La Crosse Technology WS-9043U User manual

WS-9043U
Wireless 433 MHz
Radio-controlled Weather Station
Instruction Manual

2
TABLE OF CONTENTS
Topic Page
Inventory of Contents/Additional Equipment
About WWVB
Quick Set-Up Guide
Detailed Set-Up Guide
Battery installation
Program Mode
Program Sequence and Default Settings
Function Keys
Setting the LCD Contrast
Setting the Time Zone
Daylight Saving Time Setting
Radio-controlled Time Setting
12/24-hour Time Setting
Setting the Time
Setting the Year, Day and Month
Setting the Snooze
Setting the Forecast Sensitivity
Features
Weather Forecast Icons and Tendency Arrows
Indoor Temperature, Humidity, & Comfort
Level Indicator
Outdoor Temperatures
Minimum & Maximum Records (Indoor, Outdoor, & Resetting)
Moon Phase
Time Alarm
Adding Remote Temperature/Humidity Sensors (Optional)
Mounting
Troubleshooting
Maintenance & Care
Specifications
Warranty Information

3
Moon Phase
and Date LCD
INVENTORY OF CONTENTS
1. The WS-9043U weather station (Figure 1)
2. One TX4U remote temperature/humidity sensor (Figure 2)
3. Mounting hardware
4. Instruction manual and warranty card.
ADDITIONAL EQUIPMENT (not included)
1. Three fresh AA 1.5V batteries for the indoor weather station.
2. Two fresh AA 1.5V batteries for the remote temperature/humidity sensor.
3. One Philips screwdriver for mounting.
ABOUT WWVB (Radio Controlled Time)
The NIST (National Institute of Standards and Technology—Time and Frequency Division) WWVB radio
station is located in Ft. Collins, Colorado, and transmits the exact time and date signal continuously throughout
the United States at 60 kHz. The signal can be received up to 2,000 miles away through the internal antenna in
the Weather Station. However, due to the nature of the Earth’s Ionosphere, reception is very limited during
daylight hours. The weather station will search for a signal every night when reception is best. The WWVB
radio station derives its signal from the NIST Atomic clock in Boulder, Colorado. A team of atomic physicists
is continually measuring every second, of every day, to an accuracy of ten billionths of a second per day. These
physicists have created an international standard, measuring a second as 9,192,631,770 vibrations of a Cesium-
133 atom in a vacuum. For more information on the atomic clock and WWVB please see the NIST website at
http://www.boulder.nist.gov/timefreq/stations/wwvb.htm.
Figure 1
Time LCD
Forecast LCD
Indoor LCD
O
utdoor LCD
Figure 2
Heat index and
Dew point LCD
Rain protection cover
Wall mounting base

