Lacanche LSG 1050 User manual

LSG 1050 - LSCF 1050 - LSVTR 1050
LSG 730/740 - LSVTR 740
LSG 640
"HOBS"
Ft 134a - FR - Rév 00 - Date modif : 11/06/07 1/37

TECHNICAL DATA SHEETS, MEASUREMENTS AND DIMENSIONS
—————————————————————————————————————————3
INSTALLER’S MANUAL 9
SITTING
—————————————————————————————————————————11
GAS CONNECTION
—————————————————————————————————————————13
OPENING AND REFITTING THE HOB
—————————————————————————————————————————14
CHANGE OF GAS
—————————————————————————————————————————15
ELECTRIC CONNECTION
—————————————————————————————————————————17
REPARATIES
—————————————————————————————————————————18
ELECTRIC CIRCUIT DIAGRAMS
—————————————————————————————————————————19
LIGNE GAZ
—————————————————————————————————————————20
USER’S MANUAL 21
CAUTIONS
—————————————————————————————————————————23
GAS FLAME HOB, 5 hobs
—————————————————————————————————————————25
GAS FLAME HOB, 4 hobs
—————————————————————————————————————————27
HEATING PLATE, 5 hobs
—————————————————————————————————————————29
HEATING PLATE, 3 hobs
—————————————————————————————————————————30
CERAMIC HOB, 5 hobs
—————————————————————————————————————————31
CERAMIC HOB, 4 hobs
—————————————————————————————————————————33
CLEANING AND MAINTENANCE
—————————————————————————————————————————35
Information regarding the elimination of electric and electronic waste
—————————————————————————————————————————37
Ft 134a - FR - Rév 00 - Date modif : 11/06/07 2/37

INSTALLER’S MANUAL
►LSCF 1050 «TRADITION»
4 gas hobs and one heating plate :
- 5 burners of different size and power (see hobs T,
B, C, D tabel 1, appendix 0)
- Foyer central équipé d’une plaque coup de feu
385x510 mm.
- Individually controlled by a (thermocouple) safety
valve.
LSG 1050 « CLASSIQUE» AND «TRADITION» : GAS HOBS
Nota :*Cet appareil est réglable à l’aide de vérins sur une
plage de 13 mm
N.B.This range can be adjusted by up to13 mm by means of
adjustable feet
61
C
C
B
D
A
C
C
B
D
T
1000
55
55
890
197
35
650
722.5
16
131 416
20.5
136.5
De 246 à 259
Gaz
108
Plaque a bornes
73.5
►LSG 1050 «CLASSIQUE»
5 gas hobs :
- 5 burners of different size and power (see hobs A,
B, C, D tabel 1, appendix 0).
- Individually controlled by a (thermocouple) safety
valve.
- Electric ignition.
500
61
61
500
61
► Stainless steel casing or enamelled steel .
► Pressed cooking surface.
TECHNICAL DATA SHEETS, MEASUREMENTS
AND DIMENSIONS
Gas connection : Tube ∅ 15/21, 1/2” gas thread, on male
coupling
Electric connection, on terminal block at the rear of the
appliance
Pressures and hourly consumption :
Appliance gas supplying can be switched, please refer to rating plate and marking at the rear of the
appliance (F/O, T, A, B, C, D : tab.3, appendix 0).
Directives : Gas appliances : 90/396/CEE - Low Voltage : 73/23/CEE - CEM : 89/336/CEE
Ft 134a - FR - Rév 00 - Date modif : 11/06/07 3/37

