Leadtek Amor C101 User manual

C101 IP Wireless / Wired Camera
User Manual

More Security, More Convenience
2
N CONTENTS
1 WELCOME ...................................................................................................................................................3
1.1 FEATURES................................................................................................................................................................................................3
1.2 PACKING LIST.......................................................................................................................................................................................... 3
1.3 PRODUCT VIEWS .....................................................................................................................................................................................4
1.4 PC SYSTEM REQUIREMENTS ...................................................................................................................................................................5
1.5 HARDWARE INSTRUCTION .......................................................................................................................................................................5
1.6 SOFTWARE INSTALLATION .......................................................................................................................................................................6
2. SOFTWARE OPERATION...........................................................................................................................9
2.1 IP CAMERATOOL ....................................................................................................................................................................................9
2.2 CAMERALOGIN.....................................................................................................................................................................................12
2.3 FOR IE BROWSER..................................................................................................................................................................................13
2.4 FOR SAFARI,FIREFOX,GOOGLE BROWSER ...........................................................................................................................................16
2.5 FOR MOBILE PHONE.............................................................................................................................................................................. 16
2.6ACTIVEXMODE (FOR IE BROWSER)..................................................................................................................................................... 17
2.7 FOR VISITOR..........................................................................................................................................................................................17
2.8 FOR OPERATOR...................................................................................................................................................................................... 21
2.9 FOR ADMINISTRATOR ............................................................................................................................................................................22
3 Settings as Administrator.........................................................................................................................23
3.1 MULTI-DEVICE SETTINGS...................................................................................................................................................................... 23
3.2 NETWORK SETTINGS ............................................................................................................................................................................. 28
3.3 BASIC NETWORK SETTINGS................................................................................................................................................................... 29
3.4 WIRELESS LAN SETTINGS......................................................................................................................................................................30
3.5ADSLSETTINGS....................................................................................................................................................................................31
3.6 UPNPSETTINGS .................................................................................................................................................................................... 31
3.7 DDNS SERVICE SETTINGS.....................................................................................................................................................................32
3.8 P2P SETTINGS .......................................................................................................................................................................................35
3.9 SYSTEM SETTINGS.................................................................................................................................................................................36
3.10 DEVICE NAME...................................................................................................................................................................................... 36
3.11 DATE &TIME SETTINGS.......................................................................................................................................................................37
3.12 USERS SETTINGS ................................................................................................................................................................................. 37
3.13 INDICATOR SETTINGS ..........................................................................................................................................................................38
3.14 BACKUP &RESTORE ...........................................................................................................................................................................38
3.15 OTHER SETTINGS................................................................................................................................................................................. 39
3.16 MAIL SERVICE SETTINGS..................................................................................................................................................................... 39
3.17 FTPSERVICE SETTINGS....................................................................................................................................................................... 40
3.18ALARM SERVICE SETTINGS..................................................................................................................................................................42
3.19 SEND MAIL ON ALARM........................................................................................................................................................................ 44
3.20 PATH SETTINGS....................................................................................................................................................................................46
3.21 SERVER PUSH MODE (FOR SAFARI,FIREFOX,GOOGLE BROWSER).....................................................................................................47
3.22 SIGN IN MOBILE PHONE........................................................................................................................................................................ 48
4. APPENDIX................................................................................................................................................. 49
4.1 FREQUENTLYASKED QUESTIONS ..........................................................................................................................................................49
4.2 DEFAULT PARAMETERS.......................................................................................................................................................................... 51
5. Specifications........................................................................................................................................... 52
6. OBTAINING TECHNICAL SUPPORT........................................................................................................53

