbf ft) –
Remaining screws, chassis EJOT PT®K50x18 2 Nm (1.5 lbf ft) –
Remaining screws, chassis EJOT PT®K45x12 1 Nm (0.7 lbf ft) –
Screw, air filter box lid EJOT PT®K60 2 Nm (1.5 lbf ft) –
Screw, tail light EJOT PT®K50x14 2.5 Nm (1.84 lbf ft) –
Screw, combination switch, left M4 2.5 Nm (1.84 lbf ft) –
Screw, exhaust valve cover M4 4 Nm (3 lbf ft) –
Screw, side stand switch M4 2 Nm (1.5 lbf ft) –
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft) –
Remaining screws, chassis M5 5 Nm (3.7 lbf ft) –
Screw, cable channel M5 5 Nm (3.7 lbf ft) –
Screw, chain sliding guard M5 5 Nm (3.7 lbf ft) –
Screw, combination switch, right M5 3.5 Nm (2.58 lbf ft) –
Screw, cornering light M5 2 Nm (1.5 lbf ft) –
Screw, cover part M5 3.5 Nm (2.58 lbf ft) –
Screw, filler cap M5 3 Nm (2.2 lbf ft) –
Screw, fuel level indicator M5 3 Nm (2.2 lbf ft) –
Screw, suspension travel sensor M5x16 6 Nm (4.4 lbf ft) –
Cable disk nut, exhaust valve control
unit
M6 14 Nm (10.3 lbf ft) –
Ground fitting on frame M6 10 Nm (7.4 lbf ft) –
Nut throttle cable valve control M6 5 Nm (3.7 lbf ft) –
Nut, ABS unit attachment M6 8 Nm (5.9 lbf ft) –
Nut, cable on starter motor M6 4 Nm (3 lbf ft) –
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft) –
Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –
Screw, ABS modulator on retaining
bracket
M6 5 Nm (3.7 lbf ft) –
Screw, ball joint of push rod on foot
brake cylinder
M6 5 Nm (3.7 lbf ft) Loctite®243™
Screw, battery terminal M6 4.5 Nm (3.32 lbf ft) –
Screw, clutch assembly M6 5 Nm (3.7 lbf ft) Loctite®243™
Screw, connecting piece, rear brake
line
M6 10 Nm (7.4 lbf ft) Loctite®243™
Screw, cooler retaining bracket M6 7 Nm (5.2 lbf ft) –
Screw, exhaust clamp on main silencer M6 8 Nm (5.9 lbf ft) –
Screw, exhaust clamp on manifold M6 8 Nm (5.9 lbf ft) –
Screw, foot brake cylinder M6 10 Nm (7.4 lbf ft) Loctite®243™
Screw, fuel pump M6 6 Nm (4.4 lbf ft) –
Screw, license plate holder on lower
rear panel
M6 12 Nm (8.9 lbf ft) –
Screw, radiator hose clamp M6 3 Nm (2.2 lbf ft) –
Screw, sensor box M6 6 Nm (4.4 lbf ft) Loctite®243™
Screw, shift lever stub M6 10 Nm (7.4 lbf ft) Loctite®243™
Screw, shift rod M6 5 Nm (3.7 lbf ft) Loctite®243™
Screw, shift shaft deflector on shift
shaft
M6 18 Nm (13.3 lbf ft) Loctite®243™
Screw, side stand stub M6 6 Nm (4.4 lbf ft) Loctite®243™
Screw, side stand stub extension M6 6 Nm (4.4 lbf ft) Loctite®243™

