Lang PaneBella Fresco PBF12G User manual

1
TWO SIDED
GRILLS
MODEL
PBF12G, PBF12S
PBF14G, PBF14S
PBF24G, PBF24S, PBF24SG
Installation and
Operation
Instructions
2M-W1448 Rev. A 12/15/10
PBF12G

2
These symbols are intended to alert the user to the presence of
important operating and maintenance instructions in the manual
accompanying the appliance.
FOR YOUR SAFTEY
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN
THE VICINTIY OF THIS OR ANY OTHER APPLIANCE.
POST IN PROMINENT LOCATION
INSTRUCTIONS TO BE FOLLOWED IN THE EVENT USER SMELLS GAS. THIS
INFORMATION SHALL BE OBTAINED BY CONSULTING YOUR LOCAL GAS SUPPLIER.
AS A MINIMUM, TURN OFF THE GAS AND CALL YOUR GAS COMPANY AND YOUR
AUTHORIZED SERVICE AGENT. EVACUATE ALL PERSONNEL FROM THE AREA.
WARNING
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE
CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE INSTALLATION,
OPERATION & MAINTENANCE INSTRUCTIONS THOROUGHLY BEFORE INSTALLING OR
SERVICING THIS EQUIPMENT.
WARNING
RISK OF FIRE OR ELECTRIC SHOCK
DO NOT OPEN
WARNING, TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE
CONTROL PANEL. NO USER-SERVICABLE PARTS INSIDE.
REPAIRS SHOULD BE DONE BY AUTHORIZED SERVICE PERSONNEL ONLY.
NOTICE
Using any part other than genuine Lang factory supplied parts relieves the manufacturer of all
liability.
Star reserves the right to change speci cations and product design without notice. Such
revisions do not entitle the buyer to corresponding changes, improvements, additions or
replacements for previously purchased equipment.
Due to periodic changes in designs, methods, procedures, policies and regulations, the
speci cations contained in this sheet are subject to change without notice. While Star
Manufacturing exercises good faith efforts to provide information that is accurate, we are
not responsible for errors or omissions in information provided or conclusions reached as a
result of using the speci cations. By using the information provided, the user assumes all risks
in connection with such use.
MAINTENANCE AND REPAIRS
Contact your local dealer for service or required maintenance. Please record the model number, serial
number, voltage and purchase & Installation Information in the area below and have it ready when you
call to ensure a faster service.
SAFETY SYMBOL
Model No.:
Serial No.:
Voltage:
1-Phase or 3 Phase:
Purchased From:
Location:
Purchase Date:
Installed Date:

3
TABLE OF CONTENTS
Installation
General Installation Data . . . . . . . . . . . . . . . . . . . . . 4
Ventilation & Clearence . . . . . . . . . . . . . . . . . . . . . . 4
Electrical Connection . . . . . . . . . . . . . . . . . . . . . . . 4
Electrical Grounding Instructions . . . . . . . . . . . . . . . . . 4
Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Initial Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Seasoning The Cooking Surface . . . . . . . . . . . . . . . . . . . 5
Setting the Temperature. . . . . . . . . . . . . . . . . . . . . . . . 5
Daily Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
General Operation & Programming
Operating Hints & Saftey . . . . . . . . . . . . . . . . . . . . . 6
Monthly Lubrication / Inspection. . . . . . . . . . . . . . . . . . 6
Top Housing Maintenance. . . . . . . . . . . . . . . . . . . . . 6
Maintenance
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Wiring Diagram
PBF12 & PBF14 208/240VAC. . . . . . . . . . . . . . . . . . . 8
PBF24 240V. . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Exploded View & Parts List . . . . . . . . . . . . . . . . . . . . . 10-13
PROBLEMS, QUESTIONS or CONCERNS
Before you proceed consult you authorized Lang service agent directory
or
Call the Lang Technical Service & Parts Department at 1-800-438-5264.
NOTICE ServiceonthisoranyotherLangappliancemustbeperformedbyqualied
personnel only. Consult your Lang Authorized Service Agent Directory.
You can call our toll free number 1-800-438-5264 or visit our website
WWW.LANGWORLD.COM for the service agent nearest you.

