Lastec 721XRT User manual

Lastec Articulator
Model 721XRT
Owner’s Manual
Manual Part #: Man-721XRT

© Lastec
Printed in the United States of America, all rights reserved. No part of this manual may be
reproduced in any form by any photographic, electronic, mechanical or other means or
used in any information storage and retrieval system without written permission from
Lastec, LLC
8180 W. 10th Street
Indianapolis, IN 46214
Phone [phone], Fax [phone]
www.lastec.com

Table of Contents Section-Page
Table of Contents Lastec//021819 iii
SECTION 1 TO THE OWNER 1-1
1.1 Read This Manual BEFORE Operating The Articulator .......................................... 1-2
1.2 Product Registration .................................................................................................. 1-3
1.3 If You Need To Order Parts ...................................................................................... 1-3
1.4 Lastec Product Warranty ........................................................................................... 1-4
1.5 Component Manufacturers’ Warranties .................................................................... 1-6
1.6 Servicing The Articulator .......................................................................................... 1-6
1.7 Warranty Registration ............................................................................................... 1-7
SECTION 2 SAFETY INFORMATION 2-1
2.1 Warning Symbols ...................................................................................................... 2-2
2.2 Safety Decals and Symbols ....................................................................................... 2-2
2.3 About This Manual.................................................................................................... 2-4
2.4 Safety Guards And Covers ........................................................................................ 2-5
2.5 Preoperational Safety Rules ...................................................................................... 2-6
2.6 Operational Safety Rules........................................................................................... 2-7
2.7 Maintenance Safety Rules ....................................................................................... 2-10
2.8 Storage Safety Rules................................................................................................ 2-11
2.9 Hazard Identified Chart ........................................................................................... 2-12
SECTION 3 INITIAL SET-UP 3-1
3.1 Assembly Instructions ............................................................................................... 3-2
3.2 Mounting The Articulator To The Tractor ................................................................ 3-4
3.3 Hose Spring Installation ............................................................................................ 3-7
3.4 PTO Shaft Range Verification................................................................................... 3-7
3.5 Gearbox ..................................................................................................................... 3-8
3.6 Mower Deck Leveling Adjustment ........................................................................... 3-9
3.7 Mower Deck Height Adjustment............................................................................. 3-11
3.8 Deck Drive Belts ..................................................................................................... 3-12
3.9 Deck Belts and Alignment....................................................................................... 3-13
3.10 Blades ......................................................................................................................3-15
3.11 Gauge Wheels.......................................................................................................... 3-16
3.12 General .................................................................................................................... 3-16
3.13 Pre-Operation Equipment Inspection Checklist ...................................................... 3-17

Table of Contents Section-Page
Table of Contents Lastec//021819 iv
SECTION 4 OPERATING PROCEDURES 4-1
4.1 Transporting The Articulator..................................................................................... 4-2
4.2 Hydraulic Lift Operation ........................................................................................... 4-2
4.3 Preparation For Cutting ............................................................................................. 4-4
4.4 Recommended Blades ............................................................................................... 4-6
4.5 Ground Speed ............................................................................................................ 4-7
4.6 Cutting In Reverse..................................................................................................... 4-7
4.7 Cutting Extreme Contours......................................................................................... 4-8
4.8 Cutting Wet Grass ..................................................................................................... 4-8
SECTION 5 MAINTENANCE 5-1
5.1 Mower Deck Leveling Adjustment ........................................................................... 5-2
5.2 Every 8 Operating Hours........................................................................................... 5-3
5.3 First 8 Hours .............................................................................................................. 5-4
5.4 First 50 Hours............................................................................................................ 5-4
5.5 Every 50 Operating Hours......................................................................................... 5-4
5.6 Every 200 Operating Hours....................................................................................... 5-4
5.7 Every 500 Operating Hours....................................................................................... 5-4
5.8 Annual .......................................................................................................................5-5
5.9 Articulator Specifications, 521XR/721XR/721XRT................................................. 5-6
5.10 Articulator Maintenance Chart, 721XR/721XRT ..................................................... 5-7
5.11 Torque Values ........................................................................................................... 5-8

Lastec//021819 1-1
1
SECTION 1 TO THE OWNER

To The Owner
Read This Manual BEFORE Operating The Articulator
1
1-2 Lastec//021819 To The Owner
1.1 Read This Manual BEFORE Operating The Articulator
Do not allow anyone to operate the Articulator without first read-
ing and understanding this operator’s manual in its entirety.
Never allow children to operate the Articulator. Never operate
the Articulator when children are present.
The information presented herein will prepare you to operate the
Articulator in a safe and knowledgeable manner. Proper opera-
tion of the Articulator will provide a safer working environment,
and promote higher quality, more efficient results.
Keep this manual at hand at all times for ready reference. The designed and tested safety
of the Articulator is dependent upon its operation within the guidelines and limitations out-
lined in this manual. Always adhere to all the safety rules presented in this manual.

