Kyocera FS-5800C User manual

1
BeforeYou Start
Cautions
To avoid machine malfunction, do not use the equipment under the following conditions:
• Direct exposure to sunlight
• Extremely high or low temperature [temperature range: 10˚C to 32.5˚C
(50˚F to 90.5˚F)]
• Extremely high or low humidity (humidity range: 20% to 80% RH)
• Condensation due to rapid change of temperature
• Areas of poor ventilation
• Areas of high dust or chemical
fume concentration (solvent etc.)
• Unstable or unlevel surfaces • Directly in front of air
conditioning vents • Liquids near the equipment
• Too much media which exceeds
the limit mark on the guide of
the tray.
• Front/right/left covers opened
while the printer is operating. It
may cause a media jam.
• We strongly recommend to use
only the original Kyocera toner
developer. Use of Kyocera toner
developer assures the intended
long term reliability of the printer.
Genuine or Original

2
BeforeYou Start
■CD-ROM
To prevent the CD-ROM from accidental damages:
• Do not touch or write on the
surface of the disc. • Do not leave the disc out of the protective case. • Do not leave the disc in direct sunlight or near heat sources.
• Do not place heavy objects on the
disc. • To clean the disc, hold the disc by its edges and wipe it from the
center to the edges with a dry,
soft cloth.
■Static Electricity Damage
To prevent static electricity damage to any of the following components, touch a grounded metal surface, such as the
printer’s bare metal frame prior to touching the component.
• The interface connectors: Parallel and optional network card
• Electrical components, connectors inside the printer and any components on the optional boards (RAM expansion
board, network interface board, etc.)
• The connector pins on the optional paper feeder for the printer
■Interface Cable
Always use a shielded interface cable. Use of an unshielded cable can result in radio interference with data.
■Waste Disposal Method
Waste material may be dumped or incinerated under conditions which meet the applicable environmental
regulations.

3
BeforeYou Start
Features
The FS-5800C Colour Laser Printer provides fast, high-quality colour printing on plain
paper, plus the ease of operation and high performance you expect from a laser printer.
Some of its features include:
■High quality
Resolution
Maximum 1200 dpi*
(*KPDL emulation only, with SIMM options installed)
■High speed
Continuous printing on various sizes of paper
Full-colour mode: Maximum 3.5 ppm (pages per minute)
Monochrome mode: Maximum 14 ppm
■Easy operation
Printer driver
Easily print full-colour documents.

4
BeforeYou Start
System Requirements
PC
To operate the FS-5800C effectively, refer to the following:
CPU: More than Pentium
(133 MHz or faster CPU is recommended.)
Operating System: Windows 3.1*1 / Windows 95*2 / Windows NT*3
RAM: 16 MB or more (More than 32 MB is recommended.)
Free disk space: 100 MB or more
Virtual memory: 16 MB or more (More than 32 MB is recommended.)
Display: Video card that can display more than 256 colours.
(A video card that can display more than 32,000 colours is
recommended.)
Drive: CD-ROM drive
*1 Microsoft®Windows®operating system Version 3.1 (hereafter Windows 3.1)
*2 Microsoft®Windows®95 operating system (hereafter Windows 95)
*3 Microsoft®Windows®NT 3.51/4.0 operating system (hereafter Windows NT)
Interface
■Parallel interface requirement
Interface
Based on the IEEE1284 standard(An ECP compatible paral-
lel port is recommended for Windows 95. To turn on the ECP
mode, use the computer’s BIOS setup. Refer to the comput-
er’s manual for details.)
■Network interface requirements
Manufacturer Model Applicable country
HBM HB-7SNMP Available in UK and France
Ethernet DPI EcoLAN 2000E Available in USA and Japan
SEH IC59-ETHER-KYO2 Other countries
Token Ring SEH IC69-Token-KYO2 All countries
See your nearest dealer of the manufacturer for availability.

5
BeforeYou Start
Minimum Space Requirements
Power Source
• The voltage level of the power source must not vary more than ±10% from the voltage
level marked on the nameplate (located on the back of the unit).
• Do not use an extension cord.
• Do not use a line conditioner, transient suppressor or surge protector as it may cause a
machine error.
Left Right
Rear
35 cm (13.8”)
Controller Board
Opening Space
45 cm (17.7”)
Multi-Purpose Tray
Opening Space
60 cm (23.6”)
Front cover opening space
50 cm (19.7”)
Media tray Opening
Space

6
BeforeYou Start
Unpacking
Make sure that all of the items shown below were provided and have not been damaged.
Report damage or shortages to the reseller from which the unit was purchased.
Note:
Save the original carton and packing materials for future shipping and transporting of
the unit. They have been specifically designed to protect the equipment during
shipment.
1. Printer (Colour imaging unit, Fuser kit, Paper cassette and Output tray are
included.)
2. Toner developers (black, cyan, magenta, and yellow)
3. Power cord
4. Kyocera Digital Library (Manuals, drivers, utilities) CD-ROM
5. Colour Calibration Reference card
123
5
4

