Larson Electronics EXHL-TRN-RPS-LE4-FKWL-WHT-M User manual

EXHL-TRN-RPS-LE4-FKWL-WHT-M
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com 1of 2
Explosion Proof Rechargeable White Forklift LED Forward Projection Light
C1D1-2 - C2D1-2 - Aluminum
Instruction Manual
Thank you for your purchase of the Larson Electronics EXHL-TRN-RPS-LE4-FKWL-WHT-M.
WARNING:
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
CRITICAL SAFETY INSTRUCTIONS:
•INSTALLATION SHOULD ONLY BECONDUCTED BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH NEC AND ANY
RELEVANT LOCAL BUILDING CODES.
•RISK OFFIRE OR ELECTRIC SHOCK. FIXTURE INSTALLATION REQUIRES KNOWLEDGE OF FIXTURE'S ELECTRICAL
SYSTEMS. IFNOTQUALIFIED, CONTACT A QUALIFIED ELECTRICIAN.
•BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.
•MAKE SURE THE SUPPLY VOLTAGE IS THE SAME AS THE FIXTURE'S RATED VOLTAGE.
•TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET METAL OR SHARP
OBJECTS. SUITABLE FOR DAMP LOCATIONS.
WARNING
TO AVOIDTHE RISKOF FIRE,EXPLOSION OR ELECTRIC SHOCK, THIS PRODUCT SHOULD BE INSTALLED,
INSPECTEDAND MAINTAINEDBY A QUALIFIED ELECTRICIANONLY, IN ACCORDANCEWITHALL
APPLICABLEELECTRICAL CODES.
TO AVOIDELECTRIC SHOCK:
•BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.
•PRODUCT MUST BE CONNECTED TO A WIRING SYSTEM WITH AN EQUIPMENT-GROUNDING
CONDUCTOR.
TO AVOID EXPLOSION:
•MAKE SURE THE SUPPLY VOLTAGE IS WITHIN THE VOLTAGE RATING.
•ENSURE THE MARKED T RATING IS LESS THAN THE IGNITION TEMPERATURE OF THE HAZARDOUS
ATMOSPHERE.
•DO NOT OPERATE IN AMBIENT TEMPERATURES ABOVE THOSE INDICATED ON THE PRODUCT
NAMEPLATE.
•DO NOT OPERATE IF THE LENS, CORD, SEALS, HOUSING, RECEPTACLES, ETC. IS CRACKED OR
DAMAGED. IF SO, DISCONTINUE USE AND CONTACT MANUFACTURER FOR REPLACEMENT PARTS.
•ALL FASTENERS SHOULD BE PROPERLY SEATED.
IMPORTANT
READ CAREFULLY BEFORE INSTALLING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. THE EXHL-TRN-RPS-LE4-FKWL-WHT-M MUST BE WIRED IN ACCORDANCE WITH NATIONAL
ELECTRICAL CODE AND ALL APPLICABLE LOCAL CODES. PROPER GROUNDING IS REQUIRED FOR SAFETY.
WE STRONGLY ENCOURAGE ONLY A LICENSED ELECTRICIAN INSTALL, OPERATE AND MAINTAIN THIS
PRODUCT. IF YOU ARE NOT QUALIFIED OR UNFAMILIAR WITH ANY ASPECT OF THIS INSTRUCTION SHEET,
CONSULT AN ELECTRICIAN. THERE ARE NO SERVICEABLE PARTS INSIDE.
WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE
INSTALLATION OR PERFORMING ANY MAINTENANCE.
RISK OF FIRE/ELECTRIC SHOCK –DISCONNECT POWER AT BREAKER BEFORE INSTALLING OR SERVICING.
RISK OF PERSONAL INJURY –FIXTURE MAY BECOME UNSTABLE OR DAMAGED IF NOT INSTALLED PROPERLY.
RISK OF BURN –ALLOW FIXTURE TO COOL BEFORE SERVICING.
Magnetic Warning
•PEOPLE WITH PACEMAKERS SHOULD CONSULT THEIR PHYSICIAN(S) BEFORE USE.