4
GENERAL INSTALLATION DATA
This equipment is designed and sold for commercial use only by personnel trained and experienced
in its operation and is not sold for consumer use in and around the home nor for use directly by the
general public in food service locations.
All shipping containers should be checked for freight damage both visible and concealed.
This unit has been tested and carefully packaged to insure delivery of your unit in perfect condition.
If equipment is received in damaged condition, either apparent or concealed, a claim must be made
with the delivering carrier.
Concealed damage or loss - if damage or loss is not apparent until after equipment is unpacked, a
request for inspection of concealed damage must be made with carrier within 15 days. Be certain to
retain all contents plus external and internal packaging materials for inspection. The carrier will make
an inspection and will supply necessary claim forms.
VENTILATION AND CLEARANCES
The installation of any components such as a vent hood, grease extractors, and/or re extinguishing
systems, must conform to their applicable nationally recognized installation standards and/or local
building codes.
ELECTRICAL CONNECTION
Before making any electrical connection be sure to read data plate which is located at the bottom of
the unit.
ELECTRICAL GROUNDING INSTRUCTIONS
This unit is equipped with a 3-prong (grounding) plug for your protection against shock hazard and
must be plugged directly into a properly grounded 3-prong receptacle.
DO NOT CUT OR REMOVE THIS PLUG OR GROUNDING PRONG FROM THE PLUG.
CONNECT/PLUG UNIT INTO DEDICATED A.C. LINE ONLY SPECIFIED ON THE DATA
PLATE OF THE UNIT.
CAUTION
WARNING

5
CONNECT/PLUG UNIT INTO DEDICATED A.C. LINE ONLY SPECIFIED ON THE DATA PLATE
OF THE UNIT.
INITIAL START UP
Level unit using the adjustable feet under the unit (approximately 1/2" adjustment).
Before using the unit for the rst time, wipe down the exterior and grilling area with a damp cloth. Take
to a well ventilated area and heat for approximately 30 minutes. The grill may emit a small amount of
smoke as the cooking surfaces reaches 450°F. Do not be alarmed, as the smoke is caused by oils
associated with the manufacturing process and will stop when the burn off is complete. Brush off any
debris from the grilling surface.
WARNING
Model Height (D) x Width (A) x Depth (B) Clearance from
combustible surface Weight Freight
ClassActual Shipping
PBF12(G,S) 21.8” x 15.75” x 19.9”
Sides: 0”, Back 0”
45 lbs. 50 lbs
85
554mm x 400mm x 506mm 20.4 kg 22.7 kg
PBF14(G,S) 21.8” x 19.75” x 19.9” 60 lbs. 65 lbs.
554mm x 502mm x 506mm 27.2 kg 29.5 kg
PBF24(G,S,SG) 21.8” x 28.75” x 19.9” 80 lbs. 85 lbs.
554mm x 730mm x 506mm 36.3 kg 38.6 kg
C
D
B
A
A
IL1874
ELECTRICAL SPECIFICATIONS
Model Voltage Rated Wattage Amps Cord Length Plug Type
PBF12(G,S) 120V/1-Ph 1400W 11.6 72” NEMA5-15P
208/240V 1-Ph 1320 / 1800 6.35 / 7.5 70” NEMA6-15P
PBF14(G,S) 120V/1-Ph 1800W 15 72” NEMA5-15P (5-20P*)
208/240V 1-Ph 2100 / 2800 10.1 / 11.67 70” NEMA6-15P
PBF24(G,S,SG) 208/240V 1-Ph 2700/3600W 13/15 72” NEMA6-20P
* Canadian Requirment

