Land Pride FM20 User manual

Flail Mowers
Features and Benefits
Designs, specifications, features and information are subject to change without notice.
30
FM20
Features Benefits
60” & 72” Cutting widths Good cutting widths for applications in this HP range.
25-55 HP gearbox rating Fits a large array of consumer, municipality and landscape of tractors.
3-Point hitch can be centered
or offset 6 1/4” to the right The two position hitch allows the mower to be centered behind the tractor or offset 6 1/4” to the left for a closer cut alongside buildings, fences and roadsides.
One year gearbox warranty The gearbox is designed tough to withstand the rigors of flail mowing.
3/4” – 4” Cutting height Variable cutting heights for many uses.
Lowest cutting height allows for scalping in grasses such as Bermuda prior to overseeding.
1” Cutting capacity Can cut small saplings.
3 Fine cut knives per hanger Heavy enough to cut 1” material and cuts fine enough to groom a yard.
4 1/4” Rotor diameter Large rotor diameter protects against obstructions.
Reverse rotor rotation Brings the cut material up and over which allows it to be dispersed more evenly.
High knife tip speed Knife tip speed of 8,705 fpm provides for a clean cut.
Cat. 4 driveline with
over-running clutch Upon disengaging the PTO, the over-running clutch allows the driveline to quit turning, while the clutch yoke, gearbox and rotor shaft slow down under their own inertia.
3 - “B” Section belts “B” Section belts fit snug in the sheaves, and the multiple belts ensure positive transfer of
power.
Baffles on the top inside of the
deck Keeps the cut material from clumping together, ensuring an even distribution of clippings.
Height adjusting roller Rear height adjusting roller with greaseable bearings and tapered ends to prevent gouging
during turns.
Standard scrapers on rear
height adjusting roller Keeps the roller clean for consistent cutting height.
Adjustable rear panel Adjusts to allow strong discharge of material and aids in cleaning underside of deck.
Flail Mowers
309-100F
6/24/10
