KXD LX-3L User manual

1

1
Read Me First
Dear user,
Thanks for purchasing this electric scooter. This electric scooter is
environmentally-friendly high-tech product as well as an ideal means of electric scooter
that features excellent shock absorption, streamlined appearance, portability and
flexibility, good riding comfortably, high safety and reliability. For better understanding of
the characteristics, technical parameters, correct use, maintenance and precautions of
this scooter, see to it that you read this user manual carefully before using it.
1. DO NOT use the scooter before learning about its performance
2. DO NOT lend your scooter to anyone who cannot operate it, juveniles, pregnant
women, or the disabled.
3. DO NOT arbitrarily discard spent batteries to avoid pollution to the environment; see
to it that they are handled by your distributor or service provider.
4. For sake of your own safety, please check whether the braking system functions well
before using the scooter.
5. For safety reasons, DO NOT cover the charge and keep it well ventilated during
charging.
6. When replacing a failed tire, note that the fasteners of the wheel are tightened in
case of a secondary accident due to wheel looseness.
7. For safe use of this product, DO NOT arbitrarily disassembles or modifies the circuit
or parts of the scooter.
8. In case of any abnormality, power the scooter off to stop it in order to ensure your
safety.
9. Images included in this user manual are intended for operation demonstration and
may not be used for the basis of product inspection.
10. In the event that images included in this user manual might not be in conformity with
the real product, the real product shall prevail.
11. Product performance and configurationthatmanbeimprovedfromtimetotimeare
subject to change without prior notice.
Enjoy your riding!

2
Content
1. Read ME First --------------------------------------------------------------------------01
2. Content --------------------------------------------------------------------------02
3. Asssembly Diagram -------------------------------------------------------03-04
4. Proformance ----------------------------------------------------------------------------05
5. Structural Diagram ------------------------------------------------------------------------06
6. Improper Use Cases -------------------------------------------------------------------07-08
7. Legal statement -------------------------------------------------------------------------09-10
8. Dashboard Instructions ----------------------------------------------------------------11-12
9. Parameters ---------------------------------------------------------------------------------13
10. How to Use and Precautions ------------------------------------------------14-15

3
Asssembly Diagram
Tools：
a---2.5#Allen Key 1pcs
b---4#Allen Key 1pcs
c---5#Allen Key 2pcs
d---10-12#Open End Wrench 2pcs
e---Hook Spanner Wrench 1pcs
Parts：
1---Front Fender
2---Flange Bolt M8X35，2pcs
3---Flange Bolt M8X25，2pcs
4---Self-Locking Nut M8，6pcs
Using Tools：
10-12#Open End Wrench 2pcs
Parts：
1---Front Fender
2---Flange Bolt M8X35，2pcs
3---Flange Bolt M8X25，2pcs
4---Self-Locking Nut M8，6pcs
5---Aluminum Borad
6---Connection Bridge

4
Using Tools：
5#Allen Key 2pcs
Parts：
7---Folder（Up）
8---Folder（Down）
9---Folder Pin
10---Flange Bolt￠8XM6X36
Using Tools：
4#Allen Key 1pcs
Parts：
11---Stem
12---Handebar
13---Bolt M5X16，4pcs
14---Display
15--- Power Off Switch

5
Proformace
Rear Self Balance System
Dolphin Prototype Bionics Design
Easy folding. Easy Taking
Display With 3 Speed
Power Off Switch
Accelerator
LithiumBattery ( 36V,4.0AH)
Charge & Switch off Button
Motor (36V,350W)

6
Structural Diagram
1 Accelerator 2 reducer 3 Folders 4 Motor wheel
5 Front fender 6 Charging mouth 7 Button switch 8 Battery box
9 Pedal 10 Rear wheel 11 Rear fender