INSTALLER’S MANUAL
LSVTR 1050 : ELECTRIC HOBS
Nota :*Cet appareil est réglable à l’aide de vérins sur une plage de 13 mm
N.B.This range can be adjusted by up to13 mm by means of adjustable feet
650
722.5
16
131 416
20.5
136.5
Gaz
108
Plaque a bornes
73.5
1000
990
55
197
55
500
Directives
Low Voltage : 73/23/CEE
CEM : 89/336/CEE
B
A
A
B
C
TECHNICAL DATA SHEETS, MEASUREMENTS
AND DIMENSIONS
►ELECTRIC HOB WITH VITRO-CERAMIC
HOTPLATES
- 5 ceramic hobs of different sizes and ratings under
a 6 mm glass-ceramic surface (Hobs A, B, C tabel
2 in appendix 0).
Power: 10600 W – 230 V 1N~ 50 Hz/ 400 V 3N~ 50 Hz
► Stainless steel casing or enamelled steel .
► Pressed cooking surface.
Electric connection, on terminal block at the rear of the
appliance
Ft 134a - FR - Rév 00 - Date modif : 11/06/07 4/37

INSTALLER’S MANUAL
LSG 700 « CLASSIQUE» AND «TRADITION» : GAS HOBS
Nota :*Cet appareil est réglable à l’aide de vérins sur une plage de 13 mm
N.B.This range can be adjusted by up to13 mm by means of adjustable feet
►LSG 740 «CLASSIQUE»
4 gas hobs :
- 4 burners of different size and power (see hobs B,
C, D tabel 1, appendix 0).
- Individually controlled by a (thermocouple) safety
valve.
- Electric ignition.
►LSG 730 «CLASSIQUE»
3 gas hobs :
- 3 burners of different size and power (see hobs A,
C, D tabel 1, appendix 0).
- Individually controlled by a (thermocouple) safety
valve.
- Electric ignition.
350
61
D
C
A
C
C
D
B
55
650
722.5
16
131
416
20.5
136.5
Gaz
108
Plaque a bornes
73.5
De 246 È 259
35
197
700
55
590
55
61
350
61
TECHNICAL DATA SHEETS, MEASUREMENTS
AND DIMENSIONS
► Stainless steel casing or enamelled steel .
► Pressed cooking surface.
Gas connection : Tube ∅ 15/21, 1/2” gas thread, on male
coupling
Electric connection, on terminal block at the rear of the
appliance
Ft 134a - FR - Rév 00 - Date modif : 11/06/07 5/37

INSTALLER’S MANUAL
LSG 600 « CLASSIQUE» : GAS HOBS
Nota :*Cet appareil est réglable à l’aide de vérins sur une plage de 13 mm
N.B.This range can be adjusted by up to13 mm by means of adjustable feet
►LSG 640 «CLASSIQUE»
4 gas hobs :
- 4 burners of different size and power (see hobs B,
C, D tabel 1, appendix 0).
- Individually controlled by a (thermocouple) safety
valve.
- Electric ignition.
C
C
D
B
300
61
650
722.5
16
131
416
20.5
136.5
Gaz
108
Plaque a bornes
73.5
De 246 È 259
197
35
600
55
490
55
Pressures and hourly consumption :
Appliance gas supplying can be switched, please refer to rating plate and marking at the rear of the
appliance (F/O, T, A, B, C, D : tab.3, appendix 0).
Directives
Gas appliances : 90/396/CEE
Low Voltage : 73/23/CEE
CEM : 89/336/CEE
TECHNICAL DATA SHEETS, MEASUREMENTS
AND DIMENSIONS
► Stainless steel casing or enamelled steel .
► Pressed cooking surface.
Gas connection : Tube ∅ 15/21, 1/2” gas thread, on male
coupling
Electric connection, on terminal block at the rear of the
appliance
Ft 134a - FR - Rév 00 - Date modif : 11/06/07 6/37

