Lazy Camping Lazy Tent User manual

Anleitung/Manual
Lazy Camping –Lazy Tent
Thank you for choosing a Lazy Tent from Lazy Camping.
Before you begin, take a moment to familiarize yourself with these instructions and the parts included.
On page 2 you will find a list of all parts, quantities and tools needed.
Please read first
Important notes
It is essential that all Lazy Camping products are properly and securely mounted and attached to your
vehicle. Improper attachment can result in an accident and cause serious bodily injury or death. You are
responsible for mounting and securing all Lazy Camping products to your vehicle. Attachments must be
inspected before use and products must be checked regularly for adjustment, wear and damage. Therefore,
you must read and understand all instructions and cautions before mounting or using Lazy Camping
products. If you do not understand all the instructions and cautions, or if you have no manual experience
and you are not thoroughly familiar with the assembly procedures, you should have the product installed
by a professional assembler or other qualified persons.
120
Minutes
2
Persons
Ausführliches YouTube Video
zum
Lazy Tent –Aufbau

Materialliste
Bag 1
•4x end caps for mounting rail (+2x spare)
•18x M8 screws for mounting rail
•18x washer M8
•18x spring washer M8 for mounting rail
•18x slot nuts M8 for mounting rail (already in
the rail)
Bag 2
•16x sleeve screw M4 (+2 spare)
•16x sleeve nut M4 (+2 spare)
•16x spring washer M4 (+2 spare)
•16x washer M4 (+2 spare)
Bag 3
•18x screws 30 mm M5 (+2)
•2ox washers M5 (is not needed)*
•18x spring washers M5 (+2 spare)
•18x lifting nuts M5 (+2 spare)
01
Tips from the pro: Well sorted is half
assembled!

Bag 4
•6x fully threaded screws 35 mm M5 (+2 spare)
•6x lifting nuts M5 (+2 spare)
•6x washer M5 (+2 spare)
•6x spring washer M5 (+2 spare)
•4x fabric straps (spare)
Bag 5
•2x fully threaded screws 50 mm M8
•4x half threaded screws 45 mm M8
•6x lock nut M8
•2x connecting bracket for canopy bar
Bag 6
•2x half threaded screws M8 60 mm (+2 spare)
•2x lock nut M8 (+2 spare)
•2x spacers (+1 spare)
•4x spacers (+2 spare)
Bag 7
•13 mm combination wrench
•8 mm combination wrench
•1x M8 Allen
•1x M5 Allen
•2x M4 Allen
Bag 8
Mounting set consisting of:
•4x mounting bracket
•8x screws M8 45 mm
•8x spring washer M8
•8x washer M8
•8x star grip screw
2102
Tips from a pro:
*really not needed

Material
•4x frame connector caps
•2x Mounting bracket
•2x outer frame short
•2x outer frame long
•7x inner laths
•2x outer laths
•2x long brackets
•1x canopy bracket
•4x short bars
•2x short bars with hole
•2x Gas springs
•1x telescopic ladder
•1x ladder bag
3
Detailed YouTube video
Lazy Tent -Assembly 03

Material
•2x Mounting rail
•1x Outer tent
•1x PVC cover
•2x PVC cover belt
•2x Shoe bags
•1x Inner tent
•4x Hard foam panel
•1x Opening rope
Detailed YouTube video
Lazy Tent -Assembly 04

Step 1
Screw the outer frame together
Place the two long outer frames opposite each
other so that you can connect them to the short
frames. The outer frame with the silver
retaining screw is the rear frame..
You need:
•2x Outer frame
•2x Inner frame
•4x frame connection caps
•16x sleeve screw M4
•16x washer M4
•16x spring washer M4
•16x sleeve nut M4
CONSTRUCTION
Tools
•2x Allen key small M4
Repeat the step until you have inserted all screws. Then take the two M4 Allen keys and tighten
the screws. (One Allen key locks from the inside and the other one tightens).
The connecting caps are inserted into the
respective frames to connect all four parts.
Each side is secured with 2 screws each (16 pieces in total)
Insert the sleeve bolt including washer and spring washer* from the inside through the frame and
connect it from the outside with the sleeve nut and tighten it only by hand for the time being.
Tips from a pro:
*Sequence = sleeve screw -washer - spring
lockwasher 05

