iScooter i9 User manual

1. Package Contents 01
2. Product Overview 02
3. Charging 04
4. First Riding 04
5. Riding Basics 05
6. Riding Notice 06
7. Folding and Carrying 06
8. Disc Brake Adjustment 07
9. Daily Care and Maintenance 08
10. Specifications 09
Contents
11. Question & Answer 10
12. Contact Us 10
EN

When unboxing your i9 electric scooter, please verify that
the below items are included in the package. If anything is missing
or damaged, please contact iscooter customer service for support:
[email protected]
1 x Allen Wrench4 x Screws
1 x Charger
Package Contents
01

Handlebar
Brake
Folding Clip
Display
Folding Latch
Kickstand
Platform
Taillight
Disc Brake
Headlight
Pneumatic Tire
Product Overview
02

Tips
Power Button Click to turn on. Long press to turn off.
Battery Indicator
The power level is indicated by five battery bar on the control panel.
Light Turn on your scooter, one-click to turn on/off the front light.
Mode Double-click to switch power mode.
S
Cruise Control
Keep same speed for 3 seconds, and it will beep and active the cruise control.
Lock Indicator
The scooter can be locked and unlocked by MiniRobot app.
When the scooter starts to coast, put both feet
on the deck and press the accelerator (the
accelerator initiates once the coasting speed
exceeds 3 mph). Or you can connect the
"MiniRobot" APP, then, turn on the zero start.
S
Control Panel
03

Your scooter will be fully charged when the LED light on the charger
changes to green from red.
The scooter has charging protection and charging will cut off
automatically after fully charge.
Even so, we still don't recommend charging your scooter for a long
time more than 24 hours at one time.
Do not connect the charger if the charging port is wet.
Keep the charging port closed when not charging.
When the scooter starts to coast, put both feet on the deck and press
the accelerator (the accelerator initiates once the coasting speed
exceeds 3 mph). Or you can connect the "MiniRobot" APP, then, turn on the
zero start.
Download the "MiniRobot" app from the App Store(iPhone)
or Google Play (Android phone) for more information and
functions.
Charging
First Ride
04

1. Turn the power on, and check the electricity
indicator.
2. Stand on the base with one foot and propel
yourself with the other foot.
3. When the scooter starts to coast, put both
feet on the deck and press the accelerator
(the accelerator initiates once the coasting
speed exceeds 3mph)
4. Release the accelerator and the kinetic energy
recovery system (KERS) initiates automatically to
brake slowly; And squeeze the brake lever for a
sudden brake.
5. Tilt your body to the steering direction as you
turn, and slowly turn the handlebar.
Wear helmets and knee pads in case of falls
and injuries when you learn to ride the scooter,
as shown in the figure.
S
Riding Basics
05

The iscooter i9 electric scooter is a leisure device. But once they're in a public area, they'll be
seen as vehicles, subject ing to any risks faced by vehicles. For your safety, please follow
instructions in the manual and traffic laws and regulations set forth by government and regulatory
agencies.
● Respect pedestrians' Right of Way. Try not to startle them while driving, especially children.
When you ride from behind pedestrians, ring your bell to give them a heads-up and slow your
scooter to pass from their left (applicable to countries where vehicles drive on the right). When you
ride across pedestrians, keep to the right at a low speed. When you drive across pedestrians,
keep the lowest speed or getting off the vehicle.
● Closely follow the safety instructions in the manual. iscooter shall not be liable for any financial
losses, physical injuries, accidents, legal disputes and other interest conflicts resulted from
actions that violate user instructions.
● Check the scooter before every use. When you note loosen parts, low battery alerts, excessive
wear, strange sounds, malfunctions and other abnormal conditions, stop riding.
● WARNING – Risk of Fire – No User Serviceable Parts.
Make sure that the scooter's turned off. To fold, unlock the folding mechanism, and bend the handlebar
stem to hook the buckle on the rear fender. To open, press the bell trigger to remove from the buckle,
erect the handlebar and lock the folding structure.
1
2
Riding Notice
Folding and Carrying
06

To adjust the disc brake sensitivity:
You need the Allen wrench to loosen the screw on the rocker.
• When the disc brake is too sensitive, rotate the disc brake rocker down a bit. Then, reinstall
the screw back to the brake cable core to tighten.
• When the disc brake cannot stop, rotate the disc brake rocker up a bit. Then, reinstall the
screw back to the brake cable core to tighten.
Notice: The disc brake may squeak when in use until it is broken in. This is normal and does
not affect the brake's function or performance.
To remove the disc brake noise,
First make sure the scooter is turned off. For easier operating, we suggest
you put the scooter on the desk.
• Loosen two screws on the pump (not the screw on the rocker).
• Adjust the position of the disc brake pump to ensure that the brake disc is in the middle of
the two brake pads.
• Keep the brake disc and brake pad not touching each other.
• Hold the disk brake pump in the desired position, then retighten the screws to the pump.
Disc Brake Adjustment
07

