Leftek M SERIES User guide

QUICK OPERATION GUIDE
M SERIES HIGH SPEED DOME CAMERA
Version：S2018V1

Special Declaration
Before connecting and using this product, please read these instructions
carefully and keep it for references in the future.
This manual might be not accurate technically or contains some minor
type errors.The contents in this manual about production description and
program might be updated without notice. Updated contents will be
added in the new version. We will change or upgrade the products or
program any time.
Caution
1) Avoid to installing the product in a shock environment, Keep the
product away from electromagnetic interference.
2) Do not use products in extremely hot, cold, dusty, corrosive or high
humidity environments. Speed dome camera working temperature :
-20℃æ+50℃æhumidity less than 90%.
3) Please do not make camera toward to strong light source, (such as the
sun), it will damage the image sensor.
4) Do not touch the image sensor or lens directly. If it is necessary to clean,
please use dry soft cloth or neutral cleaner to wipe lightly.
5) Please keep all the material of the equipment. if any quality problems,
better to pack the cargo well and then ship to the agents or return to
the factory. During transport, custody and install process should
prevent weight, severe vibration and soak damage to product.
6) In order to well match night vision, we sell IR speed dome camera with
zoom camera, Please not disassemble zoom camera if there is no
technical person.
7) Should obey all kinds of electric standard when using speed dome
camera, make sure signal cable keep enough distance with high voltage
equipment or cables. If it is possible, please take lightning and surge
measurement.
-01-

Contents
-02-
1.
2. Camera Specifications.................................................03
3. Installation Method....................................................04
4. Link device.................................................................05
5. Software tools............................................................07
6. Web client access.......................................................08
7. Set the ptz camera preset............................................10
8. PC client access..........................................................11
9. Mobile APP access.....................................................13
10. NVR add camera.......................................................15
11. PTZ Camera Common Function Settings:....................15
12. Q&A.........................................................................19
Packing List................................................................03

Packing List
No. Part Name Quantity
Camera
Screw
Bracket
1
2
3
1
2
1 set
1 bag
1 pcs
Camera Specifications
Video Quality
Lens f= 2.8~13.5mm, 5X Optical Motorized Zoom;
F=1.2;
Viewing Angle
SD card
Microphone
Operating Power
Night Vision
Frame Rate
POE Standard
Network
Connection
PC OS
Mobile OS
Browser
3rd Party support
list (ONVIF)
36°~100°
Support SD card slot, NOT with built-in SD card
No
PoE or DC 12V 2A
Up to 190ft (Depends on the Environment
Up to 30fps
802.3at, 44V~54V. Support up to 330ft via
CAT6 cable
P2P and QR Code
Windows, Mac OS
iOS, Android
Supports IE Edge, Chrome, Firefox, Safari
Digital WatchDog, Blue Iris, iSpy, Video
Sighthound, Security Spy, Synology, QNap.
-03-
5.0MP (3072 x 1728)2MP(1920 x 1080)

3
Step-1:
Draw positioning holes
Take out bracket from package box, place
the wall mount bracket on the wall and
mark down all 4 fixing holes
Installation Method
Step-2:
Drill holes and put expansion screws in.
Drill 4pcs expansion screw’s installation
holes at pre-marked position, then put
4pcs expansion screws in.
Note:
Please bring expansion screws own.
Wall Mount Bracket
Step-3:
Wall mount connect speed dome and
bracket.
Put the connection port of the speed
dome into bracket hole and put the
screw lock into corresponding
threaded holes.
-04-

Step-6: Cable connecting
Please refer to the Section VI of this chapter- Connecting Method.
Step-7: Tear off protection film
Tear off protection film of transparent cover.
Note: please take care of transparent cover.
Step-4:
Fix the speed dome camera.
Lead cable drawn out from the holder
recess, then put the 4 installation hole
of bracket of speed dome focus on the
wall's 4pcs expansion screw and tighten
that 4pcs nut. Then seal the appeared
groove via glass glue.
Link device
4
4.1 Connection way as following: Please connect the POE dome camera
and POE switcher/router/NVR with ethernet cable. If the switcher/
router/NVR is without POE function, please power on the dome
camera and connect it to switcher/router/NVR with the ethernet.
Details as below:
Network
Cable POE NVR
Network
Cable POE Router/Switcher
-05-

DC12V
Network
Cable
DC Connector
NVR /PC
NVR/PC
Internet
NVR /PC
NVR/PC
LAN Connection
Network Speed
Dome Camera
Network Speed
Dome Camera
Network
Cable
Network
Cable
Router/Switcher
Router/Switcher
Router/Switcher
WAN Connection
Network
Cable
Network
Cable
Router/Switcher
4.2 Typical application connection diagram
-06-

