Lantronix xPico User manual

xPico
User Guide
Part Number 900-618
Revision B January 2013

Copyright and Trademark
© 2013 Lantronix. All rights reserved. No part of the contents of this book may be
transmitted or reproduced in any form or by any means without the written permission
of Lantronix.
DeviceLinx®, xPico™ and DeviceInstaller™ are trademarks of Lantronix.
Ethernet is a trademark of XEROX Corporation. UNIX is a registered trademark of
The Open Group. Windows is a trademark of Microsoft Corp.
Warranty For details on the Lantronix warranty policy, please go to our Web site at
www.lantronix.com/support/warranty.
Contacts Lantronix Corporate Headquarters
167 Technology Drive
Irvine, CA 92618, USA
Toll Free: 800-526-8766
Phone: [phone]
Fax: [phone]
Technical Support
Online: www.lantronix.com/support
Sales Offices
For a current list of our domestic and international sales offices, go to the Lantronix
web site at www.lantronix.com/about/contact
xPico User Guide 2

Disclaimer Operation of this equipment in a residential area is likely to cause interference, in
which case the user, at his or her own expense, will be required to take whatever
measures may be required to correct the interference.
Note: This product has been designed to comply with the limits for a Class B digital
device pursuant to Part 15 of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy, and if not
installed and used in accordance with this guide, may cause harmful interference to
radio communications.
Changes or modifications to this device not explicitly approved by Lantronix will void
the user's authority to operate this device.
Note: With the purchase of xPico, the OEM agrees to an OEM firmware license
agreement that grants the OEM a non-exclusive, royalty-free firmware license to use
and distribute the binary firmware image provided, only to the extent necessary to
use the xPico hardware. For further details, please see the xPico OEM firmware
license agreement.
Revision History
Date
Rev.
Comments
April 2012
A
Initial release for firmware version 6.8.0.0.
January 2013
B
Updated for firmware version 6.8.0.3.
For the latest revision of this product document, please check our online
documentation at www.lantronix.com/support/documentation.
xPico User Guide 3

Table of Contents
Copyright and Trademark.............................................................................................2
Warranty.......................................................................................................................2
Contacts........................................................................................................................2
Disclaimer.....................................................................................................................3
Revision History............................................................................................................3
List of Tables ................................................................................................................8
List of Figures...............................................................................................................8
1. Using This Guide 9
Purpose and Audience ................................................................................................. 9
Chapter Summary ........................................................................................................9
Additional Documentation...........................................................................................10
2. Introduction 11
Capabilities.................................................................................................................11
Applications ................................................................................................................11
Protocol Support.........................................................................................................12
Configuration Methods ...............................................................................................12
Addresses and Port Numbers ....................................................................................12
Hardware Address ...............................................................................................12
IP Address............................................................................................................13
Port Numbers.......................................................................................................13
Product Information Label ..........................................................................................13
3. Using DeviceInstaller 14
Installing DeviceInstaller.............................................................................................14
Assigning an IP Address ............................................................................................14
Accessing the xPico Using DeviceInstaller ................................................................15
Viewing the Current Configuration .............................................................................15
4. Configuration Using Web Manager 18
Accessing Web-Manager Using DeviceInstaller ........................................................18
Network Configuration................................................................................................19
Network Mode......................................................................................................20
Automatic IP Address Configuration....................................................................20
Static IP Address Configuration...........................................................................21
Ethernet Configuration.........................................................................................21
xPico User Guide 4

Table of Contents
Server Configuration...................................................................................................22
Server Configuration............................................................................................23
Advanced.............................................................................................................23
Host List Configuration...............................................................................................23
Retry Settings.......................................................................................................24
Host Information...................................................................................................24
Channel 1 and 2 Configuration...................................................................................24
Serial Settings......................................................................................................25
Connection Settings - TCP ..................................................................................27
Connection Settings - UDP..................................................................................30
Configurable Pin Settings...........................................................................................32
Configurable Pin Functions..................................................................................32
Apply Settings.............................................................................................................33
Apply Defaults ............................................................................................................33
5. Configuration via Telnet or Serial Port (Setup Mode) 34
Accessing Setup Mode...............................................................................................34
Telnet Connection................................................................................................34
Serial Port Connection.........................................................................................35
Exiting Setup Mode ....................................................................................................36
6. Setup Mode: Server Configuration 37
Server Configuration (Option 0) .................................................................................37
IP Address..................................................................................................................37
Set Gateway IP Address ............................................................................................38
Netmask: Number of Bits for Host Part......................................................................38
Set DNS Server IP Address .......................................................................................38
Change Telnet/Web-Manager Password...................................................................38
DHCP Name...............................................................................................................39
7. Setup Mode: Channel Configuration 40
Channel 1 (Option 1) or Channel 2 (Option 2) ...........................................................40
Baudrate.....................................................................................................................40
I/F (Interface) Mode....................................................................................................41
Flow............................................................................................................................41
Port Number ...............................................................................................................42
Connect Mode ............................................................................................................42
a) Incoming Connection.......................................................................................43
b) Response.........................................................................................................44
xPico User Guide 5

