Vivotek SD7313 User manual

Quick Installation Guide
SD7313/SD7323
English 繁中 日本語 Español Português
簡中 Français Deutsch Italiano Türkçe Polski Русский Česky Svenska
P/N: 625008200G Ver.1.01
Copyright 2008 VIVOTEK INC. All rights reserved.
c
Outdoor 35x Zoom Day&Night

EN-1
English
Warning Before Installation
Contact your distributor in the
event of occurrence.
Refer to your user’s manual for the
operating temperature.
Power off the Network Camera as
soon as smoke or unusual odors are
detected.
Do not touch the Network Camera
during a lightning storm.
Do not disassemble the Network
Camera.
Do not drop the Network Camera.
Do not insert sharp or tiny objects
into the Network Camera.
Do not manually pan and tilt the
Network Camera when the power is
on.

EN-2
Package Contents
1
Power Adapter
Software CD
SD73x3
Warranty Card
Black Cover / Dome Cover
Wall Mount Bracket
RJ45 Female/Female Coupler Quick Installation Guide
O-ring and Screws /
Alignment Sticker
Silica Gel / Metal Ring
Silica gel
Silica gel

EN-3
English
Inner View
Reset Button
Lens
Outer View
Physical Description
2
Status LED
Ethernet 10/100
RJ45 Plug
Audio Out (green)
Microphone In (pink)
Power Cord Socket (black)
General I/O
Terminal Block
Ground
SD Card Slot

EN-4
Hardware Installation
3
Mounting the Network Camera
1. Attach the alignment sticker to the wall.
2. Drill four pilot holes into the wall.
3. Attach the black cover to the Network Camera using the supplied four black
screws.
4. Stick the supplied two pieces of silica gel symmetrically to the inner side of the
dome cover. Then place the metal ring into the dome cover to fix the silica gel.
5. Fix the dome cover to the Network Camera and secure it by rotating it clockwise.
6. Loosen the three screws on the front opening of the wall mount bracket.
7. Place the O-ring on the front opening of the wall mount bracket.
8. Feed the cables through the front opening of the wall mount bracket and pull them
from wall outlet.
9. Attach the Network Camera to the wall mount bracket by tightening the three
screws on the front opening of the wall mount bracket.
10. Fasten the wall mount bracket to the wall.
1
2
356
789
10
Silica gel
Silica gel
4

EN-5
English
Network Deployment
4
POWE
RC
OLLIS
ION
LINK
R
E
CEIVE
PAR
TITION
12345
1. If you have external devices such as
sensors and alarms, connect them to
the general I/O terminal block.
2. Use the supplied RJ45 female/female
coupler to connect the Network Camera
to a switch.
Use Category 5 Cross Cable when
Network Camera is directly connected
to PC.
3. Connect the power cable from the
Network Camera to a power outlet.
GND: Ground
DI4: Digital Input
DI3: Digital Input
DI2: Digital Input
DI1: Digital Input
GND: Ground
N.O. : RELAY_NO
COM. : RELAY_COM
+12V : Power, 12V DC
(AC 24V 2A)

EN-6
1. Install "Installation Wizard 2" from the Software Utility directory on the software CD.
2. The program will conduct an analysis of your network environment. After your network
is analyzed, please click on the "Next" button to continue the program.
3. The program will search for VIVOTEK Video Receivers, Video Servers, and Network
Cameras on the same LAN.
4. After searching, the main installer window will pop up. Click on the MAC that matches
the one labeled on the side of the camera lens or S/N number on the label of carton
to connect the Internet Explorer to the Network Camera.
Installation
Wizard 2
IW2
Assigning IP Address
5
Network Camera
Model No: SD7313
Made in Taiwan
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Pat. 6,930,709
MAC:0002D1730202
RoHS
00-02-D1-73-02-02 192.168.3.143 SD73x3
0002D1730202

EN-7
English
For further setup, please refer to the user's manual on the software CD.
Ready to Use
6
1. Access the Network Camera from the Internet.
2. Retrieve live video through web browsers or recording software.

Quick Installation Guide
