INSTRUCTIONS MANUAL
NITROGEN COMPACT BOOSTER
2480.00.32.71
Instructions manual Nitrogen Compact Booster

Document: Instructions manual
Document number: 2.7528.04.0718.0100000
Revision: R07-2018
Version: V04
Language:
In the German language, this document is the original version in the EU language of the manufacturer and is labelled
with the German national flag.
In the EU language of a country of use, this document is a translation of the original version and labelled with the
national flag of the country of use.
This document is referred to as "instructions" in the following text.
Number of pages in this manual including the title page: 38
These instructions are valid for the product
2480.00.32.71
Nitrogen Compact Booster
This document was created by
FIBRO GMBH
August-Läpple-Weg
DE 74855 Hassmersheim
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Internet: www.fibro.de
© All rights to this document are subject to copyright of the author.
Without the prior written permission of FIBRO GMBH, this document must not be copied or
reproduced, either in full or in part.
The instructions are intended only for the operator of the described machine only
and must therefore not be made available to uninvolved third parties - in particular to competitors.

Instructions manual Nitrogen Compact Booster 3/38
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.3 Incorrect application. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.4 EC declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.5 Further applicable documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.6 Set-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.7 Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.8 Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.9 Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.9.1 Legend. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.9.2 Figures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.9.3 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.9.4 General instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.1 Basic safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.1.1 Due diligence of the operator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.1.2 Personnel requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.2 Residual hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.1 General technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.1.1 Type plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4 Transport. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.1 Packaging and weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.2 Transport damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.3 Interim storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.4 Return shipping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.5 Disposing of the packaging material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5 Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.1 Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.2 Installation requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.3 Installing the machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6.1 Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6.2 Workstations for operating personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6.3 Prior to commissioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6.4 Operating the machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.4.1 Settings prior to the operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.4.2 Fill gas spring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
7 Faults. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.1 Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.2 Customer services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4/38 Instructions manual Nitrogen Compact Booster
8 Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
8.1 Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
8.2 Maintenance work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
8.3 Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
8.3.1 Prior to each use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
8.4 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
8.4.1 If necessary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
8.5 Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
9 Decommissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
9.1 Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
9.2 Temporary decommissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
9.3 Final decommissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
10 Disassembly and disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
10.1 Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
10.2 Disassembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
10.3 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
10.3.1 Disposal of components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
11 Service and spare parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
11.1 Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
11.2 Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
11.3 Spare parts ordering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
12 Indexes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
12.1 Third-party products. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
13 Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
13.1 Pneumatic plan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
13.2 Personal notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Instructions manual Nitrogen Compact Booster 5/38
Introduction
1 INTRODUCTION
1.1 Definition
The Nitrogen Compact Booster product is a machine in terms of 2006/42/EC, section 1a and 2a.
In the following text of these instructions, the product is referred to as machine.
1.2 Intended use
This machine is intended to compress the nitrogen flowing into a nitrogen bottle in order to fill
gas springs. The machine may only be used to compress nitrogen. The machine may only be
used to fill gas springs.
The intended use also includes
• reading of these instructions and.
• the adherence of safety information.
• the adherence of all applicable documents.
• adherence to the maintenance regulation.
The machine may only be used as intended. Only processes and handling may be used as de-
scribed in these instructions.
1.3 Incorrect application
Any use which goes beyond the intended use of the machine and therefore classed as misuse
and not allowed.
The machine may not be stressed beyond its limits.
The machine is not suitable for
• the compression of other gases.
• filling of other components.
• the operation with impermissible changes or alterations (see chapter 6.4 "Operating the ma-
chine" on page 22).
For all damage to persons or property which has been caused by improper use, the liability lies
with the operator of the machine described in this document.

