Kyocera EcoLAN 3000E User manual

Network Connectivity for Kyocera Printers
Kyocera EcoLAN 3000E
Quick Configuration Guide

FCC Notice:
This equipment complies with Part 15 of FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Trademarks
Kyocera®isaregistered trademarkof KyoceraCorporation. NetWare®isa registered trademark of
Novell, Incorporated. Windows®is a registered trademark of Microsoft Corporation. Macintosh®is a
registeredtrademarkofApple Computer, Incorporated. PostScript®andAcrobat®areregistered
trademarksofAdobe Systems, Incorporated. Allotherproducts referenced aretrademarks or registered
trademarksoftheirrespectivecompanies.
Thank You
Thank you for choosing the award winning Kyocera network printing products. We are
sure you will appreciate the high performance and low cost of ownership that are the
hallmarks of Kyocera products.

Contents
Introduction......................................................................... 4
Using the CD ROM ............................................................. 4
Supported Kyocera Printer Models................................... 5
EcoLAN 3000E Hardware Installation ................................ 5
NetWare 2.x & 3.x Configuration ....................................... 6
NetWare 4.x & 5.x Directory Services Configuration ....... 7
Macintosh Configuration ................................................. 10
Windows Peer to Peer Printing Configuration ............... 12
Windows NT 4.0 Configuration........................................ 14
DHCP Configuration (Dynamic Host Configuration Protocol) .......... 16
WINS Configuration (Windows Internet Naming Service) ................ 17
UNIX Configuration ........................................................... 18
IP Address Setup with the Printer Front Panel............... 19

Introduction
The EcoLAN 3000E is the next generation Kyocera internal network interface card
allowing easy installation without removing the printer mainboard. Its features include:
rEasy Slide-in Installation rMultiple Protocol Support
r10/100 Mbps Ethernet Interface rSNMP Support
r10BaseT / 100BaseTAuto Detection rFlash Upgrade Capability
rSetup with the Printer Front Panel rWINS Support
rDHCP Support forAutomatic IP rHTTP Server for Management
AddressAssignment with a Browser
The EcoLAN 3000E enables Kyocera FS-Series and LS-Series printers to communicate
over an Ethernet network with many different network operating systems, including
NetWare, Macintosh, UNIX, and Windows.
This Guides Role
This Quick Configuration Guide provides concise software configuration instructions
allowing an experienced system administrator to get the 3000E up and running quickly.
For more complete instructions or for printing or configuration options not covered in this
guide, please refer to the 3000E Users Manual on the CD ROM.
Using the CD ROM
The CD ROM packaged with the 3000E includes all installation and configuration utilities,
as well as the 3000E Users Manual and this guide in .PDF format. Quick access to the
utilities and documentation is provided by the CONTENTS.PDF file. This file and all other
documentation on the CD ROM are in Adobe Acrobat .PDF format and cannot be read
withoutAdobeAcrobat Reader 3.0 or later. (Note: The utilities may also be installed
without using CONTENTS .PDF by navigating the CD ROM to the appropriate setup file.)
On Windows 95, 98 and NT 4.0 systems, inserting the CD ROM will auto-load a screen
with options to installAcrobat Reader or to display CONTENTS.PDF. The user will be
prompted to installAcrobat Reader if it is not detected on the system.
On other systems, Acrobat Reader may be installed manually from the CD ROM.
Windows NT 3.51: From the Program Manager File menu, select Run and type:
D:\acroread\win\rdr_srch\32bit\setup.exe
Windows 3.1, 3.11: Same as NT 3.51, but type: D:\acroread\win\rdr_srch\16bit\setup.exe
Macintosh: Run the Reader 3.01 Installer in the Acroread, Mac, Reader + Search,
Reader folder. It is also very useful to install the search capability from the Search folder.
UNIX: See instguid.txt in the acroread/unix/rdr_search directory on the CD ROM.
OnceAcrobat Reader is installed, launch the Contents.PDF file on the CD ROM.
4

Supported Kyocera Printer Models
The EcoLAN 3000E is compatible with the FS/LS-600, 680, 800, 1700+, 3700+, 5800C,
6700, 7000+, 9000 and any other Kyocera printer with the slide-in interface. The 3000E is
compatible with the upper (hard disk) interface slot of an FS/LS-7000 with a Software
version of 25.05 or later. The Software version is displayed on the printer status page.
The EcoLAN 3000E is NOT compatible with previous FS/LS-Series models, including,
FS/LS-400, 850, 1500/A, 1550/A/+, 1600/A/+, 1700, 3400/A/+, 3500/A, 3600/A/+, 3700,
5500, 6500/+.
EcoLAN 3000E Hardware Installation
The 3000E is a new slide-in interface board which does not require the removal of the
printers main board for installation. These instructions describe the installation into the
FS-800 but are similar for any Kyocera printer with the slide-in interface.
1. Remove the two screws securing the interface slot cover on the rear panel
(shown) or side panel (not shown) of the printer and discard the interface slot cover.
2.Align the edges of the 3000E board with the rails in the interface slot and slide
the 3000E into the printer. Secure with the two screws removed in Step 1.
5