INSTALLER’S MANUAL
LSVTR 740 : TABLE DE CUISSON ELECTRIQUE
Nota :*Cet appareil est réglable à l’aide de vérins sur une plage de 13 mm
N.B.This range can be adjusted by up to13 mm by means of adjustable feet
650
722.5
16
131 416
20.5
136.5
Gaz
108
Plaque a bornes
73.5
700
990
55
197
55
►ELECTRIC HOB WITH VITRO-CERAMIC
HOTPLATES
- 4 ceramic hobs of different sizes and ratings under
a 6 mm glass-ceramic surface (Hobs A, B, tabel 2
in appendix 0).
Power : 8400 W – 230 V 1N~ 50 Hz/ 400 V 3N~ 50 Hz
350
B
A
A
B
TECHNICAL DATA SHEETS, MEASUREMENTS
AND DIMENSIONS
► Stainless steel casing or enamelled steel .
► Pressed cooking surface.
Electric connection, on terminal block at the rear of the
appliance
Directives
Low Voltage : 73/23/CEE
CEM : 89/336/CEE
Ft 134a - FR - Rév 00 - Date modif : 11/06/07 7/37

INSTALLER’S MANUAL
Appliances must be installed in a workmanlike manner in accordance with the instructions in this manual
and locally applicable regulations.
This manual will be handed over to the user after installation.
LSG 1050 - LSCF 1050 - LSVTR 1050
LSG 730/740 - LSVTR 740
LSG 640
Ft 134a - FR - Rév 00 - Date modif : 11/06/07 9/37

INSTALLER’S MANUAL
12
2 We recommend the front edge of the hob be positioned 50 mm further forward than the adjacent
 ttings. (see below).
1 If the adjacent parts contain heat-sensitive materials, ensure there is a 50-mm gap between the
side of the oven and the parts in question.
Ensure that the materials adjacent to the lateral panels of the oven are not
 ammable.
Cautions :
The purchaser undertakes to install or arrange for his/her equipment to be installed in a workmanlike manner
and in accordance with the applicable regulations and standards.
Any servicing or repair work on appliance must be performed by a quali ed technician.
Shipment-Packaging :
Carton packing crate on wooden palette
Unpack and check the appliance is in good condition. In case of damage, note any reservations on
the delivery note and confirm them within 48 hours by registered letter with confirmation of delivery
to the carrier.
◊ Recommendations :
→ Adjust this appliance by using the levelling feet. Allow a minimum clearance of 50 mm between
the appliance and any other surfaces (walls affected by heat).
→ If the appliance is to be built in between two surfaces, it is CRUCIAL to allow free circulation of
air behind the appliance (provide shielding at rear). Cooktops should NEVER be installed lower
than adjacent worksurfaces. It is also recommended to allow the unit front panel to protrude 50 mm
relative to the adjacent units.
→ Must be installed under an exhaust hood.
→ Do not install this unit near combustible walls, partitions, pieces of furniture or decorative
material unless these are covered with adequate thermal insulation of the noncombustible type.
Making sure the resulting installation meets local  re regulations.
SITTING
Ft 134a - FR - Rév 00 - Date modif : 11/06/07 11/37

INSTALLER’S MANUAL
12
Dosseret
◊ Use of the rear splash plate :
This feature is particularly recommended for built-in ovens as it ensures a 50 mm gap between the
appliance and the wall. It also increases the depth of the hob to 722,5 mm.
It also enables you to use the parts more easily :
Ref. LDS 1000.
A shut-off valve must be installed and accessible close to the appliance in order to isolate it from
the supply or to facilitate cutting the gas supply :
- Natural gas supply :
Mandatory to install an Automatic Shut-off Valve (since 1st July 1997 in France)
- Alimentation en GPL (Butane – Propane)
Propane : Class 1 Safety Expansion Valve.
Butane : Butane safety expansion valve  tted to the cylinder (connected to the range by a LPG
approved hose, maximum length 2 metres).
SITTING
Ft 134a - FR - Rév 00 - Date modif : 11/06/07 12/37