6
SEASONING THE COOKING SURFACES
The cooking surfaces must be "seasoned" in order to reduce product sticking. To season, bring grill
to 300°F, until completed. Brush upper and lower cooking surfaces with a a salt free liquid vegitable
oil. If using an aerosol agent, rst apply into a cup and then brush onto cooking surface. Let sit for 20
minutes, and then wipe clean using a warm damp cloth. Repeat if required.
SETTING THE TEMPERATURE
The thermostat control knob is used to set the temperature to your requirements. The maximum set
point is 450°F (232°C), the minimum set point is 175°F (79°C).
DAILY OPERATION
Check the power cord to insure that it is plugged into a proper outlet.
Check that the thermostat control is turned on.
The pilot light will come on when the thermostat control goes past the 175°F.
Set the thermostat control knob to desired temperature.
Always allow 20 minutes of preheat time before loading the unit with product.
Failure to allow sufcient preheat time will result in unsatisfactory cooking of the rst load.
OPERATING HINTS AND SAFETY
Disconnect power to the unit with the switch at the end of each day of operation.
Do not leave the unit in operation without an attendant.
Turn thermostat down to 200°F (93°C) during idle periods. It will take only a few minutes to regain
operating temperature.
Use spatula to push excess grease into grease cup after each load of food is cooked.
This will reduce smoking of hot grease and carbonizing.
Do not leave the unit at high temperature when not in use or during idle periods.
This will cause food particles and grease lm to carbonize.
"Season" cooking surfaces with non-salted vegetable oil to reduce product sticking.
MONTHLY LUBRICATION/INSPECTION
Apply two (2) drops of non-toxic mineral or vegetable oil to hinge bracket at the rear.
Check the bolts, screws and nuts, tighten if necessary.
TOP HOUSING MAINTENANCE
The Spring setting which holds the top housing in the up
position is set at the factory and should provide many years
of use without the need of adjusting. After a extended period
of time the top housing may not maintain its original setting,
therefore the spring tension can be adjusted by tightening and
loosening the Retainer bolts on the back of the unit.
Abobe: Oiling the Hinge,
Below: Tightening the top housing

7
CLEANING
While holding top lid with one hand, apply only cleaners which are safe for aluminum and iron
surfaces. Wipe with clean sponge or towel until unit is clean.
1. If particles adhere to the cooking surface during the day, scrape them off with a spatula or
stiff nylon brush.
NOTE: It is best not to let food cook on to the grill, as build up of food on the grill will increase sticking
and smoking. In addition, carbon may build up on the grill surface and reduce the cooking efciency.
2. At the end of the day, wipe down all surfaces with a warm, damp cloth, use a mild detergent on
all non-cooking areas and then dry entire unit.
3. Remove and empty to clean grease catcher cup as required using mild detergent and water.
CLEANING CARBON BUILDUP
1. When carbon build up occurs, use a carbon removal agent to clean cooking surface. When this
process is completed, you must re-season the grill (See Seasoning Grill).
2. Acidic cleaners are NOT recommended as a cleaning agent.
DO NOT IMMERSE OR LET THE UNIT STAND IN WATER.
DO NOT HOSE DOWN THE UNIT OR THE TABLE/COUNTER IF THE UNIT IS ON THE
TABLE/COUNTER.
KEEP AWAY FROM RUNNING WATER.
DO NOT USE SHARP OBJECTS TO REMOVE CARBON BUILD-UP.
BEFORE CLEANING MAKE SURE POWER IS TURNED OFF, UNIT IS UNPLUGGED
AND IS NOT TOO HOT.
DO NOT SPLASH WATER ON FRONT CONTROL PANEL!
DO NOT SPLASH WATER ON FLEX CONDUIT CONNECTING TOP AND
BOTTOM OF THE UNIT.
Do not use ice or cold water to clean the cooking surfaces when the unit is hot. The surfaces are cast
aluminum or cast iron and may crack or deform under the shock of rapid temperature change.
OPERATION TROUBLESHOOTING
1. Unit not heating.
A. Check if unit is plugged in correct receptacle.
B. Check incoming power line.
C. Check that thermostat is set to proper temperature.
If unit still does not operate contact the factory or one of its representatives or a local service company
for service or required maintenance.
CAUTION
WARNING
WARNING

