Lee Precision Auto Breech Lock Pro User manual

work bench edge
2
Re-position handle, tighten securely with �” wrench.
Auto Breech Lock Pro quick start guide
FOLDFOLD
Press fits directly on LEE Steel
Base Block included with
Reloading Stand # 90688 or
Bench Plate # 90251.
- OR -
Hold this card against work
bench edge, fold at dotted line,
drill three 17/64” (7mm) holes
in your work bench using this
card as a drill template.
Install spent primer tube.
Refer to safety guidelines and detailed steps in the instruction manual
3
1
PR2679 www.leeprecision.com
Verify the
handle
passes
completely
through lever
clamp.

Loosen and remove spline
drive breech lock bushing to
access index rod. Remove index rod and
case ejector.
Raise carrier to the mid-stroke
position, install shell plate,
lightly tighten clockwise with
¼” hex head wrench
With the carrier near
the bottom of the stroke
(handle up), install index
rod.
Install large or small primer
arm.
Install spline drive breech
lock bushing. Snug with die
wrench.
Install case ejector.
45
6 7
8
INDEX RODINDEX ROD
CASECASE
EJECTOREJECTOR
9
10 11
Remove die lock rings. Install
dies according to instructions.
IMPORTANT Lee die set users,
screw the # 1 sizing die in until it
touches the shell plate. Lower the ram,
and screw die in ⅓ turn more.
1
SIZE
2
PRIME
3
POWDER
CHARGE
5
FACTORY
CRIMP
4
BULLET
SEAT
Accessory
# 91634 ⁄ hex key
