KTM 400 LS-E/MIL User guide

OWNERS HANDBOOK
Art.Nr. 320577 9/99
2000
BEDIENUNGSANLEITUNG
400/620 SC, SUPERMOTO

ENGLISH
1
IMPORTANT
WE STRONGLY SUGGEST THAT YOU READ THIS MANUAL
CAREFULLY AND COMPLETELY BEFORE GOING ON YOUR FIRST
RIDE. IT CONTAINS A GREAT DEAL OF INFORMATION AND
ADVICE WHICH WILL HELP YOU USE AND HANDLE YOUR BIKE
PROPERLY. IN YOUR OWN INTEREST, PLEASE PAY PARTICULAR
ATTENTION TO NOTICES THAT ARE MARKED AS FOLLOWS:

WARNING

IGNORING THESE INSTRUCTIONS, CAN ENDANGER YOUR
BODY AND YOUR LIFE.
!
CAUTION
!
IGNORING THESE INSTRUCTIONS COULD CAUSE DAMAGE TO
PARTS OF YOUR MOTORCYCLE OR THAT THE MOTORCYCLE
IS NOT ROAD-SAFE ANYMORE.
Please insert the series numbers of your motorcycle in the boxes below
Frame number
Engine number
Stamp of dealer
TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED
Owners are warned that the law may prohibit:
(a)
The removal or rendering inoperative by any person other than for purposes of maintenance, repair
or replacement, of any device or element of design incorporated into any new vehicle for the pur-
pose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use; and
(b) the use of the vehicle after such device or element of design has been removed or rendered
inoperative by any person.
CONSUMER INFORMATION FOR AUSTRALIA ONLY
KTM S PORTMOTORCYCLE AG RESERVES THE RIGHT TO MODIFY ANY EQUIPMENT , TECHNICAL SPECIFICATIONS , COLORS ,
MATERIALS
, SERVICES OFFERED AND RENDERED , AND THE LIKE SO AS TO ADAPT THEM TO LOCAL CONDITIONS WITHOUT
PREVIOUS ANNOUNCEMENT AND WITHOUT GIVING REASONS
, OR TO CANCEL ANY OF THE ABOVE ITEMS WITHOUT SUBSTI -
TUTING THEM WITH OTHERS . I T SHALL BE ACCEPTABLE TO STOP MANUFACTURING A CERTAIN MODEL WITHOUT PREVIOUS
ANNOUNCEMENT
. I N THE EVENT OF SUCH MODIFICATIONS , PLEASE ASK YOUR LOCAL KTM DEALER FOR INFORMATION .
W
E SHALL NOT BE HELD LIABLE FOR ANY PRINTING ERRORS .

ENGLISH
2
Introduction
We would like to congratulate you on your purchase of a KTM motorcycle. Let us also take this
opportunity to thank you for putting your trust in us; we will not let you down.
You are now owner of a sporty and modern motorcycle which you are bound to have a great time
with provided you care for it properly. Before going for a first ride on your motorbike, you should
read this Owner’s Handbook carefully, even if this takes some of your precious time, so as to
familiarize yourself with how your motorbike is to be operated and which features it offers you.
Only by doing so will you learn how you can best tune your motorcycle to your needs and how
you can avoid bodily injuries. In addition, this Owner’s Handbook contains invaluable informa-
tion about motorcycle maintenance. At the time of printing, this User's Guide corresponded to the
latest state of this model family. It is, however, possible that we may have made slight modificati-
ons in the meantime due to development in our motorcycle design.
The Owner’s Handbook is an essential part of the motorbike and should - when the bike is sold -
be handed over to the new owner.
Many motorcyclists have a good working knowledge of motorcycle mechanics; if this is true in
your case, you will be able to use this Owner’s Handbook to carry out most of the maintenance
steps yourself. If, on the other hand, you are not very familiar with motorcycles, it might be better
to have a professional KTM dealer perform those steps marked by *found in the chapter entitled
“Maintenance Work on Chassis and Engine” of this manual.
Take special care to follow the recommended run in, inspection, and maintenance
intervals. Heeding these guidelines will significantly increase the life of your motorcycle. Be sure to
have any maintenance jobs performed by an authorized KTM dealer.
Address your special requests to an authorized KTM dealer who, should the need arise, will be
supported by the KTM importer.
Please do not forget to don your helmet, eye protection, and protective clothing when going for a
ride. KTM riders are responsible riders! We wish you a lot of fun when driving !
KTM SPORTMOTORCYCLE AG
5230 MATTIGHOFEN, AUSTRIA
Attachments: 1 spare parts manual chassis
1 spare parts manual engine
ALL RIGHTS RESERVED TO MAKE ALTERATIONS TO DESIGN AND MODEL.
©by KTM SPORTMOTORCYCLE AG, AUSTRIA All rights reserved
KTM Austria’s certificate of achievement for its Quality
System ISO 9001 is the beginning of an on-going total
re-engineering quality plan for a brighter tomorrow.

