Lamona LAM6901 Troubleshooting guide
User & Installation Guide
LAM6901
Drinks Cooler (150mm)
02_
LAMONA Appliances
Dear Customer,
Congratulations on your choice of drinks cooler which has been designed to give you excellent service.
The user manual will help you use your product quickly and safely.
• Please make a note of your products serial number on the rear of this booklet, this is important should
you have any after sales queries. The serial number can be found on the rear of the product.
• Please read this user manual before installing and using the appliance.
• Always follow the safety instructions.
• Keep this user manual within easy reach for future reference.
• Please read any other documents supplied with the product.
Explanation of symbols
Throughout this user manual the following symbols are used:
Important information or useful tips about usage.
Warning for possible hazards to health and property.
Warning possibility of electric shock.
This product’s packaging material is recyclable. Help recycle it and protect the
environment by dropping it off in the municipal receptacles provided for this purpose.
Your product also contains a great amount of recyclable material. It is marked with this
label to indicate the used appliances that should not be mixed with other waste. This
way, the appliance recycling organised by your manufacturer will be done under the
best possible conditions, in compliance with European Directive 2002/96/EC on Waste
Electrical and Electronic Equipment. Contact your town hall or your retailer for the used
appliance collection points closest to your home. We thank you doing your part to protect
the environment.
_ 03
User manual LAM6901
Index
Index
01 - Before using the drinks cooler 04
02 - Safety 04
General 04
03 - General information 05
Drinks cooler layout / control panel 05
04 - Operating your drinks cooler 06
Power On/Off control 06
Unlocking the control panel 06
Interior light On/Off 06
Temperature display window 06
Temperature setting 06
Selecting between Fahrenheit & Celsius 06
05 - Care and maintenance 07
Cleaning your drinks cooler 07
Power failure 07
Absence & holidays 07
Moving your drinks cooler 07
Shelves 07
Energy saving tips 07
06 - Installation 08
Before installation 08
Integrated Installation 08
Installing the Handle 09
Reversing the Door Swing 09
Adjusting the plinth cover 10
Connection to the mains supply 10
07 - Troubleshooting 11
08 - Your Guarantee 13
04_
LAMONA Appliances
• Makesurethatyouhaveremovedallpackaging,wrappings,stickersandlmsfromtheproducts
surface.
• Itisrecommendedthatyoucleanandwashtheproduct’ssurfacebeforeusingforthersttime.
01 - Before using the Drinks Cooler
This appliance is for domestic purposes only
and is intended to be used exclusively for the
storage of sealed bottled drinks. Commercial use or
anything beyond it’s intended purpose will void the
guarantee.
The manufacturer shall not be liable for any damage
caused by improper use or handling errors
General
This product is not intended to be used by persons
with physical, sensory or mental disorders or
unlearned or inexperienced people (including
children) unless they are supervised by a person
who will be responsible for their safety or who will
instruct them accordingly in the use of the product.
Children must be supervised to prevent them from
tampering with the product.
• Use this appliance only as described in this
manual. Other uses not recommended may
causere,electricshockorpersonalinjury.
• To protect against the risk of electric shock, do
not immerse the unit, cord, or plug in water or
spray any other liquid nearby.
• Unplug the appliance from the plug socket
when not in use, when moving from one
location to another and before cleaning.
• To disconnect the appliance, grip the plug and
pull it from the wall outlet. Never pull out by
the cord.
• Do not operate the appliance in the presence
ofexplosiveorammablegases.
• Do not place the appliance or any of its parts
nearanopename,cookingorotherheating
appliance.
• Do not use outdoors.
• Do not operate the appliance with a damaged
cord or plug, if the product malfunctions, or if
it is dropped or damaged in any manner.
• The use of attachments not recommended by
the manufacturer may be hazardous.
• Place the unit on a dry level surface.
• Do not operate if the housing is removed or
damaged.
• Aloosetbetweensocketandplugmaycause
overheating and a distortion of the plug.
Contactaqualiedelectriciantoreplaceany
loose or worn sockets.
• Locate the unit away from direct sunlight and
sources of heat (stove, heater, radiator, etc.).
• This appliance is CFC and HFC free.
• Ensure that the ventilation openings to and
from a built-in appliance are never blocked or
covered and keep children and animals away
from the slots.
• No liability will be accepted for any damage
incurred owing to misuse of the appliance or
asaresultofrepairscarriedoutbyunqualied
personnel. In this case neither the guarantee
nor any other liability claims will apply.
Do not operate any electrical appliance inside
the Drinks Cooler.