Step 2
Install the slatted frame
You need:
•2x outer laths, each with 2 additional holes in
the front area
•7x inner slats
For the connection outer slats:
•2x outer laths
•4x screw 35 mm M4
•4x washer M4
•4x spring washer M4
•4x lifting nut M4
•4x connecting lug
For the connection inner slats:
•7x inner laths
•14x screw 30 mm M4
•14x spring washer M4
•14x nut M4
•8 mm wrench M4
Tools
•8 mm open-end wrench
•5s Allen wrench
Slide the two outer laths with the pre-punched holes into the outer frame.
Make sure that the two holes point to the front.
Now slide the remaining laths into the frames,
always leaving three holes free.
Leave 3 holes free Leave 3 holes free
Tips from the pros:
Don't give up!
06

Connect the outer frames to the outer laths in the very first hole. Before inserting the lifting nut
and spring washer at the bottom, place a connecting tab between each.
1. Insert fully threaded screw 35 mm from the inside to the outside.
2. Place connecting tab over it
3. Washer
4. Spring washer
5. Lift nut
Connect the inner laths to the outer frames and tighten
the lifting nuts
1. Pass through fully threaded screw 30 mm from the
inside to the outside
2. Spring washer
3. Lift nut.
View from below
5
4
3
2
1
1
2
3
View from below
Assembled slatted frame
Tips from a professional:
Spring washer = snap ring
07

Step 3
Attach the mounting rails
You need:
•2x mounting rail
•18x M8 screws for mounting rail
•18x washer M8
•18x spring washer M8 for mounting rail
•18x slot nuts M8 for mounting rail
(already in the rail)
Tools
•1x Allen key M8
Place the mounting rails under the tent so that
the outer sides are flush with the frame. Slide
the sliding blocks into the correct position so
that they are under the holes.
Now connect the mounting rails to the battens.
Make sure that you have an equal overhang on
both sides. Choose the inner hole of the laths to
get 80cm width.
Slide the sliding block to the correct position.
Then insert the screw from above into the hole of the inner lath.
1. Washer M8
2. Spring washer M8
3. Screw M8
Repeat this step 18 times and tighten the screw with the 8 mm Allen
key.
1
2
3
Tips from the pro: flush -make sure the
rails don't peek over the frame on the left
or right side. 08

Step 4
Die Befestigungswinkel anbringen
You need:
•2x mounting bracket
•4x fully threaded screw 30 mm
•2x fully threaded screw 35 mm
•6x spring washer
•2x washer
•6x lifting nuts
Tools
•8 mm open-end wrench
•4 mm Allen
Mount the connecting brackets to the outer
frame with the 35mm screw. You will find 2
punched holes in each of the two outer laths
and a pre-punched hole on the frame.
Position the angles so that they point outward
and the tip points forward. Then first fasten the
35 mm screw in the right and left outer frame.
1. Pass screw 35mm from the inside to the
outside
2. Washer
3. Spring washer
4. Lift nut
Repeat the step without washer with the 2
screws 30 mm each to connect the outer
laths to the angle.
1. Pass screw 30mm from the inside to
the outside
2. Spring washer
3. Lift nut
1
2
3
View from below
4
35 mm
screw
30 mm
screw
Tips from a pro: The connecting brackets
are then used for the tent poles!
09

Step 5
Connect the bracket and canopy rods
You need:
•2x Long stirrup bars without bend
•4x short bars without hole
•1x long canopy poles with bend
•2x short poles with hole
•1x opening rope
Now connect the 4 small rods (without hole) with the 2 straight bracket rods.
Then connect the 2 small rods (with pre-punched hole) to the canopy rod (with bend). Before doing
so, insert the lashing strap into the canopy pole.
Notice
*If the bars are difficult or impossible to insert
into each other due to the powder coating,
please sand them with sandpaper from the
inside.
Tips from the pro: *coarse sandpaper
always helps
10

Step 6
Connect the bracket and canopy rods to the
frames
You need:
•2x clamping bracket
•2x fully threaded screw
•4x half thread screw
•6x hanger nut
Tools
•8 mm Allen key
•13 mm open end wrench
Connect the straight stirrup bars to the
mounting bracket one after the other. Start
with the lower hole.
1. Insert the semi-threaded screw from the
inside through the stirrup bar and the
connector.
2. Stick nut
Repeat this step with the second straight stirrup bar at the middle hole
The canopy bar is connected to the highest hole, the clamping bracket and the fully threaded
screws.
1. Place the clamping bracket between the canopy bar and the connector.
2. Pass the fully threaded screw through the tensioning bracket-canopy bar-tensioning bracket.
3. Stick nut
1
2
3
Then tighten well. The Allen key locks and the open-end wrench tightens.
Then tighten well. The Allen key locks and the open-end wrench tightens.
Detailed YouTube video
Lazy Tent -Assembly 11