6/38 Instructions manual Nitrogen Compact Booster
Introduction
1.4 EC declaration of conformity
All machines have a EU declaration of conformity when supplied as per the directive 2006/42/
EG (machine directive). The excerpt of the text in this EU declaration says:
EU declaration of conformity as per directive 2006/42/EG, annex II A (machinedirective)
declares herewith that the machine
Nitrogen Compact Booster
that the models introduced to the market correspond to all relevant regulations of directive 2006/
42/EG.
The machine also corresponds to all relevant regulations of further directives applied to the ma-
chine.
Applied harmonised standards:
DIN EN ISO 12100:2010 Safety of machinery - General principles for design - Risk assessment
and risk reduction (ISO 12100:2010)
Authorised for the compilation of the Technical Documentation is:
FIBRO GMBH August-Läpple-Weg DE 74855 Hassmersheim
1.5 Further applicable documents
In addition to these instructions for the safe handling of the machine further, with applicable doc-
uments are necessary.
The information in these documents have to be adhered to.
• EU declaration of conformity as per directive 2006/42/EG
• Pneumatic plan
Manufacturer FIBRO GMBH
August-Läpple-Weg
DE 74855 Hassmersheim

Instructions manual Nitrogen Compact Booster 7/38
Introduction
1.6 Set-up
The illustration shows a schematic diagram of the principal set-up of the machine
The machine consists of:
Fig. 1-1 Set-up
To fill a gas spring a filling hose, a filling adapter and a filling and control fitting is required.
The parts can be ordered from FIBRO GMBH using the indicated order number.
1 Compressor
2 Start-up valve
3 Filter- and control valve compressed air
4 Nitrogen outlet (labelled with B)
5 Pressure relief valve
6 Nitrogen inlet via bottle hose (labelled with A)
a Filling and control fitting Order number 2480.00.32.21
bFilling adapter M6 Order number 2480.00.32.10
Filling adapter G1/8" Order number 2480.00.32.11
c Filling hose Order number 2480.00.31.02
3
1
2
4
5
6
A
B

8/38 Instructions manual Nitrogen Compact Booster
Introduction
To fill a gas spring safely we recommend the use of optionally available optional additional
equipment.
The parts can be ordered from FIBRO GMBH using the indicated order number.
Fig. 1-2 Optional additional equipment
The filling and control fitting (a) is connected via the filling adapter (b) to the filling inlet of the gas
spring.
The filling hose (c) creates the connection between nitrogen outlet of the machine and the filling
and control fitting.
The bottle pressure regulator (e) can be connected between filling hose and nitrogen outlet.
For the assembly a connection adapter (d) for the filling hose and a gas bottle adaptor (f) to con-
nect the nitrogen outlet.
At the bottle pressure regulator a maximum permissible filling pressure gas spring can be ad-
justed. Permanent monitoring of the filling process is not required. A gas spring is protected
against overfilling.
With the retaining plate the machine can be adjusted securely to the nitrogen bottle.
d Connection adapter Order number 2480.00.32.07.04
e Bottle pressure regulator Order number 2480.00.32.07.01
f Gas bottle connection Order number 2480.00.32.07.02
c
a
b
e d
f

Instructions manual Nitrogen Compact Booster 9/38
Introduction
1.7 Function
The filling of a gas spring directly from a nitrogen bottle only works if the pressure in the bottle
is higher than the required filling pressure of the gas spring.
The filling of a gas spring with 150 bar is not possible with a bottle pressure of 120 bar. The re-
maining nitrogen in the bottle remains unused or has to be used for other applications.
By using the nitrogen compact booster the entire volume of a nitrogen bottle can be used up the
residual pressure of approx. 30 bar.
The machine works according to the principle of a pressure intensifier. The low inlet pressure of
a nitrogen bottle is increased by continuous and constant piston motion. A high pressure is avail-
able at the outlet of the gas spring.
If using a bottle pressure regulator between nitrogen outlet and filling hose a maximum permis-
sible filling pressure can be set.
The machine is powered with pressurised air. The operating pressure is adjustable.
1.8 Warranty
The guarantee is regulated contractually (see Terms and Conditions or contract)

