Lab.gruppen iP Series IP 450 User manual

ámQRM=
pbosf`b=j^kr^i=
=
sÉêëáçå=O
i~ÄKÖêìééÉå=^_=
dìääêÉÖåëî®ÖÉå=NSI=pbJQPQ=QQ==hrkdp_^`h^I=ptbabk=
mÜçåÉW=HQS=PMM=RS=OU=MM=
c~ñW=HQS=PMM=RS=OU=VV=
áåÑç]ä~ÄÖêìééÉåKÅçã=
ïïïKä~ÄÖêìééÉåKÅçã=

=pÉêîáÅÉ=j~åì~ä=ámQRM= m~ÖÉ=N=EQF=
=
iP450
Internal connections ..........................................................................................2
Component list ..................................................................................................3
Variant specific components.............................................................................3
Description for variant dependent components.................................................3
Sparepart list for iP450 .....................................................................................4
A02H
Schematics for A02H ........................................................................................2
Board placement for A02H ...............................................................................3
Component list for A02H-2-2 - rev 03A...........................................................4
AIDHA
Schematics for AIDHA.....................................................................................2
Board placement for AIDHA ............................................................................3
Component list for LDP42, AIDHA - rev 03A.................................................4
Variant specific components.............................................................................9
Description for variant dependent components...............................................10
MR05
Schematics for MR05........................................................................................2
Board placement for MR05...............................................................................3
Component list for MR05 - rev 02A .................................................................4
Variant specific components.............................................................................4
Description for variant dependent components.................................................4

=pÉêîáÅÉ=j~åì~ä=ámQRM= m~ÖÉ=O=EQF=
=
fåíÉêå~ä=ÅçååÉÅíáçåë=

=pÉêîáÅÉ=j~åì~ä=ámQRM= m~ÖÉ=P=EQF=
=
`çãéçåÉåí=äáëí=
- Safety critical component. Should only be replaced with the specified type.
Position Partnumber Description Comment
C1 680p400VK20005%5 Capacitor ceramic 680p 400V K2000 5% 5mm
C2 100n63VMMK5 Capacitor polyester 100n 63V MMK 5mm
C101 680p400VK20005%5 Capacitor ceramic 680p 400V K2000 5% 5mm
C102 100n63VMMK5 Capacitor polyester 100n 63V MMK 5mm
K201 K45TOd165h35_LAB Transformer 450W toridial dy165mm h 35mm LAB. Rev01
L201 2x1mH8Ad58h27 Inductor 1mH ironcoil TOROID TI-01027
P1 NL4MP_NEU Connector speakon 4pole NEUTRIK NL4MP
P2 SOIDC5P3.96_AMP Socket IDC 5pole 3.96mm AMP 640427-5
P3 SOIDC6P3.96_AMP Socket IDC 6pole 3.96mm AMP 640427-6
P101 NL4MP_NEU Connector speakon 4pole NEUTRIK NL4MP
P102 SOIDC5P3.96_AMP Socket IDC 5pole 3.96mm AMP 640427-5
P103 SOIDC6P3.96_AMP Socket IDC 6pole 3.96mm AMP 640427-6
P201 Variant dependent, see separate list
S201 RK2-0-20A25x31 Switch Rocker Double Pole Single Trough on - off 20A 25x31mm
s~êá~åí=ëéÉÅáÑáÅ=ÅçãéçåÉåíë=
Position 230V 115V
P201 MLEU3x.752mBLK MLEU3x1.52.5mBLK
aÉëÅêáéíáçå=Ñçê=î~êá~åí=ÇÉéÉåÇÉåí=ÅçãéçåÉåíë=
Partnumber Description
MLEU3x.752mBLK Mains lead EU Plug type CEE7/VII 3x.75mm2 2m Black
MLEU3x1.52.5mBLK Mains lead EU Plug type CEE7/VII 3x1.5mm2 2.5m Black

=pÉêîáÅÉ=j~åì~ä=ámQRM= m~ÖÉ=Q=EQF=
=
pé~êÉé~êí=äáëí=Ñçê=ámQRM=
Completed modules
Partnumber Description
A02H-2-2 Amplifier 200W class H, variant 2-2
AIDHA-L32 Amplifier input and driver class H type A, variant L32
LDP42 Led display and gain potentiometer 4 x led 2 channel
MR05-MTB Mains and rectifierboard 500W, variant MTB
Mecanical parts
Partnumber Description
TC04S-PBLK Top cover
FP-IP450 Front panel
RP-IP450 Rear panel 230V
RP-IP450U Rear panel 115V
HDL1HEM5_FIS Handle
KNBD18.5_TAI Gain potentiometer knob
Screws
Partnumber Description
MRX3x10SV Machine screw, pan head, phillips, M3x10, black
MFX3x12SV Machine screw, countersunk head, phillips, M3x12, black
RXS-HST2.9x6.5SV Self tapping screw, pan head, phillips, 2.9x6.5mm, black
RXS-HST2.9x13SV Self tapping screw, pan head, phillips, 2.9x13mm, black
FXS-HST2.9x9.5SV Self tapping screw, countersunk head, phillips, 2.9x9.5mm, black