4
QUICK SET-UP GUIDE
Hint: Use good quality Alkaline Batteries and avoid rechargeable batteries.
1. Have the indoor weather station and remote temperature/humidity sensor 3 to 5 feet apart.
2. Batteries should be out of both the indoor weather station and remote temperature/humidity sensor
units for 10 minutes.
3. Place the batteries into the remote temperature/humidity sensor first then into the indoor weather
station.
4. DO NOT PRESS ANY BUTTONS FOR 15 MINUTES.
In this time the indoor weather station and remote temperature/humidity sensor will start to talk to each other
and the display will show the indoor temperature/humidity, outdoor temperature/humidity, heat index and dew
point. If the indoor weather station does not display all information after the 15 minutes please retry the set up
as stated above. After all information has been displayed for 15 minutes you can place your sensors outdoors
and set your time.
Important Notes on Set-up and Operation
•The remote temperature/humidity sensor should be placed in a dry, shaded area.
•Fog and mist will not harm your remote temperature/humidity sensor but direct rain must be avoided.
•The remote temperature/humidity sensor has a range of 330 feet. Any walls that the signal will have to pass
through will reduce distance. An outdoor wall or window can have up to 30 feet of resistance and an interior
wall can have up to 20 feet of resistance. Your distance plus resistance should not exceed 330 ft. in a
straight line.
•The remote temperature/humidity sensor transmits a signal every minute. After the batteries have been
installed, the indoor weather station will search for the signal for a duration of 4 minutes. If there is no
temperature or humidity reading in the OUTDOOR LCD after 4 minutes, make sure the units are within
range of each other, or repeat the battery installation procedure.
•If a button is pressed before the indoor weather station receives the signal from the remote
temperature/humidity sensor, you will need to follow the battery installation procedure again.
To complete the set up of your new wireless weather station after the 15 minutes have passed please follow the
steps that follow in the Detailed Set-Up Guide.
DETAILED SET-UP GUIDE
BATTERY INSTALLATION
A. REMOTE TEMPERATURE/HUMIDITY SENSOR
1. Remove the mounting bracket and Rain cover.
2. Remove the battery cover by sliding the cover down.
3. Observing the correct polarity install 2 AA batteries. The batteries will fit tightly (to avoid start-
up problems make sure they do not spring free).
4. Replace the battery cover by sliding upwards. Be sure battery cover is on securely.
Battery
Cover
Mounting
Bracket
Rain
Cover
Thermo-Hygro
Transmitter

5
5. Replace the humidity hood.
B. INDOOR WEATHER STATION
1. Remove the battery cover. To do this, insert a solid object in the
space provided at the lower-central position of the battery cover,
then push up and pull out on the battery cover.
2. Observe the correct polarity, and install 3 AA batteries.
3. Replace the battery cover.
Note: Immediately after the batteries have been installed, the
LCD (Liquid Crystal Display) will flash. Within 15 seconds the
indoor temperature, indoor relative humidity, and the weather icons (sun and clouds) will be
displayed. If not, remove batteries for 10 seconds and reinstall. If the outdoor temperature is not
displayed within four minutes, remove batteries from both units, wait 30 seconds, and reinstall
making sure to install batteries into the remote temperature sensor first. The time will show
12:00 and start searching for the WWVB signal. If it successfully receives the time signal
(usually at night), it will display the correct time (default time-zone is Eastern). You will need to
adjust the time zone to match your local time.
PROGRAM MODE
Programming Note: If 15 seconds are allowed to pass, or the SNOOZE/CH button is pressed during the
programming mode, the unit will confirm/set the last information entered—the display will stop flashing
and return to normal time-date readings. If you don’t leave the program mode during the programming of
sections IV through XI, you can advance to step 4 of the next program setting. If you do leave the program
setting (or want to program a specific setting) follow each instructional step to program that setting.
I. PROGRAMMING SEQUENCE AND DEFAULT SETTINGS
The programming sequence and default (factory) settings are as follows:
LCD Contrast 5
Time Zone -5 (Eastern)
Daylight Saving Time ON
Radio-controlled time
reception ON
12/24-hour time 12
Time – Hour 12
Time – Minute :00
Year 2003
Month 1
Day 1
Snooze 10 minutes
Forecast Sensitivity 2
II. FUNCTION KEYS
The function keys are located on the front of the unit directly below the LCD (Liquid Crystal
Display).