10/38 Instructions manual Nitrogen Compact Booster
Introduction
1.9 Manual
These instructions describe the handling of the machine and contain important information
about its intended use.
A copy of these instructions must be stored and made continuously available at the operating
site of the machine, and everyone assigned to work on or with the machine must read, under-
stand and apply them.
The safety information in the individual chapters must be observed.
These instructions and the other applicable documents are not subject to any modification ser-
vice.
We reserve the right to update data and drawings in these instructions based on continuing tech-
nical development.
The respectively current version can be requested from FIBRO GMBH.
1.9.1 Legend
Certain marks, symbols and abbreviations with the following meaning are used in these instruc-
tions for clear organisation of its contents:
1) indicates an enumeration.
a) indicates the second level of an enumeration.
• indicates a listing.
– indicates the second level of a listing.
The book icon in front of the text is a reference to an applicable document or another chapter in
these instructions. The content of this document or chapter must be observed.
The information symbol before the text indicates an additional instruction or an important appli-
cation tip.
1.9.2 Figures
The figures in these instructions are examples. Deviations between a figure and the actual con-
ditions on the machine are possible.
The drawings of FIBRO GMBH and the information on third-party products are decisive.

Instructions manual Nitrogen Compact Booster 11/38
Introduction
1.9.3 Safety instructions
This manual contains safety informations, which are intended to draw your attention to possible
hazards and which should be heeded in order to avoid injury.
The associated text describes
• the type of hazard
• the source of the hazard
• the options for avoiding injury
• the possible consequences if the warning notice is not heeded
Safety informations are highlighted using a colored signal bar with a warning triangle and signal
word.
The signal bars have the following meaning:
DANGER!
A safety notice on a red signal bar with the signal word DANGER designates a hazard
with a high risk level which, if not avoided, will result in death or severe injury.
WARNING!
A safety notice on an orange signal bar with the signal word WARNING designates a haz-
ard with a medium risk level which, if not avoided, might result in death or severe injury.
CAUTION!
A safety notice on a yellow signal bar with the signal word CAUTION designates a hazard
with a low risk level which, if not avoided, could result in minor or moderate injury.
1.9.4 General instructions
In addition to the safety notices, these instructions contain information that must be observed to
prevent property damage.
The pertinent text describes
• the possible reason for property damage
• the possibilities for preventing property damage
Notices of possible property damage are emphasised by a blue signal bar and the signal word
ATTENTION.
NOTICE
Notices for the prevention of property damage are not related to possible injuries.
Furthermore, these instructions contain general information on use.
General information on use and tips for certain applications are emphasised with a blue infor-
mation symbol.

12/38 Instructions manual Nitrogen Compact Booster
Safety
2SAFETY
2.1 Basic safety instructions
Die meisten Unfälle beim Umgang mit technischen Einrichtungen sind auf die Missachtung der
grundlegenden Sicherheitsregeln zurückzuführen.
Erkennen einer möglichen Gefährdung kann einen Unfall vermeiden, bevor dieser eintritt. Sind
Gefährdungen vorhanden, warnen Sicherheitsinformationen an der machine und in diesem Do-
kument vor diesen Gefährdungen. Wenn die Warnungen nicht beachtet werden, kann es zu
Körperverletzungen oder Tod kommen.
FIBRO GMBH kann nicht alle möglichen Umstände voraussehen, die potentielle Gefährdungen
enthalten können. Die Warnungen in diesem Dokument und an der machine sind folglich nicht
alles umfassend.
Personal muss die erforderliche Schulung und Erfahrung sowie erforderliche Werkzeuge ha-
ben, um Arbeiten an der machine richtig ausführen zu können.
Unsachgemässe Bedienung, Wartung oder Instandsetzung kann gefährlich sein und schwere
oder tödliche Verletzungen verursachen.
Keine Arbeiten zu Transport, Montage, Wartung oder Instandsetzung ausführen, wenn die In-
formationen zu Transport, Montage, Wartung oder Instandsetzung nicht gelesen und verstan-
den wurden.
Die machine darf in keiner Weise abweichend von den Betrachtungen in dieser Anleitung be-
nutzt werden. Alle für die Benutzung anwendbaren Sicherheitsregeln und Schutzmassnahmen
am Einsatzort müssen beachtet werden, einschliesslich Standort bezogene Regelungen und
Schutzmaßnahmen am Arbeitsplatz.
Wird ein Arbeitsmittel, eine Handlung, eine Arbeitsmethode oder eine Arbeitstechnik angewen-
det, die nicht ausdrücklich von FIBRO GMBH vorgeschlagen ist, muss der Anwender selbst die
Sicherheit für sich und andere Personen sicherstellen.
Es muss auch gewährleistet werden, dass die machine durch die beabsichtigten Arbeiten zu
Bedienung, Wartung und Instandsetzung nicht beschädigt oder unsicher wird.
Die Informationen, Beschreibungen und Abbildungen in diesem Dokument basieren auf der
Grundlage von Informationen, die zum Zeitpunkt der Erstellung dieses Dokuments verfügbar
waren.
Diese und andere Punkte können sich jederzeit ändern. Die Änderungen können die Eigen-
schaften der Maschine beeinträchtigen. Vor der Ausführung jeglicher Arbeiten die derzeit ver-
fügbaren Informationen einholen.