=pÉêîáÅÉ=j~åì~ä=^MOe= m~ÖÉ=N=ERF=
=
A02H
Schematics for A02H ........................................................................................2
Board placement for A02H ...............................................................................3
Component list for A02H-2-2 - rev 03A...........................................................4

=pÉêîáÅÉ=j~åì~ä=^MOe= m~ÖÉ=O=ERF=
=
pÅÜÉã~íáÅë=Ñçê=^MOe=

=pÉêîáÅÉ=j~åì~ä=^MOe= m~ÖÉ=P=ERF=
=
_ç~êÇ=éä~ÅÉãÉåí=Ñçê=^MOe=

=pÉêîáÅÉ=j~åì~ä=^MOe= m~ÖÉ=Q=ERF=
=
`çãéçåÉåí=äáëí=Ñçê=^MOeJOJO=J=êÉî=MP^=
- Safety critical component. Should only be replaced with the specified type.
Position Partnumber Description Comment Side
C1 100u10V Capacitor electrolytic 100u 10V 5mm Top
C2 2n2250VMMK5 Capacitor polyester 2n2 250V MMK 5mm Top
C3 10n250VMMK5 Capacitor polyester 10n 250V MMK 5mm Top
C4 15n250VMMK5 Capacitor polyester 15n 250V MMK 5mm Top
C5 220p200VNP05%5 Capacitor ceramic 220p 200V NP0 5% 5mm Top
C6 10n250VMMK5 Capacitor polyester 10n 250V MMK 5mm Top
C7 2u2100V Capacitor electrolytic 2u2 100V 5mm Top
C8 2u2100V Capacitor electrolytic 2u2 100V 5mm Top
C9 10n250VMMK5 Capacitor polyester 10n 250V MMK 5mm Top
C10 220p200VNP05%5 Capacitor ceramic 220p 200V NP0 5% 5mm Top
C11 15n250VMMK5 Capacitor polyester 15n 250V MMK 5mm Top
C12 10n250VMMK5 Capacitor polyester 10n 250V MMK 5mm Top
C13 100u10V Capacitor electrolytic 100u 10V 5mm Top
C14 2n2250VMMK5 Capacitor polyester 2n2 250V MMK 5mm Top
C15 100n63VMMK5 Capacitor polyester 100n 63V MMK 5mm Top
C16 100n63VMMK5 Capacitor polyester 100n 63V MMK 5mm Top
D1 8V21.3W5% Diode zener 8V2 1.3W 5% Top
D2 1N4004 Diode power 1N4004 Top
D3 1N4004 Diode power 1N4004 Top
D4 1N4148 Diode signal 1N4148 Top
D5 1N4148 Diode signal 1N4148 Top
D6 BAV21 Diode signal BAV21 Top
D7 MR852 Diode power MR852 Top
D8 BAV21 Diode signal BAV21 Top
D9 BAV21 Diode signal BAV21 Top
D10 BAV21 Diode signal BAV21 Top
D13 1N4004 Diode power 1N4004 Top
D14 1N4004 Diode power 1N4004 Top
D15 BAV21 Diode signal BAV21 Top
D16 BAV21 Diode signal BAV21 Top
D17 MR852 Diode power MR852 Top
D18 BAV21 Diode signal BAV21 Top
D19 1N4148 Diode signal 1N4148 Top
D20 1N4148 Diode signal 1N4148 Top
D21 1N4004 Diode power 1N4004 Top
D22 1N4004 Diode power 1N4004 Top
D23 8V21.3W5% Diode zener 8V2 1.3W 5% Top
NTC1 NTC220K_BCC_TX Resistor NTC 220K BCC 232264063224 Top
P1 PH5PL3.96_AMP Pin header PCB 5pole locking 3.96mm AMP 640445-5 Top
P2 PH6PL3.96_AMP Pin header PCB 6pole locking 3.96mm AMP 640445-6 Top
Q1 MJE15030 Transistor bipolar power MJE15030 Top
Q2 MJL3281LY Transistor bipolar power MJL3281 lying May have different
value
Top
Q3 MJE350 Transistor bipolar power MJE350 Top
Q4 MJE15030 Transistor bipolar power MJE15030 Top
Q5 MPSA42 Transistor bipolar signal MPSA42 Top
Q6 MJL3281LY Transistor bipolar power MJL3281 lying May have different
value
Top
Q7 BD329LYb Transistor bipolar power BD329 lying Top
Q8 MJL1302LY Transistor bipolar power MJL1302 lying May have different
value
Top
Q9 MPSA92 Transistor bipolar signal MPSA92 Top

