La Crosse Technology C79790V2 User manual

SET UP GUIDE
MODEL NUMBER C79790V2
WIRELESS WEATHER
STATION

Table of Contents
02
Initial Setup
Power Up
Note: It may take up to 10 minutes for your sensor data to appear on your
station’s screen.
BASICS
1. Install 3 “AA” batteries into the Battery
Compartment of your Breeze Pro
Sensor.
2. Insert the 5V Power Adapter into
an outlet, and then plug it into the
Power Jack on the back of the
station. Next, remove the Insulation
Tab from the station’s Battery
Compartment.
Bottom of Breeze Pro Sensor
Model No. LTV-WSDTH03
Back of Station
Model No. C79790v2
WINDBASICS
TEMP. & HUMIDITY (TH)
LA CROSSE VIEW
FORECAST PRESSURE
APPENDIXEXTRA SENSORS SUPPORT
Viewing Your Wind Data
History Records
Wind Speed Alert
Initial Setup
Station Settings
Buttons
LCD Display Brightness
Auto-Dim Settings
Positioning Your Sensor
Basic Installation Options
Viewing Your TH Data
History Records
“Feels Like” Temp.
Connecting to the App
Connecting Your Station
Connecting Your Sensor
Seasonal Trees
Standalone Forecast Icons
Enhanced Forecast Data
Daily/Hourly Forecast
Relative Pressure
Specifications
Warranty/Patents
Recycling & Disposal
Cautions/Statements
Add-On TH Sensor
Add-On Sensor Info
Adding an Extra Sensor
Support Information
Factory Reset
Stay in Touch
02
06
07
08
08
09
10
13
14
14
19
20
20
20-22
17
18
18
23
23
23
03
04
05
15
15
16
16
17
11
12
12

03 04
Connecting to the App Connecting Your Station
LA CROSSE VIEW LA CROSSE VIEW
Connecting to Your Wi-Fi Network
Download the La Crosse View
Visit the App Store or Google Play Store to download the free La Crosse View
app onto your mobile device. Having troubles connecting? Make sure your mobile device is connected to your router’s
separate 2.4GHz Wi-Fi network, and that you’ve correctly entered your Wi-Fi password.
Stay connected to your home anytime, anywhere
with the La Crosse View app.
Monitor home conditions and set alerts so your home
can get ahold of you when something seems o.
Connecting your station is optional and the display
will function as a standalone unit without the Wi-Fi
connection. However, we recommend connecting
during the initial setup, as it will save you time and
unlock all of the advanced features right away.
Launch the App
Open the La Crosse View app and follow the on-screen setup instructions.
Stay Connected to Your Home
Anytime, Anywhere.
Checking Your Station’s Wi-Fi Status
Press the SET button on the top of the station to view your Wi-Fi Status.
• ALL OK CONNECTED: Your station is
connected to your Wi-Fi and its data should
be available on the station and in the app.
• SEE APP TO CONNECT: Check your La Crosse
View app for notifications.
• NO WEATHER SERVICE: Your Internet weather
and time services are not connecting. These
should resolve on their own, please be patient.
• LOST WIFI: Check your router and network
connections.
For more troubleshooting tips and support, scan the QR code or visit:
www.lacrossetechnology.com/lacrosseviewsupport
Now that you’ve created your La Crosse View account, it’s time to connect your
station to your home router using the La Crosse View app.
Ensure your station’s Wi-Fi Indicator
is flashing. This is located on
the bottom of the station’s LCD
and indicates that the station is
searching for your Wi-Fi network.
1.
If the icon isn’t flashing, press and
hold the +/- buttons down together
until it begins to flash.
2.
When connected, the indicator
will become solid.
3.

