1. Purpose
KUS Setup Tool for NMEA2000 is used for set SEAN series gauge and NS5 series sensor produced by KUS.
2. Tool Components
Quantity
1
1
Item
Set up tool
Power Adapter
3. Installing
3.1 Hardware installing, install the following chart ：
Overall wiring diagram
01
www.kusauto.com
4. Parameter
4.1 Parameter query
Use UP/DOWN to switch to Query interface.
Power on
（Product type)
Sub-product type Instance Tank volume
02
www.kusauto.com
4.2 parameter setting
4.2.1 For Product type
In product type query interface, long press MODE key until LCD flashes and release; Use UP/DOWN TO select the product
type( Sensor/Gauge); Long press MODE key again until LCD stops flashing.
Product type setting done.
Sensor Gauge
03
www.kusauto.com
4.2.2 For Sub-product type
In Sub-product type query interface, long press MODE key until LCD flashes and release; Use UP/DOWN to switch the sub-product
type; Long press MODE key again until LCD stops flashing.
Sub-product Setting completed.
Sub-product type
Sensor
Value
00
01
02
03
04
05
Type
Fuel
Fresh water
Waste Water
Live Well
Oil
Black Water
Value
00
01
02
03
04
05
Type
Oil level gauge
Water level gauge
Holding tank
Pressure gauge
Water temperature gauge
Voltage gauge
Gauge
The values specific to product
04
www.kusauto.com
4.2.3 Instance (Number) setting
In Instance query interface, long press MODE key
until LCD flashes and release; Use UP/DOWN to set
Instance(number); Long press MODE key again
until LCD stops flashing.
Setting completed
Instance
4.2.4 For tank volume (Only for fluid level sensor)
In Instance query interface, long press MODE key until LCD
flashes and release; Use UP/DOWN to set tank volume(L);
Long press MODE key again until LCD stops flashing.
Setting completed.
Tank Volume
05
www.kusauto.com
5. Parameter Sending
In Parameter Query interface, short press MODE key,
the set tool will send the setting information; In case
short press UP/DOWN during the sending process,
quit sending action.
Parameter sending
6. Setting completed
LCD will show the interface below automatically to remind
the setting is completed. Short press any key, go to next
setting.
Setting completed
06
