LeaperKim Sherman User manual

User Manual
Sherman

Company: Guangzhou Veteran Intelligent Technology Co., Ltd.
Address: No. 2, Xicheng Xingsheng Road, Renhe Town, Baiyun District, GZ.
Tel: + 86 13751045466
Email: li[email protected]

Instructions for Use
Please read the manual carefully to understand the performance
parameters of this product in details, and observe the use behaviors indicated
in this manual to avoid unnecessary losses and injuries, otherwise you need to
bear all the consequences arising therefrom.
●This product is strictly forbidden to ride on the motor vehicle lane. Be sure to
comply with local laws and regulations. Do not use this product in areas prohibited by laws
and regulations. Do not use this product beyond the speed set by local laws and
regulations.
●The following persons are prohibited from riding this product.
People who are under the influence of drugs or alcohol and have limited mobility and
reaction ability. Or suffer from high blood pressure, cardiovascular and cerebrovascular
diseases or other high-risk diseases.
Minors under 14 and seniors over 60.
●Do not use this product in dark or obstructed sight, or on slippery, stagnant water,
or pothole light.
●Do not ride at high speed or violently accelerate or decelerate when the battery
power is low.
●Do not perform all dangerous actions like jumping, one-legged, backward,
manned, speeding, etc.
●Before using this product, please wear a helmet, knee pads, elbow pads, gloves
and light protectors.
●In places where there are people or obstacles, please reasonably control the
speed and prohibit speeding.
●This product is forbidden to be disassembled or repaired by non-professionals.
Disassembling the machine by yourself will no longer enjoy the product warranty service.
●Activation with charger for first use.

This product will be constantly improved and changed during the
production or sales process. If there is any discrepancy with this manual,
please refer to the actual product.
1. Product Description
Functional Diagram

Body
Standard Accessory
一一一一一一一一一一 一一一一一一一一一 一一一一一一一一一一
Charger User Manual Softpad x 2

LCD Screen
LCD panel

Product Specification
Product Performance
Model name
Sherman
Top free spin speed
100km/h
Safe riding speed
25km/h
Motor power
2500W
Battery
PanasonicNCR18650GA100.8V3200WH
Max gradibility
30°
Operating temperature
-10-80℃
Max load
120kg
Charger
100.8V5A
Charging time
8h
Color
Black
Dimension and weight
Dimension
500mmx195mmx592mm
Net weight
35kg
Pedal dimension
250mmx130mm
Pedal altitude(from
ground)
170mm
Hardware
Mainboard
Customized connectors to fix wires firmly;12pcs Mosfets make it more
durable.
Cooling fan
Dual cooling fans,set up at 45℃.
Tire size
20inch off road tire.
Trolley handle
Central mounted build in.
LCD panel
Display speed, battery voltage, mileage, mode switching, calibration,
battery status etc.

Metal bars
Anti scratch of shells.
Charge port
Dual charge ports,support 10A max.
Headlight
1500lm modularization light.
Taillight
Turning, braking warning lights.
Software
Incline protection
Stop rolling once wheel body inclining 45°
Speed limit
Can be set through LCD panel.
Low battery protection
Alarm at 78V, tilt back at 75.6V
Battery protection
Overcharged, over-discharged, Charging port out put short circuit protection
Mainboard over heat
protection
85℃.
Calibration
Set through LCD panel.
Package
Gross weight
40kg
Size
570mmx280mmx700mm
2. Maintenance
·Always use this product, pay attention to check whether the screws are loose
on time.
·Check the tire pressure on time, the recommended pressure is 2.5-3.0pa.
·The vehicle should be parked in a dry area as much as possible.
·Try to avoid completely exhausting the battery before recharging.
·Avoid placing the battery in an environment that exceeds 50°C or -20°C.
·It is forbidden to use chargers other than the standard charger.

3. Warranty
During the warranty period, the following conditions are not covered by the
warranty and need to be repaired.
·Exceed warranty period.
·Man-made damage.
·Damage caused by force majeure.
·Failure to use, maintain, and adjust according to the requirements of the User Manual.
·Failure or damage caused by forced use of this product beyond normal use conditions.
·The product has been disassembled or maintained by non-authorized personnel of our
company.
·Malicious damage to warranty content, car body information.
·Failure or damage caused by other non-product design, technology, quality,
manufacturing and other problems.
·Natural wear without affecting function.
Item
Warranty content
Start time
Main parts
Mainboard, motor
1 year
Battery
and charger
Charger and battery
6 months

4. Warranty Card
Please keep the warranty card and use it as a credential during
maintenance.
Model__________________________ Motor Code_____________________
Purchasing date_________day______month_____year
Buyer’s name__________________________________
Phone_________________________ Address_________________________
Retailer________________________ Address________________________
Phone/tel______________________
Date
Content
Replacement
spare parts
Maintenance

Warranty Record
staff signature
User signature
