LAZERLOGIC LL2424 Programme Manual
2
Enter/Exit Programming Mode
(☆represents the default value)
3
Contents
Contents.......................................................... 3
Introduction.................................................... 4
Setup steps...................................................... 4
System setting ................................................ 5
Sleep time selection........................................ 8
Same code delay time................................... 12
Beeper sound selection................................. 14
Tone...................................................... 15
Duration................................................ 17
Volume.................................................. 19
Barcode identifier code setting.....................20
Message Terminator ..................................... 28
RS-232C interface configuration.................. 32
Baud rate .............................................. 32
Capital lock .................................................. 36
Function key emulation................................ 37
Data edit....................................................... 38
Truncate header/trailer character.......... 41
Add Code Length ................................. 43
Reading code selection................................. 44
4
Introduction
This is an advanced programming guide for
omnidirectional laser barcode scanner. If you
want to read the detailed user’s manual, please
visit the official website to download or
contact your dealer for detail.
Setup steps
In order to change the scanner setting, please
follow the steps below:
1. Scan the “Enter/Exit Programming Mode”
label.
2. Scan the label that you need to set.
3. Scan the “Enter/Exit Programming Mode”
label again to save the configuration.
5
System setting
☆Reset (Return to factory default)
Reading of the “Reset” barcode label turns all
parameters back to default values, and the
scanner remains in the last interface set when
it is reset.
Abort (Exit Programming Mode)
6
After the replacement of different types of data
lines, please do the following interface settings
according to your optional data line.
☆Return to PC/AT Default
Return to RS-232 Default
7
Return to USB Default
Return as Customer Default
8
Save as Customer Default
Sleep time selection
In this section, user can set both laser and
motor to either into sleep mode. The timeout
programming labels will allow users to set the
different time frame before entering into laser
or motor sleep mode. The feature reduces
power consumption and prolongs scanner life
time. Laser always enters sleep mode before
motor. If the motor timeout is set shorter than
the laser time, then laser would enter sleep
9
mode as motor enters sleep mode.
Motor Sleep Mode Off
Motor Sleep Time 10 Minutes
10
☆Motor Sleep Time 30 Minutes
Laser Sleep Mode Off
11
☆Laser Sleep Time 10 Minutes
Laser Sleep Time 30 Minutes
12
Same code delay time
In order to avoid an unwanted reading the
same barcode, the time interval of the same
barcode should not set too short.
50ms
200ms
13
☆300ms
500ms
14
Infinite
Beeper sound selection
☆Power up Tone Enable
15
Power up Tone Disable
Tone Low
16
☆Medium
High
17
Silent
Duration 50ms
18
☆100ms
200ms
19
Volume Low
Medium
20
☆High
Barcode identifier code setting
Code 39
