La Crosse C79790 User manual

SET UP GUIDE
MODEL NUMBER C79790
WIRELESS WEATHER
STATION

Table of Contents
WINDBASICS
TEMP. & HUMIDITY (TH)
LA CROSSE VIEW
FORECAST PRESSURE
APPENDIXEXTRA SENSORS SUPPORT
Viewing Your Wind Data
History Records
Wind Speed Alert
Initial Setup
Station Settings
Buttons
LCD Display Brightness
Auto-Dim Settings
Positioning Your Sensor
Basic Installation Options
Viewing Your TH Data
History Records
“Feels Like” Temp.
Connecting to the App
Connecting Your Station
Connecting Your Sensor
Seasonal Trees
Standalone Forecast Icons
Enhanced Forecast Data
Daily/Hourly Forecast
Relative Pressure
Specifications
Warranty/Patents
Recycling & Disposal
Cautions/Statements
Add-On TH Sensor
Add-On Sensor Info
Adding an Extra Sensor
Support Information
Factory Reset
Stay in Touch
02
06
07
08
08
09
10
13
14
14
19
20
20
20-22
17
18
18
23
23
23
03
04
05
15
15
16
16
17
11
12
12

02
Initial Setup
Power Up
Note: It may take up to 10 minutes for your sensor data to appear on your
station’s screen.
BASICS
1. Remove the Insulation Tab from the
Battery Compartment of your Breeze
Pro Sensor, and make sure the power
switch is turned ON.
2. Insert the 5V Power Adapter into
an outlet, and then plug it into the
Power Jack on the back of the
station. Next, remove the Insulation
Tab from the station’s Battery
Compartment.
Bottom of Breeze Pro Sensor
Model No. LTV-WSDTH01
Back of Station
Model No. C79790

03
Connecting to the App
LA CROSSE VIEW
Download the La Crosse View
Visit the App Store or Google Play Store to download the free La Crosse View
app onto your mobile device.
Stay connected to your home anytime, anywhere
with the La Crosse View app.
Monitor home conditions and set alerts so your home
can get ahold of you when something seems o.
Connecting your station is optional and the display
will function as a standalone unit without the Wi-Fi
connection. However, we recommend connecting
during the initial setup, as it will save you time and
unlock all of the advanced features right away.
Launch the App
Open the La Crosse View app and follow the on-screen setup instructions.
Stay Connected to Your Home
Anytime, Anywhere.
For more troubleshooting tips and support, scan the QR code or visit:
www.lacrossetechnology.com/lacrosseviewsupport

04
Connecting Your Station
LA CROSSE VIEW
Connecting to Your Wi-Fi Network
Having troubles connecting? Make sure your mobile device is connected to your router’s
separate 2.4GHz Wi-Fi network, and that you’ve correctly entered your Wi-Fi password.
Checking Your Station’s Wi-Fi Status
Press the SET button on the top of the station to view your Wi-Fi Status.
• ALL OK CONNECTED: Your station is
connected to your Wi-Fi and its data should
be available on the station and in the app.
• SEE APP TO CONNECT: Check your La Crosse
View app for notifications.
• NO WEATHER SERVICE: Your Internet weather
and time services are not connecting. These
should resolve on their own, please be patient.
• LOST WIFI: Check your router and network
connections.
Now that you’ve created your La Crosse View account, it’s time to connect your
station to your home router using the La Crosse View app.
Ensure your station’s Wi-Fi Indicator
is flashing. This is located on
the bottom of the station’s LCD
and indicates that the station is
searching for your Wi-Fi network.
1.
If the icon isn’t flashing, press and
hold the +/- buttons down together
until it begins to flash.
2.
When connected, the indicator
will become solid.
3.