More Security, More Convenience
3
1 WELCOME
This is an integrated wireless IP Camera solution. It combines a high quality digital Video Camera with network
connectivity and a powerful web server to bring clear to your Desktop from anywhere on your local network or
over the Internet.
The basic function of it is transmitting remote video on IP network. The high quality video image can be
transmitted with 30fps speed on the LAN/WAN by using MJPEG hardware compression technology.
It is based on TCP/IP standard, build-in WEB server which could support Internet Explore. Therefore the
management and maintenance of your device become more simply by using network to achieve the remote
configuration, start-up and upgrade firmware.
You can use this IP Camera to monitor some special places such as your home and your office. Also
controlling and managing images are simple by clicking the website through the network.
1.1 Features
☆Powerful high-speed video protocol processor
☆High-sensitivity 1/4’’ CMOS sensor
☆Picture total 300k pixels
☆Optimized MJPEG video compression for transmission
☆Multi-level users’ management and passwords definition
☆Embedded Web Server for users to visit by IE
☆Support wireless network (WI-FI/802.11/b/g/n)
☆Supporting Dynamic IP (DDNS) and UPNP LAN and Internet (ADSL, Cable Modem)
☆Giving alarm in cause of motion detection
☆Supporting image snapshot
☆Support multiple protocols：HTTP/TCP/IP/UDP/SMTP/DDNS/SNTP/DHCP/FTP
☆Support WEP/WPA/WPA2 encryption
☆Support 3G phone, Smart phone control and surveillance
☆Support Firefox, Safari, Google chrome browser.
1.2 Packing List
Untie the pack and check the items contained against the following list:
●IP Camera X1
●Quick Guide X1
●DC Power Supply X1
●CD X1
●Network Cable X1
●Mounting screw X1 (set)
NOTE: Please contact us immediately in case of any damaged or short of contents.

More Security, More Convenience
4
1.3 Product Views
1.3.1 Front View
Figure 1.1
1Sensitive Hole: For light sensitive
2 Infrared LED: For night vision
3 LENS: CMOS sensor with fixed focus lens. (Default is 6mm, 3.6mm optional)
4 Network Indicator LED: If there is network activity, the LED will blink
5 Microphone: Build-in microphone
6 Cover: Color cover to hide the LEDs
7 Wireless Antenna: WI-FI Antenna
1.3.2 Rear/Side Panel
Figure 1.2

More Security, More Convenience
5
LAN: RJ-45/10-100 base T
Power: DC 5V/2A power supply
Network Light: The green LED will on when connect to the network, the yellow LED will blink when data
transferred
Audio Output: The jack is used to plug external speaker
I/O PINS: 1 Output A 2 Output B 3 Alarm input 4 Input (GND)
RESET BUTTON: Press and hold the RESET BUTTON for 15 Seconds, then the IPCAM will be reset back to
the factory default Parameter. (Please keep the power on when do RESET)
1.3.3 Back View
Figure 1.3
There are some stickers at the bottom, such as MAC address sticker, QC sticker etc.
If your camera does not have these stickers, it may be a clone one, clone IPCAM could not use the original
firmware and obtain our good after sale service.
1.4 PC System Requirements
System configuration requirements :( Example for viewing four IPCAM)
CPU: 2.06GHZ or above
Memory: 256M or above
Network Card: 10M or above
Display Card: 64M or above memory
Recommendable Operating system: Windows 2000/ XP/ Vista/ 7/8/8.1
1.5 Hardware Instruction

More Security, More Convenience
6
Follow the steps below to set up your camera hardware. Make sure to follow each step carefully to ensure that
the camera operates properly
1. Plug the power adaptor into camera
2. Plug the network cable into camera and router/switch
3. It takes approx 30 seconds to boot up the camera, then you will find the IP address from
“IP Camera Tool” (Figure: 2.1)
4. When the power on and network cable connected, the green led of the real panel will keep on,
The yellow led will keep flash, and the Indicator led at the front of the camera will flash. (The indicator LED
can be controlled by software)
Figure1.4
1.6 Software Installation
Attention:In order to make the installation correctly, we suggest that turn off your Firewall and Antivirus before
install the ActiveX, Don’t worry, it is safe.
Software installation is the key to the successful use of this product.
Install the follow software:
1. IP Camera Tool: Open the CD, dbclick “IPCamSetup.exe”, only click next, you will complete the software
installation.(figure1.6/ 1.7/ 1.8)
2. ActiveX: Double click “Appinstall.exe”—“Next”—“Install”—“Finish”.
Figure1.5

More Security, More Convenience
7
Figure1.6
Figure1.7
Figure1.8
After this done, the icon “IP Camera Tool” will be displayed on desktop automatically.