ENGLISH
3
Page
SERIAL NUMBER LOCATIONS .............................................4
Chassis number ................................................................4
Engine number, engine type.............................................4
OPERATION INSTRUMENTS ...............................................4
Clutch lever ......................................................................4
Hand decompression lever................................................4
Hand brake lever..............................................................4
Indicator lamps.................................................................5
Speedometer - digital .......................................................5
Speedometer, indicator lamps...........................................5
Combination switch..........................................................5
Combination switch (AUS) ...............................................5
Flasher switch...................................................................6
Filler cap...........................................................................6
Fuel..................................................................................6
Fuel tap............................................................................6
Choke ..............................................................................7
Hot-start device................................................................7
Shift lever .........................................................................7
Kickstarter ........................................................................7
Foot brake pedal ..............................................................7
Handlebar lock .................................................................8
Compression damping of fork ..........................................8
Rebound damping of fork ................................................8
Compression damping of shock absorber .........................8
Rebound damping of shock absorber ...............................8
DRIVING INSTRUCTIONS ....................................................9
PERIODIC MAINTENANCE-SCHEDULE ..............................12
MAINTENANCE WORK ON CHASSIS AND ENGINE ..........13
Removal of seat..............................................................13
Tool set ..........................................................................13
Breather plugs front fork ................................................14
Cleaning the dust sleeves of the telescopic fork ..............14
Check and adjust steering head bearing .........................14
How to change the handlebar position...........................15
Replacing the battery of the digital speedometer............15
Checking rubber ring on the WP rear shock absorber .....15
Check/set distance of the magnetic sensor .....................17
Changing the spring preloading of the shock absorber ...18
Lubricate rear suspension linkage ...................................18
Checking chain tension...................................................18
Correct chain tension......................................................19
Chain maintenance.........................................................19
Chain wear.....................................................................19
General informations about KTM disc brakes..................20
Adjusting of free travel at the hand brake lever ..............20
Checking of brake fluid level - front brake......................20
Refilling the front brake fluid reservoir............................21
Check the front brake pads ............................................21
Replacing front brake pads .............................................21
Changing the basic position of the brake pedal ..............22
Check the rear brake fluid level ......................................22
Refilling the rear brake fluid reservoir .............................22
Checking the rear brake pads .........................................22
Replacing the rear brake pads.........................................23
Dismounting and mounting the front wheel...................23
Dismounting and mounting the rear wheel.....................24
Tires, air pressure............................................................24
Checking spoke tension..................................................25
Cooling system...............................................................26
Checking the coolant level..............................................26
Cleaning of air filter........................................................27
Exhaust system...............................................................27
Draining of the float chamber of the carburetor .............27
Carburetor – Adjust idling...............................................28
Adjust hot start device....................................................28
Check float level.............................................................28
Checking axial play of float ............................................28
Adjusting the throttle cable ............................................29
Adjusting the choke cable...............................................29
Adjusting the clutch cable...............................................29
Checking the adjustment of the hand decompression cable .....29
Engine oil .......................................................................30
Checking the engine oil level..........................................30
Oil circuit........................................................................30
Changing the engine oil .................................................30
Changing and bleeding the microfilter............................31
Changing oil filter...........................................................31
TROUBLE SHOOTING........................................................32
CLEANING..........................................................................34
CONSERVATION FOR WINTER OPERATION ....................34
STORAGE ...........................................................................34
Re-initation after time of storage....................................34
TECHNICAL SPECIFICATIONS - ENGINE ...........................35
TECHNICAL SPECIFICATIONS - CHASSIS...........................37
WIRING DIAGRAMME ..........................................APPENDIX
Index

ENGLISH
4
1-3 mm
1
2
Chassis number
The chassis number is stamped on the right side of the steering head tube.
Write this number into the relevant area on page 1.
Engine number, engine type
The engine number and engine type are stamped on the right hand side of
the engine below the chain sprocket. Write this number into the relevant
area on page 1.
Clutch lever
The clutch lever 1is fitted on the left hand side of the handlebar. When
engine is cold, there should always be a play of 1–3 mm (0,04–0,1 in) at
this lever (measured at outer edge).
!
CAUTION
!
IF THERE IS NO PLAY ON THE CLUTCH LEVER, THE CLUTCH WILL START TO SLIP. THE
CLUTCH WILL THEN OVERHEAT, DESTROYING THE CLUTCH LININGS.
Hand decompression lever
The hand decompression lever 2is only used in two special cases:
a) When the engine stalled.
When you then start the engine, you may feel a hard resistance on the
kickstarter, because the automatic decompressor cannot lock into place.
If this happens, pull the hand decompression lever and stand on the kick-
starter. You can then start the engine normally again.
b) When you want to push-start the motorcycle.
While pushing, pull the decompression lever to make it easier to get the
engine going.
!
CAUTION
!
THE SETTING OF THE DECOMPRESSION CABLE SHOULD BE REGULARLY CHECKED. A LACK
OF PLAY IN THE DECOMPRESSION LEVER CAN RESULT IN ENGINE DAMAGE.
Hand brake lever
The hand brake lever is mounted on the handle bars on the right and actua-
tes the front wheel brake.

WARNING

IF THE RESISTANCE IN THE HAND BRAKE LEVER OR FOOT BRAKE PEDAL FEELS “SPONGY”
(TOO MUCH GIVE), THIS IS AN INDICATION THAT SOMETHING IS WRONG WITH THE
BRAKE SYSTEM. DON’T RIDE YOUR MOTORCYCLE ANYMORE WITHOUT FIRST HAVING THE
BRAKE SYSTEM LOOKED OVER BY A KTM DEALER.
SERIAL NUMBER LOCATIONS
OPERATION INSTRUMENTS

ENGLISH
5
89
A
B
C
TRP
STP
DST
CLK
3
1
2
Indicator lamp
The green control lamp 1flashes when the indicator is working in
the same rhythm as the flashing indicator.
The blue control lamp 2lights up when the high beam is on.
Speedometer – digital
Some models are equipped with a digital speedometer 3.
KMH = Speed, max. 200 km/h (is always indicated)
Aside from speed indication the following indications can be selected:
TRP = Trip distance
STP = Stopwatch max. 10 h, automatic start/stop function
DST = Total distance up to 99.999 km
CLK = Reloj
See maintenance work for change of battery and basic setting.
Speedometer, indicator lamps
The mileage indicator Bin the speedometer 4indicates overall mileage.
When the turn indicator is on, the green indicator lamp 5will be flashing in
the same rhythm.
The blue indicator lamp 6will be lit when the high beam is on
Combination switch
The light switch has 3 switch positions.
A= Light off
B= Low beam light
C= High beam light
The red short circuit button 8serves to switch off the engine. Leave the
switch pressed, until the engine stops. With the button 9the horn will
sound.
Combination switch (AUS)
The light switch has 3 switch positions.
B= Low beam light
C= High beam light
The red short circuit button 1serves to switch off the engine. Leave the
switch pressed, until the engine stops. With the button 2the horn will
sound.
12
B
C
D
4
56

ENGLISH
6
35 mm
N
O
O
F
F
R
E
S
F
U
E
L
N
O
O
F
F
R
E
S
F
U
E
L
N
O
O
F
F
R
E
S
F
U
E
L
RES
ON
OFF
Flasher switch
The flasher switch is a separate unit and is mounted on the left portion of
the handlebar.
The wire harness is designed in a way that whenever you want to use your
bike on cross-country, off-road terrain you can dismount the entire turn
indicator system without affecting the function of the remaining electrical
system.
Flasher left
Flasher right
Filler cap
To open filler cap: Turn the filler cap counter-clockwise.
To close filler cap: Screw on the filler cap clockwise.
Fuel
The LC4 engine needs premium gasoline with an octane number of 95 or
higher.
!
CAUTION
!
USE LEADED OR UNLEADED PREMIUM GRADE GASOLINE (95 OCTANES). NEVER USE ANY
GASOLINE HAVING LESS THAN 95 OCTANES BECAUSE IT MAY DAMAGE THE ENGINE.

