Launch X-PROG 3 User manual

防 盗 编 程 器 PC转 接 盒
Immobilizer Programmer PC Adaptor

I
快速使用指引
防盗编程器PC转接盒
声明：此快速使用指引中的所有图片仅供参考，请以实物为准。本公司保留修改此快速使用指引的权利。
外形结构
1
DB26接口
2
DB15插头
3
DB26接口
4
电源插孔
5
USB Type B
6
POWER指示灯（上电后红灯点亮）
7
STATE指示灯（上电后绿灯闪烁）
8
ERROR指示灯（升级或异常时蓝灯闪烁）
包装清单
主机
USB线
（Type B）
快速使用指引

II
快速使用指引
防盗编程器PC转接盒
操作步骤
1
下载并安装软件
通过如下网址下载软件安装包并将其安装在电脑。
2
注册并登录账号
打开软件输入用户名和密码登录，首次使用
需注册用户账号。
3
连接PC转接盒和电脑
如下图所示，使用USB线（type A转type B）
连接PC转接盒和电脑，并将PC转接盒与防盗
编程器连接。

III
快速使用指引
防盗编程器PC转接盒
4
ECU数据读写
4.1 获取相关ECU
4.1.1 如下图所示，依次点击品牌->型号->发动机->ECU选择相应的ECU类型。
亦可在搜索框输入相关信息（品牌、博世号或ECU）进行查询。如下图所示通过ECU方式搜索MED17.1发动机。

IV
快速使用指引
防盗编程器PC转接盒
4.1.2 点击【直连接线图】获取ECU连接图。
4.1.3 参照接线图，使用BENCH模式线及相应的适配线连接ECU和PC转接盒。

V
快速使用指引
防盗编程器PC转接盒
4.1.4 完成连接后，点击【读取芯片ID】进行数据读取。
4.2 数据读写
4.2.1 点击【读取EEPROM】进行EEPROM数据备份
和保存。
4.2.2 点击【读取FLASH数据】进行FLASH数据备份和
保存。

VI
快速使用指引
防盗编程器PC转接盒
4.2.3 点击【写入EEPROM数据】并选择相应备份文件，
还原EEPROM数据。
4.2.4 点击【写入FLASH数据】并选择相应备份文件，
还原FLASH数据。
5
数据处理
5.1 防盗关闭和文件校验
5.1.1 在主界面点击【数据处理】。
5.1.2 在弹出的窗口选择【防盗关闭和文件校验】。

VII
快速使用指引
防盗编程器PC转接盒
5.1.3 点击【EEPROM防盗关闭】/【FLASH防盗关
闭】，根据软件提示加载相应的EEPROM/FLASH备份
文件。
5.1.4 系统会联网获取相应的数据，然后保存新文件即
可完成防盗关闭。
5.1.5 点击【EEPROM文件校验】/【FLASH文件校
验】，根据软件提示加载相应的EEPROM/FLASH备份
文件。
5.1.6 系统会联网获取相应的数据，然后保存新文件即
可完成文件校验。

VIII
快速使用指引
防盗编程器PC转接盒
5.2 数据克隆
此功能主要用于对大众、奥迪和保时捷的发动机ECU
进行数据克隆，其他车型通过读取和写入数据即可完成
数据克隆。
5.2.1 读取和保存原车ECU以及外来ECU的FLASH&
EEPROM数据。
5.2.2 在主界面点击【数据处理】，并在弹出的窗口选
择【数据克隆】进入如下界面。
5.2.3 选择相应的车型进行数据克隆。依照软件提示分
别加载原车ECU的FLASH和EEPROM数据。
5.2.4 依照软件提示分别加载外来ECU的FLASH和
EEPROM数据。

快速使用指引
防盗编程器PC转接盒
IX
5.2.5 系统解析防盗数据并生成克隆数据文件，点击
【确定】将其保存在电脑上。
5.2.6 连接外来ECU和PC转接盒，将原车FLASH数据
和保存的EEPROM克隆数据写入外来ECU。