7
Improper Use Cases

8

9
Legal statement
As you have been acquainted with this scooter with more riding skills, please:
1. Read this user manual carefully before using it for practice.
2. Those who haven’t read is user manual carefully in advance are not allowed to use this
scooter.
3. DO NOT charge when the slot/shock is wet. Charge the scooter with correct power supply
(100~240V/50~60Hz). While charging, keep children, pet or inflammables away from the
scooter.
4. Install all the parts of this scooter properly following this user manual, otherwise improper
installation may lead to control failure, collision or crash. Turn the power off before installation,
repair or maintenance.
5. DO NOT place the battery unit in the environment where temperature is higher than 50℃or
lower then -20℃.
6. In the event that the battery unit is damaged or hot, smells abnormally, or smokes, stop
using it immediately and keep it away from other objects.
7. DO NOT open or disassemble the batter unit that contains harmful substance.
8. The scooter that has been fully charged may stand by for 120-180 days, whereas the one
that is under charged may stand by 30-60 days. Please notice the stand–by time of your
scooter in case of unrecoverable damages to the battery unit due to untimely charging.
9. It is prohibited that you practice outdoor until you have been sufficiently familiar with the
operation methods of the scooter. The more times you practice, the safer you ca ride in new
circumstances. Please note the essentials of practice: what you need first is primary practice in
an obstacle-free area (≥10m×10m) to practice riding forward, making turns and stopping. Keep
yourself relaxed while practicing. When you practice for the first time, it is recommended that
you do this with the guidance of an experienced person or couch. Try to practice passing
narrow areas, turning and stopping as your practice deepens. You are not allowed to ride on
normal roads until you are able to control your scooter to pass a narrow area precisely and
have simulated all types of terrains. You may have a different experience every time you have
your electric scooter upgraded. Therefore, see to it that you practice in the same obstacle-free
area as if you were a beginner for the first time you ride the scooter after upgrading.
10. Check the scooter carefully to make sure there isn’t any loose part or damage before riding
it.
11. Watch the crossing carefully before or during you rid your scooter or when you stop it to
avoid any unnecessary damage to yourself, or object, people or small animals around you.
12. In the event that the tire works abnormally during riding, please stop and examine it in case
of danger.
13 DO NOT ride in high-heeled shoes.
14. DO NOT dip the battery and scooter frame into water, expose it to storms or ride in the rain
for along time. DO NOT clean the scooter with powerful water stream or a high-pressure water
gun to avoid waterlog in the charging port. In the event that your scooter is exposed to storms
for a long time, please stop using it immediately; wipe it with a piece of dry soft cloth, and
contact after-sale service personnel. Do not do anything other than wiping the scooter in case
of voided warranty due to any misconduct.
15. In the event of low battery, the scooter many not run at high speed continuously as

10
expected. You many charge it for better riding experience.
16. Note terrain changes while riding, such as road and grassplot.
17. Be careful while turning! You may lose control at fast turning.
18. DO NOT risk passing the abrupt slope, uneven surface or other unfamiliar terrains.
19. DO NOT ride on the motor way or run a red light. Follow traffic rules and give way to
pedestrians.
20. Strengthen your awareness of self-protection while riding. Watch out for yourself, vehicles
and pedest5rians.
21. Please ride the bikeway or at the edge of local government.
22. It is absolutely prohibited that you are towed by another vehicle with hand(s) on the vehicle
while riding.
23. DO NOT stunt while riding.
24. DO NOT ride your scooter in way of the following situations: severe weather, poor visibility,
at dawn, in the evening, in the dark, or exhaustion since an accident is more likely to occur in
event of any of these situations.
25. As you are higher while standing and riding helmeted on the scooter, watch out while you
are riding indoors, at the door or near any other place that is close to your head.
26. DO NOT wear loose clothes while riding in case they are entangled into the wheel.
27. DO NOT carry a passenger while riding. This scooter is designed for a single rider. It is
prohibited that it is ridden by two or by anyone carrying a baby.
28. DO NOT use your scooter to go upstairs/ downstairs, ride it into the elevator or cross the
revolving door.
29. DO NOT ride ion the highway unless it is allowed by local laws and regulations.
30. DO NOT use your scooter as a cargo carrier.
31. When approaching or crossing an intersection, motor way, turning or passing by a
door/gate, please slow down and give way to the pedestrians, bicycles and motor vehicles.
32. DO NOT ride your scooter when you fall ill or cannot fully comply with the instructions
specified in this user manual, or after you take medicine or drink alcohol.
33. To avoid distraction while riding, DO NOT make phone calls or do anything that might
distract you so that you are able to concentrate yourself on traffic.
34. Age requirement: 14-50 years old. Tips for parents: as a parent or a guardian, you are
responsible for your child’s activities and safety. It is highly recommended that your child is
kept away from the scooter.
35. Avoid abrupt braking, especially on smooth surfaces since this may lead to loss of traction
and increase the possibility of you falling off from the scooter.
36. Any modification to this scooter may undermine your safety of riding. Any unauthorized
modification to this scooter is prohibited.
37. You are obliged to be informed of and observe the laws of the place where you are located.
This statement applies to the laws of the people‘s republic of China.
We assume no responsibility for any claim, liability or loss incurred by or possibly incurred by
consumer’s violation of the clauses of the legal statement above. The rider by himself/herself
shall undertake the responsibility for any unpredictable or inevitable risk during riding.
You are free to continue to use our product if you accept the clauses set forth in our legal
statement or return it if otherwise.
Please make sure the product and its package areas intact they don’t impact resale before
returning the product to us.