More Security, More Convenience
8
CAUTION: Before installing and using the product, please read the following precautions carefully and make
sure they are fully understood.
Use only the power adaptor attached with the product. Use unauthorized power adapter may cause damage to
your IP Camera.
IP Camera terminal shall be installed in an indoor environment where the rain or snow could not pour it.
Do not touch the lens of the IP Camera at will. The optimum focus range has been set before it is delivered out
of the factory. If you turn the lens, it may cause incorrect focus and vague images.
For firmware upgrading or connection with an external, refer to detailed instructions contained in the CD.

More Security, More Convenience
9
2. SOFTWARE OPERATION
2.1 IP Camera Tool
When the Device has been mounted properly, you can double click the icon “IP Camera Tool”
and a dialog box as Figure 1.9 will pop up.
Figure1.9
Note: The software searches IP Servers automatically over LAN.
There are 3 cases:
1. No IP Cameras found within LAN. After about 1 minute search, the Result Field will show “not found IP
Server” and the program shut automatically.
2. IP Cameras have been installed within LAN. All the IP Cameras will be listed and the total number is
displayed in the result field as shown in Figure 1.9
3. The IP Cameras installed within LAN do not share the same subnet with the monitoring PC.A prompt as
shown in result field (prompt: Subnet doesn’t match, double click to change!). Click the left mouse button to
choose the prompt and click the right mouse, choose Network Configuration to set the static IP address of
the Camera to the same subnet as LAN. (Figure 2.3)
NOTE: If it shows” Subnet doesn’t match, double click to change!”, you can also choose ”Obtain IP from
DHCP Server” to get a dynamic IP. (Figure 2.2)
2.1.1 Six Options
Choose the IP Camera list and Click right mouse, there are six options: (Figure 2.0)
Basic Properties, Network Configuration, Upgrade Firmware,
Refresh Camera List, Flush Arp Buffer, About IP Camera Tool.

More Security, More Convenience
10
Figure 2.0
2.1.1 .1 Basic Properties
There are some device information in the Basic Properties, such as Device ID, System Firmware Version,
Web UI Version.（Figure 2.1）
The Device ID just is the camera’s MAC ID, which should be the same as showed on the sticker at the bottom
of camera. Every camera has its unique MAC ID. So if there are many IP address showed in the list, check the
MAC ID, you can ensure which camera is it.
Sometimes, if there is no IP address showed on the IP Camera tool, maybe it’s blocked by firewall, then add
the MAC ID to the router, and give it a fixed IP or add the MAC ID as a trusted site. There are two MAC
Address, one is Device MAC ID, the other is WIFI MAC ID.
WIFI MAC ID, you can find it from the sticker at the bottom of the camera, if this sticker lost, you can login your
WIFI router, check the host status, which will show all the WIFI device connect to this router, you can also find
the IPCAM’s WIFI MAC ID there.
Figure 2.1
2.1.1.2 Network Configuration
In this page, you can configure the Network parameter.

More Security, More Convenience
11
Figure 2.2
Obtain IP from DHCP server: If clicked, the device will obtain IP from DHCP server. In other words, the
camera will have a dynamic IP. (Make sure the Router which the camera connects has DHCP function and
DHCP is enabled). (Figure 2.2)
Figure 2.3
IP address: Fill in the IP address assigned and make sure it is in the same subnet as the Gateway, and the
subnet should be the same as your computer or router. (I.e. the first three sections are the same)
Subnet Mask: The default subnet mask of the equipment is: 255.255.255.0. You can find the subnet mask
from your PC or router.
Gateway: Make sure it is in the same subnet with PC’s IP address .Here gateway is the LAN IP of your router.
DNS Server: IP address of IPS network provider. You can also set it’s the same as the Gateway.
NOTE: You can find the Subnet Mask, Gateway, DNS Server from your router, or check the local connection
status of your computer, get all the parameters. Normally two DNS servers are optional.
Http Port: LAN port assigned for the equipment, default is 80. You could set another port number like 81, 801,
8001 etc.
User: Default administrator username is: admin (please make sure all are lowercase letter)
Password: Default password is 0000.
NOTE: When prompt “subnet doesn’t match, double chick to change!” appeared, please set the IP Address,
Subnet Mask, Gateway,DNS Server once again, or enable Obtain IP from DHCP server.
2.1.1.3 Upgrade Firmware
Enter the correct User and Password to upgrade system Firmware and Web UI. If you upgrade the camera,

