FTI 6
Industrial Thermal Imager

InstallationGuide
Safety Information
InstallationGuide
Safety Information
FTI 6FTI 6
FTI 6FTI 6
FTI 6 complies with current European directives
relatingtoelectromagneticcompatibilityandsafety
(EMCdirective89/336/EEC;Lowvoltagedirective
73/23/EEC).
Land Infrared Quality Management
System is approved to BS EN ISO
9001:1994 for the design,
manufacture, repair and on-site
servicing of non contact infrared
temperature measuring equipment.
NAMAS calibration certificates are
available from our UKAS accredited
calibration laboratory Nº 0034.
Safety Information
Observeallsafetyprocedureswherefollowingsymbolsappear.Adetailedlist
of all current symbols and their descriptions is contained at the end of these
operating instructions
CAUTION : Refer to Operating Instructions
FTI 6FTI 6
FTI 6FTI 6
FTI 6 complies with current European directives
relatingtoelectromagneticcompatibilityandsafety
(EMCdirective89/336/EEC;Lowvoltagedirective
73/23/EEC).
Land Infrared Quality Management
System is approved to BS EN ISO
9001:1994 for the design,
manufacture, repair and on-site
servicing of non contact infrared
temperature measuring equipment.
NAMAS calibration certificates are
available from our UKAS accredited
calibration laboratory Nº 0034.
Safety Information
Observeallsafetyprocedureswherefollowingsymbolsappear.Adetailedlist
of all current symbols and their descriptions is contained at the end of these
operating instructions
CAUTION : Refer to Operating Instructions
abcdefabcdefg abcdef abcdefabcdefg abcdef

InstallationGuide
Safety Information
SAFETYINFORMATION
Symbol Publication Description
IEC 417, No. 5031 Direct current
IEC 417, No. 5032 Alternating current
IEC 417, No. 5033 Both direct and
alternating current
IEC 617-2, No. 02-02-06 Three-phasealternating
current
IEC 417, No. 5017 Earth (ground) terminal
IEC 417, No. 5019 Protective conductor
terminal
IEC 417, No. 5020 Frame or chassis
terminal
IEC 417, No. 5021 Equipotentiality
IEC 417, No. 5007 On (Supply)
IEC 417, No. 5008 Off (Supply)
IEC 417, No. 5172 Equipment protected
throughout by double
insulation or reinforced
insulation(equivalentto
Class II of IEC 536)
3

InstallationGuide
Safety Information
SAFETYINFORMATION(CONTINUED...)
Symbol Publication Description
ISO 3864, No. B.3.6 Caution, risk of electric
shock
ISO 3864, No. B.3.1 Caution
BS EN 100015 Observe precautions for
handling electrostatic
discharge sensitive
devices
BS EN 60825-1 Warning, laser radiation
Refer to the Operating
Instructions.

InstallationGuide
TechnicalSupport
TECHNICALSUPPORT
Technical support for your LAND Thermal Imaging System
canbeobtainedbyeithercontactingtheaddress/telephone
number on the cover of this Installation Guide, or by Email
to the following addresses:
[email protected]
(For queries regarding
LIPS Software)
[email protected]
(For queries regarding
FTI 6 Thermal Imagers)

InstallationGuide
Contents
CONTENTS
PARTA -INTRODUCTION
PARTB -PRECAUTIONS
PARTC - SPECIFICATIONS
PARTD -CARE ANDSTORAGE
PART E - PREPARING THE FTI 6 FOR USE
PART F - SETTING UP THE FTI 6
APPENDIX

Installation Guide
Contents
Installation Guide
Contents
PART A - INTRODUCTION
Contents
A1 ABOUT THE FTI 6 2
PART A - INTRODUCTION
Contents
A1 ABOUT THE FTI 6 2

Installation Guide
Part A
Page 1
Installation Guide
Part A
Page 1
PART A - INTRODUCTION
This publication provides the necessary information for a Land FTI 6 Thermal
Imager to be operated. These instructions cover installation, operation and
maintenance of the Thermal Imager and its accessories.
The equipment must be used, maintained and serviced by properly trained
personnel, capable of following the procedures given in these instructions.
It is important to check the equipment with which you have been supplied and
then read these instructions thoroughly before proceeding with operation.
PART A - INTRODUCTION
This publication provides the necessary information for a Land FTI 6 Thermal
Imager to be operated. These instructions cover installation, operation and
maintenance of the Thermal Imager and its accessories.
The equipment must be used, maintained and serviced by properly trained
personnel, capable of following the procedures given in these instructions.
It is important to check the equipment with which you have been supplied and
then read these instructions thoroughly before proceeding with operation.