Table of Contents
c) Active Startup...................................................................................................44
d) Datagram Type................................................................................................47
e) Modem Mode...................................................................................................47
Send the Escape Sequence (+++) in Modem Mode..................................................49
Show IP addr after 'RING' ..........................................................................................49
Auto Increment Source Port.......................................................................................49
Remote IP Address ....................................................................................................50
Remote Port ...............................................................................................................50
DisConnMode.............................................................................................................50
Flush Mode (Buffer Flushing).....................................................................................51
Pack Control...............................................................................................................51
Packing Interval....................................................................................................52
Trailing Characters...............................................................................................52
Send Characters..................................................................................................52
DisConnTime (Inactivity Timeout) ..............................................................................53
Send Characters.........................................................................................................53
Telnet Terminal Type..................................................................................................53
Channel (Port) Password ...........................................................................................53
8. Setup Mode: Advanced Settings 54
Expert Settings (Option 5)..........................................................................................54
TCP Keepalive time in seconds...........................................................................54
ARP Cache timeout in seconds...........................................................................55
CPU Performance................................................................................................55
Disable Monitor Mode at bootup..........................................................................55
HTTP Port Number ..............................................................................................55
MTU Size .............................................................................................................55
TCP Re-Transmission Timeout............................................................................56
Enable alternate MAC..........................................................................................56
Ethernet Connection Type...................................................................................56
Security Settings (Option 6)........................................................................................56
Disable SNMP......................................................................................................57
SNMP Community Name.....................................................................................57
Disable Telnet Setup............................................................................................57
Disable TFTP Firmware Upgrade........................................................................58
Disable Port 77FE (Hex)......................................................................................58
Disable Web Server.............................................................................................58
Disable Web Setup ..............................................................................................58
xPico User Guide 6

Table of Contents
Disable ECHO Ports ............................................................................................58
Enable Encryption................................................................................................59
Enable Enhanced Password................................................................................60
Disable Port 77F0 (Hex) ......................................................................................60
Default Settings (Option 7).........................................................................................60
Channel 1 and Channel 2 Configuration Defaults ...............................................60
Expert Settings Defaults ......................................................................................61
Security Settings Defaults....................................................................................61
9. GPIO Interface 62
Configurable Pins .......................................................................................................62
Features...............................................................................................................62
Control Protocol..........................................................................................................63
Guidelines ............................................................................................................63
Commands...........................................................................................................63
Examples....................................................................................................................65
10. Firmware Upgrades 67
Obtaining Firmware ....................................................................................................67
Reloading Firmware ...................................................................................................67
Using TFTP: Graphical User Interface.................................................................67
Using TFTP: Command Line Interface ................................................................68
Recovering the Firmware Using the Serial Port and DeviceInstaller...................69
11. Monitor Mode 70
Entering Monitor Mode Using the Serial Port.............................................................70
Entering Monitor Mode Using the Network Port.........................................................70
Monitor Mode Commands....................................................................................70
12. Troubleshooting 73
Problems and Error Messages...................................................................................73
Technical Support.......................................................................................................76
A: Binary to Hexadecimal Conversions 77
Converting Binary to Hexadecimal.............................................................................77
Conversion Table.................................................................................................77
Scientific Calculator .............................................................................................77
B: Compliance 79
RoHS Notice...............................................................................................................79
xPico User Guide 7