ELECTROMAGNETIC FIELDS INCLOSE PROXIMITY TOHEART PACEMAKER COULD CAUSE
PACEMAKER INTERFERENCE OR PACEMAKER FAILURE.
•KEEP FINGERS AWAY FROM MAGNET WHEN MOUNTING ASINJURY COULD OCCUR.

EXHL-TRN-RPS-LE4-FKWL-WHT-M
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com 2of 2
The EXHL-TRN-RPS-LE4-FKWL-WHT-M from Larson Electronics is an Explosion Proof Rechargeable White Forklift LED
Warning Light that produces 2,250 lumens while drawing only 25 watts. Forklift operators may use this compact, forward
projection luminary as a forklift headlight to illuminate the operating area in front of the forklift. This light is also ideal for
providing increased visibility when loading a pallet onto a shelf. The EXHL-TRN-RPS-LE4-FKWL-WHT-M is Class I,
Divisions 1 & 2, Groups B, C, D, Class I, Zones 1 & 2, Groups IIB+H2, IIA, Class II, Divisions 1 & 2, Groups E, F, G and
Class III Divisions 1 & 2 rated for hazardous areas and is listed for use worldwide including the United States, Canada,
Europe and Asia. This explosion proof LED light offers 8 hours of runtime from the 8.8aH lithium ion rechargeable battery.
DURABILITY
The EXHL-TRN-RPS-LE4-FKWL-WHT-M explosion proof rechargeable LED light fixture from Larson Electronics is rated
NEMA Type 3, 4, 4X, 7 (B,C,D) and 9 (E,F,G) and designed to withstand the rigors of demanding environmental and
operating conditions while remaining lightweight and easy to use. These units can operate in temperatures of -40° Celsius
to 60° Celsius, are waterproof to 3 meter and resist ingress of dust, dirt and humidity. The housings are formed from
extruded aluminum and the lenses are unbreakable polycarbonate. The LEDs offer inherent LED resistance to shocks and
vibrations.
MOUNTING
This explosion proof LED forward projection light features an adjustable surface mount bracket for seamless control. The
included adjustable flat surface bracket has two set screws on the bracket, allowing operators to loosen the mounting
bracket, adjust the light`s tilt orientation, and retighten to hold the luminary in position. A single thru-hole mounting bolt
allows operators to adjust the rotation of the fixture by loosening one bolt.
OPERATION
The EXHL-TRN-RPS-LE4-FKWL-WHT-M runs on a 8.8aH lithium ion rechargeable battery. The battery offers 8 hours of
runtime before recharging is required.
MAINTENANCE
Caution: To avoid personal injury, disconnect power to the light and allow the unit to cool down before
performing maintenance.
Warning: No user serviceable parts inside of fixture. Risk of electric shock. Removal of the lens will void
the warranty.
1. Perform visual,mechanical and electrical inspections on a regular basis.We recommend routine checks to be made on a
yearly basis. Frequency of use and environment shoulddetermine this. It is recommendedto follow an Electrical Preventive
Maintenance Program as described in NFPA 70B: Recommendedpractice for Electrical Equipment.
2. The lens should be cleaned periodically as neededto ensure continued photometric performance. Clean the lens with a
damp, non-abrasive,lint-free cloth. If not sufficient, use mild soapor a liquid cleaner.
3. Inspect the cooling fins on the luminaire to ensure that they are free of any obstructions or contamination (i.e.excessive
dust build-up).Clean with a non-abrasive clothif needed.
4. Do not operate if the lens is cracked or damaged. All fasteners shouldbe properly seated.
USE AND CARE
Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.
Always check for damaged or worn out parts before using the device. Storeit in a secure place out of the reach of
children when not in use.Inspect for good working condition prior tostorage and before re-use.
REPLACEMENT PARTS
The EXHL-TRN-RPS-LE4-FKWL-WHT-M is designed to provide years of reliable performance. Should the need for
replacement parts arise, please contact Larson Electronics.
THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION
REQUIREMENTS. SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON
ELECTRONICS BY EMAIL AT SA[email protected] OR BY PHONE AT 1-800-369-6671 FOR FURTHER ASSISTANCE.
PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