11
Dashboard Instructions
Before you use please read the instruction following
1. Configuration
2. The keys
There has three key on the meter,, -power、-speed up、-slow down。
3. Operation
Press the forawhiletoturnonthemeter
，battery、speed shows according to the
electric vehicle running status, TRIP and ODO shows according to the different function
The meter would be cut off the power automatically if the meter has no signal input within
three minutes
Press the ，the meter will shows TIME，TRIP，ODO，DST，CHA，VOL. TIME-Riding
times, TRIP-trip A（press for awhile can clear the trip A data），ODO-trip odometer，
DST-remaining mileage（according to the Li-battery），CHA-recharge times（some can not
shows ）， VOL-current voltage (press speed up or slow down, change to the assistant
power(1st-fast speed, 2st-middle, 3st-slow speed)
Down handle, increasing speed, loosen handle, slow down.
Press for a while, the power would be turn off when the meter works.
4. Parameter setting
Press +for a while can enter setting. Then press , The meter can appear P0、
P1、P2、P3、P4、P5、P6、P7, you can use the different parameter setting. P0-undervoltage
setting, P1-wheel diameter setting, P2-number of Pole pair setting, P3-speed signal choose,
P4-kilometer and mile choose, P5-nonzero starting and zero starting(some without),

12
P6-cruise(some without), P7-hard starting and soft starting(some without).
a) When display shows P0，it’s under voltage setting, press or to modify setting.
b) When display shows P1， it’s wheel diameter setting， press or to modify setting
（mile）.
c) When display shows P2，it’s number of pole pairs setting, press or to modify
setting.
d) When display shows P3, it’s speed signal choose, set 1, choose motor holler signal
velocities; set 0, choose external speed signal.
e) When display shows P4, it’s kilometer/mile choose, set 0 is kilometer, set 0 is mile.
f) When display shows P5, it’s non-zero starting and zero starting , set 0 is zero starting,
set 1 is non-zero starting(some without).
g) When display shows P6, it’s cruise and no cruise, set 0 is no cruise, set 1 is cruise
(some without).
h) When display shows P7, it's hard starting and solt starting, set 0 is soft starting ,set 1 is
hard starting(some without).
i) When led shows P8, it means can increase the speed to max speed, determined by
percentage
j) Press +for awhile can exit the system, also can keep the setting data.
5. Malfunction setting
When electric scooter is not working ，the meter can shows which part maybe have
problem. There are brake system 、motor trouble 、handle turner trouble 、controller
trouble and so on.
6. Wire, lead wire abut upon the controller

13
Parameters
parameter Specification(36V) Specification(36V)
performance
Maximum speed 25km/h 20km/h
Maximum load 70kg 50kg
Net weight 14kg 13.5kg
Fold size 960mm*600mm*390mm 960mm*600mm*390mm
Full size 960mm*600mm*1080mm 960mm*600mm*980mm
Inner box size 1060mm*340mm*200mm 960mm*340mm*200mm
Carton size 1080mm*360mm*425mm 980mm*360mm*425mm
Handlebars adjust height / /
Renewal 10km 8km
Brake Distance 8m 8m
Age 14-40 10-16
Part
Motor power 350W 250W
Motor rating 36V 36V
Battery rating 36V 36V
Battery capacity 4.0Ah 4.0Ah
Charger input voltage AC100-240V~50/60Hz AC100-240V~50/60Hz
Charger output voltage DC 36-42V DC 36V
Charger output current 2A 2A
Charge time 4h 4h