INSTALLER’S MANUAL
A
【1】
A1
【2】
Recommendations
LEnsure that the oven is set to the type of gas used (see label on the gas connector).
If the gas supply is not compatible with the gas setting of your range the setting must be modied.
Refer to the “Changing the hob gas” section of the present instructions.
Butane-fuelled units : Connect unit to 2.6 kg/h pressure reducer. Use two cylinders connected to a
3-way valve ahead of the pressure regulator in case of prolonged, continuous duty.
Propane-fuelled units : Connect unit to a 3.0 kg/h pressure reducer. Use two cylinders and a 3-
way valve ahead of the pressure regulator in case of prolonged, continuous duty. The use of 37 kg
or extern cryogenic tanks is both possible and recommended.
Voor het aansluiten :
Check :
◊ That the gas-supply pressure matches the gas pressure for which the range is set.
◊ Pipework is perfectly clean in order to prevent the injectors becoming blocked and malfunctioning
of the magnetic heads.
◊ The gas for which the appliance was set up : rating plate and markings.
◊ Cross-sectional area of gas supply pipework is compatible with the appliance’s thermal output.
◊ Correct fresh air flowrate (Air supply sufcient to enable correct combustion to occur - see
appendix 0).
Gas connection :
Male coupling Ø 15/21, 1/2” gas thread on A (fig.【1】).
After connection :
Check the mains pressure at A1 (fig.【2】).
Check your connection is gastight.
GAS CONNECTION
Ft 134a - FR - Rév 00 - Date modif : 11/06/07 13/37

INSTALLER’S MANUAL
D
To remove top :
1- Remove the pan supports and burners.
2- Unscrew the screw(s) on burners , see B and B1 fig.【3】and【4】.
3- Pull and raise the top after having loosened the 2 screws C (fig.【5】&【6】).
4- Wedge the cooking surface.
B
【3】
B1
【4】
B1
【5】
C
【6】
Retting the cooking surface
When refitting the cooking surface, it is vital to tighten fastening screws. Failure to do so can cause
distortion of the cooking surface.
It may be necessary to open the hob under the following circumstances :
- Making adjustments when changing gas type.
- Adjusting thermocouples.
- Resetting the safety thermostat with vitro-ceramic hob.
OPENING AND REFITTING THE HOB
Ft 134a - FR - Rév 00 - Date modif : 11/06/07 14/37

INSTALLER’S MANUAL
Clé de 2 【7】
E
Clé de 2 【8】
F
【9】
G
【10】
H
D
Changing the gas type
Hob injector:
► Lift the air ring D.
► Replace the injectors E in accordance with table 5 in appendix 0 and figure 【7】 ( Ø in 1/100
mm).
If necessary, the mixer tubes of the lateral burners maintained by a cross-bar H, (H, fig.【10】) may
be released.
To release the tubes loosen screws F (fig.【8】) and then screw (G, fig.【9】).
N.B. When replacing injector(s), also replace the sealing washer (see paragraph “Gas Line”).
Adjusting the primary air of hob burners :
► Position the burner bodies and ame diffusers in their respective locations.
► Adjust the air ring F (see fig.【3】and 【8】, tabel 6 in appendix 0).
N.B: Normal ames are bluish green except for natural gas ames which are violet.
Lacanche ranges are supplied with the gas tting requested when the order is placed. The settings
must be ne-tuned when the range is installed.
The appliance is designed to operate with the gases in table 4, appendix 0.
IMPORTANT : Close the mains gas valve before carrying out any works.
IMPORTANT
In case of use with a gas other than that for which the appliance was initially set up, it is
crucial to replace the injectors and modify the adjustments as dened below.
CHANGE OF GAS
Ft 134a - FR - Rév 00 - Date modif : 11/06/07 15/37