8
MODEL:
GX & PBF SINGLE LID SERIES, WIRE DIAGRAM, 120V/230/240V
THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC.
NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED.
STAR INTERNATIONAL HOLDINGS INC. COMPANY
SK2116 Rev - 02/16/2005
GREEN
WHITE
15 AMP PLUG
NEMA 5-15P ON ALL 120V UNITS.
NEMA 6-15P ON 240V, 1,800 WATT UNITS.
20 AMP PLUG
NEMA 6-20P ON 240V, 3,600 WATT UNITS.
IEC 320 POWER INLET, 16 AMP RATING
SEE SEPERATE SKETCH, 230V UNITS.
TOP ELEMENT
1
BLACK
3
3
2
1
TERMINAL
BLOCK
BOTTOM ELEMENT
THERMOSTATINDICATOR LIGHT
FOR REFERENCE
WIRING DIAGRAM IS SHOWN AS UNIT IS ASSEMBLED
WITH THE BOTTOM PLATE REMOVED. ITEMS ARE IN
GENERAL LOCATION BUT MAY BE RELOCATED OR SCALED
FOR CLARITY.
G
20
N19
18
L
CERTAIN INSTANCES MAY NOT BE AVAILABLE
ILLUSTRATIVE PURPOSES ONLYAND IN
SOME ITEMS ARE INCLUDED FOR

9
GREEN
WHITE
20 AMP PLUG
NEMA 6-20P ON 240V, 3,600 WATT UNITS.
IEC 320 POWER INLET, 16 AMP RATING
SEE SEPERATE SKETCH, 230V UNITS.
TOP ELEMENT
1
BLACK
3
3
2
1
TERMINAL
BLOCK
BOTTOM ELEMENT
THERMOSTATINDICATOR LIGHT
FOR REFERENCE
WIRING DIAGRAM IS SHOWN AS UNIT ISASSEMBLED
WITH THE BOTTOM PLATE REMOVED. ITEMS ARE IN
GENERAL LOCATION BUT MAY BE RELOCATED OR SCALED
FOR CLARITY.
G
20
N19
18
L
TOP ELEMENT
3
2
3
1
1
11
12 11 12
CERTAIN INSTANCES MAY NOT BE AVAILABLE
ILLUSTRATIVE PURPOSES ONLYAND IN
SOME ITEMS ARE INCLUDED FOR
MODEL:
GX & PBF DOUBLE LID SERIES, WIRE DIAGRAM, 230/240V
THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC.
NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED.
STAR INTERNATIONAL HOLDINGS INC. COMPANY
SK2118 Rev - 02/16/2005

10
26
19
18
16 49
54
55
23
21
21
56
56
24
57
57
20
20
17
22
153
28
42
36
35 35
51
52
50
30
37
Nameplate
34
27
7
9
39
40
41
29
4
5
6
17
32
2
10
11
48
6
5
45
43
46
8
47
44
28
14
13
12
3
8
25
338
49
15
This drawing contains information confidential
to Lang Manufacturing, Inc.
No reproduction or disclosure of its
CERTAIN INSTANCES MAY NOT BE AVAILABLE
ILLUSTRATIVE PURPOSES ONLY AND IN
SOME ITEMS ARE INCLUDED FOR
contents is permitted.
MODEL PBF12, PBF14, PBF24 SERIES
PBF20 SHOWN SK2427 Rev. - 6/21/09
31
33