Connecting Your Sensor to La Crosse View App
LA CROSSE VIEW
•About ten minutes after connecting your station to
the app you should recieve an app notification to
add the sensor.
•If this does not appear you can manually add the
sensor to your app.
Scan Sensor ID:
1. Open your La Crosse View app. On the Main Menu
go to “ADD/EDIT” and select “DEVICES”.
2. On the Devices page select “ADD DEVICE”.
3. Scan the Bar Code on your Breeze Pro Sensor or
add the ID number manually.
4. Confirm the sensor image and device ID and add a
Device Name and Location Name. Select “DONE”.
In a few minutes you will receive sensor data in your
La Crosse View App.
05

Station Settings
BASICS
* The default pressure reading is 29.92 INHg (1013 hPa). The station will acclimate on it’s own if the pressure
number is not set. Learn more on page 15
Use the +/- buttons on the
top of the station to adjust
the values.
Press the SET button to
confirm selection and move
to next step.
You may exit the Settings
Menu at any time by pressing
the LIGHT button.
Settings Menu Order
Language • Greeting • 12/24 Hour Time • Hour • Minutes • Year • Month
Date • Fahrenheit/Celsius • Pressure Units (InHg/hPa) • Pressure Number
Setting* • Wind Speed Units (MPH or KMH) • Wind Direction (Letters or Degrees)
1.
2.
When the station is first power on, it will begin searching for your outdoor
sensor, which should connect shortly.
To manually set your time, date, and other settings, hold the SET button to
enter the Settings Menu.
06
Notes: Weekday will set automatically after year, month, & date settings are adjusted.
If you’re connected to the Wi-Fi, the time and date will automatically update from the
Internet. See pages 3-4 for more information.

Buttons
BASICS
1. WIND ALERTS
Hold to enter Wind Alert
Settings. Press to turn Wind
Alert on/o.
2. WIND
Press to view Wind Speed
History. While viewing, hold the
MINUS button to delete the
history reading.
3. TEMP.
Press to view Temperature
and Humidity History. While
viewing, hold MINUS button
to delete the history reading.
6. EXTRA
Press to toggle through extra
sensors and pressure. Hold to
add sensors. While viewing,
hold the MINUS button delete
the sensor.
9. DAILY/HOURLY
Press to see Daily or Hourly
Forecast*
4. SET
Press to view Wi-Fi status.
Hold to enter Settings Menu.
7. SENSOR
Press to view sensor ID
numbers. While viewing, hold
the MINUS button delete the
sensor.
5. PLUS/MINUS (+/-)
Use to adjust values. Hold both
together to search for Wi-Fi
signal.
8. LIGHT
Press to adjust backlight. Hold
to enter Auto-Dim settings.
13
2
6 8
7
4
5
9
Side View
* Your display must be connected to Wi-Fi to receive Daily/Hourly forecast information. 07

08
LCD Display Brightness
Adjusting the LCD Display Brightness
Auto-Dim Settings
Press the LIGHT button to adjust the backlight intensity.
There are 4 brightness levels, plus an o option.
1.
2.
3.
4.
Hold the LIGHT button to enter
the Auto-Dim Settings Menu.
Program your display to automatically
dim during preselected times.
Press the +/- buttons to turn the
Auto-Dim feature on or o. Press
LIGHT to confirm.
Press the +/- buttons to adjust the
starting hour. Press LIGHT to confirm.
Press the +/- buttons to adjust the
stopping hour. Press LIGHT to
confirm and exit.
The icon will appear on the LCD when the Auto-Dim feature activated.
BASICS

09
P
ositioning the Breeze Pro Sensor
For Accurate Measurements
Mast
The horizontal conduit where the sensor
attaches. This Piece will connect to either
the Adjustable Base or Pole Adapter.
Pole Adapter�
Used in place of the Adjustable Base
for mounting on top of cylindrical
conduits.
Alignment Arrows�
Provide exact 90 or 180 degree
angles when aligned with the arrow
on the Mast.
1-Inch Maximum Pole Diameter
Hand Screw
Used to lock down and secure the Mast
to the Adjustable Base or Pole Adapter.
Included Mounting Accessories
BASICS