-07-
After downloading there will be a search tool IPWizardlll, a PC client (HCMS)
installation package and a camera manual compression package.There are
four ways to access the dome camera: web client access,
PC client access, mobile APP access, and NVR access.
First to confirm the IP address of the device, you can use
a dedicated search tool (IPWizardlll) to search it. Factory
default IP is 192.168.0.200
Scan the QR code of manual to download the user
manual. Or go the the web:
http://121.42.188.188:83/v2/M-I-S2018V1.pdf
to download the document
Scan the QR code on the screw bag or left QR code to
download software and installation tool.
Or go the the web:http://121.42.188.188:83/HS-LF.zip
to download the software and installation tool.
Software tools
5
HCMS_2.2.9.2.exe IPWizardIII_2.1.1

-08-
Web client access
6
6.1 The default IP of camera is 192.168.0.200,
password: admin. when the web client-side access the ip Camera
need to set the ip address to a same network segment, or use
search tool to change the ip address of the device to same network
segment on the laptop, can use the red column below to change
the IP address of the camera.For example, if your computer ip
address is 192.168.1.20 , then you need to change the camera ip
address to 192.168.1. xx (xx rang from 0 to 225).
Please note that we donot change the default ip address of
camera as the computer is in same LAN (192.168.0.xx)
user name:admin,
6.2 Open the IE browser, enter the IP address(factory default IP:192.168.0.200）
of the camera then click Enter. The browser login screen appears, enter the
"user name" (default admin) "password" (default admin) then click login.

-09-
6.3 Open the IE browser, enter the IP address（factory default
IP:192.168.0.200）of the camera then click Enter. The browser login
screen appears, enter the "user name" (default admin)"password"
(default admin) then click login.

-10-
6.4 View the ID of the mobile APP, Enter the set—Network—P2P
Take IE interface for example: after you enter into the zoom camera page in
the IE interface,click”PTZ control” on the left then will appear the direction key
of controlling ptz, Figure:Operate the ptz run to the location where you want to
set preset, then click the ptz function on the left, select the preset value you
want to set, then click set to finish. Figure:
Set the ptz camera preset
7

PC client access
8
8.1 Scan code to download
the PC client(HCMS),install
the file to your computer。
8.2 Open and log in the
HCMS client software，
Default account: admin password: admin
8.3 After enter the software, click Configuration Management - Device
Management
8.4 In the device management page, click【device look-up】, the network
setup of the local Area Network will appear below the 【device IP】,
then choose the address of the device IP, the IP address will save in the
【device saved】function, at same time, the device IP address will
appear in the left top of【device list】under【local platform】，then
clicking the X in the right top of the page for exit.
-11-

8.5 In the main interface, click [Device List] - [Local Platform] – double
click the IP address to request screen.
8.6 In the main interface of the client, open the【PTZ direction control】
to control the camera on the next, left, right, zoom +, zoom -, focus +,
focus - and so on.
2. Select the device you want to add
1. Search device IP
3. Click “add”button
-12-

Mobile APP access
9
9.1 Installation and acquisition
Android system / IOS system
Search for keywords “Hisee”
on Google Play / App Store
to download and install.You
can also download by the
QR code
(Picture 1) (Picture 2) (Picture 3)
Android IOS
-13-

9.5 After adding successfully, can see your online state on the software
interface. Gray for offline, green for online. (Picture 4)
9.6 Click the phone screen and select the online device request screen.
Drag the screen then can control the direction of the camera. (when
first time using the mobile phone APP will appear operating tips).
(Picture 5 and picture 6)
9.2 Register an APP account after installation well，enter the account and
password to log in. (Picture 1)
9.3 Click the + sign on the middle, enter to the [add device interface].
And choose Wireless device. (Picture 2)
9.4 By scanning the QR code or inserting the ID manually in the page of
device adding-in, inserting the ID number of the device, When default
as scanning the code, please aim at the QR code (QR code is located in
the device web customer ID 【setup】—【internet】—【P2P】) ,
-14-
after inserting the device's ID, setup a name then click Add. (Picture 3).