If you see stains on the scooter's body, wipe them off with a damp cloth. If the stains
won't scrub off, put on some toothpaste, and brush them with a toothbrush, then wipe
them off with a damp cloth.
Notes:
• Do not clean the scooter with alcohol, gasoline, kerosene or other corrosive and volatile
chemical solvents to prevent dire damage.
• Do not wash the board with a high-pressure water spray. During cleaning, make sure that the
scooter's turned off, the charging cable is unplugged, and the rubber flap is closed as water
leakage may result in electric shock or other major problems. When the scooter not in use,
keep it indoors where it is dry and cool.
• Do not put it outdoors for a long time. Excessive sunlight, overheating and overcooling
accelerate the battery pack's lifespan．
1. Use original battery packs, use of other models or brands may bring about safety
issues;
2. Do not touch the contacts. Do not dismantle or puncture the casing. Keep the contacts
away from metal objects to prevent short circuit which may result in battery damage or
even injuries and deaths;
3. Use original power adapter to avoid potential damage or fire;
4. Mishandling of used batteries may do tremendous harm to the environment. To protect
natural environment, please follow local regulations to properly dispose used batteries.
5. After every use, fully charge the battery to prolong its lifespan.
1. Please try to store the scooter in a cool and dry place between 14℉ and 104℉. In
extremely humid environments the interior of the scooter may suffer condensation or
even water accumulation, which may damage the battery rapidly.Devices are not
intended for use at elevations greater than 2000 m above sea level Prolonged Exposure
to UV Rays, Rain and the Elements May Damage the Enclosure Materials, Store Indoors
When Not in Use.
2. In daily use, try to avoid recharging the scooter after completely exhausting the
battery. If the battery is low, charge it as soon as possible.
3. Please charge the scooter every other month to preserve the battery.
Cleaning and Storage
Battery Maintenance
Storage and Disposal
Daily Care and Maintenance
08

(1) The height of the body: Distance from the ground to the highest end of the body.
(2) Description of the battery life: It is measured under the condition of full charge, a load of
150 lb (68kg), at 77°F(24°C), on a flat road without wind, and at a speed of 9.3 mph.
The real battery life will differ with different factors of the load, humidity, wind speed and
operation habits.
(3) The maximum allowable weight shall be kept within 264 lb (120kg) (driver and objects
included) in any case. Consider an extra weight of the clothes or other accessories
with us during the trip and the gravity generated by speed, the scooter will not support
it if this load limit is exceeded.
i9
Dimensions
Weight
User
Scooter
Battery
Motor
Charger
Unfolded (Length. x Width x Height)
Folded (Length. x Width x Height)
Net Weight
Load
Recommended Age
Max.Speed
Max.Range
Max. Slope
Operating Temperature
lP Rating
Voltage
Max.Charging Voltage
Capacity
Nominal Power
Input Voltage
Output Voltage
Output Current
Charging Time
42*17*44 inch/108*43*112 cm
42*17*19 inch/108*43*50 cm
26.4 lbs/12 kg
264 lbs/120 kg
14+
18 mph/25 km/h
12-15mile/20-25km
15%
32-104°F(0-40°C)
IP54
36 V
42 V
7.5 AH
350 W
100-240 V
42 V
1.5 A
3-6 h
S
ltem Electric Scooter
Specifications
09

1. What if the E-Scooter arrived missing accessory or broken part?
A: Please take a photo and send to iscooter Support Team by sending
email: [email protected]. And iscooter Support Team will reply
you soon and send correct accessory or part replacement.
2. Is the tire replaceable and how to replace the tire?
Yes, the tire is replaceable. Please contact iscooter support team for more
information or search the video “How to replace the pneumatic tire”
in YouTube instead.
5. Why the screen returns an error code?
A: If you see any error code below, Please contact iscooter Support Team
to remove the error code.
4. What should I do when I hear an unusual noise coming from the rear wheel?
A: It usually means your disc brake tilt and cause friction noise. Please see
Disc Brake Adjustment page. If you still have problem, please contact us
for help.
3. What if the rear disc brake of the scooter doesn't work well?
A: You may please contact us for instructions of brake adjusting, or search
"How to adjust rear brake of scooter" in YouTube for tutorial video as well.
E04 Short Circuit Failure E13 Motor Phase C Current Sensor Failure
E10 Controller/Instrument Communication Failure E14 Accelerator Failure
E11 Motor Phase A Current Sensor Failure E15 Brake Failure
E12 Motor Phase B Current Sensor Failure E16 Motor Hall Failure
Question & Answer
Contact us if you experience issues relating to riding, maintenance and safety,
or errors/faults with your iscooter i9 electric scooter.
E-mail Service: [email protected]
Contact Us
www.iscooterglobal.com
10