4 TECHNICAL DATA 14
Screw, steering damper, holder, on
frame
M6 8 Nm (5.9 lbf ft) Loctite®243™
Screw, step plate for foot brake lever M6 10 Nm (7.4 lbf ft) Loctite®243™
Screw, suitcase molds M6 6 Nm (4.4 lbf ft) –
Screw, tire pressure sensor
(Super Duke GT EU/US/CN)
M6 7 Nm (5.2 lbf ft) –
Screw, wheel speed sensor, front M6 4 Nm (3 lbf ft) –
Screw, wheel speed sensor, rear M6 4 Nm (3 lbf ft) –
Cable disk nut, exhaust valve M8 7 Nm (5.2 lbf ft) –
Nut, manifold on cylinder head M8 Tightening sequence:
Tighten the nuts evenly. Do
not warp the metal plate.
25 Nm (18.4 lbf ft)
–
Nut, rear sprocket M8 36 Nm (26.6 lbf ft) –
Nut, shift rod M8 12 Nm (8.9 lbf ft) –
Nut, shift rod M8LH 12 Nm (8.9 lbf ft) –
Nut, valve, angled (Super Duke GT JP) M8 4 Nm (3 lbf ft) –
Nut, valve, angled (Super Duke GT
EU/US/CN)
M8 6 Nm (4.4 lbf ft) –
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –
Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –
Screw, axle clamp M8 15 Nm (11.1 lbf ft) –
Screw, bottom triple clamp M8 15 Nm (11.1 lbf ft) –
Screw, foot brake lever M8 20 Nm (14.8 lbf ft) Loctite®243™
Screw, front brake disc M8 30 Nm (22.1 lbf ft) Loctite®2701™
Screw, front rider footrest bracket M8 25 Nm (18.4 lbf ft) Loctite®243™
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –
Screw, ignition lock (tamper-proof
screw)
M8 25 Nm (18.4 lbf ft) –
Screw, rear brake caliper M8 25 Nm (18.4 lbf ft) Loctite®2701™
Screw, rear brake disc M8 30 Nm (22.1 lbf ft) Loctite®243™
Screw, shift lever on footrest bracket M8 20 Nm (14.8 lbf ft) Loctite®243™
Screw, shift shaft deflector on frame M8 10 Nm (7.4 lbf ft) Loctite®243™
Screw, side stand bracket M8 25 Nm (18.4 lbf ft) Loctite®243™
Screw, side stand spring M8 15 Nm (11.1 lbf ft) Loctite®2701™
Screw, steering damper on holder M8 8 Nm (5.9 lbf ft) Loctite®243™
Screw, steering damper on triple clamp M8 8 Nm (5.9 lbf ft) Loctite®243™
Screw, steering stem clamp M8 20 Nm (14.8 lbf ft) Loctite®243™
Screw, top triple clamp M8 18 Nm (13.3 lbf ft) –
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft) –
Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –
Screw, engine bearer M10 45 Nm (33.2 lbf ft) Loctite®243™
Screw, front brake caliper M10 45 Nm (33.2 lbf ft) Loctite®243™
Screw, handlebar support M10 40 Nm (29.5 lbf ft) Loctite®243™
Screw, side stand M10 35 Nm (25.8 lbf ft) Loctite®243™
Screw, side stand bracket M10 45 Nm (33.2 lbf ft) Loctite®243™
Screw, side stand retaining plate M10 45 Nm (33.2 lbf ft) Loctite®243™
Banjo bolt, brake line M10x1 25 Nm (18.4 lbf ft) –
Banjo bolt, brake line, connecting
piece, rear
M10x1 15 Nm (11.1 lbf ft) –
Nut, rear hub shock absorber carrier M10x1.25 45 Nm (33.2 lbf ft) Loctite®243™
Lambda sensor M12x1.25 25 Nm (18.4 lbf ft) –
Screw, bottom shock absorber M14x1.5 80 Nm (59 lbf ft) Thread greased
Screw, top shock absorber M14x1.5 80 Nm (59 lbf ft) Thread greased

4 TECHNICAL DATA 15
Screw, eccentric M16 70 Nm (51.6 lbf ft) –
Nut, swingarm pivot M19x1.5 130 Nm (95.9 lbf ft) Thread greased
Nut, seat lock M22x1.5 6 Nm (4.4 lbf ft) –
Bolt, front axle M25x1.5 45 Nm (33.2 lbf ft) Thread greased
Screw, steering head, top M25x1.5 18 Nm (13.3 lbf ft) –
Nut, rear axle, shock absorber side M35x1.5 200 Nm (147.5 lbf ft) Loctite®262™/lock the lock-
ing wire with locking varnish
Nut, rear axle M50x1.5 250 Nm (184.4 lbf ft) Thread greased/lock locking
wire with locking varnish

5 SUBSTANCES 16
Super unleaded (ROZ 95/RON 95/PON 91)
Standard/classification
–DIN EN 228 (ROZ 95/RON 95/PON 91)
Guideline
–Only use unleaded super fuel that matches or is equivalent to the specified fuel grade.
–Fuel with an ethanol content of up to 10 % (E10 fuel) is safe to use.
Info
Do not use fuel containing methanol (e. g. M15, M85, M100) or more than 10 % ethanol (e. g. E15, E25, E85, E100).

*3213610en*
3213610en
11/2016
KTM Sportmotorcycle GmbH
5230 Mattighofen/Austria
http://www.ktm.com
Photo: Mitterbauer/KTM