WARNING

GASOLINE IS HIGHLY FLAMMABLE AND POISONOUS. EXTREME CAUTION SHOULD BE USED
WHEN HANDLING GASOLINE. DO NOT REFUEL THE MOTORCYCLE NEAR OPEN FLAMES OR
BURNING CIGARETTES. ALWAYS SWITCH OFF THE ENGINE BEFORE REFUELLING. BE
CAREFUL NOT TO SPILL GASOLINE ON THE ENGINE OR EXHAUST PIPE WHILE THE ENGINE IS
HOT. WIPE UP SPILLS PROMPTLY. IF GASOLINE IS SWALLOWED OR SPLASHED IN THE EYES,
SEEK A DOCTOR’S ADVICE IMMEDIATELY.
Fuel expands when its temperature rises. Therefore do not fill the tank to
the top (see fig.).
Fuel tap
OFF In this position the fuel tap is closed. No fuel may flow to the carburetor.
ON When using the motorcycle, the rotating handle must be set to the
ON position. Now fuel may flow to carburetor. In this position the
tank empties down to the fuel reserve of approx. 2,5 liters.
RES The reserve tank, approximately 2,5 liters, cannot be tapped until the
rotating handle is turned to the RES position. Fill the tank as soon as
possible and remember to turn the rotating handle back to the ON
position so that you will have backup fuel next time, too.
!
CAUTION
!
THE FUEL TAP SHOULD BE LOCKED WHENEVER THE MOTORCYCLE IS PARKED. IF THE TAP
IS NOT CLOSED THE CARBURETOR MAY OVERFLOW AND FUEL GET INTO THE ENGINE.

ENGLISH
7
2,3,4,5
1
N
1
2
Choke
In these models the choke operating element is located on the engine. Pull
the knob 1and turn it (approx. 90°) to open a bore in the carburetor
through which the engine can take in additional fuel. The result is a „fat“
fuel-air mixture of the type needed for cold starts.
To close the bore in the carburetor, turn the knob again (approx. 90°); the
knob moves back into its initial position. In this position, the play of the
choke cable must be approximately 2 mm (0.1 in).
!
CAUTION
!
IF THERE IS NO PLAY IN THE CHOKE CABLE, THE COLD STARTER SYSTEM CANNOT BE
COMPLETELY CLOSED. THIS RESULTS IN HIGH FUEL CONSUMPTION, AN UNEVEN RUNNING
ENGINE, AN EXTREME WEAR OF PISTON AND CYLINDER.
Hot-start device
The carburetor is equipped with a hot-start device which makes it easier to
start the engine when hot. Press the hot-start button 2until it engages.
This will slightly lift the throttle valve. Once the engine is running, pull the
hot-start button back into its original position.
NOTE:
Always pull the hot start device back into the initial position as soon as the
engine is running. An activated hot starting device will have a negative
impact on the cold starting properties of the engine.
Shift lever
The shift lever is mounted on the left side of the engine. The position of the
gears is shown in the illustration. Neutral, or the idle speed, is located
between first and second gear.
Kickstarter
The kickstarter is mounted on the left side of the engine. Its upper part can
be swivelled.

WARNING

–IF YOU WANT TO START THE ENGINE, MAKE SURE THAT YOU ALWAYS PUT ON STURDY
MOTORCYCLE BOOTS IN ORDER TO AVOID INJURIES. YOU MIGHT SLIP OFF THE KICK-
STARTER, OR THE ENGINE MAY KICK BACK AND PROPEL YOUR FOOT UPWARD WITH
GREAT VEHEMENCE.
–A
LWAYS KICK KICKSTARTER BRISKLY ALL THE WAY WITHOUT OPENING THE THROTTLE.
KICKING THE KICKSTARTER WITH NOT ENOUGH MOMENTUM, AND AN OPENED
THROTTLE GRIP INCREASE THE KICK-BACK HAZARD.
Foot brake pedal
The foot brake pedal is disposed in front of the right foot rest. Its basic
position can be adjusted to your seat position (see maintenance work).

WARNING

IF THE RESISTANCE IN THE HAND BRAKE LEVER OR FOOT BRAKE PEDAL FEELS “SPONGY”
(TOO MUCH GIVE), THIS IS AN INDICATION THAT SOMETHING IS WRONG WITH THE
BRAKE SYSTEM. DON’T RIDE YOUR MOTORCYCLE ANYMORE WITHOUT FIRST HAVING THE
BRAKE SYSTEM LOOKED OVER BY A KTM DEALER.

ENGLISH
8
2
3
4
11
2
Handlebar lock
The handlebar can be locked by means of the lock located on the control
head. Fully turn handlebar to right to lock, insert key, turn to left, press in,
turn to right and withdraw.
!
CAUTION
!
NEVER LEAVE THE KEY INSERTED IN THE LOCK. IF YOU TURN THE STEERING TO THE LEFT
THE KEY COULD GET DAMAGED.
Compression damping of fork
Hydraulic compression damping determines the reaction when the fork is
compressed. The degree of compression can be adjusted with adjusting scr-
ews at the bottom of the fork legs.
Turn the adjusting screw 1clockwise to increase damping, turn it counter-
clockwise to reduce damping during compression.
STANDARD ADJUSTMENT
– turn adjusting screw clockwise as far as it will go
– turn it back by as many clicks as are specified for the relevant type of fork
Type White Power 05.18.U7.82...........14 clicks
Rebound damping of fork
Hydraulic rebound damping determines the reaction when the fork is rebo-
und. By turning the knob 2, the degree of damping of the rebound can be
adjusted. Turn the knob clockwise to increase damping, turn it counter-
clockwise to reduce damping during rebounding.
STANDARD ADJUSTMENT
– turn adjusting screw clockwise as far as it will go
– turn it back by as many clicks as are specified for the relevant type of fork
Type White Power 05.18.U7.82...........14 clicks
Compression damping of shock absorber
With the knob 3the degree of damping of the compression can be adju-
sted to 7 positions. Turn the knob counterclockwise to increase damping,
turn it clockwise to reduce damping during rebounding.
BASIC SETTING:
01.18.T7.05 position 3
Rebound damping of shock absorber
With the setting wheel 4the degree of damping of the rebound can be
adjusted to 11 positions. Turn the knob to the left side to increase damping,
turn it to the right side to reduce damping during rebounding.
BASIC SETTING:
01.18.T7.05 position 5

WARNING

–NEVER CHANGE DAMPING BETWEEN THE TEST DRIVES MORE THAN 2 CLICKS.
–T
HE DAMPING UNITY OF THE SHOCK ABSORBER IS FILLED WITH HIGH COMPRESSED
NITROGEN. NEVER TRY TO TAKE THE SHOCK ABSORBER APART OR TO DO ANY
MAINTENANCE WORK YOURSELF. SEVERE INJURIES COULD BE THE RESULT.

