Lefroy Brooks R1-4001 Assembly instructions

INSTALLATION, OPERATING & MAINTENANCE INSTRUCTIONS
R1-4001
THREE-WAY WALL DIVERTER ROUGH TO SUIT M1-1012 & M1-1013

2
Contents
Dimensions 3
InstalLation Procedure 4
Parts List 7
Fault Finder 8
Safety Tips, Care and Maintenance 9
Guarantee 10

3/4-14NPT
1/2-14NPT
Ø1 1/16"
5 5/8"
2 11/16"
M24X1.5
5 1/2"
4 7/16"
Ø1 11/16"
Ø1 7/8"
(Ø27.4mm)
(143mm)
(68mm)
(140mm)
(112.5mm)
(Ø42.8mm)
(Ø48mm)
Protective cap
3
Dimensions in Inches (& Millimetres)
Whilst every effort is made to ensure accuracy, design and dimensions are subject to change without
notice as part of the company’s product development process.

1 2
Wall surface
5mm-33.5mm
4
Steps 1-2
InstallationProcedure
Lefroy Brooks always recommends that plumbing products be installed by a licensed professional.
Shut off main water supply before installation.
1Take off protective cap. Don’t throw away the protective cap because it is needed in further steps.
2While placing the valve into the wall, make sure that the adaptor protruded out from the wall
surface is between 5~33.5mm as the figure indicates.

3 4
water pipe
water pipe
5
Steps 3-4
InstallationProcedure
Lefroy Brooks always recommends that plumbing products be installed by a licensed professional.
Shut off main water supply before installation.
3Connect the valve inlet with water pipe.
4Connect the 3 valve outlets with water pipes.

5
6
Fixing hole
6
Steps 5-6
InstallationProcedure
Lefroy Brooks always recommends that plumbing products be installed by a licensed professional.
Shut off main water supply before installation.
5Fix valve to the backboard with screws.
6Re-attach the protective cap.

1 Body (076894)
2 Cartridge (024545)
3 Nut (009630)
4 Spindle (110415)
5 Screw (008180)
6 Protective cap (038007)
7 Teflon tape (203000)
1
2
3
4
5
6
7
7
PartsList Exploded view

8
FaultFinder
Fault Cause Rectification
Leaks around diverter. Cartridge has come loose or
damaged.
Tighten/reinstall the cartridge or
replacement the cartridge if it is
damaged.

9
SafetyTips,CareandMaintenance
Safety Tips
If you are soldering during faucet installation,remove cartridges, seats, gaskets and washers prior to
applying flame, otherwise you will void the warranty.
Cover drain openings to avoid losing small parts.
When cutting or soldering pipe, use safety glasses to protect your eyes.
Important Points
Prior to beginning installation. turn off the cold and hot water lines and open the old faucet to release
built-up pressure.
Overtightening nuts may cause damage.
Wrap all threaded connections with pipe tape available at your local plumbing supply store.
Always wrap in a clockwise direction. The fittings should be installed by a state-licenced plumber.
Please note:
When there is a difference in water pressure between hot and cold supplies to the mixing valve, the
pressures should be equalized by a plumber in accordance with best practice and legislation.
Maintenance
Your new bathroom faucet is designed for years of trouble-free performance. Keep it looking new by
cleaning it periodically with a soft cloth. Avoid abrasive cleaners, wire wool and harsh chemicals as
these will dull the finish and void your warranty.
Routine Maintenance
The frequency and extent of attention required will vary according to prevailing site and operational
conditions, however a 12 monthly maintenance schedule is recommended.
If the product has operated satisfactorily for some time, but performance has been degraded, please
check the Fault Finder section to identify the problem.
Maintenance Check List
 s 7ORNORDAMAGEDSEALSANDWASHERS
 s $AMAGEDSEALFACES
 s 4HREADWEAR
 s )NCORRECTADJUSTMENT
 s #OMPONENTFAILURE
 s $EBRISORLIMESCALEBUILDUP