-15-
(Picture 4) (Picture 5) (Picture 6)
10 NVR add camera
10.1 Make sure the NVR and the camera are within the same network segment.
10.2 Open the channel management on NVR, and, click [search device] or
[custom add] button in the channel management
10.3 Select the IP address of the camera, click 【Add】 or manually enter the
IP address of the dome camera to add.
10.4 Select the onvif protocol, onvif port is 8999 (onvif port 8999 is fixed values
can not be changed), And then enter the correct account and password of
the camera, click Save.
PTZ Camera Common Function Settings:
11
Turn On IR Lights- call preset 90 and then call preset 2
Turn Off IR Lights-call preset 90 and then call preset 3
11.1 Turn On/Off IR Lights Manually

IR Lights Auto Mode- call preset 90 and then call preset 1
11.2 IR Lights Sensitivity Settings
High IR Lights Sensitivity- call preset 90 and then call preset 11
Medium IR Lights Sensitivity- call preset 90 and then call preset 12
Low IR Lights Sensitivity- call preset 90 and then call preset 13
11.3 IR CUT Setting
Turn on IR CUT- call preset 91 and then call preset 1
Turn off IR CUT-call preset 91 and then call preset 2
Turn on IR CUT Automatically- call preset 91 and then call preset 3
Turn off IR CUT Automatically -call preset 91 and then call preset 4
11.4 Patrol setting and call
[e.x]:Add 1-4 preset in the number one patrol, stay 30s, speed 40, operate
as below steps
Add preset in the patrol
(1) Set preset 92, call preset 1, star to set number 1 patrol
(2) Call preset 1, add preset 1, star to set number 1 patrol
(3) Call preset 2, add preset 2, star to set number 1 patrol
(4) Call preset 3, add preset 3, star to set number 1 patrol
(5) Call preset 4, add preset 4, star to set number 1 patrol
(6) Set preset 92, call preset 9, save number 1 patrol
Set the preset stay time in the patrol
(1) Set preset 92, call preset 10, star to set the preset stay time
(2) Call preset 30, set the preset stay time 30s.
Set the preset in the patrol running speed
(1) Set preset 92, call preset 11, star to set the preset running speed
(2) Call preset 40, set the preset running speed 40.
-16-

Note: All the network ptz camera support to call the number 35 preset
and execute the patrol of 1-8 preset afart March, 2015.E.x we only set
1.2.3 this three presets, call preset 35, then the ptz camera will cruising
among this presets. (Call preset 35 execute the patrol function correspond
the first patrol,default stay time 10m, speed 50. If you want to change
the stay time or patrol speed, please follow the above steps).
turn on patrol
Call preset 92, then call preset 1 (turn on patrol 1)
Call preset 92, then call preset 2 (turn on patrol 2)
Call preset 92, then call preset 3(turn on patrol 3)......and so on
11.5 Pattern setting and call
For example:If customer want to set pattern 1,then the steps as below:
Set preset 93,and then call preset 1( start to setting pattern 1)
Operate the ptz camera working according to the customers requirement
Set preset 93 and then call preset 5(save pattern 1)
Turn on pattern scan function operations:
call preset 93, and then call preset 1(turn on pattern 1)
call preset 93, and then call preset 2(turn on pattern 2)
call preset 93, and then call preset 3(turn on pattern 3)
call preset 93, and then call preset 4(turn on pattern 4)
11.6 AB line scan and call
Set line scan to A , call preset 94, call preset 41
Set line scan to B , call preset 94, call preset 42
Set AB line scan under high speed- call preset 94, call preset 43
Set AB line scan under medium speed- call preset 94, call preset 44
Set AB line scan under low speed-call preset 94, call preset 45
-17-

Set AB line scan in arc- call preset 94, call preset 46
Set AB line scan out arc- call preset 94, call preset 47
11.7 Park Settings
(1)Park Preset Settings
For example, if you wan to set preset 1 as a park preset, then please
call preset 94 and then preset 1; If you want to set the park time as
10s, then call preset 94 and then call preset 31
(2)Park Patrol Setting
For example, if you wan to set patrol 1 as a park patrol,then please call
preset 94 and then preset 9; If you want to set the park time as 10s, then
call preset 94 and then preset 31
(3)Park Pattern Setting
For example, if you wan to set pattern 1 as a park pattern,then please call
preset 94 and then call preset 17; If you want to set the park time as 10s,
then call preset 94 and then call preset 31
(4)Park AB Line Scan Setting
For example, if you want to set park AB line scan, call preset 94 and then
call preset 22; If you want to set the park time as 10s, call preset 94 and
then call preset 31
11.8 Turn on/off auto tracking(only support the camera which built in
auto tracking function)
Turn on auto tracking function, call preset 94,and then call preset 50
Turn off auto tracking function,call preset 94,and then call preset 51
11.9 Reset the camera
Call preset 96 and then call preset 10 and then call preset 12
and then call preset 14
-18-

Q&A
12
Q：The camera can do self-test, but can not control after powered on.
A：On the web client find setting—PTZ function—PTZ protocol—protocol
（pelco-D）—Baud rate（2400）—Address(1), Change the protocol baud
rate address to the default parameter。
-19-
Q When using search tool to modify the ip, it show " Network parameters
setting is illegal
：
"
12