To The Owner
Product Registration
To The Owner Lastec//021819 1-3
1
1.2 Product Registration
Immediately record the model and serial numbers of your Articulator in the spaces pro-
vided below.
Model Number: ______________________________
Serial Number: ______________________________
These numbers can be found on the serial number plate which is permanently affixed to
the mower.
You should now fill out the warranty registration form online at www.lastec.com or
located in the back of this section. This form must be completed and returned to the fac-
tory within fifteen (15) days of purchase in order to validate the warranty. Please do not
hesitate!
1.3 If You Need To Order Parts
To order parts, contact your distributor. Be sure to have your model and serial number
available as a reference. This will assist them in supplying you the correct and most cur-
rent parts available for your Articulator.
CAUTION!
Always use only genuine Lastec parts when servicing your Articulator! Use of sub-
stitute parts may cause unsafe operation, unsatisfactory performance, and void the
warranty of your Articulator!
Caution

To The Owner
Lastec Product Warranty
1
1-4 Lastec//021819 To The Owner
1.4 Lastec Product Warranty
LASTEC LIMITED GOLF & TURF WARRANTY
Lastec (“warrantor”), with its place of business at 8180 W. 10th Street, Indianapolis, IN 46214 war-
rants as stated herein to the original purchaser (“purchaser”) for two (2) years or 2000 hours* of
equipment use, whichever comes first, on parts and one (1) year of labor for equipment use from
the date of purchase from Lastec (“warrantor”), that the equipment manufactured by warrantor and
any optional equipment or accessories purchased at the same time, subject to the exclusions
herein, will be free from defects in material and workmanship attributable to warrantor so long as it
is operated and maintained in accordance with the instructions provided by warrantor and pur-
chaser has completed the registration form or warrantor may choose to not honor any warranty
claims. All urethane bushing hardware will be warranted for five (5) years from the date of pur-
chase from Lastec.
* Applies to units with hour meters
90 Day Limited Warranty
Warrantor agrees to replace any defective wear components including but not limited to seals,
bearings, idlers with bearings, wheels/tires, bushings and blades for ninety (90) days from date of
purchase. After ninety (90) days, all wear components are no longer covered under further war-
ranty from warrantor. Component failure as a result of improper maintenance of wear items may
not be covered under warranty at the warrantor’s discretion. After ninety (90) days, component fail-
ure as a result of loose hardware is no longer covered under further warranty from warrantor.
Warrantor agrees to warrant for a period of ninety (90) days from date of purchase to any original
purchaser who is a rental yard, lease-based business or temporary use facility that the equipment
manufactured by warrantor and any optional equipment or accessories purchased at the same
time will be free from defects in material and workmanship attributable to warrantor so long as it is
operated and maintained in accordance with instructions provided by warrantor. After ninety (90)
days, no further warranty will exist for rental yard, lease-based or temporary use businesses or
facilities.
Freight Allowance
Freight allowance for warranty – Next Day Air freight covered by warrantor in “mower down” situa-
tions for first year of warranty not to include wear items as listed above in the (90) day limited war-
ranty. After the first year freight for warranty items would be limited to regular ground shipment at
the discretion of the warrantor.
Warrantor’s Obligations as to Defects
Warrantor’s only responsibility shall be to replace any covered defects or repairs without cost to
purchaser. Warrantor may request that such part or unit be returned to Warrantor’s place of busi-
ness. Purchaser will be responsible for transportation or shipping of part or unit to the distributor
and such part must be returned to distributor within fifteen (15) days after requested. Warrantor
shall have a reasonable time within which to replace or repair defective part or unit. If warrantor