Instructions manual Nitrogen Compact Booster 13/38
Safety
2.1.1 Due diligence of the operator
This machine is designed and constructed according to state-of-the-art. The requirements for
maintaining the safety and health protection were met.
This safety can in the operational practice only be achieved if all measures required for this pur-
pose are put into place. The operator of the machine has to plan these measures and check
their execution.
The operator has to ensure that
• the machine is only used as intended.
• the machine is only be operated in impeccable, functional state.
• a copy of these instructions and all applicable documents are available in a legible condition
and complete at the installation location of the machine It has to be ensured that all persons
who have to carry out work on this machine can check these instructions at any time.
• only specifically trained and authorised staff can operate, maintain and repair the machine.
• staff knows the instructions and the containing safety instructions.
• the responsibility of staff during operation and maintenance has to be clearly determined
and adhered to.
• the staff is regularly instructed in all applicable topics of work safety and environmental pro-
tection.
• Operating instructions for work safety have to be issued.
• national accident prevention and in-house regulations are observed.
• if required personal safety clothing is available.

14/38 Instructions manual Nitrogen Compact Booster
Safety
2.1.2 Personnel requirements
The following safety instructions must be observed in all operations on the machine. Disregard-
ing the safety instructions can lead to serious injuries or even death.
Personnel must have the necessary training and experience and possess the necessary tools
in order to be able to perform the work on the machine correctly. Improperly performed work can
be dangerous and cause serious or fatal injuries.
Do not perform any work if you have not read and understood the information in these instruc-
tions and in the applicable documentation.
If work equipment, operation, work methods or work techniques that have not been explicitly
proposed by FIBRO GMBH are used, the operator must himself ensure the safety for himself
and for other persons.
It must be ensured that the machine is also not damaged or does not become unsafe over the
course of the intended work.
All persons working on and with the machine must
• have read and understood these instructions
• observe the safety information and guidelines in the operating instructions and the instruc-
tions contained therein
• observe the danger signs attached to the machine and the instructions on them
• observe the warning information about possible residual risks
• make sure that there are no unauthorised persons in the vicinity of the machine.
• in addition to the operating instructions, observe also the operating instructions for occupa-
tional health and safety and accident prevention issued by the operator
• inform the operator or the supervisory personnel about any malfunctions
• inform the respective managers immediately about any changes to the machine which can
affect its safety
2.2 Residual hazards
WARNING!
High pressure
The machine is designed for an inlet pressure up to 200 bar.
Connection only to N2-nitrogen bottle up to 200 bar.
WARNING!
Unauthorised changes
Any unauthorised changes or any mounting of additional equipment not approved by
FIBRO GMBH compromise the function of the machine and may result in dangerous situations.
 Modifications or unauthorised changes to the machine are prohibited.
The mounting of additional equipment must be discussed with FIBRO GMBH.
Unauthorised changes endanger the safe operation of the machine and may lead to serious
or fatal injuries.