Step 7
Attach the gas struts to the frame
You need:
•2x gas springs
•2x half thread screws
•4x spacers
•2x spacers
Tools
•8 mm Allen key
•13 mm open end wrench
Turn the two gas struts into the threaded
screw already attached to the outer frame.
Now connect the other end of the gas spring with the
canopy rod. To do this, it is best to fold the canopy rod
forward and then pull it up into the correct position to
perform the half-thread screw from the outside:
1. Semi-threaded screw
2. Eyelet gas spring
3. Spacer
4. Spacer
5. Canopy rod
6. Spacer
7. Stick nut
7
6
5
4
3
2
1
Then tighten well. The Allen key locks and the open-end wrench tightens.
Detailed YouTube video
Lazy Tent -Assembly 12

Step 8
Connect the inner fabric with the straight
stirrup bars
You need:
•Inner fabric
Then connect the tabs that we attached to the
outer battens in step 2 to the inner tent at all 4
corners. Do not pull too tight!
Unfold the inner fabric and place it inside the
frame. The Lazy Tent logo must be on the front
left.
After you have connected all 4 flaps to the inner tent, you can clip the inner tent to the two
straight poles (not to the front pole). Start with the middle pole, and then clip the tent to the rear
pole.
Tipps vom Profi:
Es gibt mehr als drei Klipps.
13

Step 9
Connect the outer tent
You need:
•Outer tent
First unfold the outer tent -the side with the longer piece is the front side.
Connect the outer tent to the rear connecting
flaps of the platform. To do this, pass the outer
tent flap through the plastic opening of the
already connected inner tent and outer frame
flap.
Now attach the outer tent from back to front to
the rear and middle hoops.
Before you connect the last pole (canopy pole)
you can lift the canopy pole a little and pull the
outer tent over the canopy pole. So that the
outer tent is already stretched by itself.
Then connect the outer tent to the connection
brackets (right & left). Make sure to pull the
strap from top to bottom through the
connection bracket and connect it to the outer
tent.
Velcro the outer tent to the canopy pole.
Tips from the pros: If the strap seems too
short, pull the canopy pole a little towards
the tent. 14

Step 10
Positioning the opening rope
Pass the opening rope between the clips and
over all the hoop poles so that the opening rope
comes out at the back of the tent.
(Simply pull the strap and hook it with the front
tab).
Fasten the Velcro
Close the tent and turn it over once. Now
attach the inner tent to the platform from
below.
Step 12
Put in hard foam panels
Step 11
Place the four hard shell panels in the tent.
Detailed YouTube video
Lazy Tent -Assembly 15

Step 13
Connect the roof tent with the roof racks
You need:
•4x mounting bracket
•8x screws M8 45 mm
•8x spring washer M8
•8x washer M8
•8x star knob screw
Lift the roof tent onto the roof rack.
Insert two screws into the aluminum profile on
each side. Then lift the tent so that one screw is
positioned to the right and one to the left of the
roof rack.
These are tightened by hand (without tools).
Then attach the four brackets in the following order:
1. Mounting bracket
2. Spring washer
3. Washer
4. Star grip screw
1
2
3
4
Notice
The mounting rails are 80 cm apart. Therefore,
you have to make sure that the free surface of
the beams must also be 80 cm apart. If this is
not the case, we offer special adapter plates.
Please contact us.
The mattress
Open the tent and unfold the Outwell
mattress*. Place it in the tent and press the two
ventilation valves inwards so that the mattress
can inflate itself.
Step 14
Tips from a professional: *For the Outwell
mattress is an instruction manual enclosed.
16

Step 15
The ladder
Loosen the Velcro and place the hooks in the
ladder. Then hook the telescopic ladder*
between the tent and the frame and pull it
down rung by rung.
Step 16
End caps
Clip the 4 cover caps to the 2 mounting rails
Step 17
The PVC-Cover
Pass the straps through the openings of the
PVC cover and place it on the roof tent.
Connect the clippers with the mounting rails
and tighten it.
Notice
Make sure to retighten the star grip screws every 200 kilometers
Tips from the professional:
First to clip, then tighten.
17