More Security, More Convenience
12
Please upgrade system firmware first and then upgrade Web UI. Or it may damage the camera.（Figure
2.4）
Figure 2.4
Please download the firmware package under the correct type of your camera before upgrade.
Follow the upgrade document in the package carefully to upgrade. Please look readme firstly before you do
upgrade.
CAUTION: Please don’t upgrade the firmware freely. Sometimes, your camera may be damaged if wrong
operation during upgrade.
If your camera works well with the current firmware, we recommend you’d better not upgrade it.
NOTE: When doing upgrade, please must keep the power on, and the best use wired mode, connect the
network cable.
2.1.1.4 Refresh Camera List
Refresh camera list manually.
2.1.1.5 Flush Arp Buffer
When cable network and wireless network of the device are fixed IP address .There is a problem you may
encounter is can search the camera IP but can’t open the camera web page .you may try to use Flush Arp
Buffer.
2.1.1.6 About IP Camera Tool
Check the IP Camera Tool Version and IP CameraActiveX Control Version here.
2.2 Camera Login
You can access the camera through IP Camera Tool or IE, Firefox, Safari, Google Chrome or other
standard browser directly.
1. Double click the IP address of the IP Camera listed (Figure 1.9). The default browser you use will run
automatically and come to the camera login interface. (Figure 2.6)
2. To access the camera by IE Browser directly, just type the camera’s IP address, for example, if the camera’s
IP address is 192.168.1.123:

More Security, More Convenience
13
Figure 2.5
Figure 2.6
The default user name is admin, and password is 0000.
Input the correct user name and password, the Sign In interface will pop-up.
There are three models to login.
(1) Active Mode (For IE Browser): available in IE6.0 or above explorer
(2) “Server Push Mode”: available in Firefox, Safari, and Google Chrome browser.
(3) “Sign in mobile phone”: available in Mobile phone
2.3 For IE Browser
Choose Active Mode (For IE Browser), and sign in.

More Security, More Convenience
14
Figure 2.7
When you login the camera for the first time, you may get an ActiveX prompt. Please click the prompt and
choose Run Add-on, refresh and login the camera again, then you will see live video.
Note: If there is still no live video after running ActiveX, and a red cross showed in the center of the
screen, or even just a black screen, please try to enable the ActiveX options of IE security settings.
Please do the follow steps:
1. Close the firewall of your computer.
2. Change the ActiveX settings, “IE” browser > “Tool” > “Internet Options” > “Security”> “Custom Level” >
“ActiveX control and Plug-ins”, all the ActiveX options set to be “Enable”:
Especially:
Enable: Download unsigned ActiveX controls
Enable: Initialize and script ActiveX controls not marked as safe
Enable: Run ActiveX controls and plug-ins

More Security, More Convenience
15
Figure 2.8
In addition: you can also click “Start” menu->“Internet Explorer”, choose “Internet attributes “ to enter, or via
“Control Panel” ->“Internet Explorer”, enter to Security setting.
If you allowed the ActiveX running, but still could not see live video, only a Red Cross in the center of
the video, and the device status light change to yellow color , not green, please change another port number
to try. Don’t use port 80, use other port such as 128, 1008 etc.
Figure 2.9

More Security, More Convenience
16
NOTE: Make sure that the firewall or anti-virus software doesn’t block the software or ActiveX. If you couldn’t
see live video, please close your firewall or anti-virus software, and try again.
2.4 For Safari, Firefox, Google Browser
Choose Server Push Mode (For Safari, Firefox, Google Browser), and sign in
Server Push Mode doesn’t support ActiveX, so some functions are not available, such as Play, Stop, Record,
Audio, Talk etc. if you want to use these functions, please use IE browser.
Figure 3.0
2.5 For Mobile Phone
Choose Sign in mobile phone, and sign in.
Mobile phone doesn’t support ActiveX, only some basic functions can be available in this mode.
It supports iPhone, Smart phone, 3G phone etc. Normally, if the mobile phone supports network video, then it
can work with our IP Camera.

