Lake Lite LL-SDL-EZ-v2 User manual

Solar Dock Lite
MODEL: LL-SDL-EZ-v2
LIGHT CHARACTERISTICS
Light Source 1-Ultra-High intensity LEDs.
Available LED Colors White
Light Mode Options (user switchable) Constant
Visible Range Constant Light Mode 0.2 – 0.25 nm
Horizontal Output (degrees) 180 Deg.
Vertical Divergence (degrees) 270 Deg.
Intensity Adjustment Automatic
LED Life Expectancy (hours) > 100,000 hrs
ELECTRICAL CHARACTERISTICS
Circuit Protection Integrated
Nominal Voltage (v) 3.2v
Autonomy (hours) 14-20 hrs
Temperature Range --10 to 80 C
SOLAR CHARACTERISTICS
Solar Module Type Multicrystalline
Power (watts) 0.45 watts
Solar Module Efficiency (%) 14-16%
POWER SUPPLY
Battery Type High Grade: LiFePo4
Battery Capacity (mAh) 400 mAhr
Nominal Voltage (v) 3.2v
Battery Service Life 3-4 years (Varies with local
Environment)
Battery Service Access Yes: User Changeable / Replaceable
PHYSICAL CHARACTERISTICS
Body Material UV Stabilized Poly Carbonate
Lens Material UV Stabilized Poly Carbonate
External Lens Design Translucent
Internal Lens design NA
Water Proof Rating IP 68
Mounting Spring Tabs – Pressure Fit
Height
Width / Diameter
Weight
NOTE:
* Information subject to change without notice
SOLAR DOCK LITE for EZ
-Dock
A great way to light up your dock and fill
those empty pockets! Make your dock
beautiful and safe to walk on while
protecting it from evening boaters. The Solar
Dock Lite
– For EZ Docks, provides ambient
top emitting pathway lighting while emitting
safety lighting from the side.
Durable construction polycarbonate
material will withstand light traffic and
walking. The powerful solar panel charges
the battery during the day and the light
automatically turns on at night. Make your
dock stand out from the rest!
Lake Lite Inc.
P.O. Box 414
105 W. Simon St.
Laotto, IN 46763
Phone: [phone]
Fax: [phone]
E-mail [email protected]
www.lakelite.com
www.ezdocksolarlites.com
U.S. Pat. No. 7,425,088
EZ DOCK is a registered trademark of E-Z Dock, Inc. Lake Lite, Inc. and this product
are not sponsored by, endorsed by, or affiliated with E-Z Dock, Inc. in any way."

Fully encapsulated PET solar
panel for increased efficiency
Automatic night
activation
Internal user changeable
LiFePo4 Battery
UV stabilized
polycarbonate
Internal
Lenticular lens
External
Fresnel Lens
Super High
Intensity LED
NEW! Fully
Sealed IP 68
Water Proof
Electronics
Lake Lite Inc.
P.O. Box 414
105 W. Simon St.
Laotto, IN 46763
Phone: [phone]
Fax: [phone]
E-mail [email protected]
www.lakelite.com
www.ezdocksolarlites.com
Stainless Steel
Mounting Tabs
Solar Dock Lite
MODEL: LL-SDL-EZ-v2
EZ DOCK is a registered trademark of E-Z Dock, Inc. Lake Lite, Inc. and this product
are not sponsored by, endorsed by, or affiliated with E-Z Dock, Inc. in any way."
U.S. Pat. No. 7,425,088

CAUTION: BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY.
NOTE:
1. LED Light inside is activated by darkness, Unit must be in a dark area before light will activate. Place in dark room to test unit.
2. Battery must be charged in order for the LED Light to turn on. Make sure battery is connected inside and then place in sunlight to charge.
NOTE: BATTERY MUST BE INSTALLED & CONNECTED TO FUNCTION
Installing your light into the EZ-Dock Pockets
1. Place the light in the pocket.
2. Firmly press the light until the top is flat
with the dock surface.
3. Check that the spring tabs are gripping
the dock and holding the light correctly.
NOTE: To remove, pull light upward with
moderate force. If light will not remove, use
screwdriver to wedge the spring tabs loose
from the side walls inside the pocket.
Lake Lite Inc.
P.O. Box 414
105 W. Simon St.
Laotto, IN 46763
Phone: [phone]
Fax: [phone]
E-mail [email protected]
www.lakelite.com
www.ezdocksolarlites.com
Solar Dock Lite
MODEL: LL-SDL-EZ-v2
NEW:
Watch Online
Installation Video!
This product uses a LiFePo4 type battery:
Volts: 3.2v Size: 14430 Capacity: 400mA
DO NOT USE: standard 1.2v NiMh or NiCd type
Rechargeable batteries or they will be damaged!
Assembling your light
1. Install battery in correct position.
2. Confirm that the silicone seal is installed
in the cover for sealing.
3. Install cover with 4-provided screws.
NOTE: Screw the cover down to apply
pressure on the seal. This will ensure the
battery compartment is fully water proof.
NOTE: Light is activated by darkness.
(battery must be charged to light
NOTE: Product uses 3.2v LiFePo4 Battery Size: 14400
N/A

Owner Registration Card
Please fill out and affix proper postage and return this owner
registration card within 10 days to insure that your new Solar Lite is
covered by the limited warranty.
Purchaser’s Name .
Address .
State .Zip .
Purchase Date: .Number of Lights: .
Where Purchased (Store Name): .
Model No. SDL-EZ-2-X
UPC No. Varies On Different Models
Lake Lite Inc.
P.O. Box 414, 105 W. Simon St., Laotto, IN 46763
Lake Lite Inc. 1-Year Limited Warranty
The retailer warrants the Solar Lite to be free from defects in workmanship and material present at
time of shipment from the factory for a period of one year after the date of purchase by the
original purchaser. We agree to correct such defects without chargeor at our option replace with a
comparable or superior model if the product is returned to the retailer. To obtainwarranty service,
you must present a copy of the receipt as proof of purchase.All costs of removing and reinstalling
the product are you responsibility. Damage to any part such as by accident or misuse or improper
installation or by affixing any accessories, is not covered by this warranty. There is no other
express warranty. The retailer hereby disclaims anyand all warranties, including but not limited
to, those of merchantability andfitness for a particular purpose to the extent permitted by law. The
duration of any implied warranty, which cannot be disclaimed, is limited to the time period as
specified in the express warranty. Some states do no allow limitation on how long an implied
warranty lasts, so the above limitation may not apply to you. The retailer shall not be liable for
incidental, consequential, or special damages arising out of or in connection with product use or
performance except as may otherwise be accordedby law. Some states do not allow the exclusion
of incidental or consequentialdamage, so the above exclusion or limitation may apply to you.
This warranty gives specific legal rights, and you may also have other rights, which vary from
state to state. This warranty supersedes all prior warranties.
Dimensions = mm
Disclaimer
EZ DOCK is a registered trademark of E-Z Dock, Inc. Lake Lite, Inc. and this product are not
sponsored by, endorsed by, or affiliated with E-Z Dock, Inc. in any way."
Solar Dock Lite
MODEL: LL-SDL-EZ-v2
Lake Lite Inc.
P.O. Box 414
105 W. Simon St.
Laotto, IN 46763
Phone: [phone]
Fax: [phone]
E-mail [email protected]
www.lakelite.com
www.ezdocksolarlites.com
167mm
100mm
80mm
100mm
167mm
