Laser NAVC-L07 User manual

NAVC-L07 USER MANUAL
1
Please read carefully before use
It is recommended to use a Class 4 ( 4Mb/s write speed) Micro SDHC card for optimal
performance. Some “Extreme Speed” class 10 UHS 2 cards may not function correctly

NAVC-L07 USER MANUAL
2
TABLE ON CONTENTS
Important Safety Instructions and Precautions 2
Product Connections and Use 3
What’s in the box 4
Features and Operation 4
Power on/off function (auto on/off) 4
Auto Record when turned on 4
Installation on the car windscreen 4
Recording 5
Change between modes 5
Mode Settings 5
-Digital Video 6
-Digital Still Camera 6
-Playback 7
-Setup Hardware 7
USB Connection 8
Typical Photo/Video Storage Capacity 8
Connecting the NAVC-L07 in the car 9
Trouble shooting / FAQ 10
Product Specifications 10
IMPORTANT SAFETY INSTRUCTIONS AND PRECAUTIONS
- Read all instructions carefully before use.
- Retain manuals for future reference.
- Use this product only in the manner described.
- Only use a water-dampened soft-cloth to clean the surface of this product.
- The following will damage this product: any liquid such as wateror moisture, extreme
heat; cold; humidity, dusty or sandy environments.
- Only place this device on stable surfaces and ensure that any attached cables are secure
and will not cause thedevice to fall.
- Ifcharging is required, it is recommended tothoroughly charge electronic devices for the
first timeovernight. Subsequent charges can be as needed. During charging, or
extended use, the product may become warm.
- There are no user serviceable parts in this product.
- Un-authorized attempts to dismantle or repair this product will void product warranty
- Using this device near other electronic devices may cause interference.

NAVC-L07 USER MANUAL
3
PRODUCT CONNECTIONS AND USE
1 Microphone 9 Up Button
2 Suction Mount
Fitting 10 Micro SD Card Slot
3 Power Button 11 LED Indicator Light
4 Reset Button 12 Camera
5 Menu Button 13 Speaker (Note: For button
sounds only)
6 OK Button 14 Suction Mount
7 Micro USB Port 15 2nd USB Port (Optional use)
8 Down Button
1
2
3
10
9
8
11
6
5
4
15
14
7
13
12

NAVC-L07 USER MANUAL
4
WHATS IN THE BOX
FEATURES AND OPERATION
Note: A memory card is required for operation
The NAVC-L07 requires a Micro SD card (not included) to record video / image content. (see
page 8 for a table showing SD card capacity and the relevant amount of video / image
content able to be stored). Foroptimal performance, we recommend using a Class 4 Micro
SD card (themost common type) to ensure fast data transfer rates.
Power on/off function (auto on/off)
To turn on the NAVC-L07, press the power button on the top of the device. To turn off,
press the same power button. When connected to the 12v DC socket (cigarette socket) of
yourcar, the NAVC-L07willturn on and offautomatically when thecar’s ignition is turned
on or off. If the NAVC-L07 does not turn off immediately it means the device is completing
the file save process before turning off (usually only a few seconds).
If the 12v socket is “constant on” (in some European vehicles), then the NAVC-L07 will need
to be turned on/off manually by the power button.
Auto Record when turned on
When the NAVC-L07 is turned on (either by pressing the power button or auto on) the
device will automatically begin recording. To stop recording, press the OK button or
disconnect the power cable.
Installation on the car windscreen
TheNAVC-L07works best when mounted centrally andhigh up onthe windscreen (typically
behind or close to the rear vision mirror). Use the supplied windscreen suction mount to
affix the NAVC-L07 to the windscreen and then adjust the mount until you can see a clear
view of the road ahead on the LCD.