Station Settings
BASICS
* The default pressure reading is 29.92 INHg (1013 hPa). The station will acclimate on it’s own if the pressure
number is not set. Learn more on page 15
Use the +/- buttons on the
top of the station to adjust
the values.
Press the SET button to
confirm selection and move
to next step.
You may exit the Settings
Menu at any time by pressing
the LIGHT button.
Settings Menu Order
Language • Greeting • 12/24 Hour Time • Hour • Minutes • Year • Month
Date • Fahrenheit/Celsius • Pressure Units (InHg/hPa) • Pressure Number
Setting* • Wind Speed Units (MPH or KMH) • Wind Direction (Letters or Degrees)
1.
2.
When the station is first power on, it will begin searching for your outdoor
sensor, which should connect shortly.
To manually set your time, date, and other settings, hold the SET button to
enter the Settings Menu.
06
Notes: Weekday will set automatically after year, month, & date settings are adjusted.
If you’re connected to the Wi-Fi, the time and date will automatically update from the
Internet. See pages 3-4 for more information.
Connecting Your Sensor to La Crosse View App
LA CROSSE VIEW
•About ten minutes after connecting your station to
the app you should recieve an app notification to
add the sensor.
•If this does not appear you can manually add the
sensor to your app.
Scan Sensor ID:
1. Open your La Crosse View app. On the Main Menu
go to “ADD/EDIT” and select “DEVICES”.
2. On the Devices page select “ADD DEVICE”.
3. Scan the Bar Code on your Breeze Pro Sensor or
add the ID number manually.
4. Confirm the sensor image and device ID and add a
Device Name and Location Name. Select “DONE”.
In a few minutes you will receive sensor data in your
La Crosse View App.
05
123456-ABC
123456-ABC

Buttons
BASICS
1. WIND ALERTS
Hold to enter Wind Alert
Settings. Press to turn Wind
Alert on/o.
2. WIND
Press to view Wind Speed
History. While viewing, hold the
MINUS button to delete the
history reading.
3. TEMP.
Press to view Temperature
and Humidity History. While
viewing, hold MINUS button
to delete the history reading.
6. EXTRA
Press to toggle through extra
sensors and pressure. Hold to
add sensors. While viewing,
hold the MINUS button delete
the sensor.
9. DAILY/HOURLY
Press to see Daily or Hourly
Forecast*
4. SET
Press to view Wi-Fi status.
Hold to enter Settings Menu.
7. SENSOR
Press to view sensor ID
numbers. While viewing, hold
the MINUS button delete the
sensor.
5. PLUS/MINUS (+/-)
Use to adjust values. Hold both
together to search for Wi-Fi
signal.
8. LIGHT
Press to adjust backlight. Hold
to enter Auto-Dim settings.
13
2
6 8
7
4
5
9
Side View
* Your display must be connected to Wi-Fi to receive Daily/Hourly forecast information. 07 08
LCD Display Brightness
Adjusting the LCD Display Brightness
Auto-Dim Settings
Press the LIGHT button to adjust the backlight intensity.
There are 4 brightness levels, plus an o option.
1.
2.
3.
4.
Hold the LIGHT button to enter
the Auto-Dim Settings Menu.
Program your display to automatically
dim during preselected times.
Press the +/- buttons to turn the
Auto-Dim feature on or o. Press
LIGHT to confirm.
Press the +/- buttons to adjust the
starting hour. Press LIGHT to confirm.
Press the +/- buttons to adjust the
stopping hour. Press LIGHT to
confirm and exit.
The icon will appear on the LCD when the Auto-Dim feature activated.
BASICS