ENGLISH
9
Instructions for initial operation
– Verify that your KTM dealer performed the PREPARATION
OF VEHICLE jobs (see Customer Service Manual).
– Read these operating instructions carefully before your first
ride.
– Familiarize yourself with the operating elements.
– Adjust the hand brake lever and foot brake lever to the
most comfortable positions for you.
– Get used to handling the motorcycle on an empty parking
lot or open space, before starting on a longer drive. Also try
to drive as slowly as possible and in standing position, to
improve your feeling for the vehicle.
– Do not drive along off-road tracks which go beyond your
abitily and experience.
– Hold the handlebars with both hands and leave your feet on
the foot rests while driving.
–
Remove your foot from the foot brake lever when you
are not braking. If the foot brake lever is not released the
brake pads rub continuously and the braking system is
overheated.
– Do not make any alterations to the motorcycle and always
use ORIGINAL KTM SPARE PARTS. Spare parts from other
manufacturers can impair the safety of the motorcycle.
– Motorcycles are sensitive to alterations in the distribution of
weight. If you are taking luggage with you, this should be
secured as close as possible to the middle of the vehicle; dis-
tribute the weight evenly between the front and rear wheel.
Never exceed the maximum permissible laden weight and
the axle weights. The maximum permissible laden weight is
made up of the following components:
– Motorcycle ready for operation and tank full
– Luggage
–
Driver with protective clothing and helmet.
– Pay attention to running-in procedure.
Running in the LC-4 models
Even very precisely machined sections of engine components
have rougher surfaces than components which have been sli-
ding across one another for quite some time. Therefore, every
engine needs to be broken in. For this reason, during its first
1000 kilometers (620 miles) the engine must not be revved up
to its performance limits. The engine speed of 4800 r.p.m.
must not be exceeded during the first 1000 kilometers (620
miles). During this break-in time, you should ride your
motorcycle in different conditions (roads, easy off-road ter-
rain). The following table shows you the maximum velocity
values in the different gears at 4800 r.p.m. as based on the
rear wheel transmission ratio of your motorcycle.
NOTE:
DURING THE STAGE OF RUNNING THE ENGINE IN, THAT IS THE FIRST
1000 KM (620 MILES), THE ENGINE OIL USED SHOULD BE OF A MINE-
RAL OIL FORMULA. THIS ALSO APPLIES IF THE ENGINE HAS BEEN REPAIRED.
Check the following before each start
When you start off, the motorcycle must be in perfect mecha-
nical condition. For safety reasons, you should make a habit of
performing an overall check of your motorcycle before each
start.
The following checks should be performed:
1 CHECK THE OIL LEVEL
Insufficient oil results in premature wear and consequently
to engine damage.
2 FUEL
Check that there is sufficient fuel in the tank; when closing
the filler cap, check that the tank venting hose is free of
kinks.
3 CHAIN
A loose chain can fall from the chain wheels; an extremely
worn chain can tear, and insufficient lubrication can result in
unnecessary wear to the chain and chain wheels.
4 TIRES
Check for damaged tires. Tires showing cuts or dents must be
replaced. The tread depth must comply with the legal regula-
tions. Also check the air pressure. Insufficient tread and incor-
rect air pressure deteriorate the driving performance.
5 BRAKES
Check correct functioning of the braking system. Check for
sufficient brake fluid in the reservoir. The reservoirs have
been designed in such a way that brake fluid does not need
to be refilled even when the brake pads are worn. If the
level of brake fluid falls below the minimum value, this indi-
cates a leak in the braking system or completely worn out
brake pads. Arrange for the braking system to be checked
by a KTM specialist, as complete failure of the braking
system can be avoided.
Also check the state of the brake hose and the thickness of
the brake linings.
Check free travel at hand brake lever and foot brake lever.
6 CABLES
Check correct setting and easy running of all control cables.
7 COOLING FLUID
Check the level of cooling fluid when the engine is cold.
8 ELECTRICAL SYSTEM
Check correct functioning of headlamps, tail-lights, brake
lights, indicators, control lamps and horn while the engine is
running.
9 LUGGAGE
If you are taking luggage with you, check that this is
securely fastened.

WARNING

–WEAR SUITABLE CLOTHING WHEN DRIVING A MOTORCYCLE. CLEVER
KTM DRIVERS ALWAYS WEAR A HELMET, BOOTS, GLOVES AND A
JACKET, REGARDLESS OF WHETHER DRIVING ALL DAY OR JUST FOR A
SHORT TRIP. THE PROTECTIVE CLOTHING SHOULD BE BRIGHTLY COLO-
RED SO THAT OTHER VEHICLE CAN SEE YOU AS EARLY AS POSSIBLE.
YOUR PASSENGER WILL ALSO NEED SUITABLE PROTECTIVE CLOTHING.
–D
O NOT DRIVE AFTER HAVING CONSUMED ALCOHOL.
–A
LWAYS TURN ON THE LIGHT TO MAKE SURE THAT OTHER DRIVERS
BECOME AWARE OF YOU AS EARLY AS POSSIBLE.
–O
NLY USE ACCESSORIES THAT HAVE BEEN RELEASED BY KTM. FOR
EXAMPLE, FRONT PANELLING CAN IMPAIR THE DRIVING PROPERTIES OF
THE MOTORCYCLE. CASES, EXTRA TANKS ETC. CAN ALTER THE WEIGHT
DISTRIBUTION AND THUS ALSO IMPAIR THE VEHICLES DRIVING
PROPERTIES.
–T
HE FRONT AND REAR WHEEL ARE ALLOWED TO BE FITTED ONLY WITH
TIRES THAT HAVE THE SAME PROFILE TYPE.