=pÉêîáÅÉ=j~åì~ä=^MOe= m~ÖÉ=R=ERF=
=
Position Partnumber Description Comment Side
Q10 MJE15031 Transistor bipolar power MJE15031 Top
Q11 MJE340 Transistor bipolar power MJE340 Top
Q12 MJL1302LY Transistor bipolar power MJL1302 lying May have different
value
Top
Q13 MJE15031 Transistor bipolar power MJE15031 Top
R1 22R.25W5% Resistor Carbon Film 22R.25W5% Top
R2 3K91W5%SO5 Resistor metal film 3K9 1W 5% 5mm stand off Top
R3 15R.25W5% Resistor Carbon Film 15R.25W5% Top
R4 390R.7W1% Resistor Metal Film 390R.7W1% Top
R5 2K7.7W1% Resistor Metal Film 2K7.7W1% Top
R6 470R.7W1% Resistor Metal Film 470R.7W1% Top
R7 33R.25W5% Resistor Carbon Film 33R.25W5% Top
R8 47R.25W5% Resistor Carbon Film 47R.25W5% Top
R9 1K.7W1% Resistor Metal Film 1K.7W1% Top
R10 220K.7W1% Resistor Metal Film 220K.7W1% Top
R11 820R.7W1% Resistor Metal Film 820R.7W1% Top
R12 4K7.7W1% Resistor Metal Film 4K7.7W1% Top
R13 15R.25W5% Resistor Carbon Film 15R.25W5% Top
R14 3K3.7W1% Resistor Metal Film 3K3.7W1% Top
R15 180R.7W1% Resistor Metal Film 180R.7W1% Top
R16 4K7.7W1% Resistor Metal Film 4K7.7W1% Top
R17 R054W10% Resistor wirewound R05 4W 10% Top
R18 12K.7W1% Resistor Metal Film 12K.7W1% Top
R19 4K7.7W1% Resistor Metal Film 4K7.7W1% Top
R20 560R.7W1% Resistor Metal Film 560R.7W1% Top
R21 1K8.7W1% Resistor Metal Film 1K8.7W1% Top
R22 R054W10% Resistor wirewound R05 4W 10% Top
R23 100R.7W1% Resistor Metal Film 100R.7W1% Top
R24 180R.7W1% Resistor Metal Film 180R.7W1% Top
R25 3K3.7W1% Resistor Metal Film 3K3.7W1% Top
R26 47R.25W5% Resistor Carbon Film 47R.25W5% Top
R27 4K7.7W1% Resistor Metal Film 4K7.7W1% Top
R28 820R.7W1% Resistor Metal Film 820R.7W1% Top
R29 220K.7W1% Resistor Metal Film 220K.7W1% Top
R30 47R.25W5% Resistor Carbon Film 47R.25W5% Top
R31 1K.7W1% Resistor Metal Film 1K.7W1% Top
R32 470R.7W1% Resistor Metal Film 470R.7W1% Top
R33 2K7.7W1% Resistor Metal Film 2K7.7W1% Top
R34 390R.7W1% Resistor Metal Film 390R.7W1% Top
R35 15R.25W5% Resistor Carbon Film 15R.25W5% Top
R36 3K91W5%SO5 Resistor metal film 3K9 1W 5% 5mm stand off Top
R37 22R.25W5% Resistor Carbon Film 22R.25W5% Top
VR1 VR220RLY2X3M Trimpotentiometer 220R lying 2x3modules Top

=pÉêîáÅÉ=j~åì~ä=^fae^= m~ÖÉ=N=ENMF=
=
AIDHA
Schematics for AIDHA.....................................................................................2
Board placement for AIDHA ............................................................................3
Component list for LDP42, AIDHA - rev 03A.................................................4
Variant specific components.............................................................................9
Description for variant dependent components...............................................10