6
NetWare 2.x & 3.x Configuration
1. Login as Supervisor and start PCONSOLE.
2. Define the Print Queue.
êIf a Print Queue already exists that will be assigned to the 3000E, skip to step 3
êSelect Print Queue Information from the Available Options menu.
êPress INSERT, type a name for the new queue to be serviced by the 3000E
and press ENTER. Press ESCAPE to return to theAvailable Options menu.
3. Define the Print Server.
êSelect Print Server Information from theAvailable Options menu.
êPress INSERT, type the 3000E Print Server name and press ENTER. The Print
Server name may be found on the 3000E status page under Novell Network
Information. Press the Status key on the printer front panel to print a printer
status page and a 3000E status page.
4. Define the Printer.
êPress ENTER with the new Print Server highlighted, select Print Server
Configuration, then select Printer Configuration.
êSelect Printer 0 and define a more meaningful name for the printer if desired.
The printer name is displayed in various NetWare printing messages, such as
when notifying users that their job is completed.
êSet the TYPE field to Remote/Other Unknown.
êPress ESCAPE to exit and select Yes to save the changes. Press ESCAPE
again to return to the Print Server Configuration menu.
5. Assign the Print Queue.
êSelect Queues Serviced By Printer, highlight the 3000E printer on the
Defined Printers list and press ENTER.
êPress INSERT to display theAvailable Queues list. Select the desired queue
and assign a Priority level (recommended choice is 1).
êPress ESCAPE several times to exit PCONSOLE.
6. Confirm Successful Configuration.
êTurn the printer off and then on. Wait 2 minutes and press the Status key on
the front panel. This will print a printer status page and a 3000E status page.
êThe Novell Connection Information in the bottom half of the status page
displays the printer name, file server, queue, etc. If it displays Attached: Yes,
this confirms that the 3000E Print Server is ready to accept print jobs.
êIf the status page does not display Attached: Yes, please verify that the Novell
Print Server Name on the status page under Novell Network Information
matches exactly with the Print Server name that was entered in PCONSOLE or
refer to the troubleshooting section in the Users Manual.

7
NetWare 4.x & 5.x
Directory Services Configuration
NetWare Directory Services (NDS) configuration is accomplished using two utilities; 1)
NetWares NWAdmin is used to define the required Directory Services objects, and 2)
the 3000E parameters are configured with the Windows-based ManagementAccess
Program (MAP) if using IPX or with a web browser if using IP.
NWAdmin Configuration
1. Enter NWAdmin and browse the tree to the container which will hold the print
objects. Note: You must have the Object Create right in this container or you will be
unable to create the print objects. Right click on the container and select Details.
The top of the Identification page displays the Name of the container. This is the full
path or context of the current container (e.g., Sales.Dallas.Acme). Make a note of
this context in the space below as it will be needed during the 3000E configuration.
Close the Details window.
Print Server Context: _______________________________
2. Select Print Services Quick Setup from the Tools menu.
êEnter the desired names for Print Server, Printer, and Queue. Make a note of the
Print Server name in the space below as it will be needed during the 3000E
configuration.
Print Server Name: ________________________________
êIn the Printer Type field select Other/Unknown from the list.
êIn the Print Queue Volume field select the desired NetWare volume which will
contain the queue. The selected volume should have sufficient disk space to
spool large print jobs.
êClick Create to complete the Print Services Quick Setup.
3. Optional: Right click on the Print Server, Printer, or Queue objects and select
Details to define a Print Server password, select Printer notification options, or to
assign Queue users. If a Print Server password is defined, make a note of it as it
must be duplicated exactly during the 3000E configuration.
Print Server Password: ________________________________