WARNING

IMPORTANT INSTRUCTIONS FOR THE SUPER COMPETI-
TION MODELS:
–T
HE ABOVE MODELS WERE DESIGNED AND BUILT FOR ONE PERSON
ONLY - NO ADDITIONAL PASSENGER ALLOWED!
–W
HEN RIDING YOUR MOTORCYCLE, PLEASE BEAR IN MIND THAT
OTHER PEOPLE MAY FEEL MOLESTED BY EXCESSIVE NOISE.
DRIVING INSTRUCTIONS
400 SC 620 SC Supermoto
16:48 t 16:40 t 17:38 t
1st 30 (19) 35 (22) 35 (22)
2nd 45 (30) 50 (32) 55 ( 35)
3rd 60 (38) 70 (44) 75 (47)
4th 75 (47) 90 (57) 90 (57)
5th 85 (54) 100 (63) 105 (66)
gear
ratio

ENGLISH
10
1
2
3
Starting when the engine is cold
1 Open the fuel tap 1
2 Swing up the side stand or center stand.
3 Put the gear in neutral
4 Operate the choke 2
5 Go to the left of your motorbike. DO NOT open the throttle, and briskly
kick the kickstarter ALL THE WAY.

WARNING

–I
F YOU WANT TO START THE ENGINE, MAKE SURE THAT YOU ALWAYS PUT ON STURDY
MOTORCYCLE BOOTS IN ORDER TO AVOID INJURIES. YOU MIGHT SLIP OFF THE KICK-
STARTER, OR THE ENGINE MAY KICK BACK AND PROPEL YOUR FOOT UPWARD WITH
GREAT VEHEMENCE.
–A
LWAYS KICK KICKSTARTER BRISKLY ALL THE WAY WITHOUT OPENING THE THROTTLE.
KICKING THE KICKSTARTER WITH NOT ENOUGH MOMENTUM, AND AN OPENED
THROTTLE GRIP INCREASE THE KICK-BACK HAZARD.
–D
O NOT START THE ENGINE AND ALLOW IT TO IDLE IN A CLOSED AREA. EXHAUST
FUMES ARE POISONOUS AND CAN CAUSE LOSS OF CONSCIOUSNESS AND DEATH.
ALWAYS PROVIDE ADEQUATE VENTILATION WHILE THE ENGINE IS RUNNING.
!
CAUTION
!
DON’T RIDE YOUR MOTORCYCLE WITH FULL LOAD AND DON’T REV ENGINE WHEN COLD.
BECAUSE THE PISTON IS WARMING UP FASTER THAN THE WATER COOLED CYLINDER, IT
CAN CAUSE ENGINE DAMAGE.
Starting when the engine is warm
1 Open the fuel tap 1
2 Swing up the side stand or center stand.
3 Put the gear in neutral
4 Leave the throttle closed and push the kickstarter hard ALL THE WAY
Starting when the engine is hot
1 Open the fuel tap 1
2 Swing up the side stand or center stand.
3 Put the gear in neutral
4 Push in the hot-start button 3on the carburetor as far as it will go
5 Leave the throttle closed and push the kickstarter hard ALL THE WAY
6 Once the engine is running, pull hot-start button back into its original
position.
What to do when the engine is „flooded”
Pull in the hand decompression lever, open the throttle fully, kick the kick
starter through the stroke 5 to 10 times and start the motor as described
above.
Starting off
Pull the clutch lever. Put the engine into first gear, slowly release the clutch
lever and open throttle at the same time.

WARNING

–B
EFORE YOU START OFF, CHECK THAT THE MAIN OR SIDE STAND HAS BEEN SWUNG
UP FULLY. IF THE STAND DRAGS ON THE GROUND, THE MOTORCYCLE CAN GO OUT
OF CONTROL.
–A
LWAYS TURN ON THE LIGHT TO MAKE SURE THAT OTHER DRIVERS BECOME AWARE
OF YOU AS EARLY AS POSSIBLE.
Shifting/Riding
You are now in first gear, refered to as the drive or uphill gear. Depending
on the conditions (traffic, hill size, etc.), you can shift to a higher gear. Close
throttle, at the same time pull clutch lever in and shift to the next higher
gear. Let clutch lever go again and give gas. If you turned on the choke,
make sure you turn it off again as soon as engine is warm.
When you reach full speed through opening the throttle all the way, turn
throttle back to 3/4; the speed hardly decreases although the engine will
use less gas.
Only give as much gas as the engine can handle. Through quick and high
reving of throttle, the gas usage increases.


WARNING

–NEVER LEAVE YOUR MOTORCYCLE WITHOUT SUPERVISION IF THE
ENGINE IS RUNNING.
–M
OTORCYCLE ENGINES PRODUCE A GREAT AMOUNT OF HEAT WHILE
RUNNING. THE ENGINE, EXHAUST PIPE, MUFFLER, BRAKE ROTORS, AND
SHOCK ABSORBERS CAN BECOME VERY HOT. DO NOT TOUCH ANY OF
THESE PARTS AFTER OPERATING THE MOTORCYCLE, AND TAKE CARE TO
PARK IT WHERE PEDESTRIANS ARE NOT LIKELY TO TOUCH IT AND GET
BURNED.
!
CAUTION
!
–C
LOSE THE FUEL TAP WHEN LEAVING YOUR VEHICLE.OTHERWISE THE
CARBURETTOR CAN FLOOD AND FUEL WILL ENTER THE ENGINE.
–N
EVER PARK YOUR MOTORCYCLE IN PLACES WHERE THERE EXIST FIRE
HAZARDS DUE TO DRY GRASS OR OTHER EASILY FLAMMABLE
MATERIALS.
NOTE REGARDING THE MAIN STAND:
We advise the following procedure to place the motorcycle on
the main stand as effortlessly as possible:
a) press main stand to ground using foot
b) swing out kickstarter and pull at an angle toward the rear of
motorcycle (see illustration)
ENGLISH
11
By shifting down, use the brakes if necessary and close throttle
at the same time. Pull clutch lever and shift down to the next
gear. Let clutch lever go slowely and open throttle or shift
down again.