11
PARTS LIST December 15, 2010, Rev B
Some items are included for illustrative purposes only and in certain instances may not be available.
MODEL: PBF12G & PBF12S PanaBella Toasters
Fig No Part No Qty Description Application
1 D9-GR0239 1 TOP HOUSING & CONDUIT- 10 ALL
2 2C-Z2054 1 CLAMP, THERMISTOR ALL
3 2C-Z2893 8 NUT 10-24 Hex STL ZP ALL
4 D9-GR0228 1 TOP INS. PLATE ASSY -10” ALL
5 D9-Z2908 1 INSULATION, 10” ALL
6 2A-Z6604 8 SPACER, INSULATION PLATE ALL
7 D9-Z7646 1 PLATE, ELE.&INS RET. -10” ALL
8 2C-08-07-0285 8 SCREW 10-24 x 3/4 3/8 ALL
9PS-Z7761 1ELEMENT, TOP, 600W, 120V-10” 120V
PS-Z2019 ELEMENT, TOP, 800W / 240V 240V
10 1O-E1500 3” SLEEVING #4 .208ID GLASS ALL
11 2F-Z7657 1 CASTING, IRON, TOPGR - 10” GROOVED MODELS
2F-Z7737 1 CASTING, IRON, TOP SM. -10” SMOOTH MODELS
12 2V-Z7641 2 ROD, ARM CONNECTION COMMON ALL
13 2B-Z7860 2 ARM, SIDE COMMON ALL
14 2V-Z7662 1 HANDLE -10” GRILL EXPRESS ALL
15 D9-Z8769 1 COVER, HINGE 10 ALL
16 2V-Z3252 1 ROD - TOP HOUSING LATCH ALL
17 2V-Z7863 2 SPACER, INSIDE 10” ALL
18 2P-Z8824 1 SPRING, TORSION LH ALL
19 2P-Z8823 1 SPRING, TORSION RH ALL
20 2V-Z8407 2 COLLAR, 2 PIECE COMMON ALL
21 2V-Z7862 2 SPACER, OUTSIDE COMMON ALL
22 2V-Z7861 1 ROD, HINGE 10” ALL
23 2F-Z8529 2 RETAINER, HANDLE COMMON ALL
24 D9-Z8444 1 BRACKET, MTG - TOP LATCH ROD ALL
25 2C-Z2992 2 BOLT 1/4”-20X1 PHP STL NP ALL
26 2F-Z7910 2 RETAINER, SPRING ALL
27 D9-GR0253 1 BODYASSY - 10” ALL
28 2T-Y2313 1 THERMOSTAT 118V-236V ALL
29 2M-Z12904 1 OVERLAY PANEBELLA GRILL- 10” ALL
30 2R-Z12886 1 KNOB, T-STAT CONTROL ALL
31 2E-Z2894 1 TERMINAL BLOCK (304) ALL
32 2J-Y6689 1PILOT LIGHT 120V 120V
2J-Z2329 PILOT LIGHT 240V
33 2V-Z8859 2 SPACER, SIDE ALL
34 D9-Z7697 1 PLATE, BOTTOM-10” ALL
35 2A-Z1485 4 FOOT 1” ADJUSTABLE ALL
36 2K-Y3240 1 BUSHING HEYCO SR 17-2 ALL
37 2E-Z2898 1 CONDUITASSY, PTFE ALL
38 2C-Z3917 2 RIVET, POP ALL
39 2E-Z3768 1 LOCKNUT, CONDUIT 1/2 IN ALL
40 2C-Z3780 2 RETAINER, CONDUIT ALL
41 2A-Z3827 1 PLATE, STAMPING - CONDUIT ALL
42 D9-Z8861 1CORD SET 120V 15Aw/TERMINALS 120 V
2E-Z2770 CORD , POWER 14-3, 6-15P 240V
43 2F-Z7730 1 CASTING, IRON, BOTTOM GR - 10” GROOVED MODELS
2F-Z7756 1 CASTING, IRON, BOT., SM.-10” SMOOTH MODELS
44 D9-GR0229 1 BRACKETASSY, THERMOSTAT ALL
45 2N-Z7765 1ELEMENT, BOT, 800W, 120V-10 120V
2N-Z2020 ELEMENT, 1000WATT 240V 10B 240V
46 D9-Z7677 1 ELEMENT PLATE, BOTTOM-10” ALL
47 D9-Z7676 1 INS. PLATE, BOTTOM-10” ALL
48 D9-Z8842 1 GREASE CUP 10” ALL
49 2C-1512 6 SCREW 10-24X3/8 RHP STLNP ALL
53 2M-Z2620 1 LABELCAUTION,BI-LINGUAL ALL
54 2C-6260 2 WASHER #10 INTSTL NP ALL
55 2C-2559 2 NUT 10-24ACHD BR NP ALL
56 2A-Z8408 2 PIN, SLOTTED SPRING-S.S. ALL
57 2C-08-07-0236 4 SCREW 10-32 X 3/4 SHCS ALL