Installation Guide
Part A
Page 2
Installation Guide
Part A
Page 2
A1 ABOUT THE FTI 6
The FTI 6 Thermal Imager can be used for creating thermal images and
measuring temperature in a wide variety of applications. It is designed to be
used either as a peremanently installed instrument or a portable unit. A range
of accessories are available to provide power, control, mounting and
environemntal protection. The FTI 6 can be controlled from an IBM compatible
PC running LIPS software, or as a self contained instrument controlled by a
remote control unit, with a TV monitor.
Fig. A1 LAND FTI 6 Thermal Imager
The FTI 6 Thermal Imager is supplied with the following components:
16MB Memory card
Video Cable
S-VHS Video Cable
FTI 6 Control options:
1. LIPS Software.
2. Remote control unit and RS232 cable.
NOTE
A 625 line (PAL) or 525 line (NSTC) TV monitor is required with
option‘2’. ItmustbecapablyofreceivingCompositevideo1Vpeak
to peak or SVHS 1V peak to peak chrominance and luminance
signal.
A1 ABOUT THE FTI 6
The FTI 6 Thermal Imager can be used for creating thermal images and
measuring temperature in a wide variety of applications. It is designed to be
used either as a peremanently installed instrument or a portable unit. A range
of accessories are available to provide power, control, mounting and
environemntal protection. The FTI 6 can be controlled from an IBM compatible
PC running LIPS software, or as a self contained instrument controlled by a
remote control unit, with a TV monitor.
Fig. A1 LAND FTI 6 Thermal Imager
The FTI 6 Thermal Imager is supplied with the following components:
16MB Memory card
Video Cable
S-VHS Video Cable
FTI 6 Control options:
1. LIPS Software.
2. Remote control unit and RS232 cable.
NOTE
A 625 line (PAL) or 525 line (NSTC) TV monitor is required with
option‘2’. ItmustbecapablyofreceivingCompositevideo1Vpeak
to peak or SVHS 1V peak to peak chrominance and luminance
signal.

Installation Guide
Part A
Page 3
Installation Guide
Part A
Page 3
Power supply options:
1. 12V power supply unit and Power cable.
2. DIN Rail power supply unit and Power cable.
Multi Imager cables:
RS422 cable
RS485 cable
Audio option:
Headset
Optional Lenses:
2.5x Magnification Telescope focus
1 x Magnification Close-up
0.4x Magnification Wide-Angle
0.25x Magnification Wide-Angle
Environmental Protection & Mounting accessories:
Environmental Enclosure
Water cooled Plate
Air Purge & Fan
Mounting Brackets
Motorized Pan and Tilt Head
Power supply options:
1. 12V power supply unit and Power cable.
2. DIN Rail power supply unit and Power cable.
Multi Imager cables:
RS422 cable
RS485 cable
Audio option:
Headset
Optional Lenses:
2.5x Magnification Telescope focus
1 x Magnification Close-up
0.4x Magnification Wide-Angle
0.25x Magnification Wide-Angle
Environmental Protection & Mounting accessories:
Environmental Enclosure
Water cooled Plate
Air Purge & Fan
Mounting Brackets
Motorized Pan and Tilt Head

Installation Guide
Contents
Installation Guide
Contents
PART B - PRECAUTIONS
Contents
B1 PRECAUTIONS 1
PART B - PRECAUTIONS
Contents
B1 PRECAUTIONS 1

Installation Guide
Part B
Page 1
Installation Guide
Part B
Page 1
PART B - PRECAUTIONS
B1 PRECAUTIONS
WARNING
Do not use the
FTI 6 in an explosive atmosphere, such as one
containing gasoline fumes.
Neverattempttodisassembleormodifythe FTI6 anditsaccessories.
Therearenouser-serviceablepartsinside,andthereisadangerof
electrical shock and possible injury due to rotating components if
the units are opened.
If a unit requires a service, take it to the nearest authorized service centre.
Openingtheunitinvalidatesthewarranty. Adjustment,maintenanceandrepair
of the opened apparatus must only be carried out by a skilled person who is
aware of the hazards involved.
CAUTION
Do not subject the FTI 6 to strong shock or vibration.
PART B - PRECAUTIONS
B1 PRECAUTIONS
WARNING
Do not use the
FTI 6 in an explosive atmosphere, such as one
containing gasoline fumes.
Neverattempttodisassembleormodifythe FTI6 anditsaccessories.
Therearenouser-serviceablepartsinside,andthereisadangerof
electrical shock and possible injury due to rotating components if
the units are opened.
If a unit requires a service, take it to the nearest authorized service centre.
Openingtheunitinvalidatesthewarranty. Adjustment,maintenanceandrepair
of the opened apparatus must only be carried out by a skilled person who is
aware of the hazards involved.
CAUTION
Do not subject the FTI 6 to strong shock or vibration.

