Lab.gruppen FP+ Series FP 13000 User manual

Item no. CDTD_FP13000_V4
Current Draw and Thermal Dissipation
FP+ Series: Dedicated Touring Amplifiers
FP 13000
Lab.gruppen ab •Sweden
internationaL contact • [e-mail] | uS contact • [e-mail]
www.labgruppen.com
-10dB
-inf 0
-10dB
-inf 0
Bchannel
channel
A
FP SERIES
VHF
TEM
VHF
TEM
channel A
-20 -15 -10 -4 VPL CPL
channel B
-20 -15 -10 -4 VPL CPL
BRIDGE A+B
SIG
SIG
PWR
P A L
NOMAD
LINK
MUTE
MUTE
CLIP
CLIP HI-IMP
HI-IMP
FP13000
R
P O W
P O W
The following tables contain information on measured current consumption as well as calculated heat dissipation during normal operation
(1/8 rated power); and during extreme heavy duty operation (1/4 rated power).
FP 13000
Level Load Rated Power Line Current *2) Watt *1) Thermal Dissipation
115 VAC 230 VAC In Out Dissipated BTU/hr kCal/hr
Standby, with remote power off via NomadLink 0 0 0 0 0
Powered on, idling 129 0129 440 111
Amp (I) Watt
Pink noise (1/8
rated power)
16 Ω/ Ch. 1200 x 2
10.6 5.3 678 300 378 1289 325
32 Ω/ Bridged 2400 x 1
8 Ω/ Ch. 2350 x 2
16.2 8.1 1083 588 495 1690 426
16 Ω/ Bridged 4700 x 1
4 Ω/ Ch. 4400 x 2
26.5 13.2 1856 1100 756 2578 650
8 Ω/ Bridged 8800 x 1
2 Ω/ Ch. 6500 x 2
37.8 18.9 2536 1625 911 3109 783
4 Ω/ Bridged 13000 x 1
Pink noise (1/4
rated power)
*3)
16 Ω/ Ch. 1200 x 2
16.0 8.0 1037 800 237 807 203
32 Ω/ Bridged 2400 x 1
8 Ω/ Ch. 2350 x 2
27.2 13.6 1840 1567 273 933 235
16 Ω/ Bridged 4700 x 1
4 Ω/ Ch. 4400 x 2
48.3 24.1 3419 2933 486 1659 418
8 Ω/ Bridged 8800 x 1
2 Ω/ Ch. 6500 x 2
58.0 29.0 4243 3250 993 3390 854
4 Ω/ Bridged 13000 x 1
Mains connector, 230 V CE version 16 A, CEE7
Mains connector, 115 V ETL version 30 A, Nema L5-30P Twist lock
*1) The amplifier’s PSU operates as a non-resistive load, so the calculation “Volts x Amps = Watts” would not be correct. Instead, measured and
specified here is what is known as the “Active Power” of the amplifier providing useful, real-world values of power consumption and heat dissipation.
*2) Current draw figures measured at 230 V. 115 V figures are 230 V figures multiplied by two.
*3) Figures measured at maximum power before amplifier protection and limiter features are engaged. Typically this is between 1/4 and 1/3 of rated
power. Note that the max. power condition is very extreme and will not occur during normal operation. Also note that the mains breaker will not be
tripped even if operation is in excess of max. ratings.