WARNING

–OBSERVE THE TRAFFIC REGULATIONS, DRIVE DEFENSIVELY AND TRYING
TO LOOK AHEAD AS FAR AS POSSIBLE SO THAT ANY HAZARDS CAN BE
RECOGNIZED AS EARLY AS POSSIBLE.
–A
DJUST YOUR DRIVING SPEED ACCORDING TO THE CONDITIONS AND
YOUR DRIVING SKILLS.
–D
RIVE CAREFULLY UN UNKNOWN ROADS OR ON UNFAMILIAR TRIALS.
–W
HEN DRIVING OFF-ROAD, ALWAYS HAVE A FRIEND ON A SECOND
MOTORCYCLE TO KEEP YOU COMPANY, SO THAT YOU CAN HELP EACH
OTHER SHOULD DIFFICULTIES ARISE.
–R
EPLACE HELMET VISOR OR GOGGLE LENS WHEN SCRATCHED OR
DAMAGED. IF BRIGHT LIGHT SHINES THROUGH A SCRATCHED VISOR OR
LENS, THE OPERATOR WILL BE BLINDED.
–A
FTER FALLING WITH THE MOTORCYCLE, CHECK ALL FUNCTIONS
THOROUGHLY BEFORE STARTING UP OPERATIONS AGAIN.
–A
BENT HANDLEBAR MUST ALWAYS BE REPLACED. NEVER TRY TO
STRAIGHTEN THE HANDLEBAR BECAUSE THIS WILL CAUSE IT TO LOSE ITS
STABILITY.
!
CAUTION
!
–H
IGH RPM RATES WHEN THE ENGINE IS COLD HAVE AN ADVERSE
EFFECT ON THE LIFE OF YOUR ENGINE. WE RECOMMEND YOU RUN
THE ENGINE IN A MODERATE RPM RANGE FOR A FEW MILES GIVING IT
A CHANCE TO WARM UP. AFTER THAT NO FURTHER PRECAUTIONS IN
THIS RESPECT NEED BE TAKEN. THE ENGINE HAS REACHED ITS OPERA-
TING TEMPERATURE AS SOON AS THE RADIATORS BECOME WARM.
–N
EVER HAVE THE THROTTLE WIDE OPEN WHEN CHANGING DOWN TO
A LOWER GEAR. THE ENGINE WILL OVER-REV, DAMAGING THE VALVES.
IN ADDITION, THE REAR WHEEL LOCKS SO THAT THE MOTORCYCLE
CAN EASILY GET OUT OF CONTROL.
–L
ONG WHEELIES LEAD TO A DROP IN THE OIL PRESSURE WHICH CAN
LEAD TO MOTOR DAMAGE.
–I
F ANY ABNORMAL VIBRATIONS OCCUR WHILE DRIVING, CHECK THAT
THE ENGINE FASTENING BOLTS ARE TIGHT.
–IN THE EVENT THAT, WHILE RIDING ON YOUR MOTORCYCLE, YOU
NOTICE ANY UNUSUAL OPERATION-RELATED NOISE, STOP IMMEDIA-
TELY, TURN THE ENGINE OFF, AND CONTACT AN AUTHORIZED KTM
DEALER.
Braking
Close throttle and apply the hand and foot brakes at the same
time. When driving on sandy, wet or slippery ground use
mainly the rear wheel brake. Always brake with feeling,
blocking wheels can cause you to skid or fall. Also change
down to lower gears depending on your speed.
When driving down hill, use the braking effect of the engine.
Change down one or two gears but do not overspeed the
engine. In this way, you will not need to brake so much and
the brakes will not overheat.

WARNING

–I
N CASE OF RAIN, AFTER WASHING THE MOTORCYCLE, AFTER RIDES
THROUGH WATER AND IN CASE OF RIDES ON WET OFF-ROAD TRACKS,
HUMID OR DIRTY BRAKE DISCS CAN DELAY THE BRAKING EFFECT. THE
BRAKES MUST BE PULLED UNTIL THEY ARE DRY OR CLEAN.
–R
IDES ON SALT-STREWED OR DIRTY ROADS CAN ALSO DELAY THE BRA-
KING EFFECT. THE BRAKES MUST BE PULLED UNTIL THEY ARE CLEAN.
–D
IRTY BRAKE DISCS CAUSE INCREASED TEAR OF BRAKE PADS AND
BRAKE DISCS.
–W
HEN YOU BRAKE, THE BRAKE DISCS, BRAKE PADS, BRAKE CALIPER
AND BRAKE FLUID HEAT UP. THE HOTTER THESE PARTS GET, THE WEA-
KER THE BREAKING EFFECT. IN EXTREME CASES, THE ENTIRE BRAKING
SYSTEM CAN FAIL.
Stopping and parking
Apply the brakes fully and put the engine into neutral. To stop
the engine, switch off the ignition or pull the short circuit but-
ton when the engine is idling, until the engine stops. Turn the
fuel tap to the OFF position, park on an area where the ground
is firm, and lock the motorcycle.

ENGLISH
12
Check engine oil level 
Change engine oil  
Clean oil screen and magnet of the drain plugs whenever you exchange the engine oil 
Change oil filter unit 
Change microfilter 
Check oil lines for leakage and proper instalment 
Check valve clearance 
Clean spark plug and adjust electrode gap 
Change spark plug after 10 000 kilometers (6 200 miles)
Check valve clearance 
Drain and clean carburator float bowl 
Adjust idling 
Check breather hoses of engine gase and gas tank for correct position without buckles 
Clean air filter and air filter box 
Check sprockets, chain guides and chain for wear 
Clean and lube chain  
Check chain tension 
Check cooling liquid level 
Check quality of antifreeze 
Check cooling system for leaks 
Check exhaust system for leakage 
Change exhaust muffler packing (aluminium-muffler) 
Check exhaust brackets 
Disassemble and clean spark arrestor discs (USA models)
Check brake fluid level front and rear 
Change brake fluid 
Check brake pad thickness 
Check brake discs for wear and wobbling 
Check condition and correct instalment of brake hoses 
Check freeplay and easy operation of hand brake lever and foot brake lever 
Check adjustment and function of fork 
Check fork for leaks 
Loosen breather screws at fork legs (overpressure) 
Change fork oil 
Perform a full maintenance job for the telescopic fork 
Clean dust scrabber on forks 
Check steering head bearing clearance / adjust 
Clean and grease steering head bearings and its seals 
Check adjustment and funktion of shock absorber 
Check O-ring of the shock absorber for wear 
Servicing the shock absorber 
Grease lubricating nipple of the Pro Lever suspension system 
Disassemble the Pro Lever suspension system and perform a full maintenance job on it 
Servicing swingarm pivots 
Check tightness of spokes and rim join 
Check wheel bearings for clearance 
Check tire condition and air pressure 
Check cables for damage and easy working 
Lube and adjust cables  
Check the electrical system 
Check adjustment of head light 
Spray ignition lock, emergency OFF switch, short circuit button, and light switch with contact spray 
Check all screws, nuts and hose clamps for proper tightness 
Grease or lube all pivot points and sliding components  
PERIODIC MAINTENANCE SCHEDULE
before each start after washing 1st service, after 1000 km (600 miles) or 10 hours after 2500 km (1500 miles) or 25 hours after 5000 km (3000 miles) or once a year at least once a year
KTM
rider
KTM
dealer
IF THE MOTORCYCLE IS USED PRIMARILI FOR OFF ROAD
RIDING OR COMPETITIVE RACING, THE 5000 KM (3000 MILES)
SERVICE NEEDS TO BE CARRIED OUT AFTER EACH RIDE OR RACE
2.99
620 SX
400/540 SXC
400/620 SC

