Lefroy Brooks M1-4701 Assembly instructions

INSTALLATION, OPERATING & MAINTENANCE INSTRUCTIONS
M1-4701
LEVER 4-HOLE KITCHEN MIXER WITH PULL-OUT HAND SPRAY

2
Contents
Dimensions 3
InstalLation Procedure 4
Parts List 6
Fault Finder 7
Safety Tips, Care and Maintenance 8
Guarantee 9

6"~12"
(152.4mm~305mm)
4 1/4"
(107.5mm)
1 15/16"
(50mm)
3 1/8"
(79mm)
4"
(102mm)
Ø2 3/16"
(Ø55mm)
2 3/16"
(56mm)
Ø2 3/16"
(Ø55mm) Ø2 3/16"
(Ø55mm)
2 7/8"
(72.5mm)
4 15/16"
(125mm)
Ø3/4"
(Ø19mm)
3/4"
(19.3mm)
5 1/2"
(140mm)
10"
(254mm)
12 3/8"
(315mm)
1/16"~1 11/16"
(1mm~43mm)
12"
(305mm)
2-G1/2
2-1/2-14NPSM
2-9/16-24UNEF
1/4-18NPSM-2A
3
Dimensions in Inches (& Millimetres)
Whilst every effort is made to ensure accuracy, design and dimensions are subject to change without
notice as part of the company’s product development process.

1
3 4
2
4
Steps 1-4
InstallationProcedure
Lefroy Brooks always recommends that plumbing products be installed by a licensed professional.
Shut off main water supply before installation.
1Position the spout in the second hole of sink. Insert spout into the mounting hole in deck from
above. From underneath the sink, install the washers and lock nut. Slide on adapter over bottom
of spout shank, and tighten with lock nut.
2Place the handle body through side hole.
Re-assemble the mounting hardware onto valve shank; use adjustable wrench for final
tightening.
3Install the right handle assembly.
4Install the left handle assembly.

5
7 8
6
5
InstallationProcedure Steps 5-8
Lefroy Brooks always recommends that plumbing products be installed by a licensed professional.
Shut off main water supply before installation.
5Connect flexible hoses. Copper nuts are supplied in case you want to connect copper pipes
instead.
6Install spray holder in sink deck: insert the spray holder from above into the mounting hole.
Tighten with lock nut.
7Insert spray hose through spray holder and install the hose adaptor to the shank. Screw side spray
onto spray hose.
8After installing faucet, remove aerator and open the hot and cold water supplies.
Check for leaks. Turn on faucet handles forone minute to flush debris from faucet.
Close the handles and re-assemble the aerator.
Warning! When installing flexible hose, please notice:
