Lea 816-964R User manual

3/3 Loft Bed
4/6 Loft Bed
Page 1
Thank you for purchasing furniture by Lea Industries. We are
honored that you have chosen our furniture to compliment
your home. Every effort has been made to ensure your
furniture is of the finest quality. If you find that your
furniture has a missing or damaged part, contact your local
Lea dealer. Thanks again for making Lea Industries a part of
your home.
4310 Regency Drive, Suite 101
High Point, NC 27265
336-294-5233
www.leaindustries.com
T
h
e
t
a
Y
o
u
t
h
S
p
e
c
i
l
i
s
TM
A La-Z-Boy Company
Assembly Instructions
Model Number:
816-964R, 816-984R

Page 2
(1) Hardware Bag & Instruction Booklet
SLAT Pack (1)
;
;
;
;
;
;
;
;
;
;
;
;
;
;
;
Follow the information on the warnings appearing on the upper bunk end structure and on the carton. Do
not remove warning label from bed.
Always use the recommended size mattress or mattress support, or both, to help prevent the likelihood
of entrapment or falls.
Surface of mattress must be at least 5 in. (127 mm) below the upper edge of guardrails. (See Page 9)
Do not allow children under 6 years of age to use the upper bunk.
Periodically check and ensure that the guardrail, ladder, and other components are in their proper
position, free from damage, and that all connectors are tight.
Do not allow horseplay on or under the bed and prohibit jumping on the bed.
Always use the ladder for entering and leaving the upper bunk.
Do not use substitute parts. Contact the manufacturer or dealer for replacement parts.
Use of a night light may provide added safety precaution for a child using the upper bunk.
Always use guardrails on both long sides of the upper bunk. If the bunk bed will be placed next to the
wall, the guardrail that runs the full length of the bed should be placed against the wall to prevent
entrapment between the bed and wall.
The use of water or sleep flotation mattresses is prohibited.
Prohibit more than one person on upper bunk.
- Never attach or hang items to any part of the bunk bed that are not
designed for use with the bed; for example, but not limited to, hooks, belts and jump ropes.
Keep these instructions for future reference.
We recommend assembling your bunk bed on the shipping carton to protect your floor or carpet. Be
certain all staples are out of the box before beginning assembly on the shipping carton.
STRANGULATION HAZARD
READ THESE INSTRUCTIONS CAREFULLY
BEFORE ATTEMPTING TO ASSEMBLE THIS BED
SAFETY WARNINGS AND GENERAL NOTES
Replacement parts, including additional guardrails, may
be obtained from any of our Lea Industries dealers.
Identifying the Parts
Use the illustrations below to correctly identify each of the parts for your bed
Carton #1 (1 required for Loft Bed)
LONG GUARD RAIL (1)
SHORT GUARD RAIL (1)
SIDE RAILS (2)
LADDER (1)
Carton #2 (1 required for Loft Bed)
Large Loft End (2)
CORK PANEL (1)

Page 3
Standard Head Screwdriver
Phillips Head Screwdriver
Barrel Nut
5mm Hex Wrench
C 3
ID # Qty
5/16" X 4-1/2” Connecting Bolt
Qty
ID #
A 8
ID #
B
Qty Qty
G
ID #
Tools Required
Identify the hardware using the illustrations below
Qty
H
ID #
4
3
8
Connecting Bolt 5/16”x2-1/2”
Qty
D
ID #
2
Carton 2
Connecting Bolt 5/16” x 2”
This quantity of the hardware is for the 4/6 Loft Bed
;
;
;
;
;
;
Above all, take your time and read the
instructions carefully
Due to the size of this bed, it must be
assembled in the room it will occupy
The assembly will require at least two
people to complete
Make sure all fasteners are tight, but do
not over tighten
Power tools are not recommended for
assembling your furniture
Give yourself plenty of room to work
Identifying the Hardware
F
9
Qty
ID #
1" Wood Screw
Qty
E
ID #
31
Qty
ID #
6
K
3/4” Wood Screw
Connector Bolt 5/16”x3/4”
L
13
Qty
ID #
Connecting Nut 1/4” x 30mm
Qty
J
ID #
5
Qty
ID #
2
K
Ladder Hook
Connector Bolt 5/16” x 3/4”
8
Qty
ID #
IConnector Bolt 1/4” x 18mm
Connecting Nut 1/4”x17mm
This quantity of the hardware is for the 3/3 Loft Bed

Page 4
1
Step
Figure 2
G
ID #
Barrel Nut
Figure 1
Hardware Used In This Step
1. Insert the into the holes in each as shown in
. Make sure the slot on top of the is aligned with
the hole in the end of the rails ( ). Once inserted, use a
to align the with the hole. This will ensure
the nuts will line up properly with the bolts used later.
Barrel Nuts (G) Bed Rail
Figure 1 Barrel Nut (G)
Figure 2 Standard
Screwdriver Barrel Nut (G)
SIDE RAILS
Qty
8

Hardware Used In This Step
Page 5
2
Step
5/16" X 2-1/2” Connecting Bolt
ID #
B
Qty
8
1. With the help of another person, line up the and install two
( ) through a Loft Bed End and into the (
).
2. Attach the to the other using two
( ). Leave the bolts only hand tight for now ( ).
Cork Panel
Connecting Bolts B Cork Panel Figure
1
Cork Panel Loft Bed End Connecting Bolts
B Figure 1
5mm Hex Wrench
D 1
ID # Qty
B
Figure 1

3
Step
Page 6
Hardware Used In This Step
Qty
ID #
1
D5mm Hex Wrench
1. Attach the to the as shown using the
( ).
2. Please note the ( ) may have to be turned slightly to start the bolts threading.
3. Install the with starting and ending flush with the end of the support cleats
attached to your ( ).
4. First install ( ) into each end of the closest to the and
. Arrange the remaining so that they are evenly spaced along the
. Insert the ( ) into both ends of all remaining , permanently
connecting the to the cleats of the .
Bed Rails Loft Bed Ends Long Connecting Bolts
A
Barrel Nuts G
Slat Pack Slats
Bed Rails Figure 1
Wood Screws E Slats Headboard
Footboard Slats Bed
Rail Wood Screws D Slats
Slats Bed Rails
1" Wood Screw
Qty
E
ID #
30
5/16" X 4-1/2” Connecting Bolt
Qty
ID #
A 8
Figure 1
1” Wood Screw

4
Step
Hardware Used In This Step
Page 7
1. Position the onto the as shown.
2. Use a ( ) to tighten the ( ) to each end of the
and into the ( ).
3. Position the onto the . : The position of the ladder
should be decided prior to attaching the .
4. Use the ( ) to tighten the ( ) to one end of the
(opposite side of the Ladder opening) into the as shown (
).
5. Use the ( ) to tighten the ( ) to cover the unused holes
in the interior of the lower ( ).
6. Screw the ( ) through the predrilled holes located on the back side of
the ( ). If the is placed next to a wall, the
should be placed against the wall.
7. Use the ( ) to install the ( ) and ( )
to cover the unused holes in the cleat that is attached to the ( ).
Long Guard Rail Bed Rail
Hex Wrench D Connecting Bolts H Long
Guard Rail Bed Ends Figure 1
Short Guard Rail Bed Rail Note
Short Guard Rail
Hex Wrench D Connecting Bolt H Short
Guard Rail Bed End Figure
2
Hex Wrench D Connecting Bolt K
Loft Bed Figure 4
1” Wood Screw E
Short Guard Rail Figure 3 Note: Bunk Bed
Long Guard Rail
Hex Wrenches D Connector Bolts I Connecting Nuts C
Cork Panel Figure 5
5mm Hex Wrench
C 3
ID # Qty
Qty
D
ID #
2
1" Wood Screw
Qty
E
ID #
1
Connecting Nut 1/4” x 17mm
Qty
H
ID #
3
Connecting Bolt 5/16” x 2”
3
Qty
ID #
IConnector Bolt 1/4” x 18mm
8
Qty
ID #
KConnector Bolt 5/16” x 18mm
This quantity of the hardware is for the 3/3 Loft Bed
This quantity of the hardware is for the 4/6 Loft Bed
12
Qty
ID #
KConnector Bolt 5/16” x 18mm
H
Figure 3
Figure 1
Figure 5
Figure 2
Figure 4

Page 8
Hardware Used In This Step
Step
51. Select the and attach the ( ) to each end at the top of the
using two ( ) for each ( ) as illustrated ( ).
2. Position the in place by hooking it over the top edge of the in the location
shown. Secure the in place by screwing a ( ) through each
( ). See .
3. Use the ( ) to tighten ( ) and ( ) to tighten
each ( ) and ( ) to cover the unused holes in the
and as shown ( ).
4. Use the ( ) to tighten each ( ) and ( ) to
cover the unused holes in the ( ).
5. Be sure to note the in the back of this booklet. In order to
avoid the possibility of falling or entrapment, these specifications must be strictly followed.
Ladder Ladder Hooks L Ladder
3/4” Wood Screws F Ladder Hook L Figure 1
Ladder Bed Rail
Ladder 3/4” Wood Screw F
Ladder Hook L Figure 2
Hex Wrench D Connector Bolt K Hex Wrenches D
Connector Bolt I Connecting Nut J Short
Guard Rail Bed End Figure 3
Hex Wrenches D Connector Bolt I Connecting Nut J
Posts Figure 4
BEDDING SPECIFICATIONS
5mm Hex Wrench
Qty
D
ID #
2
F
Qty
ID #
6
3/4” Wood Screw
5
Qty
ID #
IConnector Bolt 1/4” x 18mm
Connecting Nut 1/4” x 30mm
Qty
J
ID #
5
1
Qty
ID #
KConnector Bolt 5/16”x3/4”
L
Qty
ID #
2
Ladder Hook
Figure 3
Figure 1
Figure 2
Figure 4

Page 9
5"
GUARD RAIL
SLAT
BEDDING SPECIFICATION
UPPER BUNK MATTRESS DIAGRAM
GUARD RAIL
SIDE RAIL
MATTRESS
MATTRESS SIZES...
Upper Bed Mattress Specifications:
Minimum distance
from top of guard
rail to top of
mattress
11”
Maximum
Thickness
* Only use a mattress that is 74” - 75” long and 37-1/2” - 38-1/2” wide on the
upper bunk of the 3/3 Twin size bed.
* Ensure thickness of mattress does not exceed 11”.
* Only use a mattress that is 74” - 75” long and 52-1/2” - 53-1/2” wide on the
upper bunk of the 4/6 Full size bed.

Page 1
4310 Regency Drive, Suite 101
High Point, NC 27265
336-294-5233
www.leaindustries.com
Mod les Numéros:
816-964R, 816-984R
Lits Superposes 3/3
Lits Superposes 4/6
Merci pour avoir achet votre meuble chez Lea Industries. Nous
sommes honor s que vous ayiez choisi nos meubles pour embellir
votre foyer. Nous avons mis tous nos efforts pour vous fournir un
meuble de la meilleure qualit possible. S’il s’avère qu’une partie
est endommag e ou manquante, veuillez contacter le distributeur
Lea le plus proche. Merci encore d’avoir choisi Lea Industries pour
faire partie de votre vie quotidienne.
INSTRUCTIONS DE MONTAGE
Sp
e
c
i
ss
a
l
i
s
e
l
dn
a
s
a
j
e
u
n
e
e
TM
La Compagnie La-Z-Boy