ENGLISH
13
4
2
3
1
1

WARNING

ALL MAINTENANCE AND ADJUSTEMENT OPERATIONS THAT ARE MARKED WITH A *REQUIRE SPECIALIST
KNOWLEDGE. FOR YOUR OWN SECURITY, LET THESE TASKS BE CARRIED OUT BY A KTM-DEALER
!
CAUTION
!
– WHEN CLEANING THE MOTORCYCLE, DO NOT USE A HIGH PRESSURE CLEANING UNIT IF POSSIBLE, OTHERWISE WATER WILL PENETRATE THE BEARINGS,
CARBURETOR, ELECTRIC CONNECTORS ETC.
– WHEN TRANSPORTING YOUR KTM, ENSURE THAT IT IS HELD UPRIGHT WITH RESTRAINING STRAPS OR OTHER MECHANICAL FASTENING DEVICES AND THAT
THE FUEL TAP IS IN THE OFF POSITION - IF THE MOTORCYCLE SHOULD FALL OVER, BE AWARE OF ANY LEAKING FUEL FROM THE CARBURETOR OR
FUEL TANK
– DONOT USE TOOTHED WASHERS OR SPRING RINGS WITH THE ENGINE FASTENING SCREWS, AS THESE WORK INTO THE FRAME PARTS AND KEEP WORKING
LOOSE. INSTEAD, USE SELF-LOCKING NUTS.
– LET YOUR MOTORCYCLE COOL DOWN BEFORE BEGINNING ANY MAINTENANCE WORK IN ORDER TO AVOID GETTING BURNED.
– REMOVE OILS, FATTY MATTERS, FILTERS, FUELS, WASHING DETERGENTS ETC. ORDERLY.
– UNDER NO CIRCUMSTANCES MAY USED OIL BE DISPOSED OF IN THE SEWAGE SYSTEM OR IN THE OPEN COUNTRYSIZE. 1 LITER USED OIL CONTAMINATES
1.000.000 LITERS WATER.
Removal of seat
By using the quick-release fastener 1, the seat can be removed without
using tools. Turn the quick-release fastener about 180° counter clockwise
and lift up the rear of the seat. Pull the seat backwards and unhook it from
the front fastener screw 2.
When installing the seat, be sure to insert the rear portion of the seat into
the metal clasp 3.
Tool set
The tool set 4is accommodated in the tool compartment behind the seat.
MAINTENANCE WORK ON CHASSIS AND ENGINE

ENGLISH
14
1
2
3
4
3
Breather plug front fork
After every 5 hours of use for competitive racing, slacken the breather
plugs 1a few turns in order to relieve excess pressure from the inside of
the fork. To do this, place the motorcycle on a stand with the front wheel
lifted off the ground. When riding the motorcycle mainly on street, it will be
enough to have this job performed in the course of the periodical mainten-
ance service.
!
CAUTION
!
EXCESSIVE PRESSURE IN THE INTERIOR OF THE FORK CAN CAUSE LEAKS IN THE FORK. IF
YOUR FORK IS LEAKING, IT IS RECOMMENDED TO OPEN THE BREATHER PLUGS BEFORE
HAVING THE SEALS REPLACED.
Cleaning the dust sleeves of the telescopic fork
The dust-protection bellows 2are to remove dust and coarse dirt particles
from the fork tube. However, after some time, dirt may also get in behind
the dust-protection bellows. If this dirt is not removed, the oil sealing rings
located behind it may start to leak.
Use a screwdriver to lever the dust-protection bellows out of the outer
tubes and slide them downward.
Clean dust-protection bellows, outer tubes, and fork tubes thoroughly, and
oil them thoroughly with silicone spray. Then, push dust-protection bellows
into the outer tubes by hand.
Check and adjust steering head bearing *
Check steering head bearing for play periodically. To check this put
motorcycle on a stand so that the front wheel is off the ground. Now try to
move the fork forward and backward. To adjust, loosen the five pinch
bolts 3of the top triple clamp and turn steering stem bolt 4clockwise
until there is no more play. Don’t tighten the steering stem bolt all the way,
otherwise the bearings will be damaged. With a plastic hammer, lightly tap
on the triple clamp to release tension. Retight the five pinch bolts with
20 Nm (15 ft.lbs).

WARNING

IF THE STEERING HEAD BEARING IS NOT ADJUSTED TO BE FREE OF PLAY, THE MOTORCY-
CLE WILL SHOW AN UNSTEADY DRIVING PERFORMANCE AND CAN GET OUT OF CONTROL.
!
CAUTION
!
IF YOU DRIVE WITH PLAY IN THE STEERING HEAD BEARING FOR LONGER PERIODS, FIRST
THE BEARINGS AND THEN THE BEARING SEATS IN THE FRAME WILL BE DESTROYED.
At least once a year, the steering head bearings should be smeared with
waterproof grease.