=pÉêîáÅÉ=j~åì~ä=^fae^= m~ÖÉ=O=ENMF=
=
pÅÜÉã~íáÅë=Ñçê=^fae^=

=pÉêîáÅÉ=j~åì~ä=^fae^= m~ÖÉ=P=ENMF=
=
_ç~êÇ=éä~ÅÉãÉåí=Ñçê=^fae^=

=pÉêîáÅÉ=j~åì~ä=^fae^= m~ÖÉ=Q=ENMF=
=
`çãéçåÉåí=äáëí=Ñçê=iamQOI=^fae^=J=êÉî=MP^=
- Safety critical component. Should only be replaced with the specified type.
Position Partnumber Description Comment Side
C1 100n63VMMK5 Capacitor polyester 100n 63V MMK 5mm Top
C2 22p200VNP05%5 Capacitor ceramic 22p 200V NP0 5% 5mm Top
C3 22p200VNP05%5 Capacitor ceramic 22p 200V NP0 5% 5mm Top
C4 22p200VNP05%5 Capacitor ceramic 22p 200V NP0 5% 5mm Top
C5 22u50V Capacitor electrolytic 22u 50V 5mm Top
C6 22u50V Capacitor electrolytic 22u 50V 5mm Top
C7 100n250VMMK10 Capacitor polyester 100n 250V MMK 10mm Top
C8 4u750V Capacitor electrolytic 4u7 50V 5mm Top
C9 4u750V Capacitor electrolytic 4u7 50V 5mm Top
C10 220n63VMMK5 Capacitor polyester 220n 63V MMK 5mm Top
C11 22u50V Capacitor electrolytic 22u 50V 5mm Top
C12 68p200VNP05%5 Capacitor ceramic 68p 200V NP0 5% 5mm Top
C13 10n250VMMK5 Capacitor polyester 10n 250V MMK 5mm Top
C14 22u50V Capacitor electrolytic 22u 50V 5mm Top
C15 470p200VNP05%5 Capacitor ceramic 470p 200V NP0 5% 5mm Top
C16 68p200VNP05%5 Capacitor ceramic 68p 200V NP0 5% 5mm Top
C17 220u16V Capacitor electrolytic 220u 16V 5mm Top
C18 82p100VNP05%5 Capacitor ceramic 82p 100V NP0 5% 5mm Top
C19 4u750V Capacitor electrolytic 4u7 50V 5mm Top
C20 Variant dependent, see separate list Top
C21 Variant dependent, see separate list Top
C101 100n63VMMK5 Capacitor polyester 100n 63V MMK 5mm Top
C102 22p200VNP05%5 Capacitor ceramic 22p 200V NP0 5% 5mm Top
C103 22p200VNP05%5 Capacitor ceramic 22p 200V NP0 5% 5mm Top
C104 22p200VNP05%5 Capacitor ceramic 22p 200V NP0 5% 5mm Top
C105 22u50V Capacitor electrolytic 22u 50V 5mm Top
C106 22u50V Capacitor electrolytic 22u 50V 5mm Top
C107 100n250VMMK10 Capacitor polyester 100n 250V MMK 10mm Top
C108 4u750V Capacitor electrolytic 4u7 50V 5mm Top
C109 4u750V Capacitor electrolytic 4u7 50V 5mm Top
C110 220n63VMMK5 Capacitor polyester 220n 63V MMK 5mm Top
C111 22u50V Capacitor electrolytic 22u 50V 5mm Top
C112 68p200VNP05%5 Capacitor ceramic 68p 200V NP0 5% 5mm Top
C113 10n250VMMK5 Capacitor polyester 10n 250V MMK 5mm Top
C114 22u50V Capacitor electrolytic 22u 50V 5mm Top
C115 470p200VNP05%5 Capacitor ceramic 470p 200V NP0 5% 5mm Top
C116 68p200VNP05%5 Capacitor ceramic 68p 200V NP0 5% 5mm Top
C117 220u16V Capacitor electrolytic 220u 16V 5mm Top
C118 82p100VNP05%5 Capacitor ceramic 82p 100V NP0 5% 5mm Top
C119 4u750V Capacitor electrolytic 4u7 50V 5mm Top
C120 Variant dependent, see separate list Top
C121 Variant dependent, see separate list Top
C201 22u50V Capacitor electrolytic 22u 50V 5mm Top
C202 22u50V Capacitor electrolytic 22u 50V 5mm Top
C203 100n50VY5W5%5 Capacitor ceramic 100n 50V Y5W 5% 5mm Top
C204 2200u40V18x30A Capacitor electrolytic 2200u 40V 18x30mm axial Top
C205 2200u40V18x30A Capacitor electrolytic 2200u 40V 18x30mm axial Top
C206 10000u63V35X45LY Capacitor electrolytic 10000u 63V 35x45mm snap in lying Top
C207 10000u63V35X45LY Capacitor electrolytic 10000u 63V 35x45mm snap in lying Top
C208 22u50V Capacitor electrolytic 22u 50V 5mm Top
C209 22u50V Capacitor electrolytic 22u 50V 5mm Top
D1 1N4148 Diode signal 1N4148 Top