Toreducetheriskofreelectricshockor
personal Injury, unplug or disconnect the
appliance from the power supply before moving or
cleaning the appliance.
02 - Safety
Before Using your drinks cooler
_ 05
User manual LAM6901
03 - General Information
Dimensions
Height. 870 - 890mm
Width. 150mm
Depth 570mm (inc handle)
Drinks cooler layout / control panel
°C
°F
°C/°F
g h i kj
b
a
c
d
e
f
b
a
c
d
e
f
lm
°C
°F
°C/°F
g h i kj
b
a
c
d
e
f
b
a
c
d
e
f
lm
Control Panel
g. Power
h. Lighting
i. Display window
j. Temperature up
k. Temperature Down
l. Lock / unlock
m. °C / °F Interchange
Features
a. Interrior LED Light
b. Digital control panel
c. Handle
d. Shelf
e. Door
f. Adjustable feet
General information
06_
LAMONA Appliances
04 - Operating Your Drinks Cooler
The Drinks Cooler is operated via thermoelectric
cooling system. This means that the temperature
range achievable is dependent upon the ambient
temperature in the room. The Drinks Cooler should
only be located in a position where the ambient
temperature is below 25 ºC. Typically the cooler will
cool to around 12 ºC below ambient hence, in some
instances, the temperature range of 8 - 18 ºC may
not be reached. Extreme hot or cold temperature
maycausetheinteriortemperaturetouctuateand
affect the performance of the unit.
The Drinks Cooler will run continuously until
the required temperature range is achieved. This is
quite normal and not a cause for concern.
WhenyouusetheDrinksCoolerfortherst
time or restart the Drinks Cooler after having been
turned off for a long time, there could be a few
degrees variance between the temperature you
select and the one indicated on the LED readout.
This is normal and it is due to the length of the
activation time. Once the Drinks Cooler is running
for a few hours everything will be back to normal.
If the unit is unplugged, power lost, or turned off you
must wait 3 to 5 minutes before restarting the unit.
If you attempt to restart before this time delay, the
Drinks Cooler will not start.
Power On/Off Control
• When the appliance is plugged in to a power
outlet, it powers on automatically.
• Touch the power mark and hold for 10
seconds to turn off (or turn on) the appliance.
• No matter if it is under a locked or unlocked
situation, you can turn off the appliance by
touching the power mark and holding for
10 seconds.
Unlocking the Control Panel
• To unlock the control panel, touch the power
mark and lighting mark with 2
ngersatthesametimeandholdfor3
seconds . When unlocked a ‘bleep’ sound will
be heard.
• The control panel will be automatically locked
with a ‘bleep’ sound heard after 10 seconds
without being touched.
• Under the locked situation, the control panel
will not react to any touching order for Lighting
On/Off and Temperature Setting.
Interior light On/Off control
• Under the unlocked situation, touch the light
mark to turn on (or turn off) the interior
cool LED light
• The light will be continuously on if it is not
turned off.
Temperature display window
• The temperature is displayed digitally which
is easy to read. The digital number is shown
as the set temperature when you are setting
the temperature, and it will change to be the
real temperature of the inside cabinet after 10
seconds without being touched.
Temperature setting
• The temperature setting range is 8-18 ºC
• Directly touch the or to set the drinks
temperature that you would like.
• Thersttouchon or will recall the
previous set temperature displayed in the
digital window. If the appliance runs after a
power failure (or unplugging), the previous set
temperature does not exist and is replaced by
the default temperature of 12ºC
• Touch the to increase the set temperature
by 1ºC and touch the to decrease the set
temperature by 1ºC
• The digital number will change to display
the temperature inside the cabinet after 10
seconds without being touched.
Selecting between fahrenheit &
celsius display.
• Touch the with2ngersatthe
same time and hold for 5 seconds, you can
interchange the Fahrenheit and Celsius
display.
Operating your drinks cooler
_ 07
User manual LAM6901
Cleaning Your Drinks Cooler
• Turn off the power, unplug the appliance, and
remove all items including shelves and rack.
• To remove any of the wire shelves from the
compartment, open the door fully and slide
them out carefully taking care not to lose
the anti-vibration pads. Please ensure these
are replaced when the shelf is put back
(For further information please refer to the
‘Shelves‘ section listed below)
• Wash the inside surfaces with a warm water
and baking soda solution. The solution should
be about 2 tablespoons of baking soda to a
litre of water.
• Wash the shelves with a mild detergent
solution.
• Wring excess water out of the sponge or cloth
when cleaning any area of the controls.