NAVC-L07 USER MANUAL
5
Recording
Turn on the NAVC-L07. Recording should start automatically. If not press the “OK” button.
When recording, the green indicator LED will begin to flash. The recorded file is saved onto
the Micro SDHC Card. Stop recording by either pressing the OK button or turning the car
ignition off (stopping power to the device)
Changing between modes
Press and hold the MENU button for 5 seconds to change between modes. Each mode has a
unique icon at the top right of the screen.
MODE SETTINGS
To enter the SETTINGS for a selected mode, press the MENU button again momentarily.
Two titles will appear. The first will be named after the MODE which you have currently
selected (on the left) and the second SETUP (on the right)
Use the UP and DOWN arrows to navigate each option, the OK button to enter and confirm
and the MENU button to toggle across to the SETUP menu.
Press the MENU button a last time to exit the SETTINGS options and to return to the main
screen.
In the event of an incident / accident– STOP the Recording.
- Due to the “cycle recording” nature of this technology, older recorded files will be overwritten (depending on
the chosen resolution settings and the memory capacity of the Micro SD card). For example a 2GB SD card at
HD resolution will only offer you 20 minutes of record time before the files (2 or 5 or 15min sizes) start to get
overwritten
- Should you wish to KEEP the video footage of an incident from not being overwritten, stop the recording soon
after an incident has occurred (Either press“OK” or disconnect the power orremove theMicro SD card).
- Alternately use a larger capacity SD card or lower the recording resolution (eg; a 32GB SD card at VGA
resolution will offer you 640 minutes of record time) or otherwise use a second Micro SD card as a backup.

NAVC-L07 USER MANUAL
6
Digital Video
Available Options:
Video Output Options Action
Size Select [FHD, HD, VGA] Select theresolution andsize of recorded files
Time Stamp Select [On / Off] Records the current date and time onto the video file (date/time is set in the setup
options)
Video time Select [1,3 or 5mins] Select the time you wish to record the videos in If using a large capacity card (32GB) 10
minutes is recommended
Motion Detect Select [On / Off]
When set to “On”, the NAVC-L07 will begin
recording when it senses movement. For
example; if the NAVC-L07 is left on, the
camera will begin recording if the image is
disrupted (like aperson walking by)
Audio Record Select [On / Off] Turns the built in microphone on or off. For privacy this can be turned off sothat no audio
is recorded.
Digital Still Camera
Available Options:
Capture Options Action
Size [Select] 3, 2, 1.3MP
or VGA
3M highest image quality, least amount of
photos.
2M high image quality, least amount of photos.
1.3M average image quality, more amount of
photos.
VGA low image quality, most amount of photos.
Time Stamp [Select]On, Off Display the date and time on recorded files

NAVC-L07 USER MANUAL
7
Playback
Available Options:
Play Options Action
Delete [Select] Single, All Choose to delete the current
image or all images.
Protect [Select]Lock One, All or Unlock
One or All Protect videos or picture so they cannot be deleted.
Thumbnail [Select] Execute, Cancel Select image thumbnail view.
Volume [Select] 0 thru to 7 Select between volumes 0 to 8.
Setup (Hardware)
Available Options:
Note: The Setup options are accessible through any mode.
Setup Options Action
Format Select [Cancel /
Execute]
Select “Execute” to format the Micro SD card.
Warning: formatting the card will erase all of the
content on the card.
Sound
Effect Select [On / Off] Turn function and button noises ON or OFFwhen pressed.
Language Select [English] Choose a language for the onscreen menu display.
Auto Off Select [1, 3, 5 mins
or OFF] Used to adjust the time to automatically power off
FW Version [Display] Firmware
Version Display the Firmware Version
System
Reset Select [Execute, Cancel] Select OK to returnthe device settings back to the original factory settings.
Light
Frequency Select [50 or 60Hz]
For older television sets or monitors which cannot
auto select the refresh rate frequency, select 50Hz
(generally not applicable for newer TVs in
Australia/New Zealand).
TV Output Select [NTSC or PAL] For older television sets without refresh rate
selection. PAL is typically selected for Australia.
Date Input (Scroll through
values and adjust)
Use this option to set the date and time on the
device. Should the device not be used for a long
period of time and should the battery run
completely flat, then the date/time will need to be
re-set.
USB Select [PC Cam or
Disk Drive mode]
Change the function of your crash camera to
become a PC Camera (Webcam) or an external
storage device.
Backlight Select [15, 30 or 60
sec OFF or OPEN] Select a time for the LCD to automatically turn off. Typically used for night time driving.