Instructions manual Nitrogen Compact Booster 15/38
Technical data
3 TECHNICAL DATA
3.1 General technical data
Name Value
Inlet pressure 30 - 200 bar
Compressed driving air minimum 1 bar to 6 bar maximum
Pressurised air purified and oiled
Calculated operating pressure
(at 6 bar air drive pressure)
192 bar (+ Residual bottle pressure)
Pressure relief 400 bar
Transmission 1 : 32
Piston displacement 11,6 cm3
Medium supply performance* 280 NL/min
*The feed performance is depending on the air drive pressure and from the inlet pressure.
Max. operating temperature 60 °C
Weight approx. 7,2 kg
Dimensions (WxDXH) 160x380x345 mm
Noise emission < legally permissible peaks
Connections
Pressurized air G 1/4"
Nitrogen inlet Hose line DN4, length 1 m
for N2-bottles 200 bar
Nitrogen outlet Bottle connection W 24,32 x 1 1/4"
for N2-bottles 200 bar

16/38 Instructions manual Nitrogen Compact Booster
Technical data
3.1.1 Type plate
A type plate is fitted on the machine. Please state the information on the type plate for all ques-
tions or on all orders.
Fig. 3-1 Type plate

Instructions manual Nitrogen Compact Booster 17/38
Transport
4 TRANSPORT
4.1 Packaging and weight
The machine is packaged into a box for shipping. The weight of the entire packaging unit is 6 kg.
4.2 Transport damage
On delivery, the consignment must be checked immediately to ensure that it is complete and
has not been damaged in transit. If damage is found on the packaging that indicates possible
damage to the contents, the contents must also be inspected for damage.
If damage is found, the transport company must be informed immediately and the transport
company must verify the damage.
4.3 Interim storage
• Only store the machinewhen dry, in its original packaging and in enclosed rooms
• Storage temperature +5 - +40 °C
• Maximum humidity 60% (at 25 °C)
• No aggressive substances may be stored in the storage room (acids, bases, solvents etc.).
4.4 Return shipping
For the returns the parts which have to be sent back to the manufacturer for repair have to be
packaged securely.
4.5 Disposing of the packaging material
The packaging materials must be either reused or properly disposed of in accordance with the
country-specific regulations.

18/38 Instructions manual Nitrogen Compact Booster
Assembly
5 ASSEMBLY
5.1 Important safety instructions
WARNING!
Faulty assembly
Connection to not authorised nitrogen bottle or false connection of additional equipment is dan-
gerous.
Only qualified staff may carry out assembly work. Please adhere to the operating or assembly
instruction of additional equipment.
For the assembly of the machine or of the additional equipment, please ensure that only
authorised persons stay in the work area and that no other persons are endangered by the
assembly work.
5.2 Installation requirements
In order to use the machine properly at least the following parts have to be fitted:
• customer specific pressurised air adapter
• Filling hose
• Filling and control fitting
To securely fill a gas spring, we recommend additionally the use of the following optionally avail-
able additonal equipment:
• Bottle pressure regulator
Prior to assembly those parts and suitable tools have to be available to tighten the connections.

Instructions manual Nitrogen Compact Booster 19/38
Assembly
5.3 Installing the machine
WARNING!
High pressure
Unsuitable tools may fail. This means that nitrogen can escape under high pressure.
Only use additional equipment such as filling and control fitting, filling hose and bottle pres-
sure regulator . Risk of injury
The following description considers the assembly of all required parts and all possible additional
equipment.
1. Hang the machine over the connection of the nitrogen bottle.
2. Bottle hose to be connected.
a) Remove yellow protective cap.
b) Connect the connection screws of the bottle hose to the nitrogen bottle. ATTENTION
left-handed thread
c) Tighten the nut with a spanner.
3. Pressurised air adapter to be screwed into the pressurised air inlet.
a) pressurised air inlet at the filter and control valve, thread G 1/4".
b) Remove yellow protective cap.
c) Screw company specific pressurised air adapter with seal into the pressurised air inlet.
2.
1.
3.

20/38 Instructions manual Nitrogen Compact Booster
Assembly
4. Bottle pressure regulator to be assembled.
a) Remove green protective cap.
b) Bottle pressure regulator to be screwed at the nitrogen outlet thread.
c) Tighten the nut with a spanner.
5. Filling hose to be assembled.
a) Filling hose to be screwed on to the bottle pressure regulator.
b) Tighten the nut with a spanner.
6. Filling and control fitting to be assembled.
a) Insert the bayonet plug of the Filling and control fitting into the bayonet coupling of the
filling hose.
7. Provide pressurised air supply.
a) Pressurised air hose of the customer-side pressuriesed air supply on the pressurised air
adapter.
5.
4.
6.