• Wash the outside cabinet with warm water and
mild liquid detergent. Rinse well and wipe dry
with a clean soft cloth.
Power Failure
• Most power failures are corrected within a few
hours and should not affect the temperature
of your appliance if you minimize the number
of times the door is opened. If the power is
going to be off for a longer period of time, you
need to take the proper steps to protect your
contents
Absence & Holidays
• For short holidays, leave the Drinks Cooler in
operation for periods of less than three weeks
• For long absences or if the appliance will not
be used for several months, remove all items,
turn off the appliance and unplug. Clean
and dry the interior thoroughly. To prevent
odours and mould growth, leave the door open
slightly: blocking it open if necessary.
Moving Your Drinks Cooler
• Remove all items.
• Securely tape down any loose items (shelves)
inside your appliance.
• Turn the adjustable legs up to the base to
avoid damage.
• Tape the door shut.
• Protect the outside of the appliance with a
blanket, or similar item.
Shelves
• To prevent damaging the door gasket, make
sure the door is fully opened when pulling
shelves out of the compartment. (You may
need to pull the cooler forward to remove
shelves once it has been installed depending
upon size of unit gap)
Energy Saving Tips
• The Drinks Cooler should be located in the
coolest area of the room, away from heat
producing appliances, and out of direct
sunlight.
• Ensure that the unit is adequately ventilated.
Never cover air vents.
• Only open the door for as long as necessary.
05 - Care and Maintenance
Care and Maintenance
08_
LAMONA Appliances
Before installation
The product should only be installed by suitably
competent person.
The product must be installed in accordance
with all local regulations.
Prior to installation, visually check the product
for any damage/defects. Do not install if any issues
are found.
Damaged products may cause risks to your own
safety.
The appliance is intended for installation in
Howdens kitchen cabinets.
Kitchencabinetsmustbesetlevelandxed.
The following installation drawings are
representational and may not match exactly with
your appliance.
06 - Installation
Integrated Installation
WhenintegratingyourDrinksCoolerintoatted
kitchensufcientspaceisrequiredtoallowthe
Drinks Cooler to be fully ventilated and for the door
to be opened fully . The appliance may need to be
positioned off centre to overcome any door collision
issues.
Ensure your cabinet aperture meets the
minimum dimensions listed below.
CABINET OPENING DIMENSIONS
mm (Minimum)
Height 870
Width 160
Depth 525
305mm
300mm
870 - 890 mm
525mm
570mm (inc handle )
>875mm
160mm
150mm
870 - 890mm
525mm
570mm (inc handle )
>875mm
Installation
_ 09
User manual LAM6901
Installing the Handle
Gently pull the door gasket to one side to reveal the
two designated holes for handle installation.
Install the handle tightly as shown below with the
two screws, and washers provided.
3
2
1
4
5
7
3
2
8
Reversing the Door Swing
This Drinks Cooler door can open from either the
left or right-hand side. The unit is delivered with the
door opening from the left-hand side. Should you
wish to reverse the door swing, please follow the
reversal instructions below.
All parts removed must be saved to reinstall
the door
Open the glass door and remove the two screws
(1), under the right bottom corner of the glass door,
that are used to hold the right lower hinge (2), to the
door shaft assembly (3). Be careful to support the
glass door with both hands to prevent it dropping
after removing the screws.
3
2
1
4
5
7
3
2
8
Pull down to remove the glass door and place it on a
padded surface to prevent scratching it.
Remove the right top hinge (4), and right lower
hinge (2).
3
2
1
4
5
7
3
2
8
Remove the left top hinge (7), and left lower
hinge (8) from the component bag that includes
the instruction manual then install them at the
designated positions at the left side of the cabinet
(pictured below)
3
2
1
4
5
7
3
2
8
Turn the glass door 180’ and reinstall
Installation
10_
LAMONA Appliances
Adjusting The Plinth Cover
• The adjustable plinth cover is located behind
the louvered plinth, and is held in position by
two screws.
• Loosen the two screws. Slide the adjustable
plinth down to cover the gap between the wine
coolerandtheoor.
• Retighten the screws.
3
2
1
4
5
7
3
2
8
Connection to the mains supply
Check that the voltage marked on the product
corresponds with your supply voltage.
