Kyvol EA200 User manual

Ultrasonic Cool Mist
Humidifier
User Manual • Uživatelský manuál •
Užívateľský manuál • Használati utasítás •
Benutzerhandbuch

2
English
3-26
Čeština
27-50
Slovenčina
51-75
Magyar
76-100
Deutsch
101-125

3
The product user guide contains product features, how to use, and the operating
procedure. Read the user manual carefully to get the best experience and avoid
unnecessary damage. Keep this manual for future reference. If you have any questions
or comments about the device, please contact the customer line.
✉www.alza.co.uk/kontakt
✆[phone]
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz

4
Important Safety Instructions
Please read these IMPORTANT SAFETY INSTRUCTIONS before using EA200(WIFI). You
may avoid some issues during use of the product by doing so but following the
instructions completely to operate the humidifier is not a must.
Before Using the Humidifier
Check the Power Cord for any signs of
damage. If yes, please do not use the
humidifier.
DO NOT place the humidifier in a wet
environment.
Please always keep the humidifier out of the reach of patients, child ren, and pets.

5
Please always place the humidifier on a
smooth, flat, lint-free, non-metallic,
waterproof, and level surface; avoid the
direct sunlight.
Always place the humidifier ≥2 feet (60
cm) above the floor, and ≥12 inches (30
cm) away from the wall, other appliances,
or wooden furniture.
DO NOT place the humidifier on a
carpet, towel, or wood surface;
otherwise, it will stove, block the vent
and may damage the product.
DO NOT place the humidifier near open
flames and heat sources, such as flames
and heat sources, such as

6
When Using the Humidifier
DO NOT plug the power cord into an
outlet with wet hands.
DO NOT plug the power cord into an
outlet with wet hands.
DO NOT cover the Nozzle with your hand
or any other objects when the humidifier
is on to avoid damage to the product or
injury.
DO NOT clean the humidifier when it is
connected to a power source or when it is
turned on.
DO NOT move or tilt the humidifier
during operation.
The recommended comfortable
environment humidity is between 40% -
60%. Please adjust the mist as needed.

7
After Using the Humidifier
Always disconnect the power supply by
unplugging it when the humidifier is not
in use.
The humidifier requires regular cleaning.
Please refer to the instructions mentioned
in the section of Maintenance and Care.
DO NOT clean the humidifier immediately
after turning it off. Allow the humidifier to
cool down completely before cleaning.
DO NOT attempt to repair or adjust any
electrical/mechanical functions of the
humidifier by yourself.
Packing List
•Humidifier EA200(WI FI) X1
•Cleaning Brush X1
•Dustproof Sponge X1
•User Manual X1

8
Specifications
Model
EA200(WIFI)
Operating Voltage
AC 220 - 240V; 50/60Hz
Rated power
Min.:15W/Max.:30W
Water Tank Capacity
4.5L/1.18Gal
Dimensions
375x208x168 mm / 14.76x8.19x6.61 inches
Net Weight
1555g / 54.8 oz
Product Overview
Nozzle
Water Tank
Power Cord
Water Level Indicator /
Wi-Fi Status Indicator
Control Knob
Base

9
Tank Cap
Odor Filter
Water Inlet
Dustproof Sponge
Air Inlet
Air Outlet
Water Reservoir
Atomizer
Water Floater
Handle

10
Operationg Guide
Add Water
1. Remove the Nozzle first, separate the Water Tank from the Base, turn the Water Tank
upside down, loosen the Tank Cap, then fill the tank with clean cool water.
2. Tighten the Tank Cap, put the Water Tank upright and back on the Base.
Important
•If the tap water is too hard, we recommend using the filtered or distilled water to
avoid white dust. DO NOT use hot water.
•DO NOT add any essential oils or medicinal tablets into the Water Tank.
•DO NOT add water into the Base or through Nozzle.
•DO NOT move the humidifier while the Water Tank is full of water to avoid
leakage or Base overfilling.

11
Power ON / OFF and Mist Adjustment
1. Plug the Power Cord into a socket.
2. Rotate the Control Knob clockwise to ON/MIN to turn on the humidifier. The Water
Indicator will turn solid green and the is at the minimum level.

12
3. Continue rotating the Control Knob clockwise from ON/MIN to MAX to Level steplessly
increase the intensity of mist.
4. Rotate the Control Knob counter clockwise from MAX to ON/MIN to reduce the
intensity of mist.

