LED Group Robus R1350HSD User manual

Technical specication:
Dimensions:
Information for the Product user
1. Please note the requirement to dispose of Waste Electrical & Electronic Equipment separately from household waste (WEEE
marked with crossed out wheelie bin symbol).
2. Please consider your role in contributing to re-use and recycling by returning this product at end of life to a collection centre for
waste electrical equipment or a Civic Amenity site, or to a retail outlet from which you are purchasing a replacement.
3. This equipment may contain substances that are hazardous to health and the environment if disposed of carelessly. It is important
that it is separated from normal household waste and recycled in the WEEE chain
4. The “crossed out wheelie bin symbol” on a product indicates this equipment must not be disposed of in normal household waste,
but should be disposed of according to local WEEE regulations
Issue 1 261112
1350W HIGH SPEED HAND DRYER
R1350HSD
Please read instruction before commencing installation and retain
for future reference.
Model No.:
Dimensions:
Fixing centres:
Power:
Supply Voltage:
IP:
Weight:
Working Temperature:
Automatic Switching:
Over heat protection:
R1350HSD
W267mm x H225mm x Depth195mm
4 holes in base plate, upper holes at 128mm centres, lower
holes 184mm centres (113.5mm below upper holes)
1350W
230V-240V~ 50Hz
22
3.75KG.
5°C<ta<40°C
Infra-red beam detects hand within 15cm of air outlet,Auto
switch o after max. 60 seconds
Self-restting bimetal thermostat on heater with thermal
fuse back-up if bimetal fails
Aluminium main body
Controlled by PIR, operateds when hands are 15cm or closer to hand dryer
Ecient high speed motor
Streamline nozzle concentrates warm air to dry hands quickly
Protection against electric shock: Class I (Must be earthed)
225mm
195mm
267mm
The Installation must be carried out by an electrician
LED Group
Western Retail Park Tel: [phone]
Nangor Road Fax: [phone]
Dublin 12 Email: [email protected]
Ireland Website: www.led.ie
Page 1
ISO 9001:2008
Q UAL IT Y ASS U RED C O MPANY
Warning! To prevent overheating, the air inlet or outlet must not be obstructed
Suitable for mounting on normally ammable surface
Minimum distance from obstruction below outlet is 0.5 metre
Complies with EN60335 -1,EN60335-2-23,EN62233,EN55014-1,EN55014-2,
EN61000-3-2,EN61000-3-3,

Installation:
!Electrical products can cause death, injury or damage to property. If in any doubt about
the installation or use of this product, consult a competent electrician.
1. Ensure mains supply is switched o before commencing work
2. Before drilling, ensure that the holes will not impinge on joists, pipe work,
cables or other building services
3. Hand dryer must be connected to a circuit controlled by an RCD.
This tting has no user serviceable parts. If any part is damaged, disconnect from mains
and discontinue use.
Fig 1. Select suitable location: min 15cm free space each
side,50cm free below, lower xing holes
recommenced 130cm above oor. Please note
that a person using the dryer must not be
obstrucing walkway or door.
Mark wall with appropriate xing centres.
Fig 2. Remove four screws of the lower shell of the
dryer, and pull the lower shell.
Terminal
Wire-in hole
Fig 3. Install plastic plugs and x tight the hook with screws. Fix the dryer to
wall and wire to a 13A fused spur outlet, connecting Live(red or brown)
to L, Neutral (blue or black) to N, Green/Yellow to Earth terminal.
Ret cover and test.
Fig 4. When a hand reaches within 15cm rang to the air outlet, the dryer will
sense the hand and automatically start to blow warm air.(The lamp will
also be on at the same time). Hold hands under the nozzle until they are
dry.The hand dryer will stop working after 1 second when the hand
move out of range. The dryer will also stop working after continuous
operation for 60 seconds.
Brown Y./W.
LN
Blue
128mm
184mm
113.5mm
The Installation must be carried out by an electrician
LED Group
Western Retail Park Tel: [phone]
Nangor Road Fax: [phone]
Dublin 12 Email: [email protected]
Ireland Website: www.led.ie
Page 2
ISO 9001:2008
Q UAL IT Y ASS U RED C O MPANY
Australian products are
complete with cable
and Australian plug.