8
NetWare Directory Services Configuration continued...
3000E IPX Based Configuration
IPX configuration is accomplished using the Management Access Program (MAP).
1. Install and Run MAP.
êInsert the CD included with the EcoLAN 3000E.
êIn Windows 95, 98 or NT 4.0, click on Start and select Run, or in the
Windows 3.1 or NT 3.51 Program Manager, select File and choose Run.
êType: D:\MAP\SETUP.EXE (where D = CD drive letter) and click OK.
êOnce installed, double click on the MAP icon to start the program.
2. Select the EcoLAN 3000E to Configure.
êClick on the arrow next to the Server dialog for the list of available EcoLAN
cards displayed by unit serial number. To display the name and other details of
the EcoLAN cards, select Show All from the Options menu.
êClick on the 3000E to be configured.
3. Continue with the 3000E IP and IPX Common Configuration section below.
Note: If the 3000E Does Not Appear on the List
If your network is using multiple IPX frame types, and the workstation running MAP
and the 3000E are NOT using the same frame type, then the 3000E will not appear in
the list.Acommon scenario is that the workstation frame type is set toAuto and is
using frame type 802.2 while the 3000E is using frame type 802.3. The 3000E frame
type can be changed using the printer front panel. See the instructions on page 19 for
setting the IP address with the front panel, but go into the NetWare submenu rather
than the TCP/IP submenu.
3000E IP Based Configuration
1. Set the printers IPAddress, Subnet Mask, and Default Gateway with DHCP(page
16) or with the printers front panel (page 19).
2. Connect to the 3000E with a web browser by entering the IP address as the URL,
e.g. http://206.129.6.54
3. When the 3000E home page is displayed, select 3000E Configuration and
continue with the instructions in the next section.
3000E IP and IPX Common Configuration
1. Password Protection
Many of the configuration options are password protected. The default password
is: sysadm The password is case sensitive. To change the password, select
Change Password in the System column.

9
2. NetWare Configuration.
êSelect Setup NetWare in the Protocols column.
êEnter the Print Server Name, Preferred NDS Context, and Print Server
Password (if a password was defined) exactly as they were entered in
NWAdmin. Note: Entries are not case sensitive (except the sysadm pass-
word). Preferred Bindery File Server and Preferred NDS Tree should remain
blank unless Bindery mode is used or if the network includes multiple NDS
trees.
êIf not using Bindery emulation, click the Disable Bindery box.
êType the password, sysadm, in the appropriate box and click Accept
Settings. After a few seconds the screen should report that the update was
successful. Click the BackArrow icon twice to return to the 3000E Configura-
tion page.
êThe changes made to the 3000E do not take effect until the unit is reset. Click
on Reset in the System column, then click on the Reset Unit button. After a
few seconds the screen should report that the unit was reset.
3. Confirm Successful Configuration.
êReconnect to the 3000E.After the Reset, the program advises waiting 2
minutes before reconnecting, but the 3000E may be available sooner.
êAt the 3000E Configuration page, select Unit Status in the System column.
êScroll down to display the NetWare status. The Queue Status should be
Attached.
êIf the Queue Status is not Attached, please verify that the entries for Print
Server Name, Preferred NDS Context, and Print Server Password match those
defined in NWAdmin or refer to the troubleshooting section in the Users
Manual.

10
Macintosh Configuration
KPDL, Kyoceras PostScript compatible mode is required for Macintosh printing. KPDL
is standard on many Kyocera printers, however, it is optional on the following models:
FS-600, FS-680, FS-7000 and all LS (Japanese) models. If KPDL is installed, it will
appear in the Emulation list in the following procedure and on the printer Status Page.
Setting KPDL Emulation
For all printers except the FS-600 and FS-680, the default emulation for the Option
Interface must be set to KPDL or KPDL (Auto).
1. Press the MODE key. If the first line of the LED panel does not already display
INTERFACE, press the + or
-
key until INTERFACE is displayed.
2. If the line below INTERFACE does not already display OPTION (OPTION 2
on the FS-7000), press the ENTER key, then + or
-
until OPTION is displayed
and press ENTER.
3. Press + or
-
until Emulation is displayed. Press the ENTER key. A question
mark will appear next to the current emulation.
4. Press + or
-
until KPDL or KPDL(Auto) is displayed. If the printer will be
receiving only KPDL jobs, set the emulation to KPDL. If it will also be receiving
non-KPDL jobs, set it to KPDL (Auto). PressENTER to set the new emulation.
5. Press the MODE key to exit the menu system.
Naming the Printer and Setting the Zone
The 3000E has a default name of KYO_<serial#>, e.g. KYO_163479. This may be
changed to a more user friendly name using a standard web browser. Connecting with
a browser requires TCP/IP to be setup on the printer and the Macintosh. If TCP/IP is
not in use, the name may be changed using the KyoManage utility included on the
3000E CD. See the Users Manual for KyoManage instructions.
1. Set the printers IPAddress, Subnet Mask, and Default Gateway with DHCP or with
the printers front panel procedure on page 19.
2. Connect to the 3000E with a web browser by entering the IP address as the URL,
e.g. http://206.129.6.54
3. When the 3000E home page is displayed, select 3000E Configuration.
4. Select Setup AppleTalk in the Protocols column.
5. Enter the Printer Name. Enter the Zone Name if other than the default zone.
6. Type the password, sysadm, in the appropriate box and click Accept Settings.
After a few seconds the screen should report that the update was successful.
7. Click the BackArrow icon twice to return to the 3000E Configuration page. If
NetWare is not in use, it may be disabled under the Setup NetWare option. Be
aware that Windows IPX Peer to Peer printing requires NetWare to be enabled.
8. The new printer and zone names do not take effect until the 3000E is reset. Select
Reset in the System column, then click on Reset Unit.