List of Tables and Figures
List of Tables
Table 6-1. BootP/DHCP/AutoIP Options____________________________________________37
Table 6-2. Standard IP Network Netmasks__________________________________________38
Table 7-1. Interface Mode Options ________________________________________________41
Table 7-2. RS232 Interface Mode Settings__________________________________________41
Table 7-3. Flow Control Options __________________________________________________42
Table 7-4. Reserved Port Numbers________________________________________________42
Table 7-5. Connect Mode Options ________________________________________________43
Table 7-6. Manual Connection Address Example_____________________________________45
Table 7-7. Modem Mode Messages _______________________________________________47
Table 7-8. Modem Mode Commands ______________________________________________48
Table 7-9. Disconnect Mode Options ______________________________________________50
Table 7-10. Flush Mode Options__________________________________________________51
Table 7-11. Pack Control Options _________________________________________________52
Table 10-1. Firmware Files ______________________________________________________67
Table 11-1. Monitor Mode Commands _____________________________________________71
Table 11-2. Command Response Codes ___________________________________________72
List of Figures
Figure 2-1. Product Label _______________________________________________________13
Figure 4-1. Web-Manager Login Window ___________________________________________19
Figure 4-2. Lantronix Web-Manager _______________________________________________19
Figure 4-3. Network Settings_____________________________________________________20
Figure 4-4. Server Settings ______________________________________________________22
Figure 4-5. Hostlist Settings _____________________________________________________24
Figure 4-6. Channel Serial Settings _______________________________________________25
Figure 4-7. TCP Connection Settings ______________________________________________28
Figure 4-8. UDP Connection Settings ______________________________________________31
Figure 4-9. Configurable Pins Settings _____________________________________________32
Figure 4-10. Apply Settings and Apply Defaults ______________________________________33
Figure 5-1. MAC Address _______________________________________________________35
Figure 5-2. Setup Menu Options __________________________________________________35
Figure 7-1. Serial Port Parameters ________________________________________________40
Figure 7-2. Hostlist Option_______________________________________________________46
Figure 8-1. Expert Settings ______________________________________________________54
Figure 8-2. Security Settings_____________________________________________________56
Figure 10-1. TFTP Window ______________________________________________________68
xPico User Guide 8

1. Using This Guide
Purpose and Audience
This guide covers xPico Device Server Module. It provides the information needed to
configure, use, and update the xPico firmware and is intended for OEMs and system
integrators who are embedding the xPico in their end product designs.
Chapter Summary
The remaining chapters in this guide include:
Document
Description
2: Introduction
Describes the main features of the xPico and the protocols
it supports.
3: Using DeviceInstaller
Provides information for getting your unit up and running,
using DeviceInstaller to assign an IP address.
4: Configuration Using Web
Manager
Details using the Web-Manager to set parameters such as
port and server properties.
5: Configuration via Telnet or
Serial Port (Setup Mode)
Provides instructions for accessing Setup Mode (command
line interface) using a Telnet connection through the
network or a terminal or terminal emulation program
through the serial port.
6: Setup Mode: Server
Configuration
Details the network (server) settings
7: Setup Mode: Channel
Configuration
Details the serial port settings.
8: Setup Mode: Advanced
Settings
Details expert and security settings and explains how to
reset the unit to factory default values.
9: GPIO Interface
Provides instructions for configuring the eight General
Purpose I/O pins (CP1-8).
10: Firmware Upgrades
Provides instructions for obtaining the latest firmware and
updating the xPico.
11: Monitor Mode
Provides instructions for accessing and using the
command line interface for monitoring the network and
diagnosing problems.
12: Troubleshooting
Describes common problems and error messages and how
to contact Lantronix Technical Support.
A: Binary to Hexadecimal
Conversions
Provides instructions for converting binary numbers to
hexadecimals.
B: Compliance
Provides compliance information.
xPico User Guide 9

1: Using This Guide
Additional Documentation
Visit the Lantronix Web site at www.lantronix.com/support/documentation for the
latest documentation and the following additional documentation.
Document
Description
xPico Quick Start
Provides the steps for getting the xPico evaluation board up
and running.
xPico Integration Guide
Provides information about the xPico hardware, testing the
xPico using the evaluation board, and integrating the xPico
into your product.
xPico Development Kit
Quick Start
Instructions for using the xPico on the xPico evaluation board.
Com Port Redirector
User Guide
Provides information on using the Windows-based utility to
create a virtual com port.
DeviceInstaller Online
Help
Provides information on using DeviceInstaller to configure IP
addresses and locate Lantronix devices on the network.
xPico User Guide 10