Installation Guide
Contents
Installation Guide
Contents
PART C - SPECIFICATIONS
Contents
C1 FTI 6 THERMAL IMAGER 1
C2 TEMPERATURE MEASUREMENT FUNCTION 2
C3 GENERAL 3
C4 MOUNTINGS AND ACCESSORIES 4
C5 COMPLIANCES 5
C6 DIMENSIONS 6
PART C - SPECIFICATIONS
Contents
C1 FTI 6 THERMAL IMAGER 1
C2 TEMPERATURE MEASUREMENT FUNCTION 2
C3 GENERAL 3
C4 MOUNTINGS AND ACCESSORIES 4
C5 COMPLIANCES 5
C6 DIMENSIONS 6

Installation Guide
Part C
Page 1
Installation Guide
Part C
Page 1
PART C - SPECIFICATIONS
C1 FTI 6 THERMAL IMAGER
Observable temperature range: -20 to 2000°C/-5 to 3600°F based on
blackbody temperature
Frame frequency: 20 Hz
Focusing range: 0.5m to infinity (Standard)
Temperature resolution: 0.1°C (for 30°C blackbody)
Field of view: 16° x 16° (Standard)
16° x 16° (Close Focus)
6.4° x 6.4°
40° x 40°
60° x 60°
Scanning spot field of view: 1.1 mrad (horizontal) x 1.1 mrad (vertical)
Image pixels: 256 (horizontal) x 256 (vertical)
Detector: HgCdTe Focal Plane Array
Detector cooling system: Thermoelectric
Spectral response: 'L' Range: 3 to 4µm
'M' Range: 3.9µm
'H' Range: 3.9µm
Temperature display levels: 256 colours
User modes: Three configurations can be stored
Start-up modes: Start-up in any of the three user modes or
with the settings used when switched off, or
factory default.
Automatic functions: Temperature Span, Window and Offset.
PART C - SPECIFICATIONS
C1 FTI 6 THERMAL IMAGER
Observable temperature range: -20 to 2000°C/-5 to 3600°F based on
blackbody temperature
Frame frequency: 20 Hz
Focusing range: 0.5m to infinity (Standard)
Temperature resolution: 0.1°C (for 30°C blackbody)
Field of view: 16° x 16° (Standard)
16° x 16° (Close Focus)
6.4° x 6.4°
40° x 40°
60° x 60°
Scanning spot field of view: 1.1 mrad (horizontal) x 1.1 mrad (vertical)
Image pixels: 256 (horizontal) x 256 (vertical)
Detector: HgCdTe Focal Plane Array
Detector cooling system: Thermoelectric
Spectral response: 'L' Range: 3 to 4µm
'M' Range: 3.9µm
'H' Range: 3.9µm
Temperature display levels: 256 colours
User modes: Three configurations can be stored
Start-up modes: Start-up in any of the three user modes or
with the settings used when switched off, or
factory default.
Automatic functions: Temperature Span, Window and Offset.

Installation Guide
Part C
Page 2
Installation Guide
Part C
Page 2
C2 TEMPERATURE MEASUREMENT FUNCTION
Measuring area: Adjustable over scene
1x1 to 8x8, 32x4, 64x2 and 128x1 pixels.
Measurable temperature range:
'L' Range: -20 to 200°C/-5 to 400°F
'M' Range: -20 to 650°C/-5 to 1200°F
'H' Range: -20 to 2000°C/-5 to 3600°F
Display resolution: 1°C/1°F
Accuracy: 'L' Range: ±1.25% temperature (absolute)
'M' Range: ±2% temperature (absolute)
'H' Range: ±2% temperature (absolute)
Emissivity setting range: 0.10 to 1.00 in 0.01 intervals
Background temperature
compensation: -20 to 2000°C/-5 to 3600°F
Measurement modes: Single shot (instantaneous); Average; Peak/
Valley; Isotherm, Temperature Difference
C2 TEMPERATURE MEASUREMENT FUNCTION
Measuring area: Adjustable over scene
1x1 to 8x8, 32x4, 64x2 and 128x1 pixels.
Measurable temperature range:
'L' Range: -20 to 200°C/-5 to 400°F
'M' Range: -20 to 650°C/-5 to 1200°F
'H' Range: -20 to 2000°C/-5 to 3600°F
Display resolution: 1°C/1°F
Accuracy: 'L' Range: ±1.25% temperature (absolute)
'M' Range: ±2% temperature (absolute)
'H' Range: ±2% temperature (absolute)
Emissivity setting range: 0.10 to 1.00 in 0.01 intervals
Background temperature
compensation: -20 to 2000°C/-5 to 3600°F
Measurement modes: Single shot (instantaneous); Average; Peak/
Valley; Isotherm, Temperature Difference