INSTALLER’S MANUAL
【11】
J
【12】
K
Adjusting reduced ow of hob burners :
After connection or change of gas, it is crucial to modify this adjustment :
► Remove the knob.
► Light the appropriate burner.
► Adjust to minimum setting.
► Use a small screwdriver to set the adjusting screw J (fig.【11】).
N.B : Flame is reduced to  of its size in the minimum setting, the burner must remain lit when
changing from maximum setting to minimum setting.
Adjusting the safety devices for each thermocouple of the hob: :
If the burner goes out, having kept the control knob pushed in for roughly twenty seconds, check
that :
- The magnetic head grip the valve moderately.
- The flame touches the point of thermocouple (fig.【12】).
- The thermocouples and magnetic heads are absolutely clean.
CHANGE OF GAS
Ft 134a - FR - Rév 00 - Date modif : 11/06/07 16/37

INSTALLER’S MANUAL
L N
12
400 V 3N ~ 50 Hz 230 V 1N ~ 50 Hz
230 V 1N ~ 50 Hz 230 V 3 ~ 50 Hz
L1 N
L2 L3
12345
N L1 L2 L3
L
12345123
4
5
【1】
【2】
T
U
L
Appliances must be installed in a workmanlike manner in accordance with the instructions in
this manual and locally applicable regulations. This manual will be handed over to the user after
installation.
Before connection, check :
ü That the electrical supply of the system is compatible with the voltage and power of the range..
ü That the user’s fixed installation includes an approved all-pole cut-out device..
Connection : ATTENTION :
- Cable insulation must be type 245 IEC 57 or 245 IEC 66
- The wires in the power supply cable between the anti-tugging device and the terminals must be
long enough to enable the live wires to extend before the ground wire in the event of the cable
being pulled.
- If this unit is permanently connected to a xed electrical cable, the cable should be equipped with
a fault leak protector.
- If this unit is connected to a wall outlet, the outlet should be permanently
- Remove rear cover .
- Use a standard flexible cable to connect to terminal block T
(fig.【1】&【2】).
- Secure the cable by means of cable clamp U (fig.【1】).
It is hazardous to put the appliance into service without connecting it to suitable
ground.
ELECTRIC CONNECTION
No liability can be accepted for accidents resulting from non-compliance with this
requirement or incorrect grounding.
Ft 134a - FR - Rév 00 - Date modif : 11/06/07 17/37

INSTALLER’S MANUAL
All work on or repair of an appliance must be carried out by a qualied installer.
Gas repairs
Greasing gas valve :
The valve may lose its grease through use. It is therefore necessary to grease the valve in order to
make it leaktight and facilitate turning.
1 - Shut off the valve and / or the main electrical supply of the unit.
2 - Take out the knob corresponding to the gas valve to be greased.
3 - Unscrew the head from the body of the burner valve.
4 - Grease the tap shaft (High temperature lubricant, for example : SILICAL GEL ™ BARBAHL).
Caution ! Any excess grease should be removed.
Reverse operation 3 to 1 (in that order) to put valve and knob back on.
Limiting thermostat :
In accordance with the construction regulations, the limiter thermostat is intended to protect the
range from overheating.
In the event of overheating the limiter thermostat is triggered and cuts out the range’s oven
functions.
The advanced technology used in the limiter means that it is very sensitive to impacts and vibration
that may occur during transport and handling.
The limiter may therefore be unexpectedly triggered when the oven is first heated and stop the
oven from working.
To reset limiting thermostat :
1- Remove the ventilation strip from the rear of the hob.
2- Unscrew the cover protecting the knob.
3- Press the knob marked V (fig.【5】)
1- Remove the ventilation strip from the rear of the hob.
2- Unscrew the cover protecting the knob.
3- Press the knob marked V (fig.【5】)
For electric hobs :
The pushbutton is located under the hob. To access it, it is necessary to open the hob (see
paragraph “Opening and refitting the hob”) and press the pushbutton W (fig.【6】).
REPARATIES
V
【5】
W
【6】
Ft 134a - FR - Rév 00 - Date modif : 11/06/07 18/37