2. Introduction
This chapter summarizes the xPico device server’s features and the basic
information needed to get started.
Capabilities
The xPico device server has the following capabilities:
Connects devices through a TCP data channel or through a Telnet connection to
computers or to another device server. The xPico also supports UDP datagrams.
Contains a web [HTTP] server allowing presentation of custom content and easy
configuration through a browser.
Has eight programmable I/O pins used to monitor or control attached devices.
Applications
The xPico device server connects serial devices such as those listed below to
Ethernet networks using the IP protocol family.
ATM machines
CNC controllers
Data collection devices
Environmental sensors
Universal Power Supply (UPS) management units
Telecommunications equipment
Data display devices
Security alarms and access control devices
Handheld instruments
Modems
Time/attendance clocks and terminals
xPico User Guide 11

2: Introduction
Protocol Support
The xPico device server uses the Internet Protocol (IP) for network communications.
It uses the Transmission Control Protocol (TCP) to assure that no data is lost or
duplicated, and that everything sent to the connection arrives correctly at the target.
Supported protocols include:
ARP, TCP/IP, UDP/IP, BOOTP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, and
SNMP for network communications and management.
TCP/IP, UDP/IP, and Telnet for connections to the serial port.
TFTP for firmware and web page updates.
IP for addressing, routing, and data block handling over the network.
User Datagram Protocol (UDP) for typical datagram applications in which devices
interact with other devices without maintaining a point-to-point connection.
Configuration Methods
For the unit to operate correctly on a network, it must have a unique IP address on
the network. There are three basic methods for logging into the device server to
assign an IP address and configure the unit:
DeviceInstaller: Assign an IP address and view the current xPico configuration using
a Graphical User Interface (GUI) on a PC attached to a network. (See 3 Using
DeviceInstaller.)
Web-Manager: Through a web interface, configure the xPico and its settings using
the xPico’s Web-Manager. (See 4Configuration Using Web Manager
Serial & Telnet Ports: There are two approaches to accessing Serial Mode. Make a
Telnet connection to the network port (9999) or connect a terminal (or a PC running a
terminal emulation program) to the unit’s serial port. (See 5 Configuration via Telnet
or Serial Port (Setup Mode) )
Addresses and Port Numbers
Hardware Address
The hardware address is also referred to as the Ethernet address or the MAC
address. The first three bytes of the Ethernet address identify the unit as a Lantronix
product. The fourth, fifth, and sixth bytes are unique numbers assigned to each unit.
Example: 00-80-A3-14-01-18
Note: Make note of the MAC address. It is needed to locate the xPico using
DeviceInstaller.
xPico User Guide 12

2: Introduction
IP Address
Every device connected to an IP network must have a unique IP address. This
address is used to reference the specific unit. The xPico is automatically assigned an
IP address on DHCP-enabled networks, as it is DHCP-enabled by default.
Port Numbers
Every TCP connection and every UDP datagram is defined by a destination IP
address and a port number. For example, a Telnet application commonly uses port
number 23. A port number is similar to an extension on a phone system.
The unit's serial channel (port) can be associated with a specific TCP/UDP port
number. Port number 9999 is reserved for access to the unit's Setup (configuration)
Mode window. Ports 0-1024 are reserved as well. For more information on reserved
port numbers, see to Table 7-4. Reserved Port Numbers on page 42.
Product Information Label
The product information label on the unit contains the following information about the
specific unit:
Part Number
Revision
Manufacturing Date Code
Product Model
Country of Origin
Lantronix Datamatrix Barcode
MAC Address
Figure 2-1. Product Label
Part Number
Manufacturing
Date Code
Lantronix
Datamatrix
Barcode
Product Model
Country of Origin
Revision
MAC Address
xPico User Guide 13

3. Using DeviceInstaller
This chapter covers the steps for getting the xPico device server online and viewing
its current configuration.
Note: DeviceInstaller is a free utility program provided by Lantronix that
discovers, configures, upgrades, and manages Lantronix Device Servers. It
can be downloaded from the Lantronix website at
www.lantronix.com/support/downloads.
For instructions on using DeviceInstaller to configure the IP address and
related settings or for more advanced features, see the DeviceInstaller
Online Help.
Installing DeviceInstaller
To install DeviceInstaller:
1. Download the latest version of DeviceInstaller from
http://www.lantronix.com/downloads.
2. Run the executable to start the installation process.
3. Respond to the installation wizard prompts. (If prompted to select an installation
type, select Typical).
Assigning an IP Address
The unit’s IP address must be configured before it can work correctly on a network.
You have several options for assigning an IP to your unit. We recommend that you
manually assign the IP address over the network using DeviceInstaller.
Note: To use a serial connection instead of an Ethernet connection to configure the
device, see 5Configuration via Telnet or Serial Port (Setup Mode) on page 35.
The unit’s IP address is normally set to 0.0.0.0 at the factory. The hardware address
is on the product label. The unit is DHCP enabled as the default.
To assign an IP address manually:
1. Click StartPrograms LantronixDeviceInstallerDeviceInstaller. If your
PC has more than one network adapter, a message displays. Select an adapter
and click OK.
Note: If the unit already has an IP address (e.g., DHCP has assigned an IP address),
click the Search icon and select the unit from the list of Lantronix device servers on
the local network.
xPico User Guide 14