6
II. SETTING THE LCD CONTRAST
1. Press and hold the SET button for 3 seconds.
2. “LCD” will show in the TIME LCD and the number setting will flash.
Note: There are 8 LCD contrast levels to choose from—“Lcd 0” is the lightest, and “Lcd 7” is
the darkest.
3. Press and release the ALM/+ button to select the level you desire.
4. Press and release the SET button to confirm and advance to the Time Zone setting.
III. TIME ZONE SETTING
1. Press and hold the SET button for 3 seconds.
2. “LCD” will show in the TIME LCD and the number setting will flash.
3. Press and release the SET button again.
4. The time zone will flash in the DATE LCD.
5. Press and release the ALM/+ button to select your time zone.
Note: It is possible to select any time zone from –12 GMT to +12 GMT (for example to see the
time in another country).
TIME ZONES
GMT 0
Atlantic -4
EST; Eastern -5
CST; Central -6
MST; Mountain -7
PST; Pacific -8
ALA; Alaska -9
HAW
; Hawaii -10
6. Press and release the SET button to confirm and advance to the Daylight Saving Time setting.
IV. DAYLIGHT SAVING TIME (DST) SETTING
1. Press and hold the SET button for 3 seconds.
2. “LCD” will show in the TIME LCD and the number setting will flash.
3. Press and release the SET button twice.
4. “DST” will appear in the DATE LCD and either “ON” or “OFF” will flash in the TIME
LCD.
5. Press and release the ALM/+ button to select DST on or off.

7
Note: “DST OFF” indicates that the feature is off and the WWVB will not change times
automatically. “DST ON” indicates that the feature is on and the WWVB will change times
automatically.
Note: Some locations (Arizona and parts of Indiana) do not follow Daylight Saving Time, and
should select “DST OFF”.
6. Press and release the SET button to confirm and advance to the radio-controlled time on/off
setting.
V. RADIO-CONTROLLED TIME ON/OFF SETTING
1. Press and hold the SET button for 3 seconds.
2. “LCD” will show in the TIME LCD and the number setting will flash.
3. Press and release the SET button three times.
4. “RCC” will appear in the DATE LCD and “ON” or “OFF” will flash in the TIME LCD.
5. Press and release the ALM/+ button to select radio-controlled time on or off.
6. Press and release the SET button to confirm and advance to the 12/24-hour time setting.
VI. 12 OR 24 HOUR TIME SETTING
1. Press and hold the SET button for 3 seconds.
2. “LCD” will show in the TIME LCD and the number setting will flash.
3. Press and release the SET button four times.
4. “12h” or “24h” will flash in the DATE LCD.
5. Press and release the ALM/+ button to select 12 or 24-hour time format.
Note: When in the 12-hour format “P.M.” will appear to the left of the hour in the time LCD
between the hours of noon and midnight.
6. Press and release the SET button to confirm and advance to the time setting.
VII. TIME SETTING
There are two methods by which the time and date can be set:
A) Automatically via WWVB reception, or
B) Manually.
A. WWVB (Remote Control Time)

8
This method requires you to do nothing, except wait for the signal to be received, and to select a
time zone. Reception usually takes approximately 10 minutes during optimal conditions. The best
conditions for reception is at night, between midnight and 6:00 am—when there is less atmospheric
interference. To keep your time as accurate as possible, the indoor weather station conducts a
WWVB search every night between these hours, and overrides any manually set time. The WWVB
tower icon (appearing in the TIME LCD) will flash when a signal-search is in progress and a signal
is being received, and will remain steady when the signal has been received. If the WWVB time has
not been received after 15 minutes of battery installation, you may manually set the time or leave the
time function alone (reception will occur regardless).
B. MANUAL TIME SETTING
Note: When in the 12-hour format “P.M.” will appear to the left of the hour in the time LCD
between the hours of noon and midnight.
Note: Reception of the WWVB signal will automatically set the time. The reception of the
signal will override any programmed time.
1. Press and hold the SET button for 3 seconds.
2. “LCD” will show in the TIME LCD and the number setting will flash.
3. Press and release the SET button five times.
4. The hours digits will flash in the TIME LCD.
5. Press and release the ALM/+ button to advance the hours.
6. Press and release the SET button to confirm the hours setting and advance to the minutes
setting.
7. The minutes digits will flash in the TIME LCD.
8. Press and release the ALM/+ button to advance the minutes.
9. Press and release the SET button to confirm and advance to the year setting.
VIII. SETTING THE YEAR, DAY AND MONTH
Note: Reception of the WWVB signal will also set the date and day. The reception of the signal
will override any programmed date and day.
1. Press and hold the SET button for 3 seconds.
2. “LCD” will show in the TIME LCD and the number setting
will flash.
3. Press and release the SET button seven times.
4. The year will flash in the DATE LCD.
5. Press and release the ALM/+ button to advance the year.
6. Press and release the SET button to confirm the year and
advance to the month setting.
7. The month will flash in the DATE LCD.
8. Press and release the ALM/+ button to advance the month.
9. Press and release the SET button to confirm the month and
advance to the day setting.
10. The day of the month will flash in the DATE LCD.
11. Press and release the ALM/+ button to advance the day of the
month.
12. Press and release the SET button to confirm and advance to the
snooze setting.
IX. SETTING THE SNOOZE
1. Press and hold the SET button for 3 seconds.
2. “LCD” will show in the TIME LCD and the number setting will flash.