14
How to Use and Precautions
(1) Safe use
1. In the benefit of you and the others, please read this user manual carefully before using the
scooter. DO NOT use it until you have adequate knowledge about its performance. DO NOT
lend it to whoever is unfamiliar with the operation of this scooter.
2. Please observe traffic rules consciously. Ride your scooter in the non-motor lane. DO NOT
carry a passenger.
3. Pleas brake in advance to ensure the scooter stops within an appropriate braking distance.
4. DO NOT ride in waterlogged area.
(2) Check before use
1. Check whether the wheels rotate well.
2. Check whether the battery has been fully charged.
3. Check whether the braking system works flexibly and make sure that the power is cut off
when braking.
4. Check whether the folding mechanism has been locked up.
(3) operation
1. Start the button switch on the left side of the battery box and then turn on the power switch
on the meter. Then regulate the speed threshold to an appropriate gear, press the speed
regulating handle slowly and rotate it to an appropriate position based on speed to keep the
scooter running at a safe speed.
2. Please keep the two feet one behind the other to make the human body in the most
appropriate position while riding.
3. Avoid frequent braking or startup while riding, which helps prolong the battery’ service life.
When decelerating, release the speed regulating handle until motor power is cut off.
(4) Use of battery and precautions
1. The battery unit consists of sealed li-ion batteries that feature long service life and leakage-
proof sealed structure. Considering the fact that the battery unit has been in storage for a long
time since it is manufactured, please make sure it is fully charged before using the scooter for
the first time. Recharge the battery unit timely in the event of low battery during riding. Have
the battery unit fully charged before long storage, and charge/discharge once a week if

15
possible.
2. Using the dedicated charger only, otherwise battery’s service life might be undermined.
Battery indication: obverse battery level while riding since the observed result in the stationary
state is inaccurate. Charge the scooter timely in the event of low battery indication.
3. DO NOT touch the metal contacts on the charger socket with hand or metal that may cause
short-circuit in case of accidents.
(5) Use of charger and precautions
1. Plug the charge’s out put terminal into charging hole on the battery unit, then connect the
charger to AC 100-200V/50-60HZ power supply and make sure charging indicator is on. To
avoid damage to the controller, power the scooter off during charging time that can last 3
hours.
2. Trip distance can decline at a low temperature.
3. Charging mode: it is recommended that the scooter be charged once a day if possible. The
whole charging process is automatically controlled: when the charging indicator turns to green,
it means the battery unit has been fully charged and is in a floating charge state. Floating
charging doesn’t cause any damage to batteries. At this point, it is unnecessary to stop
charging sine very little energy is consumed during floating charge.
4. In case of damages, avoid violent bump or impact when using, shipping or carrying the
charger. Keep liquid or metal filings away from the charger in case it is short-circuited or
damaged.
5. DO NOT place inflammables under the charger because heat is generated while it is
working. It is prohibited that the charger is covered or surrounded by anything so as not to
affect heat dissipation. The charger shall be used in a well-ventilated place. In the event that
there is peculiar smell, smoke, or excessive temperature (higher than 65℃)from/onthe
charger, stop charging immediately and have it repaired in the maintenance department.
6. In the event that the charging indicator doesn’t turn green for long time (generally longer
than 10 hours) while the charger is in the charging mode all the time, particularly along with a
high battery temperature due to charger failure, battery damage or low voltage, please stop
charging immediately and have the scooter repaired in the maintenance department.
7. For sake of adaptability between the charger and battery, please DO NOT charge your
scooter using chargers other than the dedicated one.
(6) Routine maintenance and precautions
1. Rotate the speed regulating handle slowly rather than violently.
2. DO NOT washing the scooter directly to avoid short-circuit of electric/electronic parts due to
moisture/water.
3. For safety sake, turn the main power switch off when parking the scooter.
4. Replace for a new brake pad when 1/3 of it has been worn out and braking effect is
impacted.
5. Remove the contaminants adhered to brake disc or other surfaces.
6. Check whether or not the electric part of power-cut brake is well connected and whether the
fasteners are loose. Make timely adjustment if any.
7. Make periodical examinations and maintenance, generally once every six mouths.
