LAZBOY Lucie D71 M34958 User manual

OWNER’S MANUAL
Sears Lucie Umbrella Base
Product Code: D71 M34958
UPC Code: 7 22938 10462 8
Date of Purchase: / /
If you have any problems with this product, DO NOT RETURN IT TO THE STORE.
CALL OUR CUSTOMER SERVICE HOT-LINE AT
1 866-391-4868
8AM-5PM (EST), Monday – Thursday,
8AM-4PM (EST), Friday.
View the expanded assortment of outdoor living product on-line at
WWW.sears.com
Page 1 of 3
La-Z-Boy® is a registered trademark of La-Z-Boy Incorporated and is used under license to BJI, Inc.
© 2014 La-Z-Boy Incorporated.

WARRANTY
Care and Maintenance
Be careful to never allow water to build up in frames as this will cause corrosion and freeze damage in cold climates. Wash all frames
with a solution of mild soap and water. Rinse with cleam water and dry with a soft absorbent cloth towel. Frames an be treated with a
liquid wax for maximum protection against UV rays and/or salty damp air. If your set includes cushions, slings, and/or an umbrella
they may be cleaned by hand with a solution of soap and water with a clean water rinse. (Never machine wash cushions, slings or
umbrella covers as this will result in shrinkage or damage).
After cleaning cushions tip on end and alow to drip dry. (Never use a commercial or home dryer to tumble dry fabric goods).
Do not use bleach or solvents to clean any product! This will void the warranty.
CAUTION: Read all the instructions before beginning assembly.
Failure to do so may result in faulty assembly and potential injury!
Assemble the item on a soft, non-abrasive surface such as a carpet or cardboard to avoid damaging the item.
Seek assistance to assemble bulky or heavy items.
After final alignment, make sure all bolts, nuts and nut covers are securely tightened.
Assembly Instruction:
Note: 1. DO NOT tighten bolts completely until all bolts are in place.
2. Paint Not provided with all furniture.
Page 2 of 3
In order to activate your warranty please register at There you can review our full warranty details and
other helpful information. Or, you may call us at
1 866-391-4868, 8am - 5pm (EST), Monday – Thursday, 8am – 4pm(EST), Friday.
THIS IS A RESIDENTIAL WARRANTY AND DOES NOT APPLY FOR COMMERICIAL USE.
www.bjifurniture.com.
A
B
C
D
E
1 x Base
1 x Support Pole with
Secured Knob Pre-assembled.
1 x M12 Nut
1 x M12 Spring Washer
1 x Open Wrench
B
A
C
D
1

Secure the umbrella to the base by tightening the secure knob.
Warning: This is not a free standing umbrella base! In-correct use! (See Figure
Base must be used in combination with a matching table! Correct use! (See Figure 2 )
Figure 1
Figure 2
Page 3 of 3
Secure Knob
2
Notice:
1 )
In-correct use Correct use
((
) )