To The Owner
Lastec Product Warranty
To The Owner Lastec//021819 1-5
1
determines that the part or unit is not defective under the terms of this warranty, then purchaser
shall be responsible for expenses incurred by warrantor in returning part or unit to original pur-
chaser. Warrantor gives no allowance for labor, travel time, mileage or incidental or consequential
damages. Purchaser must submit warranty claims to a distributorship authorized by Warrantor.
Warrantor’s authorized distributors are responsible for all repairs and the processing of all war-
ranty claims.
Warranty Parts Return
Lastec reserves the right to have parts returned that have been submitted for warranty. The ser-
vice department will issue an RMA number. The part must be returned within 30 days of the
requested return date. Parts not returned within 30 days of the RMA issue date will result in rejec-
tion of claim.
Limitations and Disclaimers of Other Warranties
EXCEPT FOR THE EXPRESS WARRANTY PROVISIONS STATED ABOVE, WARRANTOR DIS-
CLAIMS ALL WARRANTIES, EXPRESS AND/OR IMPLIED, INCLUDING WITHOUT LIMITATION,
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE.
No representation or other affirmation of fact by representatives of warrantor, whether verbal or in
writing, including photographs, brochures, samples, models, or other sales aids, shall constitute a
warranty or other basis for any legal action against warrantor. THE ORIGINAL PURCHASER, ANY
PERSONS TO WHOM THIS EQUIPMENT IS TRANFERRED AND ANY INTENDED USER OR
BENEFICIARY OF THIS EQUIPMENT SHALL NOT BE ENTITLED TO RECOVER ANY CONSE-
QUENTIAL OR INCIDENTAL DAMAGES FROM WARRANTOR FOR ANY REASON WHATSO-
EVER, INCLUDING WARRANTY OR DEFECT IN THE PRODUCT. Warrantor does not warrant
that its equipment meets or complies with the requirements of a particular safety code or govern-
mental requirements.
Design Changes
Warrantor reserves the right to change the design of its products from time to time without notice
and without obligation to make corresponding changes in its products previously manufactured.
Rights of Purchasers
The validity and effect of this limited warranty as well as its interpretation, operation and effect,
shall be determined exclusively by the principles of law and equity of the State of Indiana. This lim-
ited warranty gives purchaser specific legal rights. Purchaser may also have other rights, which
may vary from State to State. Some States may not allow limitations as to duration of warranties so
the above may not apply.
This contract supersedes all prior written and oral agreements related to the purchase and is
intended to be an integration of the entire agreement between the parties. All of the promises, war-
ranties, guarantees and representations made by warrantor or its representatives that are not spe-
cifically contained herein are not included in this warranty.

To The Owner
Component Manufacturers’ Warranties
1
1-6 Lastec//021819 To The Owner
1.5 Component Manufacturers’ Warranties
Some of the component parts of your Articulator are warranted by their respective manu-
facturers. These parts include:
Superior Gearbox
Bondioli PTO Shaft
The complete manufacturers’ warranty information for these components is available
upon request. Contact your Lastec dealer if you have questions concerning warranties on
these component parts.
1.6 Servicing The Articulator
CAUTION!
Always use only genuine Lastec parts when servicing the Articulator! Use of substi-
tute parts may cause unsafe operation, unsatisfactory performance, and void the
warranty of the Articulator!
The Articulator is carefully engineered and manufactured to provide safe, dependable,
and satisfactory service. As with all other mechanical equipment, the Articulator requires
routine inspection, cleaning and maintenance.
When servicing the Articulator, be sure to use only genuine Lastec parts. Utilization of
substitute parts will not only void the warranty, but may also cause unsafe or unsatisfac-
tory operation of the Articulator due to their substandard quality or incorrect application.
In order to handle all of your service needs, your authorized Lastec dealer stocks genuine
Lastec parts, and has trained mechanics on hand.
Be sure to complete the following Lastec Warranty Registration Form and return to Lastec
within 15 days of the purchase of the Articulator. This will aid you, Lastec, and Lastec dis-
tributor in warranting and servicing of your Articulator.
Warranty registration can also be done online through the Lastec website at www.las-
tec.com.
Caution

To The Owner
Warranty Registration
To The Owner Lastec//021819 1-7
1
1.7 Warranty Registration
Company Name
Company Contact
Mailing Address
Shipping Address
Phone
Fax
A
uthorized Company
Representative Signature:
Detatch Here Detatch Here Detach Here
Serial Number:
Please check the box that most accurately describes your business:
Please check the box to your left if you would not allow Lastec to use your company's name for marketing purposes.
Lastec Warranty Registration Form
IMPORTANT! To validate the warranty, this registration form must be completed in full and returned to Lastec within
fifteen
(
15
)
da
y
s of
p
urchase
!
Mower Model:
How did you hear about Lastec?
Who referred you to Lastec?
Date Purchased:
Distributor/Dealer Purchased From:
How Did You Hear About Us? Your Lastec Mower
Average Operating Hours:
Total Acreage Cut:
Customer Profile Information
I have read and understand the warranty policy
and maintenance sections of the operators
manual for the machine described below.
Who was the salesman that assisted you?
Please help us to better serve you by completing the following survey
information:
Please list the features and/or benefits which
helped you to choose your Lastec Mower:
Do you own a Lastec Mower, and if so what model?
Purchase Price:
Golf Course
Municipal
Sod Farm
Government
Sports Complex
Other
Weekly
Weekly Monthly
Monthly Annually
Annually
Schools
College Landscaping Company
Light Agriculture