12
PARTS LIST December 15, 2010, Rev B
Some items are included for illustrative purposes only and in certain instances may not be available.
MODEL: PBF14G & PBF14S PanaBella Toasters
Fig No Part No Qty Description Application
1 D9-GR0239 1 TOP HOUSING & CONDUIT - 10 ALL
2 2C-Z2054 1 CLAMP, THERMISTOR ALL
3 2C-Z2893 8 NUT 10-24 Hex STL ZP ALL
4 D9-GR0228 1 TOP INS. PLATE ASSY -10” ALL
5 D9-Z2908 1 INSULATION, 10” ALL
6 2A-Z6604 8 SPACER, INSULATION PLATE ALL
7 D9-Z7646 1 PLATE, ELE.&INS RET. -10” ALL
8 2C-08-07-0285 8 SCREW 10-24 x 3/4 3/8 ALL
9PS-Z7761 1ELEMENT, TOP, 600W, 120V-10” 120V
PS-Z7771 ELEMENT, TOP 1250W 240V-14T 240V
10 1O-E1500 3” SLEEVING #4 .208ID GLASS ALL
11 2F-Z7657 1 CASTING, IRON, TOP GR - 10” GROOVED MODELS
2F-Z7737 1 CASTING, IRON, TOP SM. -10” SMOOTH MODELS
12 2V-Z7641 2 ROD,ARM CONNECTION COMMON ALL
13 2B-Z7860 2 ARM, SIDE COMMON ALL
14 2V-Z7662 1 HANDLE -10” GRILL EXPRESS ALL
15 D9-Z8769 1 COVER, HINGE 10 ALL
16 2V-Z3252 1 ROD - TOP HOUSING LATCH ALL
17 2V-Z7863 2 SPACER, INSIDE 10” ALL
18 2P-Z8824 1 SPRING, TORSION LH ALL
19 2P-Z8823 1 SPRING, TORSION RH ALL
20 2V-Z8407 2 COLLAR, 2 PIECE COMMON ALL
21 2V-Z7862 2 SPACER, OUTSIDE COMMON ALL
22 2V-Z7861 1 ROD, HINGE 10” ALL
23 2F-Z8529 2 RETAINER, HANDLE COMMON ALL
24 D9-Z8444 1 BRACKET, MTG - TOPLATCH ROD ALL
25 2C-Z2992 2 BOLT 1/4”-20X1 PHP STL NP ALL
26 2F-Z7910 2 RETAINER, SPRING ALL
27 D9-GR0253 1 BODY ASSY - 10” ALL
28 2T-Y2313 1 THERMOSTAT 118V-236V ALL
29 2M-Z12904 1 OVERLAY PANEBELLAGRILL - 10” ALL
30 2R-Z12886 1 KNOB, T-STAT CONTROL ALL
31 2E-Z2894 1 TERMINAL BLOCK (304) ALL
32 2J-Y6689 1PILOT LIGHT 120V 120V
2J-Z2329 PILOT LIGHT 240V
33 2V-Z8859 2 SPACER, SIDE ALL
34 D9-Z7697 1 PLATE, BOTTOM-10” ALL
35 2A-Z1485 4 FOOT 1” ADJUSTABLE ALL
36 2K-Y3240 1 BUSHING HEYCO SR 17-2 ALL
37 2E-Z2898 1 CONDUITASSY, PTFE ALL
38 2C-Z3917 2 RIVET, POP ALL
39 2E-Z3768 1 LOCKNUT, CONDUIT 1/2 IN ALL
40 2C-Z3780 2 RETAINER, CONDUIT ALL
41 2A-Z3827 1 PLATE, STAMPING - CONDUIT ALL
42 D9-Z8861 1CORD SET 14/3 120V 15A 120V
2E-Z2770 CORD, POWER 14-3 6-15P 240V
43 2F-Z7730 1 CASTING, IRON, BOTTOM GR - 10” GROOVED MODELS
2F-Z7756 1 CASTING, IRON, BOT., SM.-10” SMOOTH MODELS
44 D9-GR0229 1 BRACKET ASSY, THERMOSTAT ALL
45 2N-Z7765 1ELEMENT, BOT, 800W, 120V-10 120V
2N-Z7774 ELEMENT, 1550WATT 240V-14B 240V
46 D9-Z7677 1 ELEMENT PLATE, BOTTOM-10” ALL
47 D9-Z7676 1 INS. PLATE, BOTTOM-10” ALL
48 D9-Z8842 1 GREASE CUP 10” ALL
49 2C-1512 6 SCREW 10-24X3/8 RHP STL NP ALL
53 2M-Z2620 1 LABELCAUTION,BI-LINGUAL ALL
54 2C-6260 2 WASHER #10 INT STLNP ALL
55 2C-2559 2 NUT 10-24ACHD BR NP ALL
56 2A-Z8408 2 PIN, SLOTTED SPRING-S.S. ALL
57 2C-08-07-0236 4 SCREW 10-32 X 3/4 SHCS ALL