1
Quick Guide
Immobilizer Programmer PC Adaptor
Note: Pictures illustrated herein are for reference purpose only. Due to continuing improvements, actual products may differ slightly from the product described herein
and this material is subject to change without notice.
Structure
1
DB26 Interface
2
DB15 Plug
3
DB26 Interface
4
Power Supply Jack
5
USB Type B
6
Power Indicator (Red light turns on after power on)
7
State Indicator (Green light flashes after power on)
8
ERROR Indicator (Blue light flashes when
upgrading or abnormal)
Packing List
Main Unit
USB Cable
(Type B)
Quick Guide

2
Quick Guide
Immobilizer Programmer PC Adaptor
Operation Procedure
1
Download and install the software
Download the software installation package through the following website and install it on the computer.
2
Register and log in to your account
Open the software, input username and password to
log in. Please register an account for new user.
3
Connect PC adapter and computer
As shown in the figure below, use a USB cable
(type A to type B) to connect the PC adapter and the
computer, and connect the PC adapter to the Immobilizer
Programmer.

3
Quick Guide
Immobilizer Programmer PC Adaptor
4
ECU Data Read and Write
4.1 Get Related ECU Information
4.1.1 As shown in the figure below, click Brand->Model->Engine->ECU to select the corresponding ECU type.
You can also enter relevant information (Brand, Bosch ID or ECU) in the search box to inquire. For example, search for MED17.1 engine
through ECU as shown in the figure below.

4
Quick Guide
Immobilizer Programmer PC Adaptor
4.1.2 Click Direct Connection of Diagram to get the ECU wiring diagram.
4.1.3 Referring to the wiring diagram, use the BENCH mode cable and the corresponding adapter cable to connect the ECU and
Immobilizer Programmer PC adapter.

5
Quick Guide
Immobilizer Programmer PC Adaptor
4.1.4 After completing the connection, click Read Chip ID to read the data.
4.2 Data Read and Write
4.2.1 Click Read EEPROM Data to backup the EEPROM data
and save it.
4.2.2 Click Read Flash Data to backup the FLASH data and save
it.

6
Quick Guide
Immobilizer Programmer PC Adaptor
4.2.3 Click Write EEPROM Data and select the corresponding
backup file to restore the EEPROM data.
4.2.4 Click Write Flash Data and select the corresponding
backup file to restore the FLASH data.
5
Data Processing
5.1 Immobilizer Shutoff and File Checkout
5.1.1 Click Data Processing on the main interface.
5.1.2 Select Immobilizer shutoff and file checkout on the pop-
up window.

7
Quick Guide
Immobilizer Programmer PC Adaptor
5.1.3 Click EEPROM immobilizer/FLASH immobilizer, load the
corresponding EEPROM/FLASH backup file as software prompts.
5.1.4 The system will obtain the corresponding data online, and
then save the new file to complete the immobilizer shutoff.
5.1.5 Click EEPROM checkout/FLASH checkout, load the
corresponding EEPROM/FLASH backup file as software prompts.
5.1.6 The system will obtain the corresponding data online, and
then save the new file to complete the file checkout.

8
Quick Guide
Immobilizer Programmer PC Adaptor
5.2 Data Cloning
Note: Before performing data cloning, it is necessary to backup and save the FLASH&EEPROM
data of the original ECU and the external ECU. For specific operation steps, please refer to the
previous chapter.
This function is mainly used for engine ECU data cloning of VW, Audi
and Porsche, other models can complete data cloning by directly
reading and writing data.
5.2.1 Read and save the FLASH&EEPROM data of the original vehicle
ECU and the external ECU.
5.2.2 Click Data Processing on the main interface, and select Data
Cloning in the pop-up window to enter the following interface
5.2.3 Select the corresponding car model for data cloning.
Follow the software prompts to load the FLASH & EEPROM
data of the original vehicle ECU respectively.
5.2.4 Follow the software prompts to load the FLASH &
EEPROM data of external ECU respectively.

9
Quick Guide
Immobilizer Programmer PC Adaptor
5.2.5 The system analyzes the anti-theft data and generates a clone
data file, click Confirm to save it.
5.2.6 Connect external ECU and PC adapter, write FLASH
data of original ECU and saved EEPROM clone data into
external ECU.