Safety Information
Safety Information Lastec//021819 2-1
2
SECTION 2 SAFETY INFORMATION

Safety Information
Warning Symbols
2
2-2 Lastec//021819 Safety Information
2.1 Warning Symbols
Following is a legend describing the warning symbols utilized throughout this manual, and
the potential types of hazards which they indicate:
DANGER!
This symbol indicates a potential serious or fatal injury hazard. Failing to properly
adhere to the instructions, rules, or procedures may result in serious injury or death.
WARNING!
This symbol indicates a potential personal injury hazard. Failing to properly adhere
to the instructions, rules, or procedures may result in personal injury.
CAUTION!
This symbol indicates a potential equipment hazard. Failing to properly adhere to
the instructions, rules, or procedures may result in personal equipment malfunction,
damage, or destruction.
The above illustrated symbols are displayed throughout this manual in order to indicate
important safety information. When one of these symbols appears in this manual, be
aware of a potential hazard being discussed in the accompanying paragraphs. Hazards
such as damage to equipment, serious personal injury, or even fatal injury are possible,
perhaps even likely, if the accompanying instructions or procedures are not heeded.
2.2 Safety Decals and Symbols
The following safety symbols are used on the deck. Operators should become familiar
with these symbols and heed the warnings where they appear on the deck.
Attention!
Pinching/Crushing Danger!
Danger
Warning
Caution

Safety Information
Safety Decals and Symbols
Safety Information Lastec//021819 2-3
2
Caution! Rotating Blades!
Keep Hands and Feet Away from Blades!
Keep Covers Locked Down
Pinch Point!
Read the Manual!
Remove the Key!
Rotating Parts!
Rotating Shaft!
Stay Away!
Thrown Objects!

Safety Information
About This Manual
2
2-4 Lastec//021819 Safety Information
2.3 About This Manual
DANGER!
Safety instructions are important! Read all safety rules in this manual as well as all
safety rules in any related equipment manuals!
The purpose of this manual is to assist you in properly and
safely operating and maintaining the deck. Read and under-
stand this entire manual before attempting to set-up, operate,
adjust, perform any maintenance on, or store the deck. This
manual provides essential information and instructions which
will help you enjoy years of dependable performance from the
deck.
The designed and tested safety of the deck is dependent upon its operation within the
parameters and limitations explained in this manual. Be familiar with and follow all safety
rules in this manual as well as all safety rules for any related equipment.
Although these instructions have been compiled through extensive field experience and
engineering data, some information presented herein may be general in nature due to
unknown and/or varying operating conditions. However, these instructions, combined
with your increasing experience with the deck, will enable you to develop procedures suit-
able to your particular cutting application.
The illustrations and data used in this manual were current at the time of printing, but the
deck may vary slightly due to ongoing engineering changes. Lastec reserves the right to
implement engineering and design changes to the deck as may be necessary without
prior notification.
Throughout this manual, we make references to right and left directions. We determine
right and left while sitting in the operator seat and facing in the direction of forward travel.
Blade rotation is clockwise as viewed from the top of the deck.
Danger

Safety Information
Safety Guards And Covers
Safety Information Lastec//021819 2-5
2
2.4 Safety Guards And Covers
DANGER!
Danger
NEVER operate the deck with any safety covers removed!
Work safely! Follow all safety rules! A careful operator is the best insurance against
accidents!
Some illustrations in this manual show the deck with safety covers removed in order to
provide improved viewing of the particular components being discussed. This is for
informational purposes only -- never operate the deck without all covers, shields,
safety devices, and grass chute or mulching plate installed and secure!
Safety is a primary concern in the design and manufacture of all Lastec products. Unfor-
tunately, our extensive efforts to provide safe equipment can be negated by a single care-
less act of an operator. In addition to the design and configuration of the deck, hazard
control and accident prevention are also dependent upon the awareness, concern, pru-
dence and proper training of all personnel involved in the operation, transportation, main-
tenance, and storage of the deck.
The best safety device is an informed, careful operator!
We ask you to be that kind of operator.