13
PARTS LIST December 15, 2010, Rev B
Some items are included for illustrative purposes only and in certain instances may not be available.
MODEL: PBF24G & PBF24S PanaBella Toasters
Fig No Part No Qty Description Application
1 D9-GR0239 1 TOP HOUSING & CONDUIT - 10 ALL
2 2C-Z2054 1 CLAMP, THERMISTOR ALL
3 2C-Z2893 16 NUT 10-24 Hex STLZP ALL
4 D9-GR0228 2 TOP INS. PLATE ASSY -10” ALL
5 D9-Z2908 4 INSULATION, 10” ALL
6 2A-Z6604 16 SPACER, INSULATION PLATE ALL
7 D9-Z7646 1 PLATE, ELE.&INS RET. -10” ALL
8 2C-08-07-0285 16 SCREW 10-24 x 3/4 3/8 ALL
9 PS-Z2019 2 ELEMENT, TOP, 800W, 240V 240V
10 1O-E1500 3” SLEEVING #4 .208ID GLASS ALL
11 2F-Z7657 1 or 2 CASTING, IRON, TOPGR - 10” GROOVED MODELS
2F-Z7737 1 or 2 CASTING, IRON, TOP SM. -10” SMOOTH MODELS
12 2V-Z7641 4 ROD,ARM CONNECTION COMMON ALL
13 2B-Z7860 4 ARM, SIDE COMMON ALL
14 2V-Z7662 2 HANDLE -10” GRILL EXPRESS ALL
15 D9-Z8769 2 COVER, HINGE 10 ALL
16 2V-Z3252 2 ROD - TOP HOUSING LATCH ALL
17 2V-Z7863 2 SPACER, INSIDE 10” ALL
18 2P-Z8824 2 SPRING, TORSION LH ALL
19 2P-Z8823 2 SPRING, TORSION RH ALL
20 2V-Z8407 4 COLLAR, 2 PIECE COMMON ALL
21 2V-Z7862 2 SPACER, OUTSIDE COMMON ALL
22 2V-Z7861 1 ROD, HINGE 10” ALL
23 2F-Z8529 4 RETAINER, HANDLE COMMON ALL
24 D9-Z8444 1 BRACKET, MTG - TOP LATCH ROD ALL
25 2C-Z2992 12 BOLT 1/4”-20X1 PHP STL NP ALL
26 2F-Z7910 4 RETAINER, SPRING ALL
27 D9-GR0255 1 BODY ASSY - 20” ALL
28 2T-Y2313 2 THERMOSTAT 118V-236V ALL
29 2M-Z12906 1 OVERLAY PANEBELLA GRILL - 20” ALL
30 2R-Z12886 2 KNOB, T-STAT CONTROL ALL
31 2E-Z2894 2 TERMINAL BLOCK (304) ALL
32 2J-Z3157 2 PILOT LIGHT 250V AMBER ALL