INSTALLER’S MANUAL











LSG1050
N2N1
L3L2L1 N2N1
L3L2L1
LE
H
SB
2S
P1 H
RV1
(simple)
3 1 4
P3 P1 P2
2 1 3 45
Crd
H
SB
2S
P1 H
2S
P1 H
RV1
(simple)
3 1 4
P3 P1 P2
2 1 3 45
P3 P1 P2
2 1 3 45 2 1 3 45
Crd
H
S2
RV2
(double)
24
4A
P1 P2 Pilot
4A 4 2
S1
S2
S
H
Crd
H
SB
2S
P1 H
RV1
(simple)
3 1 4
P3 P1 P2
2 1 3 45
Crd
H
SB
2S
P1 H
2S
P1 H
RV1
(simple)
3 1 4
P3 P1 P2
2 1 3 45
P3 P1 P2
2 1 3 45 2 1 3 45
Crd
H
S2
RV2
(double)
24
4A
P1 P2 Pilot
4A 4 2
S1
S2
S
H
Crd
H
S2
RV2
(double)
24
4A
P1 P2 Pilot
4A 4 2
S1
S2
S
H
Crd
H
S2
RV3
(ovale)
24
4A
P1 P2 Pilot
4A 4 2
S1
S2
S
H
Crd
H
S2
RV3
(ovale)
24
4A
P1 P2 Pilot
4A 4 2
S1
S2
S
H
Crd
St
TT
TD
TD
LSVTR1050
N2N1
L3L2L1
LE
H
S1
2S
P1 H
RV1
3 1 4
P3 P1 P2
2 1 3 45
Crd
H
S2
RV2
24
4A
P1 P2 Pilot
4A 4 2
S1
S2
S
H
Crd
H
S1
2S
P1 H
RV1
3 1 4
P3 P1 P2
2 1 3 45
Crd
H
S2
RV2
24
4A
P1 P2 Pilot
4A 4 2
S1
S2
S
H
Crd
St
N2N1
L3L2L1 N2N1
L3L2L1
LE
H
S1
2S
P1 H
RV1
3 1 4
P3 P1 P2
2 1 3 45
Crd
H
S1
2S
P1 H
2S
P1 H
RV1
3 1 4
P3 P1 P2
2 1 3 45
P3 P1 P2
2 1 3 45 2 1 3 45
Crd
H
S2
RV2
24
4A
P1 P2 Pilot
4A 4 2
S1
S2
S
H
Crd
H
S2
RV2
24
4A
P1 P2 Pilot
4A 4 2
S1
S2
S
H
Crd
H
S1
2S
P1 H
RV1
3 1 4
P3 P1 P2
2 1 3 45
Crd
H
S1
2S
P1 H
2S
P1 H
RV1
3 1 4
P3 P1 P2
2 1 3 45
P3 P1 P2
2 1 3 45 2 1 3 45
Crd
H
S2
RV2
24
4A
P1 P2 Pilot
4A 4 2
S1
S2
S
H
Crd
H
S2
RV2
24
4A
P1 P2 Pilot
4A 4 2
S1
S2
S
H
Crd
St
LSVTR740
For references and descriptions of the various components refer to table 9 in appendix 0
Note: Ignition controller terminal lugs
not in use are to be grounded.
ELECTRIC CIRCUIT DIAGRAMS
Ft 134a - FR - Rév 00 - Date modif : 11/06/07 19/37

INSTALLER’S MANUAL
65.033018
65.080005
1,5 kW = 65.064007
3,0 kW= 65.064007
4,0 kW= 65.064007
5,0 kW= 65.064007
65.39895
65.226006
88.064012
65.330006
65.640004
65.330008
65.640006
65.330007
65.330005
65.640003
65.640005
65.330008
65.640004
65.330006
65.32638
Pour les références et désignations des différents composants se référer tableau 10 en annexe 0
LIGNE GAZ
Ft 134a - FR - Rév 00 - Date modif : 11/06/07 20/37