09 10
U-bolt Adapters
Tripod Setup
Chimney Mount
1B Pole Adapter
1A Adjustable Base
Basic Assembly
Basic Installation Options
Advanced Installation Options
Some advanced installation options include tripods, wall mounts, eave cross mounts, chimney mounts,
and many others. Any of these can be combined with U-bolts for attachment onto a tall cylindrical conduit
using our Adjustable Base. Please note that these advanced options will require additional equipment and
possibly professional help for best results.
The illustrations above are not to scale and are for informative purposes only.
La Crosse Technology is not responsible for any damages or injury that may occur during installation.
BASICS
Positioning the Breeze Pro Sensor
For Accurate Measurements
Included Mounting Accessories
•Ensure the sensor is mounted level with the Solar Panel facing
directly to the south. This will help optimize battery life and transmit
correct wind direction readings.
•Ideally, the Breeze Pro Sensor should be mounted on the tallest
object in your area. Avoid positioning the sensor in line or below
eaves, rooflines, trees, or other objects that may obstruct wind
readings.
•Make sure all screws on the Mounting Bracket, Winds Cups, and
Wind Vane, are securely fastened.
•The sensor should be mounted with the Wind Cups on top.
Mast
The horizontal conduit where the sensor
attaches. This piece will connect to either
the Adjustable Base or Pole Adapter.
Adjustable Base
The main bracket used for mounting onto flat surfaces or with
added U-bolts (not included). The grooves and Hand Screw allow
the bracket to secure to angled surfaces while still ensuring the
Mast and sensor are level.
Hand Screw
Used to lock down and secure the Mast
to the Adjustable Base or Pole Adapter.
Alignment Arrows
Provide exact 90 or 180 degree
angles when aligned with the arrow
on the Mast.
Pole Adapter
Used in place of the Adjustable Base
for mounting on top of cylindrical
conduits.
1-Inch Maximum Pole Diameter

12
Wind Speed History and Alerts
WIND
Viewing Wind Speed History Records
Activate/Deactivate Wind Speed Alert Important Notes:
Press the WIND button to toggle
through wind speed history records
with time and date stamps.
The wind speed records include:
past 24 hours, 7 days, 1 month, & 1 year.
Press and release the WIND ALERTS button to
activate/deactivate the alert. WIND SPEED ALERT
ON or OFF will appear on the bottom of the LCD.
•The alert is defaulted to be o.
•When the armed alert value is reached, the station
will beep and the icon will flash. Press any button
to stop the alert sound.
•The Alert Icon will remain flashing until out of the
alert range.
•This Wind Speed Alert is for the station only
and will not aect the app.
1. Hold the WIND ALERTS button for to enter the Alert Settings Menu.
2. Use the +/- buttons adjust the on/o and wind speed settings. Press the
WIND ALERTS button to confirm your selection.
3. Your wind speed alert is active when the icon on.
Setting the Wind Speed Alert Monthly Wind Speed Record Example
Viewing Your Wind Data
WIND
1
2
3
5
4
68
7
1. WIND SPEED TREND
INDICATOR
Shows wind speed trends
over the past 60 minutes
2. COMPASS ROSE
Displays cardinal direction
with animated arrows
(16 directions total)
5. RECEPTION INDICATOR
Indicates if the station is
receiving data from the
sensor
8. TOP WIND SPEED
The top wind speed in
the past 60 minutes
3. LOW BATTERY ICON
Appears when the sensor
battery needs to be
replaced
6. “NOW” WIND SPEED
The top wind speed in the
past 31 seconds
4. WIND DIRECTION
Choose between cardinal
points (letters) or degrees
in the Settings Menu
7. WIND SPEED ALERT
Appears if a wind speed
alert is set & active 11

1
2 3
5
4
7
6
8
7. INDOOR TEMPERATURE
Current Indoor Temperature
8. INDOOR HUMIDITY
Current Indoor Humidity
1413
Current Temperature: When the temperature is between 51°F and 79°F the reading