More Security, More Convenience
17
Figure 3.1
2.6 ActiveX Mode (For IE Browser)
Login the camera in ActiveX mode, the main User Interface as below:
NOTE: There are 3 levels of users, Visitor, Operator, Administrator, if you login with different users, the use
authority is different. (See 3.11 User Settings, Figure 7.4
2.7 For Visitor
When login as Visitor, you can enter the IP Camera for visitor.
Visitor is the lowest level with only some operation available

More Security, More Convenience
18
Figure 3.2
Channels:
Our IE software supports 9 channels totally. Click can get different windows.
: Click this one, you can view the main channel of the camera you login.
: Click this one; you can view 4 Channels of cameras which connected, from CH1 to CH4.
:Click this one; you can view 9 Channels of cameras which connected, from CH1 to CH9.
NOTE:If you want to view 4/9 channels, you should set the Multi-Device firstly (See 3.1 Multi-Device
Settings)
Status of Channels:
There are 9 icons at the bottom of the UI which show the status of each channel of the camera.
:Grey color, means there is no device connected to the main device from this channel.
: Green color, means the device connected from this channel, and it works well.
: Red color, means the device of this channel is recording.
: Yellow color, means set this channel in multi-device already, but it fails to connect to the main device.

More Security, More Convenience
19
OSD Settings:
 
Figure 3.3
OSD: Means “On-Screen Display”, click “Audio video” > “OSD”, set display date and time on the video.
Disabled: Click this one, means clear the OSD.
Color: Can set the OSD text color as black, yellow, red, white, blue etc.
Add time stamp on record: Click this, there will be time OSD on record video files.
Figure 3.4
Rate and Resolution:
Rate: Set video frame here, from “full-speed to 1fp/5s”. (Figure 3.5

More Security, More Convenience
20
Resolution: Set the resolution to be 160*120/ VGA(640*480)/ QVGA (320*240). (Figure 3.6
NOTE: When doing recording, Rate and Resolution parameter settings is very helpful for getting small
size record files, the lower parameter to get the smaller file.
Figure 3.5 Figure 3.6
TOP Menu:
Figure 3.7
: Click it to get live video. When you want to back to live video from other menus, just click it. Only
under live video, you can do the operation on the right side, such as play, stop, snapshot etc.
: Click it to get into play mode, when you click stop icon, the video will be stopped, then click play
icon, it will show the video again.
:Click it to stop the live video. You can click play icon if you want to see live again.
: Click it to get snapshot. It will show the date and time of the snapshot you get, when you want to
save it, you will find the snapshot file named by “snapshot_MAC ID_date_time”.
: Click it to start record by manual, and the icon will change to red color, click it again, it will stop
record. The record file will be saved to the folder you set. (Figure 9.5-Figure 9.7)
: Click it to collect the sound around the camera, if you plug a earphone or a speaker in the
computer which you are using, you will hear the sound around the camera. This IP Camera has a built-in
microphone, when you click it to start work, the icon will change to red color, click it again, will stop audio
function.
: Click it to start the talk function, firstly you have to plug a microphone in your computer. When
you are talking about something with the microphone from your computer, the sound will come out from the
built-in speaker of the camera, people beside the camera will hear the sound. If you connected an external
speaker from the audio output hole at the back of the camera (Figure 1.2), you will get better sound effect.
Once click it to start work, the icon will change to red color, click it again, will stop talk function.
NOTE: For visitor, if you click other menus which visitor don’t have the right to operate it, there will be a pop-up
of login interface (Figure 2.6), please input the user name / password for at least 3 times to login again.