9
3. Press and release the SET button ten times.
4. “Sn” will appear in the DATE LCD and a number will be flashing next to it.
5. Press and release the ALM/+ button to select the duration of the snooze.
Note: The snooze can be set for 0 to 30 minutes in 5-minute increments. If 0 minutes is selected
pressing the WIND/SNZ button will deactivate the alarm and it will not come back on.
6. Press and release the SET button to confirm and advance to the forecast sensitivity setting.
X. SETTING THE FORECAST SENSITIVITY
Note: The forecast sensitivity can be adjusted to allow for areas that have a higher or lower
sensitivity to changing air pressure (for example coastal areas have more pressure change than
areas such as southern Arizona).
The numbers correspond to the amount of air pressure change necessary to trigger a change in
the forecast icon. Areas that tend to have more air pressure change would set the sensitivity to 3,
while areas that experience lower than normal air pressure change would set the sensitivity to 1.
1. Press and hold the SET button for 3 seconds.
2. “LCD” will show in the TIME LCD and the number setting will flash.
3. Press and release the SET button eleven times.
4. Either “1”, “2” or “3” will flash in the TIME LCD and the forecast icon and tendency arrows
will flash in the FORECAST LCD.
5. Press and release the ALM/+ button to select the forecast sensitivity.
6. Press and release the SET button to confirm the forecast sensitivity and complete the
programming.
FEATURES OF THE WS-9043U
WWVB Tower
Icon (indicates
time reception)
Radio-controlled
time icon
(indicates radio-
controlled time
turned on
)

10
I. WEATHER FORECAST
The weather forecasting feature is estimated to be 75% accurate and is for the next 12 to 24 hours. The
weather forecast is based solely upon the change of air pressure over time. The WS-9043U averages past
air-pressure readings to provide an accurate forecast—creating a necessity to disregard all weather
forecasting for 12-24 hours after the unit has been set-up, reset, or moved from one altitude to another
(i.e. from one floor of a building to another floor). In areas where the weather is not largely affected by
the change of air pressure, the sensitivity setting should be set to 1. In areas where the air pressure
changes more rapidly (such as coastal areas) the sensitivity setting should be set to 3.
A. WEATHER ICONS
There are 3 possible weather icons that will be displayed in the FORECAST LCD:
Sunny—indicates that the weather is expected to improve (not that the weather will be sunny).
Sun with Clouds—indicates that the weather is expected to be fair (not that the weather will be
sunny with clouds).
Clouds with Rain—indicates that the weather is expected to get worse (not that the weather will
be rainy).
These icons indicate the expected weather change in the next 12 to 24 hours. The icon does not
give an exact prediction of the weather, however it should be viewed as a generalization of the
expected weather change (for example a “sunny” icon indicates the weather is expected to
improve).
The weather icons change when the unit detects a change in air pressure. The icons change in
order, from “sunny” to “partly sunny” to “cloudy” or the reverse. It will not change from
Comfort Level
Indicator
Weather
Tendenc
y Arrow
Satellite icon
(indicates
outdoor
transmission)
Forecast
icon
Current moon
phase display
Dew point
Heat Index