=pÉêîáÅÉ=j~åì~ä=^fae^= m~ÖÉ=R=ENMF=
=
Position Partnumber Description Comment Side
D2 1N4148 Diode signal 1N4148 Top
D3 1N4148 Diode signal 1N4148 Top
D4 1N4148 Diode signal 1N4148 Top
D5 1N4148 Diode signal 1N4148 Top
D6 1N4148 Diode signal 1N4148 Top
D7 1N4148 Diode signal 1N4148 Top
D8 1N4148 Diode signal 1N4148 Top
D9 1N4148 Diode signal 1N4148 Top
D10 1N4148 Diode signal 1N4148 Top
D11 1N4148 Diode signal 1N4148 Top
D12 1N4148 Diode signal 1N4148 Top
D13 1N4148 Diode signal 1N4148 Top
D14 1N4148 Diode signal 1N4148 Top
D15 1N4148 Diode signal 1N4148 Top
D16 Variant dependent, see separate list Top
D17 Variant dependent, see separate list Top
D18 Variant dependent, see separate list Top
D19 Variant dependent, see separate list Top
D20 Variant dependent, see separate list Top
D21 Variant dependent, see separate list Top
D101 1N4148 Diode signal 1N4148 Top
D102 1N4148 Diode signal 1N4148 Top
D103 1N4148 Diode signal 1N4148 Top
D104 1N4148 Diode signal 1N4148 Top
D105 1N4148 Diode signal 1N4148 Top
D106 1N4148 Diode signal 1N4148 Top
D107 1N4148 Diode signal 1N4148 Top
D108 1N4148 Diode signal 1N4148 Top
D109 1N4148 Diode signal 1N4148 Top
D110 1N4148 Diode signal 1N4148 Top
D111 1N4148 Diode signal 1N4148 Top
D112 1N4148 Diode signal 1N4148 Top
D113 1N4148 Diode signal 1N4148 Top
D114 1N4148 Diode signal 1N4148 Top
D115 1N4148 Diode signal 1N4148 Top
D116 Variant dependent, see separate list Top
D117 Variant dependent, see separate list Top
D118 Variant dependent, see separate list Top
D119 Variant dependent, see separate list Top
D120 Variant dependent, see separate list Top
D121 Variant dependent, see separate list Top
D201 1N5404 Diode power 1N5404 Top
D202 1N5404 Diode power 1N5404 Top
D203 18V1.3W5% Diode zener 18V 1.3W 5% Top
D204 18V1.3W5% Diode zener 18V 1.3W 5% Top
D205 PBC10-04 Diode bridge PBC10-04 Top
D206 1N4148 Diode signal 1N4148 Top
D207 1N4148 Diode signal 1N4148 Top
FU1 T5A250-5x20 Fuse slow blow 5A 250V 5x20mm Top
FU2 T5A250-5x20 Fuse slow blow 5A 250V 5x20mm Top
FU101 T5A250-5x20 Fuse slow blow 5A 250V 5x20mm Top
FU102 T5A250-5x20 Fuse slow blow 5A 250V 5x20mm Top
FU201 T4A250-5x20 Fuse slow blow 4A 250V 5x20mm Top
FU202 T4A250-5x20 Fuse slow blow 4A 250V 5x20mm Top

=pÉêîáÅÉ=j~åì~ä=^fae^= m~ÖÉ=S=ENMF=
=
Position Partnumber Description Comment Side
L1 L2xBEAD2M Inductor bead double 2 modules Top
L2 L2xBEAD2M Inductor bead double 2 modules Top
L7 1u2HD1.4_LAB Inductor 1,2uH axial LAB. Rev 01 Top
L101 L2xBEAD2M Inductor bead double 2 modules Top
L102 L2xBEAD2M Inductor bead double 2 modules Top
L107 1u2HD1.4_LAB Inductor 1,2uH axial LAB. Rev 01 Top
P1 NCJ6FI-H_NEU Connector XLR/J 3pole female+jack 90dg NEUTRIK NCJ6FI-H Top
P2 - Not used Top
P3 Variant dependent, see separate list Top
P4a SO8P901M Socket 8pole 90dg 1module Top
P4b Variant dependent, see separate list Top
P5 FBPC5x209M Fuseblock PCB 5x20mm fuse 9 modules Top
P6 FBPC5x209M Fuseblock PCB 5x20mm fuse 9 modules Top
P101 NCJ6FI-H_NEU Connector XLR/J 3pole female+jack 90dg NEUTRIK NCJ6FI-H Top
P102 - Not used Top
P103 Variant dependent, see separate list Top
P104a SO8P901M Socket 8pole 90dg 1module Top
P104b Variant dependent, see separate list Top
P105 FBPC5x209M Fuseblock PCB 5x20mm fuse 9 modules Top
P106 FBPC5x209M Fuseblock PCB 5x20mm fuse 9 modules Top
P201 DI16P901M_PRE Dil socket 16pole 90dg 1 module PRECI-DIP 299-93-316-11-001 Top
P202 FBPC5x209M Fuseblock PCB 5x20mm fuse 9 modules Top
P203 FBPC5x209M Fuseblock PCB 5x20mm fuse 9 modules Top
Q1 Q6015L5 Triac Q6015L5 Top
Q2 BC557B Transistor bipolar signal BC557B Top
Q3 BC547B Transistor bipolar signal BC547B Top
Q4 BC547B Transistor bipolar signal BC547B Top
Q5 BC557B Transistor bipolar signal BC557B Top
Q6 MPSA92 Transistor bipolar signal MPSA92 Top
Q7 MPSA42 Transistor bipolar signal MPSA42 Top
Q8 2N5457 Transistor Jfet signal 2N5457 Top
Q9 Variant dependent, see separate list Top
Q10 Variant dependent, see separate list Top
Q11 Variant dependent, see separate list Top
Q101 Q6015L5 Triac Q6015L5 Top
Q102 BC557B Transistor bipolar signal BC557B Top
Q103 BC547B Transistor bipolar signal BC547B Top
Q104 BC547B Transistor bipolar signal BC547B Top
Q105 BC557B Transistor bipolar signal BC557B Top
Q106 MPSA92 Transistor bipolar signal MPSA92 Top
Q107 MPSA42 Transistor bipolar signal MPSA42 Top
Q108 2N5457 Transistor Jfet signal 2N5457 Top
Q109 Variant dependent, see separate list Top
Q110 Variant dependent, see separate list Top
Q111 Variant dependent, see separate list Top
Q201 MPSA42 Transistor bipolar signal MPSA42 Top
Q202 MPSA92 Transistor bipolar signal MPSA92 Top
R1 10K.7W1% Resistor Metal Film 10K.7W1% Top
R2 10K.7W1% Resistor Metal Film 10K.7W1% Top
R3 10K.7W1% Resistor Metal Film 10K.7W1% Top
R4 10K.7W1% Resistor Metal Film 10K.7W1% Top
R5 10K.7W1% Resistor Metal Film 10K.7W1% Top
R6 30K.7W1% Resistor Metal Film 30K.7W1% Top
R7 2K.7W1% Resistor Metal Film 2K.7W1% Top
R8 4K7.7W1% Resistor Metal Film 4K7.7W1% Top