This Appliance Must Be Earthed
The wires in the mains lead are coloured in
accordance with the following code:
GREEN / YELLOW – EARTH
BLUE – NEUTRAL
BROWN- LIVE
Earth
(Green / Yellow)
Neutral
(Blue) Live
(Brown)
Earth
(Green / Yellow)
Neutral
(Blue) Live
(Brown)
Thisapplianceisttedwithaplugwhichhasa5
amp fuse. Should the fuse fail, then it must be
replaced with an ASTA approved fuse (conforming to
BS1362) of the same rating. If you need to replace
the plug or if the plug is incorrect for your type of
socket, remove it and replace it with an appropriate
plug. Dispose of the old plug safely.
As the colours of the wires in the mains lead of this
appliance may not correspond with the coloured
markings identifying the terminals in your plug,
proceed as follows: The GREEN / YELLOW wire is
the EARTH and must be connected to the terminal
which is marked with the letter ‘E‘ or by the earth
symbol
The BLUE wire is the NEUTRAL and must be
connected to the terminal which is marked with the
letter ‘N’ or coloured BLACK.
The BROWN wire is the LIVE wire and must be
connected to the terminal which is marked with the
Letter ‘L’ or coloured RED.
Always ensure that the plug cord grip is fastened
correctly,ifindoubtconsultaqualiedelectrician
who will be pleased to do this for you. This product
conforms to EC Directive 92/31 /EEC with respect
to Electromagnetic Compatibility.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable
plugttedtothemainslead,youwillndthatit
incorporates a fuse, the value of which is indicated
either on the base of the plug or on the fuse carrier.
Should the fuse need replacing, you must use an
ASTA approved one (conforming to BS1382) of the
same rating.
If the fuse cover is lost, the plug must not he used
until a replacement is obtained from an electrical
supplier.
If you need to remove the plug, cut it from the
mains lead and immediately dispose of it.
Never attempt to re-use this plug or insert it into a
socket outlet as there is a very great risk of an
electric shock.
Connection to the mains supply
_ 11
User manual LAM6901
TROUBLESHOOTING GUIDE
Symptoms Possible Cause Solutions
No cooling • Plug not put in correctly Ensure the plug is in and the socket is switched on
• Low voltage Ensure normal voltage
• Fuse blown Replace the fuse with the recommended AMP rating
Temperature inside is not
cold enough
• The Drinks Cooler is placed too close
to a heat source
Keep the Drinks Cooler away from sunshine or other heat
sources .
• Bad ventilation Place the Drinks Cooler in an area with good ventilation
and keep objects away from the fans
• Fans don’t work Check whether the plug is connected or change the fan.
• The door is not closed tightly, or
opened too frequently or for too long
Close the door tightly and do not open the door too
frequently or for too long.
Strange smell inside the
Drinks Cooler
• Check contents for anything sour or
perishable.
Remove any perishable items and clean thoroughly.
Displaylightashes • The set temperature is higher than
the inner temperature of the Drinks
Cooler
Adjust the temperature accordingly
• The Drinks Cooler is defrosting This is a normal automatic function, and no repair is
needed
Frost is forming on the
cooling surface
• There may be too much humidity or
the temperature is too low inside
the case.
Disconnect the power to the Drinks Cooler and defrost
manually, reconnect the power once the frost has thawed.
If you cannot eliminate the problem after following the instructions in this section, consult your
depot or the authorized service agent. Never try to repair a nonfunctional product yourself.
07 - Troubleshooting
Troubleshooting
12_
LAMONA Appliances
08 - Your guarantee
Product Guarantee Details (UK only)
Yourappliancehasthebenetofacomprehensivemanufacturer’sguaranteewhichcoversthecostof
breakdown repairs. (Details of which are shown on your Proof of Purchase Document).
• Any claim during the period of the guarantee (MUST BE ACCOMPANIED BY THE PROOF OF PURCHASE)
• The product must be correctly installed and operated in accordance with the manufacturer’s
instructions and used for normal domestic purposes.
• This guarantee does not cover accidental damage, misuse or alternations which are likely to affect the
product.
• The guarantee is invalid if the product is tampered with, or repaired by any unauthorised person.
(The guarantee in no way affects your statutory or legal rights)
What to do if you need to report a problem-
Pleaseensureyouhaveready:
• Theproduct’smodel&serialnumbers
• Howdens Proof of Purchase document
• Your full contact details
CalltheServiceLineon08450060006
Guarantee
_ 13
User manual LAM6901
14_
LAMONA Appliances
Notes
_ 15
User manual LAM6901
Notes
If supplied, please stick your self adhesive product rating plate
here, or make a note of the product serial number below in the
box below for future reference.
Serial Number : ...........................................................................................
ISSUE v3-150113
Table of contents
Other Lamona Freezer manuals