Installation Guide
Part C
Page 3
Installation Guide
Part C
Page 3
C3 GENERAL
Data memory (Optional): Memory space for 64 thermal and visual
scenes on 16MB PCMCIA card. 2 x Type I or
II PCMCIA slots available.
Fast Capture (Optional): Imagesstoredsequentiallyata user selected
rate up to full frame rate. Capacity of 512
images (thermal or visual).
Calendar function: Day/Month/Year or Month/Day/Year
Clock function: Hour/Minute/Second
Operating temperature and
humidity range: -20 to +40°C/less than 90% RH at 35°C
Storage temperature range: -30 to 70°C
Power source: 12 to 16V d.c., 2A
Video output: PAL or NTSC composite video or SVHS.
(1 volt peak to peak into 75 ohms)
Colour Display: Four palettes, including monocromatic.
Digital data output: RS232, RS422or RS485Serialinput/output.
Audio: Recording and playback of 15 seconds of
commentary, stored with each thermal/visual
image.
Dimensions (W x H x D):
Weight: 4.1kg/9lb
Sealing: EN 60529 IP65 (main unit)
EN 60529 IP42 (external heat exchanger)
C3 GENERAL
Data memory (Optional): Memory space for 64 thermal and visual
scenes on 16MB PCMCIA card. 2 x Type I or
II PCMCIA slots available.
Fast Capture (Optional): Images stored sequentially at a user selected
rate up to full frame rate. Capacity of 512
images (thermal or visual).
Calendar function: Day/Month/Year or Month/Day/Year
Clock function: Hour/Minute/Second
Operating temperature and
humidity range: -20 to +40°C/less than 90% RH at 35°C
Storage temperature range: -30 to 70°C
Power source: 12 to 16V d.c., 2A
Video output: PAL or NTSC composite video or SVHS.
(1 volt peak to peak into 75 ohms)
Colour Display: Four palettes, including monocromatic.
Digital data output: RS 232,RS422 orRS485 Serial input/output.
Audio: Recording and playback of 15 seconds of
commentary, stored with each thermal/visual
image.
Dimensions (W x H x D):
Weight: 4.1kg/9lb
Sealing: EN 60529 IP65 (main unit)
EN 60529 IP42 (external heat exchanger)

Installation Guide
Part C
Page 4
Installation Guide
Part C
Page 4
C4 MOUNTINGS AND ACCESSORIES
Optional accessories: Environmental Enclosure
Water Cooled Plate
Adjustable Mounting
Mounting Brackets
Pan & Tilt Head
Air purge & Fan
0.4x Lens
2.5x Lens
0.25x Lens
1x Closeup Lens
Remote Control Unit.
C4 MOUNTINGS AND ACCESSORIES
Optional accessories: Environmental Enclosure
Water Cooled Plate
Adjustable Mounting
Mounting Brackets
Pan & Tilt Head
Air purge & Fan
0.4x Lens
2.5x Lens
0.25x Lens
1x Closeup Lens
Remote Control Unit.

Installation Guide
Part C
Page 5
Installation Guide
Part C
Page 5
C5 COMPLIANCES
CE: EN 50-082-2 (immunity)
EN 50-081-1 (emission)
IEC 1010 (safety)
C5 COMPLIANCES
CE: EN 50-082-2 (immunity)
EN 50-081-1 (emission)
IEC 1010 (safety)

Installation Guide
Part C
Page 6
Installation Guide
Part C
Page 6
C6 DIMENSIONS
153.25 mm
174.5 mm
153.25 mm
269.34 mm approx
90 mm
167.6 mm approx
30 mm 50 mm
3 holes M6
2 holes M8
TI980240
Fig. C1 FTI 6 Dimensions
C6 DIMENSIONS
153.25 mm
174.5 mm
153.25 mm
269.34 mm approx
90 mm
167.6 mm approx
30 mm 50 mm
3 holes M6
2 holes M8
TI980240
Fig. C1 FTI 6 Dimensions

Installation Guide
Part C
Page 7
Installation Guide
Part C
Page 7
268 mm
146 mm
120 mm
TI990027
Fig. C2 Environmental Enclosure Dimensions
536 mm
295 mm
240mm
TI990027
Fig. C2 Environmental Enclosure Dimensions