3: Using DeviceInstaller
2. Click the Assign IP icon .
3. If prompted, enter the hardware address (on the product label) and click Next.
4. Select Assign a specific IP address and click Next.
5. Enter the IP address. The Subnet mask displays automatically based on the IP
address; if desired, you may change it. On a local network, you can leave the
Default gateway blank (all zeros). Click Next.
6. Click the Assign button and wait several seconds until a confirmation message
displays. Click Finish.
7. Select the device from the main window list and select Ping from the Tools
menu. The Ping Device dialog box shows the IP address of the selected unit.
8. From the Tools menu, click the Ping button. The results display in the Status
window. Click the Clear Status button to clear the window so you can ping the
device again.
Note: If you do not receive “Reply” messages, make sure the unit is properly
attached to the network and that the IP address assigned is valid for the particular
network segment you are working with. If you are not sure, check with your systems
administrator.
9. Click the Close button to close the dialog box and return to the main window.
Accessing the xPico Using DeviceInstaller
1. Click StartPrograms LantronixDeviceInstallerDeviceInstaller.
2. Click the xPico folder. The list of available Lantronix xPico modules display.
3. Expand the list of xPicos by clicking the + symbol next to the xPico icon. Select
the xPico unit by clicking on its IP address to view its configuration.
Viewing the Current Configuration
DeviceInstaller provides a view of the unit's configuration.
To view the unit's current settings:
1. Follow the instructions above to locate the xPico.
2. In the right pane, click the Device Details tab. The current xPico configuration
displays:
Name
Configurable field. A name that identifies the xPico.
Double-click the field, type in the value, and press Enter to
complete. This name is not visible on other PCs or laptops
using DeviceInstaller.
xPico User Guide 15

3: Using DeviceInstaller
DHCP Device Name
Non-configurable field. Displays the name associated with
xPico’s current IP address, if the IP address was obtained
dynamically.
To change the DHCP device name, see Configuration Using
Web Manager
or Configuration via Telnet or Serial Port (Setup Mode).
Group
Configurable field. A group name to categorize the xPico.
Double-click the field, type in the value, and press Enter to
complete. This group name is not visible on other PCs or
laptops using DeviceInstaller.
Comments
Configurable field. Information about the xPico.
Double-click the field, type in the value, and press Enter to
complete. This description or comment is not visible on other
PCs or laptops using DeviceInstaller.
Device Family
Non-configurable field. Displays the xPico’s device family as
xPico.
Type
Non-configurable field. Displays the device type as xPico.
ID
Non-configurable field. Displays the xPico’s ID embedded
within the unit.
Hardware Address
Non-configurable field. Displays the xPico’s hardware (or MAC)
address.
Firmware Version
Non-configurable field. Displays the firmware currently installed
on the xPico.
Extended Firmware
Version
Non-configurable field. Displays the full version nomenclature of
the firmware.
Online Status
Non-configurable field. Displays the xPico’s status as online,
offline, unreachable (the xPico is on a different subnet), or busy
(the xPico is currently performing a task).
IP Address
Non-configurable field. Displays the xPico’s current IP address.
To change the IP address, see Assigning an IP Address on
page 14.
IP Address was Obtained
Displays “Dynamically” if the xPico automatically received an
IP address (e.g., from DHCP). Displays “Statically” if the IP
address was configured manually. If the IP address was
assigned dynamically, the following fields appear:
Obtain via DHCP with value of True or False.
Obtain via BOOTP with value of True or False.
Obtain via RARP with value of True or False
Obtain via Auto IP with value of True or False
Subnet Mask
Non-configurable field. Displays the xPico’s current subnet
mask. To change the subnet mask, see Assigning an IP
Address on page 14.
Gateway
Non-configurable field. Displays the xPico’s current gateway.
To change the gateway, see Assigning an IP Address on page
14.
Number of COB partitions
supported
Non-configurable field. Displays the number of COB partitions
supported.
Number of Ports
Non-configurable field. Displays the number of ports on the
xPico.
TCP Keepalive
Non-configurable field. Displays 1-65s, the xPico’s TCP
keepalive value. The default setting is 45.
xPico User Guide 16