ENGLISH
15
1
2
3
4
15 mm
3,5 mm
5
A
A
8
min. 2,5 mm
7
6
8
How to change the handlebar position
The handlebar position can be readjusted by 22 mm. Thus, you can put the
handlebar to the position that is the most convenient for you. The upper tri-
ple clamp 1includes 2 bores arranged at a distance of 15 mm (0,6 in) from
one another. The bores at the handlebar support 2are offset from the cen-
ter by 3.5 mm (0.13 in). Accordingly, you can mount the handlebar in
4 different positions.
For this purpose, remove screws 3of the handlebar clamps and screws 4
of the handlebar support. Position handlebar support, and tighten screws 4
to 40 Nm (30 ft.lbs). Mount handlebar and handlebar clamps, and tighten
screws 3to 20 Nm (15 ft.lbs). The gap between handlebar support and
handlebar clamps is to be of equal size in the front and in the rear.
Replacing the battery of the digital speedometer
After approx. 2 years, the battery of the digital speedometer will be empty
and must be replaced. For this purpose, the speedometer must be
dismounted.
Remove headlight mask, and pull speedometer illumination system 5out
of the speedometer housing.
Use a screwdriver to lever the blue speedometer glass 6downward and
out of the speedometer housing 7. The two noses Amust be disengaged
from the speedometer housing. Remove screws 8, and take speedometer
out of housing.
Before you remove the battery, do not forget to write down the following
data:
– total kilometer reading (DST)
– wheel circumference (WS)
– Remove the battery cover on the back of the speedometer and detach the
batteries. The new batteries must be inserted with the plus pole on top.
– Make sure that the seal ring has the right position on the cover when
mounting the battery cover.
– Now total mileage, wheel circumference and time have to be entered.
To mount the speedometer, proceed by following the reverse order of the
above procedure.
Checking rubber ring on the WP rear shock absorber
A rubber ring mounted on the rear shock absorber serves as a vibration
damper. This ring gets pressed together with time and loses its shock ab-
sorbing quality.
Measure the distance between the two discs at various points around their
circumferences. The space should be at least 2.5 mm (0,1 in) wide. Have
the rubber ring replaced by an KTM dealer when compaction due to wear
has exceeded this lower limit.
!
CAUTION
!
NOT REPLACING THE RUBBER RING IN TIME CAN RESULT IN DAMAGE TO THE REAR SHOCK
ABSORBER.

WARNING

THE DAMPING UNIT OF THE SHOCK ABSORBER IS FILLED WITH HIGH COMPRESSED NITRO-
GEN. NEVER TRY TO TAKE THE SHOCK ABSORBER APART OR TO DO ANY MAINTENANCE
WORK YOURSELF. SEVERE INJURIES COULD BE THE RESULT.

ENGLISH
16
TOTAL MILEAGE „DST“
TIME „CLK“
after changing battery
1 sec
5 sec
1 sec
1. use the right button to select
the position to be changed
1. make sure the time is indicated
and push the button on the
back approx. 5 seconds (time
starts blinking)
2. push the left button until the right
figure is showed in the display
3. by pushing the right button you
jump to the next figure
4. repeat nos. 2 + 3 until correct time is indicated
5. push the button on
the back approx. 1
second to terminate
the setting procedure
2. push the left button until the right
figure is showed in the display
3. by pushing the right button
you jump to the next figure
4. repeat nos. 2 + 3 until the previously
noted total mileage is indicated
5. push the button on the back
with a sharp object approx. 1
second to terminate the set-
ting procedure (the value is
thus stored)

ENGLISH
17
Check/set distance of the magnetic sensor
The distance between magnet 2and sensor 1must be 2-4 mm, otherwise
malfunctions on the speedometer might occur.
This distance can be corrected by screwing in or off the sensor 1.
WHEEL CIRCUMFERENCE „WS“
1. make sure that the indication "TRP" is
active and push the button on the
back approx. 5 seconds ("WS"
appears)
2. use the right button to select the
position to be changed
3. push the left button until the right
figure is showed in the display
4. repeat nos. 2 + 3 until correct
wheel circumference is indicated
5. push the button on the back
for approx. 1 second to termi-
nate the setting procedure
5 sec
1 sec
mm x 3,14
km/h:
WS = mm x 3,14
mp/h:
WS = (mm x 3,14) : 1,61
1
1
2
Wheel circumference with standard tires
17” = 1882 mm / 21” = 2205 mm

ENGLISH
18
B
16:48
16:40 A = 0mm
16:45
17:38
30mm
A
3
A
Changing the spring preloading of the shock absorber
KTM sets the shock absorber for a driver only, weighing approximately
75 kg (165 lb). If you want to take a passenger with you, of if you weigh
considerably more or less than 75 kg (165 lb), you should change the spring
preloading Aaccordingly. This is easily done.
NOTE:
– Before changing the spring preload note down the basic setting, e.g.
how many threads are visible above the adjusting ring.
– One rotation of the adjusting ring 2changes the spring pretension by
approximately 1,75 mm (0,07 in).
Loosen the locking ring 1with the hook spanner from the tool set. Change
the spring preload with the adjusting ring 2and re-tighten the locking ring.
BASIC SETTING – SPRING PRELOAD
A = 23 mm (0,9 in)
Lubricate rear suspension linkage
The bearings in the link lever must be greased in regular intervals. For this
purpose, a lubricating nipple 3is mounted on the link lever.
!
CAUTION
!
AFTER EACH TIME THE MOTORCYCLE IS WASHED, IT IS ESPECIALY IMPORTANT TO GREASE
THE LUBRICATING NIPPLE TO PUSH ANY WATER OUT OF THE BEARINGS.
Checking chain tension
– For checking, put the motorcycle on its main stand or jack it up on its
frame so that the rear wheel is relieved of any load.
– Push the chain upwards appr. 30 mm (1,2 in) from the end of the chain
sliding component until the upper part of the chain is tensioned (see
illustration)
– Now, the distance Abetween chain and swingarm should be 0 mm res-
pectively 5 mm (0,2 in) (depending on final drive ratio). The upper part
of the chain Bmust be tight (see illustration).
– Correct chain tension, if necessary!

WARNING

–I
F CHAIN TENSION IS TOO GREAT, PARTS WITHIN THE SECONDARY TRANSMISSION
(CHAIN, SPROCKETS, DRIVE ASSEMBLY AND REAR WHEEL BEARINGS) WILL BE
SUBJECTED TO UNNECESSARY STRESS, RESULTING IN PREMATURE WEAR AND EVEN
CHAIN BREAKAGE.
–T
OO MUCH SLACK IN THE CHAIN, ON THE OTHER HAND, CAN RESULT IN THE CHAIN
JUMPING OFF THE SPROCKETS. IF THIS HAPPENS, THE CHAIN COULD ALSO BLOCK THE
REAR WHEEL OR DAMAGE THE ENGINE.
–I
N EITHER CASE THE OPERATOR IS LIKELY TO LOSE CONTROL OF THE MOTORCYCLE.
1
2