7
BeforeYou Start
Part Names
■Front side view
■Rear side view
Front cover
Operation panel
Imaging unit
( ☞P. 12)
Fuser
( ☞P. 80)
Right side cover
Output tray
Media cassette
( ☞P. 16)
Power switch
( ☞P. 25)
Network interface card slot
Multi-purpose (MP) tray
( ☞P. 20)
Left side cover ( ☞P. 19)
[Media thickness switch*
( ☞P. 19)
Parallel interface
connector
( ☞P. 24)
AC inlet
( ☞P. 24) *Accessible by opening
the left side cover
Serial interface connector
( ☞P. 25)
Memory card connector
( ☞P. 51)
Harddisk access indicator

8
BeforeYou Start
Control Panel Overview
Message Display
The message display displays the printer’s operational mode. Messages which are
displayed and their meanings are given in the table below.
Message Meaning
Self test The printer is self-testing after power-up and is not ready to
print.
Please wait The printer is warming up and is not ready to print.
Ready The printer is ready to print.
Processing The printer is processing print data or in the middle of printing.
Waiting The last page remains unprinted. The printer waits awhile and
eventually generates a form feed allowing the last page to be
printed. (The length of time depends on the form feed timeout
setting.) The printing will begin immediately when the Form
Feed key is pressed. If a memory card is being used this can in-
dicate the printer is waiting for data to be written (☞P. 51).
FormFeed TimeOut An automatic form feed has been generated.
Ready
PAR 600 A4 001

9
BeforeYou Start
Interface Indicator
The interface indicator indicates the interface over which data is currently being received
or was last received. The current interface is indicated by one of the following messages:
Display Description
PAR Parallel interface
SER Serial interface
OPT Optional interface (if a network interface card is installed)
Note:
The display will blink while the printer is receiving data and continue blinking until
the interface is released, even after data transmission is finished.
Resolution Indicator
This shows the current printing resolution in either 1200 or 600 dpi (dot-per-inch).
Paper Size Indicator
This indicator indicates the paper size of the cassette currently selected. The following
abbreviations are used to indicate the paper sizes:
Indicator Paper Size
A4 ISO A4 (21 ×29.7 cm)
EX Executive (7-1/4×10-1/2inches)
B5 JIS B5 (18.2 ×25.7 cm)
LT Letter (8-1/2×11 inches)
LG Legal (8-1/2×14 inches)
b5 ISO B5 (17.6 ×25.0 cm)
Copy Indicator
This indicator indicates the number of copies to print from 001 to 999. This number is
reduced as printing proceeds.

10
BeforeYou Start
ON LINE
DATA
ATTENTION
Symbolic Indicator
This printer icon includes the indicators which show the following information regarding
the printer’s paper and toner status.
Name Description
Face-down indicator This indicates when printed pages are delivered to the output
tray in the face-down stack (correct order). The pages are deliv-
ered in the reverse order when this indicator is not lit. If flash-
ing, it indicates that paper is jammed on the output tray.
Toner indicator This indicates the status of toner supply in either colour of
cyan, magenta, yellow, or black. The toner supply is normal
when this indicator is off. If flashing, the toner supply is dwin-
dling. If this is lit, it indicates that the printer is out of toner
and not operative until the appropriate toner cartridge is re-
placed (☞P. 73).
Cassette feed This indicates paper is being fed from the media cassette.
indicator When flashing, it indicates that there is no media in the
cassette or that media is jammed in the media cassette.
Multi-purpose feed Indicates when media is fed from the multi-purpose feed tray.
indicator If this is flashing, it indicates that there is no media in the tray
or that media is jammed on the multi-purpose tray.
ON LINE indicator When lit, it indicates that the printer is on-line (The printer
prints received data). When this is off, the printer is offline
(The printer stores but does not print received data).
DATA indicator This indicator flashes when data is arriving at the printer’s in-
terface. When lit continuously, it indicates that data is being
processed for printing (or that data is being written to the
memory card).
ATTENTION indicator This indicator indicates a problem that may be resolved by the
user is taking place. When flashing, it indicates that the print-
er needs maintenance (☞P. 73). When lit, it indicates that the
printer cannot print due to an error.

11
BeforeYou Start
Control Keys
Key Function
ON LINE This key toggles the printer on-line and off-line.
CANCEL This key cancels the data processed in the printer during print-
ing. When the printer is in a mode selection sequence (See
MODE key below), pressing this key abandons mode selection
in course.
STACK/+ • This key selects whether to output media face-down (printed
side down) or face-up (printed side up).
• During a mode selection sequence, this key is used to select
menus and change setting values.
FEED/- • This key selects the paper feed cassette or multi-purpose tray
as the paper source. It can also select an optional feeder if
one is installed.
• During a mode selection sequence, this key is used to select
menus and change setting values.
CONTINUE/ • In normal operating mode, this key forcibly cancels errors
and resumes printing when printing is halted due to errors
such as memory overflow.
• This key functions as the key during a mode selection
sequence: It moves the selection upward in the menu hierar-
chy or moves the cursor left.
EXIT/MODE This key is used to start and end a mode selection sequence.
(☞P. 35)
FORM FEED/ • In normal operating mode, this key is used to forcibly form-
feed when a print timeout occurs.
• This key functions as the key during a mode selection
sequence: It moves the selection downward in the menu hier-
archy or moves the cursor right.
ENTER/STATUS • In normal operating mode, this key prints a status page.
• During a mode selection sequence, this key confirms the set-
ting made in the mode selection.
Notes
• Menus set using these keys are enabled only for the interface currently indicated on
the message display.
• Settings made from the control panel may be automatically switched to different
settings by application software being used.