=pÉêîáÅÉ=j~åì~ä=^fae^= m~ÖÉ=T=ENMF=
=
Position Partnumber Description Comment Side
R9 4K7.7W1% Resistor Metal Film 4K7.7W1% Top
R10 4K7.7W1% Resistor Metal Film 4K7.7W1% Top
R11 47R.25W5% Resistor Carbon Film 47R.25W5% Top
R12 2R22W5% Resistor metal film 2R2 2W 5% Top
R13 220K.7W1% Resistor Metal Film 220K.7W1% Top
R14 47R.25W5% Resistor Carbon Film 47R.25W5% Top
R15 390K.7W1% Resistor Metal Film 390K.7W1% Top
R16 22K.7W1% Resistor Metal Film 22K.7W1% Top
R17 22K.7W1% Resistor Metal Film 22K.7W1% Top
R18 120K.7W1% Resistor Metal Film 120K.7W1% Top
R19 4M7.25W5% Resistor Carbon Film 4M7.25W5% Top
R20 4M7.25W5% Resistor Carbon Film 4M7.25W5% Top
R21 150K.7W1% Resistor Metal Film 150K.7W1% Top
R22 330K.7W1% Resistor Metal Film 330K.7W1% Top
R23 150R.7W1% Resistor Metal Film 150R.7W1% Top
R24 150K.7W1% Resistor Metal Film 150K.7W1% Top
R25 19K6.7W1% Resistor Metal Film 19K6.7W1% Top
R26 33K.7W1% Resistor Metal Film 33K.7W1% Top
R27 680K.7W1% Resistor Metal Film 680K.7W1% Top
R28 33K.7W1% Resistor Metal Film 33K.7W1% Top
R29 33K.7W1% Resistor Metal Film 33K.7W1% Top
R30 4M7.25W5% Resistor Carbon Film 4M7.25W5% Top
R31 2K2.7W1% Resistor Metal Film 2K2.7W1% Top
R32 4K7.7W1% Resistor Metal Film 4K7.7W1% Top
R33 330K.7W1% Resistor Metal Film 330K.7W1% Top
R34 4K7.7W1% Resistor Metal Film 4K7.7W1% Top
R35 100R.7W1% Resistor Metal Film 100R.7W1% Top
R36 1K5.7W1% Resistor Metal Film 1K5.7W1% Top
R37 1K5.7W1% Resistor Metal Film 1K5.7W1% Top
R38 22K6.7W1% Resistor Metal Film 22K6.7W1% Top
R39 620R.7W1% Resistor Metal Film 620R.7W1% Top
R40 12K.7W1% Resistor Metal Film 12K.7W1% Top
R41 12K.7W1% Resistor Metal Film 12K.7W1% Top
R42 1K5.7W1% Resistor Metal Film 1K5.7W1% Top
R43 1K5.7W1% Resistor Metal Film 1K5.7W1% Top
R44 2K2.7W1% Resistor Metal Film 2K2.7W1% Top
R45 22K.7W1% Resistor Metal Film 22K.7W1% Top
R46 34K.7W1% Resistor Metal Film 34K.7W1% Top
R47 Variant dependent, see separate list Top
R48 Variant dependent, see separate list Top
R49 Variant dependent, see separate list Top
R50 Variant dependent, see separate list Top
R51 Variant dependent, see separate list Top
R52 Variant dependent, see separate list Top
R53 Variant dependent, see separate list Top
R54 Variant dependent, see separate list Top
R55 Variant dependent, see separate list Top
R56 10R.7W1% Resistor Metal Film 10R.7W1% Top
R57 Variant dependent, see separate list Top
R101 10K.7W1% Resistor Metal Film 10K.7W1% Top
R102 10K.7W1% Resistor Metal Film 10K.7W1% Top
R103 10K.7W1% Resistor Metal Film 10K.7W1% Top
R104 10K.7W1% Resistor Metal Film 10K.7W1% Top
R105 10K.7W1% Resistor Metal Film 10K.7W1% Top
R106 30K.7W1% Resistor Metal Film 30K.7W1% Top

