Coleman Avior X2 User manual

Assemble Frame
– Start with the Main Tent Pole and
gradually apply pressure to the pole,
forming an arch, until you are able to
insert the pole tip into the grommet on
the corner web. (illus. 2, illus. 3)
– Repeat for Side pole. (illus. 2, illus. 3)
Avior
™
X
2
part number 2000000453
1
2
Layout & Positioning
of Rainfly, Pole Assembly
– Layout and position Rainfly with doors facing
desired direction. (illus. 1) Unzip doors.
– For best results in windy conditions, position
back of tent into the wind.
– Insert the cap end of the Main Pole into front
sleeve. (illus. 1)
– Insert the cap end of the Side Pole into
back sleeve. (illus. 1)
Main Tent Pole (Red)
Part No. 9830-1121
Side Pole (Silver)
Part No. 9830-1221
Rainfly
Part No. 9830-1321
illus. 1
illus. 2
Insert Pole Tip
into grommet.
illus. 3
Tent frame up
POLE ASSEMBLY PARTS
Main Tent Pole
Main Tent Pole
Side Pole
Side Pole

Things You Should Know
• Under certain conditions (cold weather, high humidity, etc.) condensation will form on the inside surfaces of your tent. Condensation
is caused by water vapor from your breath, perspiration, or any wet clothing inside your tent. It is NOT LEAKAGE through the tent
fabric. It can be minimized by removing wet clothing from your tent and by providing good ventilation through the tent.
• Never store tent, even for a short period of time, without
drying it thoroughly and brushing off caked dirt. Do not pack
stakes or poles inside your tent. Use separate storage bag.
• STAKES SHOULD BE REMOVED BY PULLING ON THE STAKE
ITSELF. NEVER PULL ON THE TENT FABRIC OR TENT STAKE
LOOP TO REMOVE STAKE.
• TENT POLES SHOULD NOT BE LEFT TELESCOPED TOGETHER
DURING STORAGE.
3600 N. Hydraulic • Wichita, Kansas 67219
1-800-835-3278 • www.coleman.com
3Attach Tent
– Layout the tent. (illus. 4)
– Position the tent in under the Rainfly
– Starting at the back of the tent, clip the tent to the
Rainfly in the corners and then the side. (illus. 6)
– Attach the top of the tent to underside of the
Rainfly with toggle and loops.
– Optional ground cloth in vestibule can be removed
or attached and clipped to the webbing at front of
the Rainfly. (illus. 6)
– Stake out rainfly doors, keep rainfly taut. (illus. 6)
– Attach Guy Lines to Guy Wings on back and sides
of the Rainfly and stake out. (illus.6).
illus. 4
Tent positions
in under Rainfly
illus. 6
Completed tent
with Rainfly.
Tent toggles to loops
on underside of Rainfly
illus. 5
Tent clips onto
pole stake loop
PRINTED IN CHINA Rev. 11/07
© 2006 The Coleman Company, Inc. All Rights Reserved.