33 2V-Z8859 2 SPACER, SIDE ALL
34 D9-Z7918 1 PLATE, BOTTOM-20” ALL
35 2R-200716 4 LEG, 2.5” INCH METAL ALL
36 2K-Y6764 1 BUSHING - STRAIN RELIEF ALL
37 2E-Z2898 2 CONDUITASSY, PTFE ALL
38 2C-Z3917 2 RIVET, POP ALL
39 2E-Z3768 2 LOCKNUT, CONDUIT 1/2 IN ALL
40 2C-Z3780 4 RETAINER, CONDUIT ALL
41 2A-Z3827 2 PLATE, STAMPING - CONDUIT ALL
42 2E-Z2905 1 CORD SJTO 12/3 NEMA6-20P 240V
43 2F-Z7730 1 or 2 CASTING, IRON, BOTTOM GR - 10” GROOVED MODELS
2F-Z7756 1 or 2 CASTING, IRON, BOT., SM.-10” SMOOTH MODELS
44 D9-GR0229 2 BRACKET ASSY, THERMOSTAT ALL
45 2N-Z2020 2 ELEMENT, 1000WATT 240V 10B 240V
46 D9-Z7677 1 ELEMENT PLATE, BOTTOM-10” ALL
47 D9-Z7676 2 INS. PLATE, BOTTOM-10” ALL
48 D9-Z8838 1 GREASE CUP 20” ALL
49 2C-1512 6 SCREW 10-24X3/8 RHP STLNP ALL
53 2M-Z2620 1 LABEL CAUTION,BI-LINGUAL ALL
54 2C-6260 4 WASHER #10 INTSTL NP ALL
55 2C-2559 4 NUT 10-24ACHD BR NP ALL
56 2A-Z8408 4 PIN, SLOTTED SPRING-S.S. ALL
57 2C-08-07-0236 8 SCREW 10-32 X 3/4 SHCS ALL

16
STAR INTERNATIONAL HOLDINGS INC. COMPANY
Star - Holman - Lang - Wells - Bloomeld - Toastmaster
10 Sunnen Drive, St. Louis, MO 63143 U.S.A.
(314) 781-2777
www.star-mfg.com
This manual suits for next models
6
Table of contents
Other Lang Grill manuals
Popular Grill manuals by other brands

GRILLS-MAX
GRILLS-MAX 45SCFT Installation and operation instructions

gascraft
gascraft Kamado instructions

THOMSON
THOMSON THPL935 user manual

Matador
Matador Outdoor Entertainer HS-KC003A user manual

Kenmore
Kenmore 415162140 Assembly instructions/use and care manual

Kasanova
Kasanova KBO000011NOC instruction manual