15
Viewing Your Forecast Data
FORECAST
Forecast Icons
Please Note: The Forecast Icons may not represent your current weather. They are a future prediction
of the weather to come over the next 12 hours.
When using as a standalone station, the display
will use changes in barometric pressure to predict
your weather to come in the next 12 hours. This is
represented by the 6 forecast scenes below.
However, when connected to Wi-Fi, the station
will receive additional weather icons, chance of
precipitation values, and future forecast information.
These enhanced Internet features are powered by
AccuWeather.*
Seasonal Trees
Foliage Scenes
The foliage scene in the forecast section changes
seasonally. The dates are pre-programmed.
*Your display must be connected to Wi-Fi to receive AccuWeather forecast data.
Available Forecast Icons on Standalone Station
Sunny Clouds T-StormPartly Sunny Rain Snow
Spring (March 20th to June 20th)
Summer (June 21st to Sept. 20th)
Fall (Sept. 21st to Dec. 20th)
Winter (Dec. 21st to March 19th)
16
Viewing Your Forecast Data
FORECAST
Daily & Hourly Forecast Buttons
When connected to Wi-Fi, use the DAILY & HOURLY buttons on the side of the station to view
future forecast information.
Tip: The icon will appear in the top right corner of the forecast section when your display is
connected and receiving AccuWeather forecasts.
Sunny
Light Snow
Clouds
Wintry Mix
Rain
Ice
Partly Sunny
Snow
Light Rain
Windy
T-Storm
Fog
Available Forecast Icons when Connected*
Daily Forecast: Press the DAILY
button on the side of the station to
automatically scroll through 7 days
of forecast data, including forecast
icons and highs and lows.
Hourly Forecast: Press the
HOURLY button to view 12 hours
of future forecasts, including
forecast icons and forecasted
temp. & humidity with time stamps.

17
Relative Pressure
Add-On Temperature & Humidity Sensor
PRESSURE
EXTRA SENSORS
•Your Relative Pressure reading will come from your
station’s internal barometer.
•Please allow up to 10 days for automatic calibration, or
program your local pressure value in the Settings Menu.
•The arrows located to the left of the values represents
Pressure Tendency (rising/falling).
2. Hold the MINUS (-) button to delete these
Temperature & Humidity readings.
3. Press the SENSOR button until this Outdoor
Temp. and Humidity section lights up again.
Then hold the PLUS (+) button until the blue
Sensor Reception Indicator starts to animate.
Adding a Separate Temperature & Humidity Sensor
Pressure Reading Example
If you feel the temperature & humidity is not reading correctly from your
Breeze Pro Sensor, you can add a separate sensor to your system.
Visit: www.lacrossetechnology.com/view to learn more.
1. Press the SENSOR button until you see the
Outdoor Temperature and Humidity section light
up on screen. “ID WTH 123” and “TWH SENSOR”
will appear below.
4.
5.
Install new batteries into the add-on sensor
and press the TX button inside its battery
compartment. The LED light on the sensor
will flash.
The sensor should connect almost instantly
with its data appearing on screen. The
icon will appear when an add-on TH sensor
is being used.
18
Additional Add-On Sensors
EXTRA SENSORS
Rain Data Example
Whether you choose to connect with the La Crosse
View app or not, this station can display data for up
to 4 extra sensors. This data will appear in the green
EXTRA SENSOR section on the LCD, and in your
La Crosse View app if connected.
Scan the QR code above or visit:
www.lacrossetechnology.com/R3RainSensor
www.lacrossetechnology.com/view
Model Number
LTV-R3
To learn about all of your
add-on sensor options,
scan the QR code or visit:
2. Install batteries into your sensor. If the sensor
has a TX button, press it to force a transmission
signal. This button is usually located in or near
the sensor’s battery compartment. The LED
light on the sensor will flash once.
3. Your sensor should connect within the next 3
minutes, briefly displaying its ID and type on
the LCD. The Sensor Reception Indicator will
show solid on the screen when a sensor is
connected.
Adding Sensors to Your StationWould you like backyard rain data as well?
1. Hold the EXTRA button until you see the Sensor
Reception Indicator start to animate.
Note: When first powering up, or after a factory
reset, extra sensors should automatically connect
to your station.
4. Press the EXTRA button to cycle through the
data you’d like displayed on the LCD. The
Auto Scroll Icon ( ) will appear if activated.
