Lee Precision AUTO PRIME XR User manual

AUTO-PRIME XR
When priming cases, handle as a loaded gun. never point at yourself or anyone else.
primers Will explode if shocked or crushed. Wear safety glasses at all times When priming or handling primers.
Warning If you feel an increase in pressure on the lever earlier than normal, you have a problem and continued pressure may
result in a primer detonation. STOP pressing and determine what is causing the early increase in pressure. It is likely a tipped primer,
a military case that does not have its crimp completely removed, or attempting to prime an already primed case.
1.3.11 Lee Precision, Inc. 5721 CHECKED BY
AUTO PRIME XR INSTRUCTIONS mjh
Place a deprimed case into shell holder. Depress thumb lever
to seat primer. Primers should be seated flush to slightly be-
low flush of the case head. Lever will not bottom out and you
will quickly be able to feel when primer has reached home by
the increase in pressure on lever.
Remove lever and connecting rod by pulling lever
towards the tray.
Install correct primer tray — marked on the bot-
tom as small and large.
Place a box of 100 primers in the tray. Remove box and shake the tray side to side
to upright all the primers.
Tip tool so primers slide away from body. Be sure no
primers remain on the
no primer zone
. Hook tray cover as
shown, slide towards handle, and make sure small tab on
cover engagesthe trough.
Slide the primer tray down away from shell holder slot; pull from the body.
Lubricate metal parts at wear points with grease or Vaseline. Reinstall into body.
Hold tool at 45º from horizontal;
rotate tool clockwise to fill
feed rail.
1
3
6
7
2
4
89
5
Push down on tray—install appropriate shell
holder. Slide tray upward until it contacts
bottom of shell holder.
45º
Lead Warning Primers contain lead: a substance known to cause birth defects,
reproductive harm and other serious physical injury. Wash hands after exposure.
PT1204

© 2011 Lee Precision, Inc. Printed in USA
The Auto-Prime XR (patent pending) is designed to greatly reduce the
likelihood of a mass detonation when priming cases. This is accomplished
by remotely locating the mass of primers during the priming operation. A
separate elevator pin raises a single primer from the tray and presents it
for priming.
Our testing of the XR tool continues to demonstrate a huge
dierence in primer safety from brand to brand. Our observation
is that the size of the packaging in which the primers are shipped
seems to have a direct correlation to the probability of
mass detonation. The larger the shipping package, the
more likely a mass detonation could occur.
Always wear safety glasses when
handling primers or priming cases.
AUTO-PRIME XR
LEE PRECISION, INC.
4275 Hwy. U · Hartford WI 53027
www.leeprecision.com
4 17 Rem.
20 22 Hornet
20 22 K Hornet
3 22 Savage
2 22 BR
6 218 Bee
3 219 Zipper
10 220 Swift
4 221 Fireball
4 222 Rem.
4 222 Rem. Magnum
4 223 (5.56mm)
2 224 Clark (22/257)
10 225 Win.
2 22/250
2 240 Weatherby
2 243 Win.
2 6mm Rem.
2 244 Rem.
2 6mm Int’l
2 6mm/284
2 6mm/06
4 6 x 47 (6mm/222M)
2 25/284
2 25/06
6 25/20 Win.
2 250 Savage
3 25/35
2 257 Roberts
5 257 Weatherby
5 303/25
2 6.5mm 06
2 6.5mm x 57
3 6.5 x 55 Mauser
10 6.5 Japanese
5 6.5 Rem. Magnum
2 6.5 Carcano
5 264 Win. Magnum
2 270 Win.
21 6.8 SPC
5 270 Weatherby
2 280 Rem.
2 7mm/08
2 7mm BR
4 7mm TCU
3 7 x 30 Waters
2 7 x 57mm Mauser
5 7 x 61 Sharpe & Hart
5 7mm Rem. Magnum
5 7mm Weatherby
2 284 Win.
3 7.5mm Schmidt-Rubin
7 30 M 1 Carbine
3 7.62x53 Arg. Mauser
12 7.62mm x 39
16 7.62x54 Russian
3 30 Herrett
3 30/30 Win. (30 W.C.F.)
21 30 Remington
2 300 Savage
2 308 Win. (7.62 NATO)
5 30/40 Krag (30 U.S.)
2 30/06 Springfield
5 300 H & H
5 300 Weatherby
5 300 Win. Mag.
5 308 Norma Mag.
5 303 British
2 7.7 Japanese
3 32 Win. Special
3 32 Win. S.L.
6 32/20 (32 W.C.F.)
3 32/40 Win.
2 8 x 57 Mauser
2 8mm 06
2 8mm Man. Schoe.
5 8mm Rem. Mag.
8 33 Win.
5 338 Win. Mag.
5 340 Weatherby
8 348 Win.
2 35 Rem.
5 35 Win.
2 35 Whelan
5 350 Rem. Mag.
3 356 Win.
2 358 Win.
5 358 Norma Mag.
3 375 Win.
5 375 H & H
5 375 Weatherby
14 38/40 Win.
3 38/55 Win.
8 40/82 Win.
3 408 Win.
5 416 Rem.
8 416 Rigby
14 44/40
11 444 Marlin
8 45/70 Gov’t
5 458 Win. Mag.
1 22 Rem. Jet
1 256 Win. Mag.
15 25 ACP
19 30 Luger
19 30 Mauser
4 32 Short Colt
4 32 Long Colt
4 32 S & W
4 32 S & W Long
7 32 ACP
4 32 Colt N.P.
4 380 Auto
19 9mm LUGER
1 38 S & W
1 38 Colt N.P.
19 38 Super Auto
19 38 ACP
1 38 Short Colt
1 38 Long Colt
1 38 Special
1 357 Magnum
2 357 Auto Mag.
19 40 S&W
19 10mm AUTO
1 41 Long Colt
19 41 Action Express
9 41 Magnum
11 44 S & W Special
11 44 S & W Russian
11 44 Magnum
2 44 Auto Mag.
2 45 Auto
11 45 Colt
11 454 Casull
5 455 Webley
12 PPC
13 45 Auto Rim
3 45 Win. Mag.
5 480 Ruger
16 500 S&W
HOLDER RIFLE HOLDER RIFLE HOLDER RIFLE HOLDER PISTOL
HOLDER PISTOL
SHELLHOLDERS
PARTS LIST
Body · · · · · · · · · · · · · · · · · · · · · PT1001
Lever · · · · · · · · · · · · · · · · · · · · PT2971
Connecting Link · · · · · · · · · · · PT2970
Cover · · · · · · · · · · · · · · · · · · · · PT2964
Small Tray Assembly · · · · · · · PT2965A
Large Tray Assembly · · · · · · · PT2965B
Instructions · · · · · · · · · · · · · · · PT1204