13
5. Rotate the Control Knob counter clockwise to OFF to turn off the humidifier, and the
Water Level Indicator will be off.
Low Water Protection
When there is not enough water in the Water Reservoir, the Water Level Indicator will
turn red. The humidifier stops misting to prevent it from overheating and damaging the
Atomizer

14
Operating Via Kyvol App
This operation is available for AF600 (with Wi-Fi) ONLY.
App Downloading and Installation
Option 1:
Search for Kyvol from App StoreTM,/Google PIayTM ,then download and install it on your
mobile device.
Note:
Google PlayTM is a trademark of Google Inc., and App StoreTM is a trademark of Apple Inc.
Option 2:
Scan the QR codes below to download and install.
For iOS
For Android

15
App Registration and Login
Launch Kyvol APP, register an account with your mobile phone number or a valid email
address at your first use, then log in.
Note:
For a successful connection, please allow Kyvol APP to use your WLAN & Cellular Data
when running it.
Connection Mode
Important
For the humidifier:
Make sure the humidifier has been plugged into a socket.
For Wi-Fi network:
1. Before connecting, please turn on location service/GPS on your phone and grant all
the permissions required by Kyvol App.
2. Make sure your mobile device is connected to a 2.4GHz Wi-Fi.
3. Make sure you've entered the correct Wi-Fi name and password when connecting.
4. Make sure the humidifier, your mobile phone and your router are close enough when
connecting.
1. Bluetooth Mode
•Connect the power cord of the humidifier to a socket.
•Launch Kyvol App, and tap Add Device.
•Tap Humidifier, then select the model.
•Tap Next on the Bluetooth Mode page.
•Turn on the Bluetooth and Location access on your mobile device.

16
•Quickly rotate the Control Knob from OFF to ON, then from ON to OFF three
times. The WiFi Status
Indicator will keep flashing red, which means the humidifier is ready for network
connection.
•Tap Search.
•Select the device model and tap Connect.
•Select WiFi and enter the correct password; tap Confirm.
•Connecting.
•Connected. The WiFi Status Indicator will turn solid.
2. Wi-Fi Mode
•Connect the power cord of the humidifier to a socket.
•Launch Kyvol App, and tap Add Device.
•Tap Humidifier, then select the model.
•Turn on the Location access on your mobile device. Tap Wi-Fi Mode, then tap
Next.
•Quickly rotate the Control Knob from OFF to ON, then from ON to OFF three
times. The Wi-Fi Status
indicator will keep flashing red, which means the humidifier is ready for network
connection.
•Select Wi-Fi and enter the correct password; tap Confirm.
•Connecting.
•Connected. The Wi-Fi Status Indicator will turn solid on.
Power ON / OFF
Step 1:
Launch Kyvol App.
Step 2:
Select Power On/Off.

17
Mist Adjustment
Step 1:
Launch Kyvol App.
Step 2:
Select Mist Level.
Maintenance and Care
Important
•DO NOT submerge the Base in the water.
•Make sure the water does not enter the Base through the Air Outlet, Air Inlet or
Control Knob.
•DO NOT wash any part of this humidifier in the dishwasher; otherwise, it will
damage the humidifier.
Daily Maintenance
Step 1:
Turn off the humidifier and unplug the Power Cord from the socket.
Step 2:
Drain water from the Water Tank, Water Reservoir, and Base.

18
Weekly Maintenance
1. To property clean your humidifier, we recommend that you remove scale and
disinfect the humidifier separately.
2. DO NOT mix vinegar and bleach solution together. To avoid damage to the humidifier,
do not use more than 1 teaspoon of bleach per gallon of water.
3. Please make sure the white sealing ring on the Tank Cap is installed correctly after
cleaning to avoid water leakage.
Scale Removal Instructions
Step 1:
Turn off and unplug the humidifier.
Step 2:
1. Separate the Water Tank from the Base, then remove the Tank Cap. Make sure that
the white Sealing ring does not come off.
2. Drain water from the Water Tank and Base, then remove all accessories and set aside.
Step 3:
1. Fill the Water Tank halfway.
2. Add in 1 teaspoon of undiluted distilled white vinegar.
3. Attach the Tank Cap and shake for 15 seconds.
Step 4:
1. Place the Water Tank back to the Base.
2. The vinegar solution will enter the Water Reservoir to loosen mineral scale on the
Atomizer, Water Floater, and the bottom of the Water Tank. Leave it for 15-20minutes.
Step 5:
1. Uncap the Tank Cap and drain the solution.
2. Wipe the Atomizer and floater with a soft cloth to remove loose mineral deposits.

19
Step 6:
Flush both the Water Reservoir and Water Tank until the smell of vinegar ( for scale
removal) or bleach solution (for disinfection, see below) is gone.

20
Disinfection Instructions
Step 1:
Follow steps 1 to 2 in the previous section for scale removal.
Step 2:
1. Fill the Water Tank halfway.
2. Add '/2 teaspoon of bleach.
3. Attach the Tank Cap and shake for 15 seconds.
4. Place the Water Tank back to the Base. The bleach solution will enter and disinfect the
Water Reservoir and the other components. Leave it for 15-20 minutes.
Step 3:
Follow steps 4 to 6 of the previous section for scale removal to complete the disinfection
of the humidifier.
Dustproof Sponge Cleaning
Clean the Dustproof Sponge (located at the bottom of Base) with water or detergent
once a month, then put it back in place after cleaning.
End-Of-Season Care and Storage
1. Follow the cleaning instructions when the humidifier will not be used for at least one
week, or at the end of the season. Remove all accessories used in the humidifier. Allow
the humidifier and accessories to dry completely before storing it.
2. DO NOT store water in the Base, Water Reservoir or Water Tank.