3: Using DeviceInstaller
Telnet Supported
Non-configurable field. Indicates if Telnet sessions are
permitted.
Telnet Port
Non-configurable field. Displays the xPico’s port for Telnet
sessions.
Web Port
Non-configurable field. Displays the xPico’s port for Web-
Manager configuration.
Maximum Baud Rate
Supported
Non-configurable field. Displays the xPico’s maximum baud
rate.
Note: the xPico may not currently be running at this rate.
Firmware Upgradeable
Non-configurable field. Displays True, indicating the xPico’s
firmware is upgradeable as newer version become available.
Supports Configurable
Pins
Non-configurable field. Displays True, indicating configurable
pins are available on the xPico.
Supports Email Triggers
Non-configurable field. Displays False, indicating email triggers
are not supported on xPico.
Supports AES Data
Stream
Non-configurable field. Displays True. xPico supports AES
encryption.
Supports 485
Non-configurable field. Displays True. xPico supports the RS-
485 protocol.
Supports 921K Baud Rate
Non-configurable field. Displays True. xPico supports baud
rates up to 921600 bits per second (bps).
Supports HTTP Server
Non-configurable field. Displays True.
Supports HTTP Setup
Non-configurable field. Displays True.
Supports 230K Baud Rate
Non-configurable field. Displays True.
Supports GPIO
Non-configurable field. Displays True, indicating the xPico
supports General Purpose Input Output (GPIO).
xPico User Guide 17

4. Configuration Using Web Manager
You must configure the unit so that it can communicate on a network with your serial
device. For example, you must set the way the unit will respond to serial and network
traffic, how it will handle serial packets, and when to start or close a connection.
The unit’s configuration is stored in nonvolatile memory and is retained without
power. You can change the configuration at any time. The unit performs a reset after
you change and store the configuration.
In this chapter, we describe how to configure the xPico using Web-Manager,
Lantronix’s browser-based configuration tool. (For information on using Setup Mode,
our command line configuration interface, see 5 Configuration via Telnet or Serial
Port (Setup Mode).
Note: The examples in this section show a typical device. Your device may have
different configuration options.
Accessing Web-Manager Using DeviceInstaller
Note: For more information on DeviceInstaller, see 3 Using DeviceInstaller.
1. Run DeviceInstaller and search for the list of available Lantronix device servers.
2. Click on the xPico folder. The list of available xPicos displays.
3. Expand the list of xPicos by clicking the +symbol next to the xPico icon.
4. Select the xPico unit by clicking its hardware address.
5. In the right pane, click the Web Configuration tab.
6. To view the xPico’s Web-Manager in the current DeviceInstaller window, click the
Go button. To open the Web-Manager in a web browser, click the External
Browser button.
Note: Alternatively, to open Web-Manager, open your web browser and
enter the IP address of the xPico.
A dialog box appears to prompt for a User Name and Password.
xPico User Guide 18

4: Configuration Using Web Manager
Figure 4-1. Web-Manager Login Window
7. Perform one of the following:
If no Telnet password has been defined (default), leave both fields blank and
click OK.
If a Telnet password has been defined, leave the username blank, type in the
password, and then click OK.
The Web-Manager displays.
Figure 4-2. Lantronix Web-Manager
The main menu is in the left pane of the Web-Manager window.
Network Configuration
The unit’s network values display when you select Network from the main menu. The
following sections describe the configurable parameters on the Network Settings
page.
xPico User Guide 19

4: Configuration Using Web Manager
Figure 4-3. Network Settings
Network Mode
1. Click Network from the main menu.
2. Note the following:
Network Mode
Wired Only is the only choice. It enables the Ethernet network
connectivity.
Automatic IP Address Configuration
An IP address can be assigned automatically. You then enter related network
settings.
To assign an IP address automatically:
1. On the main menu, click Network.
2. Select Obtain IP address automatically.
3. Enter the following (as necessary):
BOOTP
Select Enable to permit the Bootstrap Protocol (BOOTP).
server to assign the IP address from a pool of addresses
automatically. Enable is the default.
DHCP
Select Enable to permit the Dynamic Host Configuration
xPico User Guide 20