=pÉêîáÅÉ=j~åì~ä=^fae^= m~ÖÉ=U=ENMF=
=
Position Partnumber Description Comment Side
R107 2K.7W1% Resistor Metal Film 2K.7W1% Top
R108 4K7.7W1% Resistor Metal Film 4K7.7W1% Top
R109 4K7.7W1% Resistor Metal Film 4K7.7W1% Top
R110 4K7.7W1% Resistor Metal Film 4K7.7W1% Top
R111 47R.25W5% Resistor Carbon Film 47R.25W5% Top
R112 2R22W5% Resistor metal film 2R2 2W 5% Top
R113 220K.7W1% Resistor Metal Film 220K.7W1% Top
R114 47R.25W5% Resistor Carbon Film 47R.25W5% Top
R115 390K.7W1% Resistor Metal Film 390K.7W1% Top
R116 22K.7W1% Resistor Metal Film 22K.7W1% Top
R117 22K.7W1% Resistor Metal Film 22K.7W1% Top
R118 120K.7W1% Resistor Metal Film 120K.7W1% Top
R119 4M7.25W5% Resistor Carbon Film 4M7.25W5% Top
R120 4M7.25W5% Resistor Carbon Film 4M7.25W5% Top
R121 150K.7W1% Resistor Metal Film 150K.7W1% Top
R122 330K.7W1% Resistor Metal Film 330K.7W1% Top
R123 150R.7W1% Resistor Metal Film 150R.7W1% Top
R124 150K.7W1% Resistor Metal Film 150K.7W1% Top
R125 19K6.7W1% Resistor Metal Film 19K6.7W1% Top
R126 33K.7W1% Resistor Metal Film 33K.7W1% Top
R127 680K.7W1% Resistor Metal Film 680K.7W1% Top
R128 33K.7W1% Resistor Metal Film 33K.7W1% Top
R129 33K.7W1% Resistor Metal Film 33K.7W1% Top
R130 4M7.25W5% Resistor Carbon Film 4M7.25W5% Top
R131 2K2.7W1% Resistor Metal Film 2K2.7W1% Top
R132 4K7.7W1% Resistor Metal Film 4K7.7W1% Top
R133 330K.7W1% Resistor Metal Film 330K.7W1% Top
R134 4K7.7W1% Resistor Metal Film 4K7.7W1% Top
R135 100R.7W1% Resistor Metal Film 100R.7W1% Top
R136 1K5.7W1% Resistor Metal Film 1K5.7W1% Top
R137 1K5.7W1% Resistor Metal Film 1K5.7W1% Top
R138 22K6.7W1% Resistor Metal Film 22K6.7W1% Top
R139 620R.7W1% Resistor Metal Film 620R.7W1% Top
R140 12K.7W1% Resistor Metal Film 12K.7W1% Top
R141 12K.7W1% Resistor Metal Film 12K.7W1% Top
R142 1K5.7W1% Resistor Metal Film 1K5.7W1% Top
R143 1K5.7W1% Resistor Metal Film 1K5.7W1% Top
R144 2K2.7W1% Resistor Metal Film 2K2.7W1% Top
R145 22K.7W1% Resistor Metal Film 22K.7W1% Top
R146 34K.7W1% Resistor Metal Film 34K.7W1% Top
R147 Variant dependent, see separate list Top
R148 Variant dependent, see separate list Top
R149 Variant dependent, see separate list Top
R150 Variant dependent, see separate list Top
R151 Variant dependent, see separate list Top
R152 Variant dependent, see separate list Top
R153 Variant dependent, see separate list Top
R154 Variant dependent, see separate list Top
R155 Variant dependent, see separate list Top
R156 10R.7W1% Resistor Metal Film 10R.7W1% Top
R157 Variant dependent, see separate list Top
R201 1K53W5% Resistor metal film 1K5 3W 5% Top
R202 10R.7W1% Resistor Metal Film 10R.7W1% Top
R203 10K.7W1% Resistor Metal Film 10K.7W1% Top
R204 100R.7W1% Resistor Metal Film 100R.7W1% Top