NAVC-L07 USER MANUAL
8
USB Connection
Connect the NAVC-L07 to a Windows PC with the USB cable (included). The LCD screen will
display a NOTEBOOK icon. Under “My computer” or “Windows Explorer” you should see a
drive which will resemble a “Removable Disk (?:)” (like a USB Flash drive orHard drive).
Recorded videos and photos are stored in theDCIM\100DSCIM folder, and the files are
named as PICT****. AVI for video, or PICT***.JPG for still images. These files can be played
back using Windows Media player or a compatible .avi media player or an image viewer (for
images)
Note:
1) A Micro SDHC card must be inserted into the device before recording.
2) The NAVC-L07 supports cycle recording. It will overwrite the oldest video files with new
ones. Depending on the size of the Micro SDHC card and the speed rating of the card, there
may be as much as a 3 second pause time whilst old files are overwritten with the newer
files. This pause time will not be recorded.
3) As theNAVC-L07 has a DC5Vinput, please use the original car charger which will step
down the car’s 12VDC to 5VDC and fuse the circuit in the event of an overload.
Typical Video/Photos Storage Capacity
Resolution 2GB 4GB 8GB 16GB 32GB
Video
1296 x 1080p (FHD) 10min 20min 40min 80min 160min
1280*720 (720P) 20min 40min 80min 160min 320min
640*480 (VGA) 40min 80min 160min 320min 640min
1M (1280*1024) 11650
photos 23300 photos 46600 photos 93200 photos 186400 photos
2M (1600*1200) 8400
photos 16800 photos 33600 photos 67200 photos 134400 photos
3M (2048*1536) 6000
photos 12000 photos 24000 photos 48000 photos 96000 photos
5M (2560*1920) 3500
photos 7000 photos 14000 photos 28000 photos 56000 photos

NAVC-L07 USER MANUAL
9
Connecting the NAVC-L07 in the Car
The above wiring diagram shows a left hand drive vehicle. Wiring path is only a
suggestion.
1. NAVC-L07 device mounted behind the rear vision mirror.
2. 12vDC cable routed behind rearvision mirror
3. Cable hidden behind roof headlining
4. Cable hidden behind “A” pillar– beware of airbag equipped cars
5. Cable is routed beside the dashboard / near the door hinges
6. Cable is passed under the passenger carpet (or under the dashboard)
7. 12v DC plug is connected to the car’s 12v “cigarette socket”.
Once the wiring and installation of the NAVC-L07 have been completed, please check the following:
- With the car’s ignition on (or engine started), the red LED indicator on the NAVC-L07 will light up and the LCD
screen should turn on. Recording should start automatically. This will indicate a successful installation –
- When the car’s ignition is turned off, the device should turn off within 20 seconds. If this doesn’t happen then
power is still being supplied to the car’s 12v socket and thedevice will need to be switched off manually.

NAVC-L07 USER MANUAL
10
TROUBLE SHOOTING / Q & A
Fault
Suggestion
Device does not
turn off
If in vehicle: check that the
12V socket is not still powered (on) when the key
is removed (as with some European cars).
Wait 20 seconds for file finalisation / closure.
Disconnect power lead to device
Press “ok” to stop recording, then press power to turn off.
Cant playback the
.avi video files
Upgrade
your
windows media player
version
or use an alternate media
player such as VLC media player
My video/pictures
of an incident are
NOT there
Check the capacity of your SD card, the files may have been overwritten in
the record cycle process. Ensure you STOP THE RECORDING if you want to
keep a video/picture of an event otherwise, it will be over written.
The device has
frozen / stopped
working.
Check the speed of your Micro SD card. We recommend class 4 for faster
transfer rates,especially if the record file size is bigger (say 10min recording
increments at 1080p).
Press the “reset” button with a paper clip to reset the settings back to
default
The date/time is
incorrect
Reset the date / time in the settings menu. If the batter
y runs completely
flat, then the date/time will need to be reset
The suction cup
keeps coming off
Ensure the windscreen and surface area of the suction cup are clean.
In wet or very hot weather, the suction cup mount may need to be
reapplied.
Can
’
t see
the
device in my
computer
Check the USB cable connection to the device and USB port. Try another
USB port, possibly directly to the PC/notebook (rather than through a USB
hub)
PRODUCT SPECIFICATIONS
True 1080 FHD video recording in AVI format, no special software needed for playback
Video output: 1080p (not software interpolated)
Video resolution: 1920*1080P
Standard.avi video formats and.jpg image formats for maximum playback
compatibility.
Photo output: Maximum resolution is 8 megapixels
High density CMOS sensor for high quality image capture and processing
High-speed dynamic video recording, instant response to light environment
1.5 inch colour TFT LCD display screen
On board rechargeable Lithium battery
120° HD wide angle lens to capture more detail.
Loop cycle record in selectable 1, 3 or 5 minute increments
Time and date stamp on video or still image whilst recording
USB direct connection to PC (no need for a card reader)
When inused in a car,automatic on/ off whencar is on / off
This device can be charged and record at the same time.
Supports Micro SDHC upto 32GB. Class 4cards are recommended
Built-in microphone
For further product information on this and other products please visit our product web
page at www.navig8r.com.au or email [e-mail]