Safety Information
Preoperational Safety Rules
2
2-6 Lastec//021819 Safety Information
2.5 Preoperational Safety Rules
Danger
Warning
DANGER!
NEVER allow children to operate the deck!
NEVER allow children on or near the deck!
NEVER operate the deck when children are present.
ALWAYS clear area of all personnel before operating the deck!
WARNING!
NEVER allow anyone to operate the deck without proper instruction! Any and all
operators must be instructed in and capable of the safe operation of the deck, its
attachments, and controls!
KNOW the controls and how to stop the deck quickly in an emergency!
READ this entire manual before attempting to operate the deck! Only allow persons
who have read and understand the entire operator's manual to operate the deck!
Always wear relatively tight and belted clothing to avoid entanglement in moving
parts. Wear sturdy rough-soled work shoes, as well as protective equipment for the
eyes, hands, hearing and head. Never operate the deck or related equipment in
bare feet, sandals, or sneakers.
Clear the cut area of stones, branches, balls or other debris that may be thrown and
cause injury or damage.
Verify that all safety decals are properly installed, visible, and legible.
Always remove accumulated debris, fuel, or excess grease and oil from the drive
unit engine area to avoid a fire hazard.
Verify that the deck is properly mounted, set up, adjusted, and in good operating
condition.
Always perform the pre-operation equipment inspection and the appropriate mainte-
nance schedule (Section 5) before operating the deck.
Do not change the engine governor settings or over-speed the engine.

Safety Information
Operational Safety Rules
Safety Information Lastec//021819 2-7
2
2.6 Operational Safety Rules
DANGER!
NEVER allow children to operate the deck!
NEVER allow children on or near the deck!
NEVER operate the deck when children are present.
ALWAYS clear area of all personnel before operating the deck!
DANGER!
NEVER operate the deck without all safety covers properly installed and in good
condition!
ALWAYS stay well clear of all moving parts!
ALWAYS stay clear of blades during operation!
WARNING!
ALWAYS work safely! Follow all safety rules! A careful opera-
tor is the best insurance against accidents!
ALWAYS clear area of all personnel before operating the deck!
Only allow persons who have read and understand the entire
operator's manual to operate the deck!
Be sure that the parking brake is set before attempting to start the engine.
Operate only in daylight or good artificial light (min. 200 Lux).
Be sure that all auxiliary equipment switches (blades, lights, etc.) are in the OFF
position before attempting to start the engine.
Be sure your drive unit is equipped with a ROPS (Roll Over Protection System), and
be sure to wear your seat belt.
Danger
Danger
Warning

Safety Information
Operational Safety Rules
2
2-8 Lastec//021819 Safety Information
Never operate the deck without the grass chute or mulching plate installed and
secure.
Never operate the deck unless all covers, shields, and safety devices are installed
and secure.
Never permit any person other than the operator to ride or board the drive unit or
deck at any time. Never allow riders!
Never allow anyone near the drive unit or deck while operating. Be sure that the
area behind you is clear before operating in reverse!
Never allow anyone near or in the path of discharge.
Never discharge in the direction of bystanders, vehicles, or buildings.
Do not stop or start suddenly when going up or down a hill. Avoid operating on
steep slopes.
Do not mow in reverse unless absolutely necessary - and then only after careful and
constant observation of entire area behind the drive unit and deck.
Use extreme care and maintain minimum ground speed when transporting on a hill-
side or over rough ground, and when operating close to ditches, fences, or water.
Reduce speed on slopes and in sharp turns to minimize potential tipping or loss of
control. Use caution when changing directions on slopes.
Be alert for holes in the terrain as well as any other hidden hazard. Always drive
slowly over rough ground.
Disengage the blades, stop the engine, set the parking brake, and remove the key
before dismounting the drive unit or making any adjustments to the deck.
Stop the drive unit immediately upon striking any obstruction. Disengage the
blades, turn off the engine, set the parking brake, remove the key, and inspect the
drive unit and deck for any damage. Always repair any damage before resuming
operation of the deck.
Never adjust the mower deck height or lift the deck into transport position while the
blades are engaged.
Never engage the blades with the mower decks raised into transport position.
Never place your hands or feet under the deck while the engine is running.