=pÉêîáÅÉ=j~åì~ä=^fae^= m~ÖÉ=V=ENMF=
=
Position Partnumber Description Comment Side
R205 1K53W5% Resistor metal film 1K5 3W 5% Top
R206 10K.7W1% Resistor Metal Film 10K.7W1% Top
R207 100R.7W1% Resistor Metal Film 100R.7W1% Top
R208 5K62.7W1% Resistor Metal Film 5K62.7W1% Top
S5 SPPJ32F29A_ALP Switch inter locking PCB DPDT ALPS SPPJ32F29A Top
U1 MC33078 IC Operational amplifier MC33078 Top
U2 LF353 IC Operational amplifier LF353 Top
U3 VTL5C4 IC photocoupler VTL5C4 Top
U101 MC33078 IC Operational amplifier MC33078 Top
U102 LF353 IC Operational amplifier LF353 Top
U103 VTL5C4 IC photocoupler VTL5C4 Top
U201 NE5532 IC Operational amplifier NE5532 Top
VR1 Variant dependent, see separate list Top
VR101 Variant dependent, see separate list Top
s~êá~åí=ëéÉÅáÑáÅ=ÅçãéçåÉåíë=
Position AIDHA-L32 AIDHA-L30 AIDHA-30
C20 1u50V 1u50V -
C21 1u50V 1u50V -
C120 1u50V 1u50V -
C121 1u50V 1u50V -
D16 1N4148 1N4148 -
D17 1N4148 1N4148 -
D18 LYEL2.5X5 LYEL2.5X5 -
D19 LRED2.5X5 LRED2.5X5 -
D20 LGRN2.5X5 LGRN2.5X5 -
D21 LGRN2.5X5 LGRN2.5X5 -
D116 1N4148 1N4148 -
D117 1N4148 1N4148 -
D118 LYEL2.5X5 LYEL2.5X5 -
D119 LRED2.5X5 LRED2.5X5 -
D120 LGRN2.5X5 LGRN2.5X5 -
D121 LGRN2.5X5 LGRN2.5X5 -
P3 TBPI3P90M_SAU - -
P4b PH7P1M PH7P1M -
P103 TBPI3P90M_SAU - -
P104b PH7P1M PH7P1M -
Q9 BC547B BC547B -
Q10 BC557B BC557B -
Q11 BC557B BC557B -
Q109 BC547B BC547B -
Q110 BC557B BC557B -
Q111 BC557B BC557B -
R47 33K.7W1% 33K.7W1% -
R48 8K2.7W1% 8K2.7W1% -
R49 4K32.7W1% 4K32.7W1% -
R50 33K.7W1% 33K.7W1% -
R51 2K2.7W1% 2K2.7W1% -
R52 2K2.7W1% 2K2.7W1% -
R53 68K.7W1% 68K.7W1% -
R54 2K2.7W1% 2K2.7W1% -

=pÉêîáÅÉ=j~åì~ä=^fae^= m~ÖÉ=NM=ENMF=
=
Position AIDHA-L32 AIDHA-L30 AIDHA-30
R55 2K71W5% 2K71W5% -
R57 - 150K.7W1% 150K.7W1%
R147 33K.7W1% 33K.7W1% -
R148 8K2.7W1% 8K2.7W1% -
R149 4K32.7W1% 4K32.7W1% -
R150 33K.7W1% 33K.7W1% -
R151 2K2.7W1% 2K2.7W1% -
R152 2K2.7W1% 2K2.7W1% -
R153 68K.7W1% 68K.7W1% -
R154 2K2.7W1% 2K2.7W1% -
R155 2K71W5% 2K71W5% -
R157 - 150K.7W1% 150K.7W1%
VR1 VR10KLIN31_TOK VR10KLIN31_TOK -
VR101 VR10KLIN31_TOK VR10KLIN31_TOK -
aÉëÅêáéíáçå=Ñçê=î~êá~åí=ÇÉéÉåÇÉåí=ÅçãéçåÉåíë=
Partnumber Description
150K.7W1% Resistor Metal Film 150K.7W1%
1N4148 Diode signal 1N4148
1u50V Capacitor electrolytic 1u 50V 5mm
2K2.7W1% Resistor Metal Film 2K2.7W1%
2K71W5% Resistor metal film 2K7 1W 5%
33K.7W1% Resistor Metal Film 33K.7W1%
4K32.7W1% Resistor Metal Film 4K32.7W1%
68K.7W1% Resistor Metal Film 68K.7W1%
8K2.7W1% Resistor Metal Film 8K2.7W1%
BC547B Transistor bipolar signal BC547B
BC557B Transistor bipolar signal BC557B
LGRN2.5X5 Diode LED Green 2.5x5mm
LRED2.5X5 Diode LED Red 2.5x5mm
LYEL2.5X5 Diode LED Yellow 2.5x5mm
PH7P1M Pin header 7pole 1module
TBPI3P90M_SAU Terminal block plug in 3pole 90dg male 3.81mm Sauro CTM039PT
VR10KLIN31_TOK Potentiometer 10K LIN 31step TOKOS B103 TP96N08 Y4929 Rev1
